Manufacturer
Amana Commerical
Model Number
MCHDC21
Description
Heavy Duty Commercial Compact Microwave
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 12296806 | ACCESS PANEL-E CT |
|
|
ANTENNA SHIELD |
| 59174545 | BARRIER-AIR GASKETS |
| 59184621 | BASEPAN GASKET ASSEMBLY |
| 59002074 | BASEPAN GASKET ASSEMBLY |
| 59174526 | BLOWER MOTOR ASSEMBLY |
| 59114142 | BOARD, HV/LV |
| 21028802 | BRACKET-CAPACITOR |
| M0104106 | CLIP, CORD |
|
|
CUTOUT-THERMAL, MAG |
| 12905602 | DIVIDER-FLOW |
| 12107304 | DUCT, MAG INLET |
| 12107407 | DUCT, MAG OUTLET |
|
|
FILTER, AIR |
|
|
FUSE-30A |
| R0000413 | GASKET, BASEPAN- 90 IN (228 CM |
|
|
GASKET, PER FT |
| 10966612 | GASKET-NEOPRENE |
|
|
HARNESS, HV |
| 20135801 | HARNESS-OVEN |
| 59114168 | INNER DOOR |
| 14179122 | KIT, ANTENNA MOTOR- BOTTOM |
|
|
KIT, ANTENNA MOTOR- TOP |
|
|
KIT, CAPACITOR- .82 DIODE |
| 14159099 | KIT, CAVITY- 18 21 |
| 14119064 | KIT, DOOR ASSEMBLY- MM |
| 14179127 | KIT, EXHAUST DUCTS GASKET |
|
|
KIT, INTERLOCK FUSES BLOCK |
| R9900584 | KIT, RECEPTACLE |
|
|
KIT, TRIAC(40A) SNUBBER |
|
|
KIT, WINDOW |
|
|
LAMP-LED |
| 59154465 | LAMP-LED 3W, 208/240V |
|
|
LIGHT COVERS- INSIDE OUT |
|
|
MAGNETRON |
| 20018904 | NUT-#6 HEX |
| 10098934 | POWER CORD |
| 20159201 | SCREW-MACH/HEX |
|
|
SCREW-SM/HEX |
|
|
SCREW-SM/HEX |
| 12990524 | SCREW-SM/HEX ROHS |
| 12990522 | SCREW-SM/HEX ROHS |
|
|
SCREW-TC/SOCKET TORX |
| 12992307 | SCREW-TF/HEX |
| 12160602 | SHIELD-SPILL |
| A4055406 | STRAP-CAPACITOR |
| 20071101 | SUPPORT-CAVITY |
| 59174546 | TAPE, FOAM (12 IN) |
| M0275163 | TAPE-TRANSFER |
| B5684129 | THERMAL CUTOUT |
|
|
THERMAL CUTOUT, CAVITY |
|
|
TOUCH PANEL ASSEMBLY END CAPS |
| 59114143 | TRANSFORMER, HV |
| 59174522 | TRAY, CERAMIC SUPPORTS |
| 12408503Q | WRAPPER |
