Model Image
Manufacturer

Liebherr

Model Number

CBS2082

Description

Combined Fridge-freezer-nofrost-biofresh-st. Steel

Interactive Exploded View
Exploded View

Parts List

Part Number Description
694245300 694245300 ADDITIONAL SENSOR
409876900 409876900 ADJUSTING SCREW
959020602 959020602 AIR SENSOR FOR FREEZER COMPARTMENT
694239900 694239900 AIR SENSOR FOR REFRIGERATOR COMPARTMENT
711366900 711366900 BOLT
711375701 711375701 BOLT
764301500 764301500 BOTTLE RACK RETAINING STRIP
764301700 764301700 BOTTLE RACK RETAINING STRIP
774532300 774532300 BRACKET
726607901 726607901 BUFFER
743352900 743352900 BUSHING
743219500 743219500 BUSHING
711369700 711369700 BUSHING
742923701 742923701 BUSHING
401069701 401069701 CHEESE-HEAD SCREW WITH SLOT
611869900 611869900 COMPACT FAN
611864501 611864501 COMPACT FAN
610809801 610809801 COMPACT FAN
611933600 611933600 COMPRESSOR R 600 A
610950400 610950400 COMPRESSOR R 600 A
408450001 408450001 COUNTERSUNK SCREW
408291501 408291501 COUNTERSUNK SELF-TAPPING SCREW
408269900 408269900 COUNTERSUNK SELF-TAPPING SCREW
704336900 704336900 COVER
742909101 742909101 COVER
742935501 742935501 COVER
742776700 742776700 COVER
742873400 742873400 COVER
742746402 742746402 COVER
743309800 743309800 COVER
743262701 743262701 COVER GRILLE FOR FAN
743272200 743272200 COVER PLATE
743249500 743249500 COVER, WELDED
919041900 919041900 COVERS, VARIOUS
919041700 919041700 COVERS, VARIOUS
743254501 743254501 DIVIDING WALL
742952101 742952101 DIVIDING WALL
743261100 743261100 DIVIDING WALL
902058801 902058801 DOOR, CAVITY-FOAMED
901546912 901546912 DOOR, CAVITY-FOAMED
901547112 901547112 DOOR, CAVITY-FOAMED
902057201 902057201 DOOR, CAVITY-FOAMED
742936401 742936401 DRAWER BODY
743509201 743509201 DRAWER BODY
742934400 742934400 DRAWER BODY
789065100 789065100 DRAWER RAIL
789065300 789065300 DRAWER RAIL
789064900 789064900 DRAWER RAIL
742606101 742606101 DRAWER-COMPLETE
594207001 594207001 DRYER
765101001 765101001 EDGE STRIP FOR GLASS PLATES
614323501 614323501 ELECTRICAL CONTROL SYSTEM
987317301 987317301 EVAPORATOR - REFRIGERATION
743220100 743220100 EVAPORATOR FIXTURE
743429900 743429900 EVAPORATOR TRAYS
629979700 629979700 FAN BLADE
629969900 629969900 FAN BLADE
743818900 743818900 FAN COVER PRE-ASSEMBLED
743846300 743846300 FASTENING
743846100 743846100 FASTENING
704311100 704311100 FILTER MAT
990282900 990282900 FILTER MAT
804269300 804269300 FOLDING CARDBOARD BOX
710904702 710904702 GASKET
710904502 710904502 GASKET
727301901 727301901 GLASS PLATE - COMPLETE
727302501 727302501 GLASS PLATE - COMPLETE
594158302 594158302 HEAT EXCHANGER
615367501 615367501 HEATING TUBE
694153700 694153700 HEATING TUBE
694168900 694168900 HEATING TUBE
409800800 409800800 HEXAGON-HEAD SELF-TAPPING SCREW
409869100 409869100 HEXAGON-HEAD SELF-TAPPING SCREW
409869500 409869500 HEXAGON-HEAD SELF-TAPPING SCREW
409837201 409837201 HEXAGON-HEAD SELF-TAPPING SCREW
409819600 409819600 HEXAGON-HEAD SELF-TAPPING SCREW
409801000 409801000 HEXAGON-HEAD SELF-TAPPING SCREW
409802901 409802901 HEXAGON-HEAD SELF-TAPPING SCREW
409874300 409874300 HEXAGON-HEAD SELF-TAPPING SCREW
409838400 409838400 HEXAGON-HEAD SELF-TAPPING SCREW
994103101 994103101 HOSE
610801500 610801500 ICE-CUBE MAKER
742446900 742446900 ICE-SHOLVER
936310900 936310900 INSULATING PLATE, ASSY.
936310700 936310700 INSULATING PLATE, ASSY.
614538600 614538600 INTEGRAL BOARD
614632200 614632200 INTEGRAL BOARD
614328900 614328900 INTEGRAL BOARD
980379700 980379700 INTERIOR LIGHT
607156700 607156700 INTERIOR LIGHT
704460700 704460700 KEY
704369900 704369900 KEY
704208900 704208900 KEY
704202900 704202900 KEY
770049000 770049000 LOKRING
770048000 770048000 LOKRING
770047400 770047400 LOKRING
770046400 770046400 LOKRING
770048800 770048800 LOKRING
710936500 710936500 MAGNETIC DOOR SEAL TO BOND
710936700 710936700 MAGNETIC DOOR SEAL TO BOND
710936900 710936900 MAGNETIC DOOR SEAL TO BOND
750100100 750100100 MAGNETIC STRIP
704336301 704336301 MOULDED HANDLE
800308601 800308601 MOULDING
708484301 708484301 OPERATING INSTRUCTIONS
708484900 708484900 OPERATING INSTRUCTIONS
611598901 611598901 OPERATING PANEL HOUSING
614431200 614431200 OPERATING UNIT BOARD
614432200 614432200 OPERATING UNIT BOARD
408401101 408401101 OVAL-HEAD SCREW
409866700 409866700 OVAL-HEAD WOOD SCREW
409868500 409868500 OVAL-HEAD WOOD SCREW
988008100 988008100 PACKAGING, COMPLETELY
770000100 770000100 PIPE
742546100 742546100 PLASTIC TUBE
743011200 743011200 PLUG
743495100 743495100 PLUG
743318800 743318800 PLUG
743124900 743124900 PLUG CONNECTOR WATER
945055100 945055100 PRE-ATTACHED BRACKET
908603300 908603300 PSEUDOGROUP
903601200 903601200 PSEUDOGROUP
409868900 409868900 PT SCREW
614318000 614318000 REED BOARD
594468900 594468900 REFRIGERATOR EVAPORATOR, SPEC. DESIGN
774231701 774231701 REINFORCING SECTION
710920300 710920300 SEAL
743750000 743750000 SEALING RINGS
742746202 742746202 SENSOR RETAINING FIXTURE
726617600 726617600 SLEEVE
743261300 743261300 SLIDE FOR AIR CONTROL
959275900 959275900 SOLENOID VALVE
987545900 987545900 SPECIAL SECURING HARDWARE
726679700 726679700 SPECIAL SECURING HARDWARE
726620201 726620201 SPECIAL SECURING HARDWARE
945365900 945365900 STEEL BEARING BLOCK
903300801 903300801 STORAGE RACK, STUDDED
743266700 743266700 STORAGE TRAY
600969900 600969900 SUPPLY LINE
743634900 743634900 SWITCHING COMPONENTS
742643900 742643900 SWITCHING COMPONENTS
750101000 750101000 SWITCHING COMPONENTS
615203600 615203600 TEMPERATURE LIMITER
727111500 727111500 TOUGHENED SAFETY-GLASS PLATE
727701100 727701100 TOUGHENED SAFETY-GLASS PLATE
694366100 694366100 TRANSFORMER
764102301 764102301 TRIM STRIP PROFILE
909627100 909627100 VALVE ADAPTER
742323000 742323000 VARIABLE EGG TRAY
612232300 612232300 VARIOUS COMPONENTS
614320001 614320001 VARIOUS COMPONENTS
743030601 743030601 VARIOUS HOUSINGS
742935200 742935200 VARIOUS INJECTION-MOULDED ITEMS
743563301 743563301 VARIOUS INJECTION-MOULDED ITEMS
742946500 742946500 VARIOUS INJECTION-MOULDED ITEMS
742946700 742946700 VARIOUS INJECTION-MOULDED ITEMS
743337500 743337500 VARIOUS INJECTION-MOULDED ITEMS
743014500 743014500 VARIOUS INJECTION-MOULDED ITEMS
742962302 742962302 VARIOUS INJECTION-MOULDED ITEMS
742936100 742936100 VARIOUS INJECTION-MOULDED ITEMS
743552900 743552900 VARIOUS INJECTION-MOULDED ITEMS
743004800 743004800 VARIOUS INJECTION-MOULDED ITEMS
726605200 726605200 VARIOUS INJECTION-MOULDED ITEMS
743221701 743221701 VARIOUS INJECTION-MOULDED ITEMS
742920700 742920700 VARIOUS INJECTION-MOULDED ITEMS
743261700 743261700 VARIOUS PLATES
743261500 743261500 VARIOUS PLATES
743247300 743247300 VARIOUS RETAINING FIXTURES
743821600 743821600 VARIOUS RETAINING FIXTURES
742942301 742942301 VARIOUS RETAINING FIXTURES
742223400 742223400 VARIOUS RETAINING FIXTURES
742223600 742223600 VARIOUS RETAINING FIXTURES
743133300 743133300 VARIOUS RETAINING FIXTURES
743240600 743240600 VARIOUS RETAINING FIXTURES
743257600 743257600 VARIOUS RETAINING FIXTURES
743257800 743257800 VARIOUS RETAINING FIXTURES
774219400 774219400 VENTILATION TRIM
743257300 743257300 VENTILATION TRIM
744000200 744000200 WATER FILTER
711254000 711254000 WIRE BRACKET/GLASS-LINE DOOR
704363400 704363400 ZINC DIE-CAST BEARING BLOCK
