Model Image
Manufacturer

Liebherr

Model Number

WS4000

Description

Multi-temperature Wine Cabinet-upright-st. Steel

Interactive Exploded View
Exploded View

Parts List

Part Number Description
704375300 704375300 ADJUSTING SCREW
694241900 694241900 AIR SENSOR FOR FREEZER COMPARTMENT
694241700 694241700 AIR SENSOR FOR REFRIGERATOR COMPARTMENT
694238700 694238700 AIR SENSOR FOR REFRIGERATOR COMPARTMENT
694044500 694044500 ALUM. HEATING STRIP
694044700 694044700 ALUM. HEATING STRIP
711307301 711307301 BOLT
743032800 743032800 BRACKET
726607901 726607901 BUFFER
704360101 704360101 BUSHING
611876500 611876500 COMPACT FAN
610876500 610876500 COMPACT FAN
611967300 611967300 COMPRESSOR R 134 A
594157100 594157100 CONDENSER SPIRAL
409814401 409814401 COUNTERSUNK SCREW
408291501 408291501 COUNTERSUNK SELF-TAPPING SCREW
742776700 742776700 COVER
741270200 741270200 COVER CAP
742773900 742773900 COVER PLATE
743214502 743214502 CROSS PIECE FOR COMB. DOORS
708002100 708002100 DISPLAY TRIM
773478300 773478300 DISPLAY TRIM
602102101 602102101 DISTRIBUTOR STRIP
789073700 789073700 DRAWER RAIL
789073500 789073500 DRAWER RAIL
594204801 594204801 DRYER
611314500 611314500 ELECTRONICS
774318101 774318101 ELECTROPLATED STEEL SHEET
694238500 694238500 EVAPORATOR SENSOR FOR REFRIGERATOR
989071900 989071900 EVAPORATOR TRAYS
629901200 629901200 FAN BLADE
594063700 594063700 FIN-TYPE EVAPORATOR
804138500 804138500 FOLDING CARDBOARD BOX
744099900 744099900 FRESHAIR ACTIVATED CHARCOAL FILTER
743174500 743174500 FRONT TRIM
710972302 710972302 GASKET
980920303 980920303 GLASS DOOR, COMPLETE
409810001 409810001 HEXAGON-HEAD SELF-TAPPING SCREW
704360301 704360301 HINGE PLATE
704359501 704359501 HINGE PLATE
704359701 704359701 HINGE PLATE
994178900 994178900 HOSE
611334100 611334100 INTEGRAL BOARD
607165102 607165102 INTERIOR LIGHT
929200400 929200400 KEY
704379901 704379901 MOULDED HANDLE
708168900 708168900 OPERATING INSTRUCTIONS
408400501 408400501 OVAL-HEAD SCREW
408270401 408270401 OVAL-HEAD SELF-TAPPING SCREW
409876301 409876301 OVAL-HEAD SELF-TAPPING SCREW
408280501 408280501 OVAL-HEAD SELF-TAPPING SCREW
409876700 409876700 OVAL-HEAD WOOD SCREW
409899101 409899101 OVAL-HEAD WOOD SCREW
409877100 409877100 OVAL-HEAD WOOD SCREW
988010700 988010700 PACKAGING, COMPLETELY
774322900 774322900 PERFORATED METAL PLATE, FINISHED
989062701 989062701 PIPE
770000100 770000100 PIPE
742760100 742760100 PLATE
740261200 740261200 PLUG
742461500 742461500 PLUG
611307700 611307700 POWER BOARD
409872300 409872300 PT SCREW
694042300 694042300 RELAY
694042100 694042100 SAFETY TEMPERATURE LIMITER
409890401 409890401 SCREW
740298700 740298700 SENSOR RETAINING FIXTURE
288479300 288479300 SLEEVE
288498901 288498901 SLEEVE
950369301 950369301 SOLENOID VALVE
774317900 774317900 SPARE PART
704361700 704361700 SPARE PART
904014403 904014403 SPECIAL SECURING HARDWARE
740288800 740288800 SPECIAL SECURING HARDWARE
726612000 726612000 SPECIAL SECURING HARDWARE
720377300 720377300 SPRING
720377500 720377500 SPRING
840902801 840902801 STAINLESS STEEL CLEANER CHROMOL
742829300 742829300 STRIP
600974701 600974701 SUPPLY LINE
750101000 750101000 SWITCHING COMPONENTS
611309100 611309100 THERMOSTAT
409802803 409802803 THREAD-CUTTING SCREW
742776101 742776101 VARIOUS INJECTION-MOULDED ITEMS
742874700 742874700 VARIOUS INJECTION-MOULDED ITEMS
742847300 742847300 VARIOUS INJECTION-MOULDED ITEMS
743029300 743029300 VARIOUS RETAINING FIXTURES
743029501 743029501 VARIOUS RETAINING FIXTURES
742770200 742770200 VARIOUS RETAINING FIXTURES
742223600 742223600 VARIOUS RETAINING FIXTURES
742223400 742223400 VARIOUS RETAINING FIXTURES
774479100 774479100 WASHER
774400900 774400900 WASHER
711246300 711246300 WOODEN SHELF
