Manufacturer
Amana Commerical
Model Number
RC518SU2
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 10827220 | ACCESS PANEL WLD-E CT |
| 20172101 | ACCESS- PNT BOTTOM |
|
|
ANTENNA SHIELD |
| 10766601 | ANTENNA SHIELD |
| 59001130 | BASEPAN GASKET ASSEMBLY |
|
|
BIT, NON MAGNETIC Y DRIVE |
|
|
BLADE, FAN |
|
|
BLOCK, FUSE- 3 POLE |
| 12136502 | BLOCK, FUSE- 3 POLE |
| 10091101 | BLOCK-FUSE |
| B5677203 | BLOCK-TERMINAL |
|
|
BLOWER MOTOR ASSEMBLY- MC, RC |
|
|
BOARD, DISPLAY |
| 59144423 | BOARD, HV- RC5 |
| 10782402 | BOTTOM ACCESS-E CT |
| 20172901 | BRACKET-HINGE SUPPORT |
| 12189003 | BRACKET-HINGE SUPPORT |
| 12502404 | BRD, DISPLAY- SEE BULLETIN TCM0086A-B / ITCM0062A- |
| 59001561 | BRD, HV/LV- SEE BULLETIN TCM0086A-B / ITCM0062A-B |
| 59001128 | BUSHING, SNAP |
| A3293506 | BUSHING-SNAP |
| M0325401 | BUSHING-TERMINAL |
| M0308801 | CAP-SCREW |
| 59001169 | CAPACITOR- 1.05 |
| M0104106 | CLIP, CORD |
| B5667304 | CLIP-WIRE |
| 59174559 | COVER- LIGHT HARDWARE |
| 10785608 | COVER-LIGHT |
|
|
DIODE |
| 10781901 | DUCT- EXHAUST |
| 59174557 | DUCT- EXHAUST GASKET |
| 10989301 | DUCT-BTM EXHAUST |
| 12173003 | FILTER, LINE |
|
|
FUSE-15A |
|
|
FUSE-30A |
| A3030330 | GASKET |
| R0000413 | GASKET, BASEPAN- 90 IN (228 CM |
| 59001647 | GASKET, BASEPAN- CUT |
| 59001646 | GASKET, BASEPAN- CUT |
| A3263904 | GASKET, EACH |
| 59004077 | GASKET, PER FT |
|
|
GASKET, PER FT |
| 10966607 | GASKET-NEOPRENE |
| 10966601 | GASKET-NEOPRENE |
| 12570101 | GEAR-SPUR |
|
|
GRILL, AIR INLET THUMBSCREWS |
| 10853102 | GRILLE-AIR INLET |
| 12164102 | GROMMET, RUBBER |
| 12164101 | GROMMET, RUBBER |
| 12490901 | HANDLE-DOOR |
| 12543101 | HARNESS, INTERLOCK/DISPLAY BD |
| 12598201 | HARNESS, LOWER ANTENNA MOTOR |
| 13095501 | HARNESS-INTERLOCK |
| 13018801 | HARNESS-LW ANT MTR |
| C8961811 | HINGE-DOOR |
|
|
INNER DOOR ASSEMBLY (NO SCREWS) |
| R0130262 | KIT, ANTENNA |
| 59174543 | KIT, CAPACITOR- 1.05 DIODE |
| 12002483 | KIT, CAVITY- 2 TUBE S CHASSIS |
| R0156942 | KIT, CERAMIC TRAY SEALER |
|
|
KIT, HANDLE SCREWS |
| R0130265 | KIT, HARNESS- HVB/DISPLAY |
|
|
KIT, INTERLOCK SWITCH |
|
|
KIT, LATCH- RC CHASSIS |
|
|
KIT, TRIAC(40A) SNUBBER |
|
|
KIT- ANTENNA (PLAIN TIP) & MOTOR |
| 14179140 | KIT- HINGE DOOR RING WELD- RC |
| 14179136 | KIT- TOP BOTTOM EXHAUST DUCTS |
| 14179130 | KIT- TOP, BOTTOM, & REAR DIVIDERS |
|
|
LAMP (40W-250V) |
| 67002552 | LAMP- 40W-250V |
| 59174554 | LIGHT COVERS- INSIDE OUT |
|
|
MAGNETRON |
| 59001862 | MAGNETRON |
|
|
MOTOR, ANTENNA (230V) |
| 59001482 | MOTOR, BLOWER |
| M0288215 | NUT-#6 SPEED |
| R0156918 | OUTER DOOR ASSY- WINDOW |
| R0156970 | PANEL, ACCESS- REAR |
| 59174558 | PCB SUPPORTS (10) SCREWS (10) |
|
|
PLATE-PARTITION |
|
|
PLUG-HOLE |
|
|
PLUG-WHITE BUTTON |
| 59002001 | POWER CORD |
| B8383102 | RECTIFIER |
|
|
RELAY |
| 12492202 | RELAY |
| M0370009 | RELIEF-STRAIN |
| 12570202 | RETAINER, GEAR SHAFT |
| 12570201 | RETAINER, GEAR SHAFT |
| A4539637 | RIVET, POP |
| M0216517 | SCREW |
| 67003392 | SCREW HI LO Y-DRIVE HEAD |
| 59002047 | SCREW, TF/HEX ROHS |
| 12876603 | SCREW- PLASTITE |
|
|
SCREW-HI LO Y-DRIVE |
|
|
SCREW-SET/CONE ROHS |
|
|
SCREW-SET/DOG ROHS |
|
|
SCREW-SM/HEX |
|
|
SCREW-SM/HEX |
|
|
SCREW-SM/HEX |
| 12990522 | SCREW-SM/HEX ROHS |
| 13095201 | SCREW-SM/OVAL |
| M0229916 | SCREW-TC |
|
|
SCREW-TC/SOCKET TORX |
| 13042101 | SCREW-TC/Y DRIVE ROHS |
| 12992306 | SCREW-TF/HEX ROHS |
| 12992302 | SCREW-TF/HEX ROHS |
| 13042002 | SCREW-TF/OVAL |
| 13042901 | SCREW-THUMB |
| 12552001 | SCROLL, BLOWER |
| M0275598 | SEALER |
|
|
SEALER |
|
|
SNUBBER ASSEMBLY |
| B8376801 | SOCKET-LIGHT |
| C8893502 | SPRING-DOOR LATCH |
| 3010003001 | STANDOFF-POLY |
| A4055406 | STRAP-CAPACITOR |
| M0590602 | SUPPORT |
| B5684106 | THERMAL CUTOUT |
| 59001992 | THERMAL CUTOUT |
| B5795317 | THERMAL CUTOUT, CAVITY |
| M0322202 | TIE-WIRE |
| 44780P01 | TOROID |
|
|
TOUCH PANEL ASSEMBLY- SIDE |
| R0130108 | TOUCH PANEL ASSEMBLY- TOP |
| 59104128 | TOUCH PANEL ASSEMBLY- TOP |
| 10788620 | TRANSFORMER |
| 59004054 | TRANSFORMER, HV |
| D7681501 | TRIAC |
| 59174560 | TRIM- OC SCREWS |
| 10909005 | TRIM-OC |
| M0274066 | WASHER-NYLON |
| 10903002 | WASHER-SPUR GEAR |
| 59002013 | WELD, DOOR RING |
| C3670809 | WHEEL-BLOWER |
| B8367701 | WINDOW-OVEN LIGHT |
| 10908909Q | WRAPPER- STAINLESS |
| 10908901Q | WRAPPER- STAINLESS |
