Manufacturer
Samsung
Model Number
ML-2551N
Description
Ml-2551n Monochrome Laser Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 6902-000332 | BAG CONDUCTIVE;LDPE,T0.07,W250,L500,BLK, |
| 6902-000183 | BAG PE;LDPE,T0.05,W350,L400,TRP,28LANGUA |
| JC71-00042A | BAR-P_CROSS BOTTOM;ML-2150,SECC T1.0 |
| 3301-000317 | BEAD-SMD;120OHM,2012,TP,-,- |
|
|
BEARING-H/R L;ML-165,PPS(RBA313N),ID26.2 |
| JC66-10202A | BEARING-PICK UP;ML-80,POM |
| JC61-00623A | BRACKET-P-EXIT;ML-2150,SECC,1.20,77,85,- |
| JC61-00617A | BRACKET-P-FUSER;ML-2150,SECC,1.20,-,-,-, |
| JC61-00622A | BRACKET-P-MAIN;ML-2150,SECC,1.60,163,123 |
| JC61-00755A | BRACKET-P-SHAFT MP;ML-2150,SECC,1.20 |
| JC61-00845A | BUSH-M-EXIT;ML-2550,DE8903(NTR),?5,?7,7, |
| JC61-00665A | BUSH-M-FEED, DUP;ML-2150,POM, SW01,4.0,7 |
|
|
BUSH-M-HR_R;ML-2150,PPS,?12.7,?32.6,-,BL |
| JC61-00657A | BUSH-M-RETAINER;ML-2150,POM (DELIN DE-89 |
| JC61-00652A | BUSH-M-RETARD;ML-2150,POM (DE-8903),?6,B |
| JC61-00668A | BUSH-M-ROLLER REGI L;ML-2150,POM CE20,?6 |
| JC61-00669A | BUSH-M-ROLLER REGI U;ML-2150,POM CE20,?6 |
|
|
BUSH-PRESSURE R;ML-165,PPS(RBA313N),14,7 |
| JC72-00382B | BUSH;ML-1710,POM(DERLIN 8903),WHITE |
| JC64-00043A | BUTTON-M-POWER;ML-2150,ABS,-,V0,-,- |
| 2402-000176 | C-AL,SMD;10UF,20%,16V,GP,TP,4.3X4.3X5.4 |
| 2401-000042 | C-AL;100UF,20%,16V,GP,TP,6.3X7,5 |
| 2401-000880 | C-AL;220UF,20%,50V,WT,TP,10X16MM,5M |
| 2203-000384 | C-CER,CHIP;0.015NF,5%,50V,C0G,TP,1608,0. |
| 2203-000426 | C-CER,CHIP;0.018NF,5%,50V,C0G,1608 |
| 2203-000041 | C-CER,CHIP;0.01NF,0.25PF,50V,C0G,TP,1608 |
| 2203-000626 | C-CER,CHIP;0.022NF,5%,50V,C0G,1608 |
| 2203-000998 | C-CER,CHIP;0.047NF,5%,50V,C0G,1608 |
| 2203-001683 | C-CER,CHIP;0.068NF,5%,50V,NP0,1608 |
| 2203-000783 | C-CER,CHIP;0.33NF,5%,50V,C0G,1608 |
| 2203-005249 | C-CER,CHIP;100NF,10%,50V,X7R,TP,1608 |
| 2203-000257 | C-CER,CHIP;10NF,10%,50V,X7R,TP,1608 |
| 2203-000440 | C-CER,CHIP;1NF,10,50V,X7R,TP,1608 |
| 2203-000491 | C-CER,CHIP;2.2NF,10%,50V,X7R,1608 |
| 2203-002392 | C-CER,CHIP;220NF,+80-20%,50V,Y5V,2012 |
| 2201-000119 | C-CERAMIC,DISC;100NF,+80-20%,50V,Y5V,8X3 |
| 2404-000284 | C-TA,CHIP;10UF,20%,16V,-,TP,3528 |
| 6501-000004 | CABLE TIE;DA-80,T1,W2.5,L80,NTR,NYLON66 |
| JC66-00452A | CAM-M-PICK UP MP;ML-2150,POM M90-44,-,-, |
| JC67-00039A | CAP-M-GEAR;ML-2150,POM,BLK |
| JC67-00037A | CAP-M-GUIDE SIDE,L;ML-2150,POM,BLK |
| JC67-00034A | CAP-M-SENSOR;ML-2150,ABS,1.0,-,-,-,- |
| JC67-00036A | CAP-M-WIRE PTL LOWER;ML-2150,POM,BLK |
| JC67-00035A | CAP-M-WIRE PTL UPPER;ML-2150,PC(NH-1023) |
| JC67-00047A | CAP-M_BUSHING ACTUATOR;ML-2150,POM |
| JC67-00038A | CAP-P_BUSHING REGI LOWER;ML-2150,SUS301, |
| JC39-00259A | CBF HARNESS-CONNECTOR;ML-2150,CBF,UL 106 |
| JC39-00258A | CBF HARNESS-COVER OPEN;ML-2150,CBF,UL 10 |
| JB39-00017A | CBF HARNESS-EARTH (TX MOTOR);SF-3100,UL |
| JC39-00254A | CBF HARNESS-EXIT;ML-2150,CBF,UL 1061,3,1 |
| JC39-00279A | CBF HARNESS-FUSER;ML-2150,CBF,UL 3122,3, |
| JC39-00247A | CBF HARNESS-HVPS;ML-2150,CBF,UL 1617,8,1 |
| JC39-00246A | CBF HARNESS-INLET;ML-2150,CBF,UL 1617 / |
| JC39-00249A | CBF HARNESS-LCD;ML-2150,WIRE,UL2877,8,40 |
| JC39-00257A | CBF HARNESS-MAIN MOTOR;ML-2150,CBF,UL 10 |
| JC39-00157A | CBF HARNESS-MOTOR;ML-1650,WIRE HARNESS,U |
| JC39-00256A | CBF HARNESS-MP EMPTY;ML-2150,CBF,UL 1061 |
| JC39-00205A | CBF HARNESS-MPF JOINT;ML-3550,UL1061AWG2 |
| JB39-40532A | CBF HARNESS-OPE;SF3000,CBF,UL1007,1,100, |
| JB39-00128A | CBF HARNESS-P1284 FG;SF-430,UL1007,#18,1 |
| JC39-00251A | CBF HARNESS-PANEL;ML-2150,CBF,UL 1061,6, |
| JC39-00181A | CBF HARNESS-PTL;SCX-5100,WIRE HARNESS,UL |
| JC39-00250A | CBF HARNESS-SCF EMPTY;ML-2150,CBF,UL 106 |
| JC39-00261A | CBF HARNESS-SENSOR;ML-2150,CBF,UL 1061,4 |
| JC39-00253A | CBF HARNESS-SMPS;ML-2150,CBF,UL 1061,24, |
| JC39-00255A | CBF HARNESS-THRMISTOR;ML-2150,CBF,UL 106 |
| JC39-00298A | CBF HARNESS-TONER_SEN;ML-2550,CBF,UL 106 |
| JC39-40511A | CBF HARNESS;ML-80,JUMPER,AWG22,52MM,SILV |
| JC39-30002A | CBF IF;1810,GRY |
|
|
CBF-POWER CORD;DT,EU,FP3/YES,IEC320 C13/ |
| 3702-001121 | CONNECTOR-RIBBON;60P,MALE,STRAIGHT,AUF |
| JC63-00122A | COVER-M-FRAME EXIT;ML-2150,ABS,2.5,-,-,V |
| JC63-00118A | COVER-M-FRONT INNER;ML-2150,ABS,-,-,-,VO |
| JC63-00110A | COVER-M-FUSER;ML-2150,PET+GF30%,-,-,-,V0 |
| JC63-00127A | COVER-M-MP;ML-2150,ABS,-,-,-,V0,SEC,G713 |
| JC63-00116A | COVER-M-OPEN;ML-2150,ABS,-,-,-,V0,-,-,- |
| JC63-00120A | COVER-M-REAR;ML-2150,ABS,-,-,-,V0,-,-,- |
| JC63-00115A | COVER-M-RIGHT;ML-2150,ABS,-,-,-,V0,-,-,- |
| JC63-00361B | COVER-M-TOP(XEV);ML-2551N/XEV,ABS ,2.5,- |
| JC63-00256A | COVER-WINDOW;ML-2150,PVC FILM,T0.15,90MM |
| 0402-000129 | DIODE-RECTIFIER;1N4003,200V,1A,DO-41,TP |
| 0404-000112 | DIODE-SCHOTTKY;RB420D,40V,100MA,SOT-23,T |
| 0401-000005 | DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T |
| 0407-000122 | DIODE-SWITCHING;KDS226,80V,100MA,SOT-23, |
| 0401-000116 | DIODE-SWITCHING;MMSD914T1,100V,200MA,SOD |
| 0403-000433 | DIODE-ZENER;ZPU150,130-165V,1300MW,DO-41 |
| JC96-02675A | ELA HOU BASE-HOLDER PAD;ML-2150,SEC,110V |
| JC96-02127A | ELA HOU-CST SENSOR HAWK16;ML-7250,XEROX, |
| JC96-02778B | ELA HOU-POWER_V2C;ML-2550,SEC,V2_CHINA,S |
| JC96-01772A | ELA HOU-VARISTOR;ML-6060,NEC/SEC,110/220 |
| JC96-02845A | ELA UNIT-CASSETTE(550);ML-2150,SEC,-,110 |
| JC96-02679A | ELA UNIT-COVER MP;ML-2150,SEC,220V,-,-,- |
| JC96-02697A | ELA UNIT-COVER RIGHT;ML-2150,SEC,220V,-, |
| JC96-02996B | ELA UNIT-COVER TOP;ML-2551N/XEV,SEC,RUSS |
|
|
ELA UNIT-FUSER_25;ML-2550,XEROX,USA,220V |
|
|
ELA UNIT-HOLDER TR L;ML-6060A,SAMSUNG,-, |
| JC96-01729A | ELA UNIT-HOLDER TR R;ML-6060A,SAMSUNG,-, |
| JC96-02680A | ELA UNIT-KNOCKUP MP;ML-2150,SEC,220V,-,- |
| JC96-02857A | ELA UNIT-MOTOR EXIT CARDINAL2;ML-2550,XE |
| JC96-02725B | ELA UNIT-MOTOR MAIN CAR 25;ML-2550,XEROX |
|
|
ELA UNIT-PICK UP;ML-2150,SEC,220V,-,-,-, |
| JC96-02681A | ELA UNIT-PICKUP MP;ML-2150,SEC,220V,-,-, |
| JC96-03666A | ELA UNIT-REGI;ML-2150,SAMSUNG,KOR,-,-,-, |
| JC96-02682A | ELA UNIT-RETARD;ML-2150,SEC,220V,-,-,-,- |
|
|
ELA UNIT-ROLLER P/UP MP;ML-2150,SEC,220V |
| JC71-00039A | ELECTRODE-P-FU_M;ML-2150,T0.6,6,L61.8,C5 |
| JC71-00040A | ELECTRODE-P-FU_R;ML-2150,T0.6,6,L73.35,C |
| JC71-00041A | ELECTRODE-P_FU_L;ML-2150,T0.6,6,L81 |
| JC31-00027B | FAN-DC CARDINAL;AD0424LS-C50,ML-2550 |
| JC31-00029A | FAN-DC;AD0824MS-A70GL(TR),ML-2150,P.B.T, |
| 2901-001178 | FILTER-EMI SMD;25V,2A,100000PF,2X1.25X1M |
| JC61-40001A | FOOT-ML80;ML-80,NBR,GRAY |
| JG61-40001A | FOOT-SF4000;SF4000,CR RUBBER,W14XL14,BLK |
| JC61-00677A | FRAME-M-BASE;ML-2150,ABS V0 VE0860P,-,-, |
| JC61-00642A | FRAME-M-CASSETTE;ML-2150,HIPS,-,HB,G7131 |
| JC61-00683A | FRAME-M-HOLDER PAD;ML-2150,HIPS,-,HB,BLA |
| JC61-00676A | FRAME-M-LSU LOWER;ML-2150,ABS(HB(HF0660I |
| JC61-00641A | FRAME-M-PICKUP;ML-2150,PC+ABS ,-,-,BLACK |
| JC61-00640A | FRAME-M-RETARD;ML-2150,PC,-,-,BLACK,-,-, |
| JC61-00621A | FRAME-P-FUSER;ML-2150,SECC T1.2,-,-,-,-, |
| JC66-40911A | GEAR-DP,IDLE;ML-165,POM,1,Z21,WHITE,NW-0 |
| JC66-00415A | GEAR-DUPLEX IDLE;ML-2150,POM,1,Z23,31.5, |
| JC66-00422A | GEAR-DUPLEX;ML-2150,POM,1,19,9,NTR,21,-, |
| JC66-40211B | GEAR-EXIT/U,ID;ML-1605,POM,1,Z16,BLACK |
| JC66-40209A | GEAR-EXIT;ML-80,POM,WHT |
| JC66-40913B | GEAR-FUSER 7300;ML-7300,PPS,1,34,-,DARK |
| JC66-00418A | GEAR-FUSER IDLE;ML-2150,POM,1,29,8,NTR,3 |
|
|
GEAR-HUB CLUTCH;SCX-5100,POM,M0.8,Z13,NT |
|
|
GEAR-IDLE 23;ML-2150,POM,1,23,8,YELLOW,2 |
|
|
GEAR-IDLE 33;ML-2150,POM,1,33,8,YELLOW,3 |
| JC66-00674A | GEAR-M-EXIT Z17;ML-2550,M90-44,1,17,F5,B |
| JC66-00413A | GEAR-MP DRV;ML-2150,POM,0.8,Z45,7.5,NTR, |
| JC66-00424A | GEAR-MP HOLDER_CAM;ML-2150,POM,0.8,37,13 |
| JC66-00423A | GEAR-MP PICK_UP;ML-2150,POM,0.8,37,22.7, |
| JC66-00644A | GEAR-OPC DRV INNER;ML-2150,POM,0.5,53,18 |
| JC66-00645A | GEAR-OPC DRV OUTER;ML-2150,POM,0.8,31,13 |
| JC66-00533A | GEAR-PICK_UP CAM;ML-2150,POM,0.8,29,10,N |
| JC66-00412A | GEAR-PICK_UP DRV;ML-2150,POM,0.8,Z59,10. |
| JG66-40003A | GEAR-PINION;SF4000,POM,1,Z16,WHT |
| JC66-00414A | GEAR-RDCN DUPLEX;ML-2150,POM,A:1,B:0.8,Z |
| JC66-00419A | GEAR-RDCN EXIT;ML-2150,POM,A:1,B:0.5,53/ |
| JC66-00409A | GEAR-RDCN FEED;ML-2150,POM,A:0.8,B:0.8,Z |
| JC66-00416A | GEAR-RDCN FUSER IN;ML-2150,POM,0.5,75,16 |
|
|
GEAR-RDCN FUSER OUT;ML-2150,NYLON,1,25,8 |
| JC66-00405A | GEAR-RDCN OPC;ML-2150,POM,A:0.5,B:0.5,Z6 |
| JC66-00411A | GEAR-RDCN PICK_UP;ML-2150,POM,A:0.8,B:0. |
| JC66-00407A | GEAR-RDCN REGI;ML-2150,POM,A:0.8,B:0.5,Z |
| JC66-00410A | GEAR-RDCN RETARD;ML-2150,POM,A:0.8,B:0.8 |
| JC66-00408A | GEAR-REGI IDLE;ML-2150,POM,0.8,Z29,15,NT |
| JC66-00420A | GEAR-REGI Z25;ML-2150,POM,0.8,25,5.6,NTR |
| JC66-00039A | GEAR-TR29;ML-6060A,POM M90-44,0.6,29,BLK |
| JC61-00658A | GUIDE-M-DUPLEX;ML-2150,PC,CLEAR |
| JC61-00644A | GUIDE-M-EXTENSION CST;ML-2150,HIPS,HB,-, |
| JC61-00655A | GUIDE-M-HANDLE;ML-2150,ABS,V0,-,-,-,G713 |
| JC61-00704A | GUIDE-M-INNER CST;ML-2150,HIPS,HB,-,-,-, |
| JC61-00664A | GUIDE-M-LEFT, DUP;ML-2150,PET,V0,2.0,211 |
| JC61-00267B | GUIDE-M-LOCK A;ML-2150,HIPS,HB,C75064 |
| JC61-00648A | GUIDE-M-PAPER SIZE;ML-2150,POM,-,-,-,WHT |
| JC61-00646A | GUIDE-M-REAR;ML-2150,HIPS,HB,-,-,-,C7506 |
| JC61-00620A | GUIDE-M-REAR;ML-2150,PET+GF30%,-,-,-,BLK |
| JC61-00662A | GUIDE-M-RIGHT, DUP;ML-2150,PC+ABS, V0,2. |
| JC61-00645A | GUIDE-M-SIDE LOCK;ML-2150,ABS,HB,-,-,-,C |
| JC61-00801A | GUIDE-M_FRONT;ML-2150,PET+GF30%,VO,-,-,- |
| JC61-00661A | GUIDE-P-BOTTOM, DUP;ML-2150,SECC,0.8,259 |
| JC61-00660A | GUIDE-P-FRONT, DUP;ML-2150,SECC,0.8,76,2 |
| JC61-00751A | GUIDE-P-REAR PAPER CST;ML-2150,SUS-301,T |
| JC61-00691A | GUIDE-PLATE PAPER;ML-2150,SECC,T0.6 |
| JC61-00674A | GUIDE-P_REGI LOWER;ML-2150,SECC,1.2 |
| JC61-00670A | GUIDE-P_REGI PLATE;ML-2150,SECC,1.2 |
| JC61-00675A | GUIDE-P_REGI UPPER;ML-2150,SECC,1.2T |
| JC61-00678A | GUIDE-P_TRANSFER;ML-2150,SECC,0.6,-,-,-, |
| 3711-005861 | HEADER-BOARD TO BOARD;BOX,40P,2R,0.8MM,S |
| 3711-002813 | HEADER-BOARD TO CABLE;BOX,12P,1R,2MM,STR |
| 3711-003204 | HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,STR |
| 3711-000826 | HEADER-BOARD TO CABLE;BOX,2P,1R,2MM,ANGL |
| 3711-003408 | HEADER-BOARD TO CABLE;BOX,2P,1R,2MM,STRA |
| 3711-003968 | HEADER-BOARD TO CABLE;BOX,3P,1R,2.5MM,ST |
| 3711-000906 | HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,ANGL |
| 3711-003409 | HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,STRA |
| 3711-000967 | HEADER-BOARD TO CABLE;BOX,4P,1R,2MM,ANGL |
| 3711-002807 | HEADER-BOARD TO CABLE;BOX,6P,1R,2MM,STRA |
| 3711-002809 | HEADER-BOARD TO CABLE;BOX,8P,1R,2MM,STRA |
| 3711-002810 | HEADER-BOARD TO CABLE;BOX,9P,1R,2MM,STRA |
| JC61-00666A | HINGE-M-FRONT GUIDE, DUP;ML-2150,PC,2.0, |
|
|
HOLDER-BEARING EXIT F/DOWN;SCX-4216F,POM |
| JC61-00673A | HOLDER-M-BUSHING EXIT;ML-2150,POM,BLK |
| JC61-00671A | HOLDER-M-BUSHING TX;ML-2150,POM,BLK |
| JC61-00785A | HOLDER-M-IDLE ROLLER;ML-2150,PC,BLK |
| JC61-00639A | HOLDER-M-INDICATOR;ML-2150,POM,-,-,-,BLK |
|
|
HOLDER-M-PAD;ML-2150,PC,BLK |
| JC61-00705A | HOLDER-M-PICKUP MP;ML-2150,POM,BLK,HB |
| JC61-00638A | HOLDER-M-RETARD;ML-2150,HIPS,-,-,-,C8726 |
| JC61-00672A | HOLDER-M-SENSOR;ML-2150,HIPS,-,-,-,BLK,- |
| JC61-00637A | HOUSING-M-FEED;ML-2150,ABS HB,-,-,-,BLK, |
| JC61-00685A | HOUSING-M-PICK UP MP;ML-2150,PC+ABS,WHT |
|
|
HOUSING-M-RETARD;ML-2150,POM(M90-44),BLK |
| JB13-00004A | IC ASIC-OPE;HT48C50-1-SPPF,SF-3100,48P,+ |
| JC13-00028A | IC ASIC-SPGPV3;SPGPV3,ML-2550_VE,496PIN, |
| 1205-002339 | IC-CLOCK GENERATOR;CY25811SC,SOIC,8P,150 |
| 0801-000205 | IC-CMOS LOGIC;4050,BUFFER,SOP,16P,150MIL |
| 0801-002446 | IC-CMOS LOGIC;74LCX14,SCHMITT INVERTER,T |
| 1105-001357 | IC-DRAM;K4S281632,128NBIT,4X2MX16,TSOP(I |
| 1103-001183 | IC-EEPROM;24C04,4KBIT,512X8,SOP,8P,5X4MM |
| 1103-001279 | IC-EEPROM;24C32,32KBIT,4KX8,SOP,8P,5X4MM |
| 1107-001549 | IC-FLASH MEMORY;K9F5616U0C,256MBIT,16MX1 |
| 1006-001224 | IC-LINE TRANSCEIVER;74LVX161284,TSSOP,48 |
| 1003-001535 | IC-MOTOR DRIVER;A3977SLP,TSSOP,28P,9.6X4 |
| 1203-003700 | IC-POSI.ADJUST REG.;LD1117ADT-R,DPAK,3P, |
| 1203-000001 | IC-POSI.FIXED REG.;7805,TO-220,3P,-,PLAS |
| 1202-000164 | IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL, |
| JC70-00327A | ICT-STUD DRV GEAR, DUP;ML-2150,SUM24L,5. |
| JC70-00457A | ICT-STUD PAPER GUIDE, DP;ML-2150,SUM24L, |
| JC64-00041A | INDICATOR-M-EMPTY;ML-2150,HIPS HB,-,G713 |
| 2703-000158 | INDUCTOR-SMD;1UH,10%,2012 |
| JC70-00195A | IPR-BRACKET SENSOR;ML-7250,SECC,1.0T |
| JC70-00467A | IPR-GND-P-PAPER_SIZE;ML-2550,SUS,0.2 |
| JC70-00325A | IPR-P-FINGER LEFT;ML-2150,SPCC,T1.2,ZN |
| JC70-00326A | IPR-P-FINGER RIGHT;ML-2150,SPCC,T1.2,ZN |
| JC70-00192A | IPR-PLATE SENSOR;ML-7250,SUS301,0.2T |
| JC70-00336A | IPR-P_GND SOLENOIDE FEED;ML-2150,SUS304 |
| JC70-00328A | IPR-P_GROUND GUIDE TR;ML-2150,C5210P,0.2 |
| JC70-00330A | IPR-P_GROUND MOTOR MAIN2;ML-2150,C5210P, |
| JC70-00332A | IPR-P_GROUND OPC;ML-2150,SUS301 3/4H,0.2 |
| JC70-00339A | IPR-P_GROUND PLATE PAPER;ML-2150,SUS304 |
| JC70-00333A | IPR-P_GROUND REGI ROLLER;ML-2150,SUS304 |
| JC70-00334A | IPR-P_GROUND SCF MAIN;ML-2150,SUS304 1/2 |
| JC70-10961A | IPR-TERMINAL FU;ML-165,C5210P,T0.3 |
| 3722-000124 | JACK-DIN;8P,AU,BLK,ANGLE |
| 3722-001319 | JACK-MODULAR;8P/8C,STANDARD,Y,ANGLE,INVE |
| 3722-001101 | JACK-USB;4P/1C,AU,IVR,ANGLE,B TYPE |
| JC64-00045A | KEY-M-BUTTON;ML-2150,ABS VO,-,V0,C71312, |
| JC64-00044A | KEY-M-DUPLEX;ML-2150,ACRYL,MILKY WHITE |
| JC64-00046A | KEY-M-ON LINE;ML-2150,-,-,-,MILKY WHITE, |
| JC64-00047A | KEY-M-SAVE MODE;ML-2150,MILKY WHITE |
| JC64-00042A | KNOB-M-REAR;ML-2150,HIPS HB,-,-,-,-,C750 |
| JB68-00916A | LABEL RATING-BLANK;SF-340,SEC,TETRON,0.0 |
| JC68-10932A | LABEL(P)-BLANK(ML);ML-85,ART,G100,WHT,CO |
| JC68-01898A | LABEL-INFORMATION;CLP-300/SEE,SAMSUNG,AR |
| JC47-00010A | LAMP-PTL;90-20-210-167,ML-2150,4.1 X 9.4 |
| JC07-00005A | LCD-PANEL;VHC1625SLYC9-1,ML-2150,16X2,36 |
| 0601-001332 | LED;CBI,GRN,2.9MM,567NM |
| 0601-001619 | LED;CBI,RED/GRN,3MM,635/568NM,6.35X7X6MM |
| 0601-000161 | LED;ROUND,GRN,5MM,563NM |
| 0601-000353 | LED;ROUND,RED/Y-GRN,5MM,630/570NM |
| JC66-00443A | LEVER-M-OPEN, DUP;ML-2150,HIPS HB,-,52.7 |
|
|
MEA RACK-EXIT ROLLER;ML-1605,SUMSUNG,KOR |
| JC97-01692A | MEA UNIT- ROLLER CLEAN;ML-2150,SAMSUNG,C |
| JC97-02361A | MEA UNIT-COVER REAR;ML-2150,SEC,-,COVER |
| JC97-01714B | MEA UNIT-DUPLEX;ML-2550,XEROX,USA,DUPLEX |
| JC97-01738A | MEA UNIT-GEAR P/UP MP CARDINA;ML-2150,GE |
| JC97-01715A | MEA UNIT-GUIDE FRONT, DUP;ML-2150,SEC,-, |
| JC97-01713A | MEA UNIT-ROLLER FEED, DUP;ML-2150,SEC,-, |
| JC97-01401A | MEA UNIT-TERMINAL:TR;ML-5000A,SAMSUNG,KO |
|
|
MEC-BRUSH ANTISTATIC;ML-6060A,SEC,NTR |
| JC47-00009A | MEP-CLUTCH FEED CARDINAL;-,ML-2150,4.0W, |
| JC31-00024A | MOTOR BLDC-CARDINAL;50M8432030,1259,-,-, |
| JC74-00011A | MPR-PAD KNOCK UP MP;ML-6060A,CR+CORK,NTR |
| JC74-10901A | MPR-WASHER SUPPLY;POLY,ID4.1*OD11*T0.13, |
| 6021-000222 | NUT-HEXAGON;2C,M3,ZPC(YEL),SM20C,- |
| 6021-001194 | NUT-SQUARE;M3,PASS,SWCH+ZN COATING,SQUAR |
| JC92-01473A | PBA MAIN-LCD PANEL;ML-2150,SEC,KOREA,LCD |
| JC92-01658A | PBA MAIN-MAIN;ML-2550,SEC,USA,CARDINAL_P |
| JC92-01475A | PBA MAIN-PTL1;ML-2150,SEC,KOREA,PTL1 B'D |
| JC92-01488A | PBA MAIN-ZENER;ML-2150,SEC,KOREA,ZENER B |
| JC92-01336A | PBA SUB-CASSETTE;ML-1650,KOREA/EXPORT,-, |
| JC92-01530A | PBA SUB-CONNECTOR B'D;ML-2550,SEC,KOREA, |
| JC92-01510A | PBA SUB-COVER JOINT;ML-2150,SEC,KOREA,CO |
| JC92-01514A | PBA SUB-COVER OPEN;ML-2150,SEC,KOREA,COV |
| JC92-01511A | PBA SUB-EMPTY SENSOR;ML-2150,SEC,KOREA,E |
| JC92-01512A | PBA SUB-EXIT SENSOR;ML-2150,SEC,KOREA,EX |
| JC92-01700B | PBA SUB-NPC_PRT;SCX-4720FN,SEC,KOREA,10/ |
| JC92-01516A | PBA SUB-PTL2;ML-2150,SEC,KOREA,PTL2,-,-, |
| JC92-01528A | PBA SUB-TONER_SENSOR;ML-2150,SEC,KOREA,T |
| 0604-001210 | PHOTO-INTERRUPTER;TR,200MW,DIP-4,ST |
|
|
PHOTO-INTERRUPTER;TR,90%,150MW,DIP-4,BK |
| JC61-00686A | PLATE-M-KNOCK UP MP;ML-2150,HIPS,-,-,-,G |
| JC72-00991A | PMO-ACTUATOR EMPTY;ML-2150,POM,BLK |
| JC72-00988A | PMO-ACTUATOR EXIT;ML-2150,PET+GF30%,BLK |
| JC72-00997A | PMO-ACTUATOR FEED, DUP;ML-2150,POM,HB,BL |
| JC72-01002A | PMO-ACTUATOR MP;ML-2150,POM,BLK |
| JC72-01310A | PMO-ACTUATOR OUTFULL;ML-2150,POM,VO,BLK |
| JC72-00998A | PMO-ACTUATOR REGISHUTTER;ML-2150,ABS G/F |
| JC72-41191B | PMO-BEARING SHAFT;ML-2150,POM,BLK,DE8903 |
| JC72-40232A | PMO-CAP AGITATOR;ML-80,PP,BLK |
| JC72-00463A | PMO-CAP CONNECTOR L;ML-6060A,POM,BLACK |
| JC72-00465A | PMO-CAP CONNECTOR U;ML-6060A,POM,V0,BLAC |
| JC72-41292B | PMO-CAP TR;ML-3560,POM,45.4*6.6,HB,M90-4 |
| JC72-00999A | PMO-DUMMY FRAME FUSER;ML-2150,PET+GF30%, |
|
|
PMO-GUIDE CLAW;ML-165,PEEK,BLK |
| JC72-00317A | PMO-GUIDE DEVE L;ML-6060A,POM,2715C |
| JC72-00318A | PMO-GUIDE DEVE R;ML-6060A,POM,2715C |
| JC72-41006A | PMO-HOLDER EXIT ROLL;ML-165,PC,BLK,HB |
| JC72-41010A | PMO-HOUSING TERMINAL;ML-165,ABS GF10%,BL |
| JC72-00994A | PMO-HUB IN RETARD;ML-2150,POM,DELIN 100P |
| JC72-00993A | PMO-HUB OUT RETARD;ML-2150,POM,M90-44,BL |
| JC72-01004A | PMO-IDLE KNOCK UP MP;ML-2150,POM,M90-44, |
|
|
PMO-IDLE PICK UP MP;ML-2150,POM,HB,WHITE |
| JC72-00825A | PMO-IMPELLER_DRV;ML-6200,NYLON66,V0,BLK |
| JC72-41007A | PMO-ROLLER FD F;ML-165,POM,BLACK |
| JC72-01005A | PMO-SIDE GUIDE MP(L);ML-2150,HIPS,HB,G71 |
| JC72-01006A | PMO-SIDE GUIDE MP(R);ML-2150,HIPS,HB,G71 |
| JC72-00995A | PMO-STACKER LOCKER;ML-2150,PC,V0,0810P |
| JC72-00996A | PMO-STACKER REAR;ML-2150,ABS,SR-0320D |
| JC72-00973A | PMO-STACKER_RX;ML-2150,ABS,V0,LIGHT GRAY |
| JC72-01359A | PMO-STRIPE;ML-3560,PE BOX 7033,T1X215.83 |
| 2001-000019 | R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M |
| 2001-000281 | R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM |
| 2001-000502 | R-CARBON;20OHM,5%,1/4W,AA,TP,2.4X6.4MM |
| 2007-000123 | R-CHIP;1.5KOHM,5%,1/10W,TP,1608 |
| 2007-000287 | R-CHIP;100OHM,1%,1/10W,TP,1608 |
| 2007-000074 | R-CHIP;100OHM,5%,1/10W,TP,1608 |
| 2007-000293 | R-CHIP;100OHM,5%,1/4W,TP,3216 |
| 2007-000052 | R-CHIP;10KOHM,1%,1/10W,TP,1608 |
| 2007-000090 | R-CHIP;10KOHM,5%,1/10W,TP,1608 |
| 2007-000303 | R-CHIP;10KOHM,5%,1/4W,TP,3216 |
| 2007-000309 | R-CHIP;10OHM,5%,1/10W,TP,1608 |
| 2007-002901 | R-CHIP;12.1KOHM,1%,1/10W,TP,1608 |
| 2007-000402 | R-CHIP;150OHM,5%,1/10W,TP,1608 |
| 2007-007937 | R-CHIP;17.4KOHM,1%,1/10W,TP,1608 |
| 2007-000078 | R-CHIP;1KOHM,5%,1/10W,TP,1608 |
| 2007-000109 | R-CHIP;1MOHM,5%,1/10W,TP,1608 |
| 2007-000105 | R-CHIP;200KOHM,5%,1/10W,TP,1608 |
| 2007-000106 | R-CHIP;220KOHM,5%,1/10W,TP,1608 |
| 2007-000075 | R-CHIP;220OHM,5%,1/10W,TP,1608 |
| 2007-000094 | R-CHIP;22KOHM,5%,1/10W,TP,1608 |
| 2007-000071 | R-CHIP;22OHM,5%,1/10W,TP,1608 |
| 2007-000082 | R-CHIP;3.3KOHM,5%,1/10W,TP,1608 |
| 2007-000729 | R-CHIP;300OHM,5%,1/10W,TP,1608 |
| 2007-000096 | R-CHIP;30KOHM,5%,1/10W,TP,1608 |
| 2007-000076 | R-CHIP;330OHM,5%,1/10W,TP,1608 |
| 2007-000134 | R-CHIP;33KOHM,5%,1/10W,TP,1608 |
| 2007-000113 | R-CHIP;33OHM,5%,1/10W,TP,1608 |
| 2007-000084 | R-CHIP;4.7KOHM,5%,1/10W,TP,1608 |
| 2007-000077 | R-CHIP;470OHM,5%,1/10W,TP,1608 |
| 2007-007226 | R-CHIP;49.9OHM,1%,1/10W,TP,1608 |
| 2007-000965 | R-CHIP;5.1KOHM,5%,1/10W,TP,1608 |
| 2007-000086 | R-CHIP;5.6KOHM,5%,1/10W,TP,1608 |
| 2007-000120 | R-CHIP;680OHM,5%,1/10W,TP,1608 |
| 2007-001134 | R-CHIP;68OHM,5%,1/10W,TP,1608 |
| 2007-000121 | R-CHIP;820OHM,5%,1/10W,TP,1608 |
| 2007-007445 | R-CHIP;9.09KOHM,1%,1/10W,TP,1608 |
| 2011-000651 | R-NETWORK;10OHM,5%,1/16W,L,CHIP,8P,TP,32 |
| 2011-000002 | R-NETWORK;22OHM,5%,1/16W,L,CHIP,8P,TP,32 |
| 2011-001094 | R-NETWORK;39OHM,5%,1/16W,L,CHIP,8P,TP,3. |
| 2005-000168 | R-WIRE WOUND,NON;0.22OHM,5%,2W,AA,BK,4X1 |
| 6044-000107 | RING-C;ID2.5,OD6,T0.4,PASS,STS304 |
| 6044-000125 | RING-E;ID4,OD9,T0.6,STSC |
| 6044-000231 | RING-E;ID5.0,OD11.0,T0.6,PASS,STS304 |
| JC73-40915B | RMO-RUBBER EXIT_DUP;ML-2150,EPDM,?11.6 X |
| JC66-00668A | ROLLER-EXIT_F/DOWN;ML-2150,SUM24+EPDM 60 |
| JC66-00597A | ROLLER-HEAT;ML-2150,AL PIPE T1.8MM,26MM, |
| JC66-00442A | ROLLER-M-IDLE, DUP;ML-2150,POM, SW01,8.0 |
| JC66-00647A | ROLLER-M_REGI IDLE L25;ML-2150,POM,12.4, |
| JC66-00648A | ROLLER-M_REGI IDLE S25;ML-2150,POM,?11.9 |
| JC66-00599A | ROLLER-PRESSURE;ML-2150,STK ?18, LTV RIB |
| JC66-00540A | ROLLER-TRANSFER;ML-2150,NBR SPONGE+SUM/N |
| JC72-40981A | ROLLER;ML-165,POM,WHT,HB |
| JC72-20902A | ROLLER;ML-5000A,TEFLON,WHT |
|
|
RPR-FRICTION PAD MP;ML-2150,NBB,53*9.8*T |
| JC73-10910A | RPR-PAD CST;ML-165,CORK,25.8*24.6,NTR,NI |
| JC73-00128A | RUBBER-FEED;ML-2150,PNR,30,SEC,GRAY |
| JC73-00127A | RUBBER-PICK UP;ML-2150,PNR,30,SEC,GRAY |
|
|
RUBBER-RETARD;ML-2150,PNR,30,SEC,GRAY |
| 6001-000568 | SCREW-MACHINE;PH,+,M3,L8,NI PLT,SWRCH18A |
| 6006-001193 | SCREW-MACHINE;PH,+,WSP,M3,L10,ZPC(WHT),S |
| 6002-000440 | SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWR |
| 6002-000175 | SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(WHT),SM2 |
|
|
SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW |
| 6003-000003 | SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(BLK),S |
|
|
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SW |
| 6003-000301 | SCREW-TAPTYPE;BH,+,S,M4,L6,ZPC(WHT),SWRC |
| 6003-000179 | SCREW-TAPTYPE;PH,+,S,M3,L6,ZPC(WHT),SWRC |
| 6003-000264 | SCREW-TAPTYPE;PWH,+,-,B,M3,L6,ZPC(WHT),S |
| 6003-000266 | SCREW-TAPTYPE;PWH,+,-,S,M3,L6,ZPC(WHT),S |
| 6003-000267 | SCREW-TAPTYPE;PWH,+,-,S,M3,L8,ZPC(WHT),S |
| 6003-000196 | SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRC |
| JC66-00592A | SHAFT-FEED;ML-2150,SUM 22,220,6,-,-,- |
| JC66-00591A | SHAFT-HUB IN;ML-2150,SUM 24L,8.5,1.9 |
| JC66-00444A | SHAFT-IDLE ROLL, DUP;ML-2150,SUM24L,25,2 |
| JC66-00439A | SHAFT-M-COUPLING RETARD;ML-2150,POM GF 2 |
| JC66-00401A | SHAFT-M-EXIT_DUPLEX;ML-2150,PC,-,-,BLK,- |
| JC66-00438A | SHAFT-M-GEAR RETARD;ML-2150,POM DELIN+GF |
| JC66-00453A | SHAFT-M-PICK UP MP;ML-2150,PC NH-1023,-, |
| JC66-00440A | SHAFT-M-PICK UP;ML-2150,POM GF25%,-,-,BL |
| JC66-00402A | SHAFT-M_EXIT_F/UP;ML-2150,PBT+GF30%,BLAC |
| JC66-00446A | SHAFT-REGI UPPER;ML-2150,SUM22,6 |
| JC66-00590A | SHAFT-RETARD;ML-2150,SUM 22,58,6 |
|
|
SHAFT;ML-5000A,SUS304,17.2,1.9,PI1.9 |
| JC63-00293A | SHEET-COVER PICKUP;ML-2550,PVC,0.188,14. |
| JC63-00132A | SHEET-COVER TR;ML-2150,PVC,0.2,17.5,28.9 |
| JC63-00297A | SHEET-GUIDE BOTTOM;ML-2550,PP/PET,6,148, |
| JC63-00124A | SHIELD-P_CONTROLLER;ML-2150,SECC,0.6,166 |
| JC44-00054A | SMPS-V2C_HVPS;ML-2150,CARDINAL-V2C,AC/DC |
|
|
SOLENOID-MAIN;DLH-34L008-07,ML-2150,24V, |
| JC33-00013A | SOLENOID-MP;DLH-34L008-06,ML-2150,24V,8O |
| JC61-00003A | SPRING ETC--CAM MP;ML-6100,SUS304-WPB,0. |
| JC61-70903A | SPRING ETC-ACTUATOR;ML-165,SUS304,PI0.2, |
| JC61-00391A | SPRING ETC-DUPLEX COVER;ML-9400W,SUS304W |
| JC61-70965A | SPRING ETC-EMPTY;ML-6000,SUS304-WPB,PI0. |
| JC61-70911A | SPRING ETC-EXIT ROLL FD;ML-165,SUS304 WP |
| JC61-70950A | SPRING ETC-EXTENSION;ML-5000A,SUS304WPB |
| JC61-70932A | SPRING ETC-GUIDE DEVE;ML-5000A,D4.3,L16. |
| JC61-00414A | SPRING ETC-GUIDE PAPER;ML-9400W,SUS304WP |
| JC61-70929A | SPRING ETC-HV LARGE;ML-5000A,SUS304-WPB, |
| JC61-70913A | SPRING ETC-KNOCK UP MP;ML-2150,SUS304 WP |
| JC61-70918A | SPRING ETC-LEVER;ML-165,SUS304 WPB,PI0.5 |
| JC61-00387A | SPRING ETC-PAD;ML-9400W,SUS304WPB,PI0.5, |
| JC61-00056A | SPRING ETC-PR(7300);ML-7300,PIANO WIRE,1 |
|
|
SPRING ETC-SEPERATION;ML-165,SUS304 WPB, |
| JC61-00047A | SPRING ETC-TR L HAWK;ML-6060A,SWP-B |
| 6107-001174 | SPRING-CS;SUS 304 WPB,-,PI1.1,D22.9,L100 |
| 6107-000014 | SPRING-CS;SUS304-WPB,PI0.55,D6.9,L14 |
| 6107-001155 | SPRING-ES;SWP-B,PI0.55,L25,OD4.4 |
| 6107-001159 | SPRING-TS;SUS304,PI0.45,D3.85,L20,W10,ID |
| 6107-001160 | SPRING-TS;SUS304,PI0.45,D5.45,L19.8,W14. |
| 6107-001158 | SPRING-TS;SUS304-WPB,PI0.4,D6.7,ID6.5,OD |
| 6107-001156 | SPRING-TS;SWP-B,PI0.6,W20,ID3.5 |
| 6107-001157 | SPRING-TS;SWP-B,PI0.8,D11.5,N11.5,PI8.9, |
|
|
STOPPER-M-FAN80;ML-2150,ABS HB,26.4,BLAC |
| JC61-00656A | STOPPER-M-HINGE OPEN;ML-2150,ABS VO,19,L |
| 3405-001069 | SWITCH-MICRO;125V,5A,30GF,SPDT |
| 3405-001073 | SWITCH-MICRO;125V,5A,40GF,SPDT |
| 3404-000155 | SWITCH-TACT;12V,50MA,160GF,6X6X3.5MM,SPS |
| 3404-000165 | SWITCH-TACT;12V,50MA,160GF,6X6X5,SPST |
| 0203-001100 | TAPE-OPP MASKING;OPP/W75/CLR,T0.075,W75, |
| JC65-00004A | TERMINAL-P_DEVE;ML-2060,SUS304WPB,PI 0.9 |
| JC65-00006A | TERMINAL-P_HV CARDINAL;ML-2060,SUS304 1/ |
| JC65-00007A | TERMINAL-P_PTL 2;ML-2150,PB(C5210P),T0.2 |
| JC65-00002A | TERMINAL-P_PTL L;ML-2060,PB(C5210P),T0.2 |
| JC65-00003A | TERMINAL-P_PTL R;ML-2060,PB(C5210P),T0.2 |
| JC65-00001A | TERMINAL-P_PTL;ML-2060,SUS301 3/4H,T0.2 |
| JC65-00005A | TERMINAL-P_TR CARDINAL;ML-2060,SUS304WPB |
| 0501-000338 | TR-SMALL SIGNAL;2SC2812,NPN,200MW,SOT-23 |
| 0501-000279 | TR-SMALL SIGNAL;KSA1182-Y,PNP,150MW,SOT- |
| 0501-000457 | TR-SMALL SIGNAL;MMBT2222A/KST2222A,NPN,3 |
| JC63-00128A | TRAY-M-EXTEND MP;ML-2150,HIPS(G6972),-,- |
| JC63-00129A | TRAY-M-LINK MP(L);ML-2150,HIPS(G71312),- |
| JC63-00130A | TRAY-M-LINK MP(R);ML-2150,HIPS(G71312),- |
| JC59-00019B | UNIT-LSU_CARDINAL_25;ML-2550,-,-,600DPI, |
| 6031-001255 | WASHER-PLAIN;NYLON,CUTTING,ID5,OD9,T0.5, |
| JC64-00048A | WINDOW-M-LCD;ML-2150,ACRYL,-,-,-,-,TRANS |
