Model Image
Manufacturer

Samsung

Model Number

PN64D550C1FXZA

Description

64 Inch 3d Plasma Tv

Interactive Exploded View

Parts List

Part Number Description
BN96-16541A BN96-16541A A/S ASSY-PDP E BUFFER BOARD;S63FH-YB06,P
BN96-16542A A/S ASSY-PDP F BUFFER BOARD;S63FH-YB06,P
BN96-16543A A/S ASSY-PDP G BUFFER BOARD;S63FH-YB06,P
BN96-20517A A/S ASSY-PDP LOGIC BOARD;S63FH-YB06,PL63
BN96-16546A BN96-16546A A/S ASSY-PDP X BUFFER BOARD;S63FH-YB06,P
BN96-16544A BN96-16544A A/S ASSY-PDP X MAIN BOARD;S63FH-YB06,PL6
BN96-16545A BN96-16545A A/S ASSY-PDP Y MAIN BOARD;S63FH-YB06,PL6
BN96-16548A A/S ASSY-PDP Y SCAN LOWER BOARD;S63FH-YB
BN96-16547A BN96-16547A A/S ASSY-PDP Y SCAN UPPER BOARD;S63FH-YB
BN61-04692A ADHESIVE-AA;94PRIMER,CLEAR,C043
BN61-05826A ADHESIVE-HM;PUR,BLACK,C043
BN96-18013E ASSY ACCESSORY-SCREW;ALL MODEL,6003-0017
BN96-18013Q ASSY ACCESSORY-SCREW;ALL MODEL,6003-0018
BN96-17492A ASSY ACCESSORY;PN64D550C1FXZA
BN92-08286L ASSY ACCESSORY;PN64D550C1FXZA
BN96-16729E ASSY BOARD P-IR FUNCTION TOUCH;PN64D490,
BN92-07578A ASSY BOX;PD550 64
BN96-16793A ASSY BRACKET P-STAND LINK;PD550 59,SECC
BN96-16790A BN96-16790A ASSY BRACKET P-WALL;PD450/490,SECC
BN90-03183A ASSY COVER FRONT;PD550 64
BN96-16778A ASSY COVER P-FRONT;PD550 64,MABS(CLEAR)+
BN96-16785C ASSY COVER P-REAR;PD550 64,NORTH AMERICA
BN90-03195A ASSY COVER REAR;PD550 64
BN97-06223A ASSY DRM-KEY CODE-ASS`Y;COM_005,TV,GEN
BN96-18641A ASSY GUIDE P-NECK;PD550,560 59",PETG,80
BN92-08836G ASSY LABEL;PN64D550C1FXZA
BN97-05171F ASSY MICOM-SUB;T-MSTAUSS-1003,2011.05.31
BN97-05171A ASSY MICOM;T-MST4AUSC
BN92-07879A ASSY P/MATERIAL;PD550 64
BN92-10909A ASSY P/MATERIAL;PN64D550C1FXZA
BN94-04354A BN94-04354A ASSY PCB MISC-MAIN;PN64D550C1FXZA
BN96-20271A BN96-20271A ASSY PDP MODULE P;S63FH-YB06,PL63FF030A,
BN91-08229G ASSY PDP;PD8000
BN91-06867D ASSY SHIELD;PD550 59
BN97-05172A ASSY SMD;PN51-59D550,560, BN41-01590A,BN
BN96-18071E ASSY SPEAKER P;6OHM,4PIN,15W,PDP NORMAL
BN96-16795B ASSY STAND P-COVER BOTTOM;PD550 59,GLASS
BN96-16885A ASSY STAND P-GUIDE;UD6500 55,GLASS
BN90-03303D ASSY STAND;PD550 59
6902-000706 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W1700,L1
6902-000476 BAG PE;LDPE,T0.03,W250,L350,TRP,RECYCLE+
6902-001221 BAG PE;LDPE,T0.05,W120,L200,TRP,RECYCLE
6922-000013 BAND;PP,T0.8,W18,L2300,TRP,ECO. N
4301-000121 BATTERY-MN;1.5V,4.4MAH,R03,10.5X44.5MM,7
3301-000314 BEAD-SMD;120OHM/100MHZ,1.6X0.8MM,TP,120O
3301-002039 3301-002039 BEAD-SMD;26OHM/100MHZ,1.6X0.8MM,TP,7MOHM
BN69-06487B BOX UNIT-01,SET,OUT;64PD550-GS,CB,C3,DW3
BN69-06488A BOX UNIT-IN;64PD550-GS NEW,CB,DW1,C1,L20
BN61-07042A BRACKET-PANEL;EGI-SECC PL,T1.2,NATURAL
BN61-07248A BN61-07248A BRACKET-PCB;SK5,T0.5,PLATING,HEAT TREATM
BN61-07308A BRACKET-STAND BOTTOM;HGI,T3,NATURAL
BN61-07067A BRACKET-STAND LINK;EGI-SECC,T2,NATURAL
BN61-07044A BRACKET-WALL;EGI-SECC PL,T1.6,NATURAL
2203-006048 C-CER,CHIP;100NF,10%,10V,X7R,TP,1005,T0.
2203-006158 C-CER,CHIP;100NF,10%,16V,X7R,TP,1005,T0.
2203-005249 C-CER,CHIP;100NF,10%,50V,X7R,TP,1608,55
2203-002285 C-CER,CHIP;10NF,10%,50V,X7R,TP,1005,55T
2203-007176 C-CER,CHIP;10UF,10%,16V,X5R,TP,2012,T1.2
2203-001851 C-CER,CHIP;16PF,5%,50V,C0G,TP,1608,55TO
2203-006348 C-CER,CHIP;1UF,10%,25V,X5R,TP,1608,T0.8,
2203-000491 C-CER,CHIP;2.2NF,10%,50V,X7R,TP,1608,55
2203-000575 C-CER,CHIP;220NF,10%,25V,X7R,TP,2012,55
2203-002398 C-CER,CHIP;22NF,10%,50V,X7R,TP,1608,55T
2203-006378 C-CER,CHIP;4.7UF,10%,6.3V,X5R,TP,1608,5
2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005,T0.5
2203-006513 C-CER,CHIP;47PF,5%,50V,C0G,TP,1005,55TO
2203-003039 C-CER,CHIP;8PF,0.25PF,50V,C0G,TP,1005,T0
3701-001746 CONNECTOR-DSUB;15P,3R,FEMALE,AU,31.30X19
3708-002909 CONNECTOR-FPC/FFC/PIC;82P,0.5MM,SMD-S,AU
3701-001762 3701-001762 CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5MM,BLK
3701-001591 3701-001591 CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5MM,NTR
3711-007585 CONNECTOR-HEADER;BOX,4P,1R,2.5MM,ANGLE,S
3711-007776 CONNECTOR-HEADER;BOX,8P,1R,1.25MM,SMD-A,
3707-001106 CONNECTOR-OPTICAL;STRAIGHT,SPDIF,2.5PI
BN63-07800A COVER-BOTTOM;PD550 58",HIPS,HB,BLACK
BN63-07796A COVER-FRONT;PD550 64,MABS(CLEAR)+PMMA/AB
BN63-07798A COVER-REAR;63PD550,CR,T0.45,BKN-P824
BN63-09624B COVER-STAND BOTTOM;PD550 59",GLASS,T8,W3
BN63-08125B COVER-STAND BOTTOM;PD550 59",GLASS,T8,W3
BN64-01673B COVER-STAND NECK;PD550 59",ABS,HB,DARK B
BN63-07783A COVER-TERMINAL;42PD490SO,ABS,BLACK(BK500
2801-004775 CRYSTAL-SMD;12MHZ,30PPM,16PF,30OHM,TP
2801-003948 CRYSTAL-SMD;12MHZ,30PPM,28-AAN,12PF,60OH
2801-003326 CRYSTAL-SMD;24MHZ,30PPM,28-ABX,20PF,50OH
2801-004734 CRYSTAL-SMD;25.000000MHZ,20PPM,28-AAN,12
BN69-05667A CUSHION-SET;PD550 64",EPS,16.7G/L,OVERSE
BN44-00445A DC VSS-POWER BOARD;PB6F,AC/DC,100-240V,5
0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200MA,SOT-23,
0407-000114 DIODE-SWITCHING;KDS184,80V,100MA,SOT-23,
0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO
0406-001271 DIODE-TVS;RCLAMP0524P,6V,1MAV,5A,TR
0403-001783 DIODE-ZENER;BZB84-C6V2,5.8~6.6V,300MW,SO
BN63-08595A FELT;FELT,T0.3,BLK,17, 565
0505-000110 FET-SILICON;2N7002,N,60V,0.115A,7.5OHM,0
2901-001648 FILTER-EMI AC LINE;250V,7.5A,UL, CSA, TU
2901-001658 FILTER-EMI SMD;5V,0.13A,0PF,2.0X1.0X0.5M
BN67-00327H FOOT-RUBBER;PE400,SI,GRAY,W14,L30,T2.5
BN67-00385C FOOT-RUBBER;SILICONE,GRAY,T10
BN96-18130F FPC;PDP 59 NORMAL,STRAIGHT,L93.6,82P
BN74-00031A GREASE;SMART F&S FLC-512,WHITE
BN61-06106B GUIDE-STAND NECK;58PC550,PETG,HB,TP0005,
BN61-07313A GUIDE-STAND NECK;PD550 59",PC+GF20%
BN61-07310A GUIDE-STAND NECK;PD550 59",PC+GF20%
BN61-07309A GUIDE-STAND NECK;PD550 59",PETG,V-2,TP00
BN61-07053A BN61-07053A GUIDE-STAND;PD550 58",PC+GF,V-2,BLACK
3711-007769 HEADER-BOARD TO CABLE;BOX,12P,1R,2MM,ANG
3711-007775 HEADER-BOARD TO CABLE;BOX,7P,1R,1.25MM,S
BP62-00017A HEAT SINK-ES;LED_KS8000,A6063,W26.2,L26.
AA61-20285C HOLDER-BOX;ALL,PP,BLACK,HB,HB,17.5G
BN65-00003A HOLDER-CABLE;42C7,LDPE,BLACK
BN65-00005A HOLDER-CABLE;55UD6500,PA66,BLACK
BN61-07441A HOLDER-CAP;PDP NORMAL,HIPS,BLACK,HB,PDP
BN61-07314A HOLDER-STAND SWIVEL;PD550 59",ACETAL
BN13-00042A IC ASIC;SDP1005,PARMA,404P,3.3V,25TO+85
1205-003201 IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2X2.3MM
1203-006619 IC-DC/DC CONVERTER;AOZ1033AI,SO-8,8,4.9X
1203-006684 IC-DC/DC CONVERTER;TPS54327DDAR,HSOP8,8,
1105-002191 IC-DDR2 SDRAM;W9725G6JB-18,DDR2 SDRAM,25
1105-002194 IC-DDR3 SDRAM;K4B1G1646G-BCH9,DDR3 SDRAM
1204-003240 IC-DECODER;SEMS20-LF,HSBGA,572P,20X20MM,
1103-001310 1103-001310 IC-EEPROM;2KBIT,256X8,SOIC,8Z30,5X4MM,2.
1103-001487 IC-EEPROM;AT24C256C-SSHL-T,256KBIT,32KX8
1205-003834 1205-003834 IC-ETHERNET CONTROLLER;RTL8201E-VC-GRT,Q
1006-001266 IC-LINE TRANSCEIVER;3232,TSSOP,16P,174MI
0903-001718 IC-MICROCONTROLLER;61P805-RG480WT,LQFP,4
1107-001990 IC-NAND FLASH;KFG1GN6W2D-HIB6,1GBIT,64MX
1203-006138 IC-POSI.ADJUST REG.;AP1117DGZ-13-89,TO-2
1203-006136 IC-POSI.FIXED REG.;AP1117D-18-GZ-13-89,T
1203-006135 IC-POSI.FIXED REG.;AP1117D-33-GZ-13-89,T
1203-006337 IC-POSI.FIXED REG.;G9091-330T11U,SOT-23-
1203-002898 IC-POSI.FIXED REG.;G950T45R,T0-252,3,6.5
1201-003153 IC-POWER AMP;NTP-7411S,MLF,48P,7X7MM,5,P
1205-003735 IC-SWITCH;AP2151WG-7,SOT25,5P,2.9X1.6MM,
1205-003733 IC-SWITCH;AP2191MPG-13,MSOP-8L-EP,8P,2.9
0904-002631 IC-USC;QFN,28P,5X6MM,12MHZ,TP,PLASTIC,5V
1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P,
1203-006017 IC-VOL. DETECTOR;RT9824GJ8,TSOT23,8P,2.9
2704-000029 INDUCTOR-SMD-ARRAY;5.6UH,2300MA,2,0.08OH
2703-000158 INDUCTOR-SMD;1UH,10%,0.4OHM,50MA,45,MULT
2703-003790 INDUCTOR-SMD;4.7UH,20%,8080,0.025OHM,450
BN64-01584D INLAY-TERMINAL;PD550,PS SHEET,T0.5,NORTH
BN64-01581D INLAY-TERMINAL;PD550,PS,T0.5,BLACK,NORTH
BN63-07761A INSULATOR-SMPS;58PD550,PC,NATURAL,L240,W
3722-003229 JACK-MODULAR;8P/8C,Y,STRAIGHT,NONE,AU,1P
3722-003226 JACK-PHONE;1P/7C,SN,BLK,STRAIGHT,3.6PI,1
3722-003227 JACK-PIN;10P,NI,BLU/GRN/RED/WHT,STRAIGHT
3722-003225 JACK-USB;4P/1C,AU,BLK,SMD-A,A,2.0,13.1X1
BN46-00110G KEY CODE-CERTIFICATION;HDCP1.X,TV,MSTAR
BN46-00109H KEY CODE-CERTIFICATION;MAC,TV/AV,GENERAL
AA68-03539A LABEL BAR CODE;65X40MM,ART PAPER
BN68-04746A LABEL ETC;ALL,PET,W25.4,L9.53,POLYESTER,
BN68-01648F LABEL WARNING;A/P 100G,T0.08,25MMX40MM,P
BN68-02422B LABEL WARNING;ALL,ART,T0.05,W240,L100,WH
BH68-00329D LABEL-BARCODE;ALL,LABEL-BARCODE,MOJO,W90
BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W
AA68-03540A LABEL-MICOM;ART,W7,L6
AA68-01018A LABEL-PQS;ART,W50,L13,WHITE
BP68-00052B LABEL-RATING;FPTV,WW,PE,T0.05,W93,L73
BN68-02775A LABEL-SMD;ALL MODEL,WW,PAPER,T0.08,W10,L
BN68-03616A LABEL-STICKER;59"/ 64", PANTONE 1535C,AR
BN68-03593G LABEL-STICKER;PD5C,ZA,T0.05,38,140,ENERG
AA68-03752B LABEL-STICKER;WW,ART,W25,L30,3DO SILK
BN68-03543A LABEL-TV-POP;D490,AMERICAN,PET,T0.1,100,
BN39-01285D BN39-01285D LEAD CONNECTOR-DIMMING;PN42C431,UL1007,1
BN39-01447B LEAD CONNECTOR-SUB ASSY;PS59D550,UL10368
BN68-03608A LEAFLET-04,STOP GUIDE;ALL,SAMSUNG,ENG/FR
AA68-03242L LEAFLET-REGULATORY GUIDE;HD/MFM,NORTH TO
BN68-04708A LEAFLET-STOP GUIDE;ALL,SAMSUNG,ENG,USA,W
BN68-02021A LEAFLET-WARRANTY;COMM,SAMSUNG,ENG/FRE,CA
BP68-00263E LEAFLET-WARRANTY;COMM,SAMSUNG,ENGLISH,US
BN68-03503D MANUAL FLYER-03,STAND GUIDE;P550(59 64),
BN68-03448F MANUAL USERS-03;PD550,SAMSUNG,ENG/SPA/FR
BN96-17107A BN96-17107A NETWORK-BLUETOOTH;WIBT20B,20.8,37,7.7
BN69-00391E PACKING ANGLE;ALL,PAPER,T5,W50,L1500,YEL
BN69-07221A PAD-CUSHION;EPE,90 MM,58 MM,CUSHION EPE
BN69-05528A PAD-SHEET;PAD COMM,CB,SW2,W100,L1828.8,Y
BN41-01590B PCB-MAIN;PDP D450/D490/D550 USA/ASIA/BRA
3903-000552 3903-000552 POWER CORD-DT;USA,NAME 5-15P,125V,10A,BL
2007-007463 R-CHIP;1.1KOHM,1%,1/16W,TP,1005
2007-008649 R-CHIP;220OHM,1%,1/16W,TP,1005
2007-000695 R-CHIP;3.3OHM,5%,1/10W,TP,1608
2007-001116 R-CHIP;680OHM,1%,1/10W,TP,1608
2007-001125 R-CHIP;68KOHM,1%,1/10W,TP,1608
2007-008015 R-CHIP;75OHM,1%,1/16W,TP,1005,T0.35
2007-001168 R-CHIP;75OHM,5%,1/4W,TP,3216
2011-001587 R-NETWORK;100OHM,5%,1/16W,L,CHIP,4P,TP,1
2011-001264 R-NETWORK;10OHM,5%,1/16W,L,CHIP,8P,TP,2.
2011-001449 R-NETWORK;22OHM,5%,1/16W,L,4P,TP,1.0X1.0
2011-001262 R-NETWORK;22OHM,5%,1/16W,L,CHIP,8P,TP,2.
2011-001261 R-NETWORK;33OHM,5%,1/16W,L,CHIP,8P,TP,2.
2011-000515 R-NETWORK;4.7KOHM,5%,1/16W,L,CHIP,8P,TP,
AA59-00482A AA59-00482A REMOCON;TM950,48,3V,NORTH AMERICA,550,56
BN73-00216A RUBBER-FOOT;LB650,RUBBER,1430,DARK GRAY
BN73-00182A RUBBER-FOOT;P750,CR RUBBER
BN46-00055A S/W MICOM;T-MST4AUSC-1019.0,2011.10.25,E
BN46-00039A S/W-E-MANUAL;PX5ATSCA-1021,2012.01.31,7
6001-002283 SCREW-MACHINE;BH,+,M3,L5,ZPC(WHT),SWRCH1
6001-002781 SCREW-MACHINE;BH,+,M3,L8,NI PLT,SWRCH18A
6001-002606 6001-002606 SCREW-MACHINE;PH,+,WSP,M3,L10,NI PLT,SWR
6003-001782 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
6003-001807 6003-001807 SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR
6003-000337 6003-000337 SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR
6003-001439 6003-001439 SCREW-TAPTYPE;BH,+,S,M4,L8,ZPC(WHT),SWRC
6003-001239 6003-001239 SCREW-TAPTYPE;FH,+,B,M4,L10,ZPC(WHT),SWR
6003-001374 6003-001374 SCREW-TAPTYPE;FH,+,B,M4,L12,NI PLT,SWRCH
BN63-04755D SHEET-COVER;PE,T0.05,W520MM,200M,600FE,C
0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3SN/0.
0202-001463 SOLDER-WIRE;LFC2-W3.0,D3,99.79SN/0.2CU/0
BN60-00288H SPACER-EVA;43PD490,EVA,L1430,T1.5,W5,EVA
BN60-00288J SPACER-EVA;43PD490,EVA,L210,T1.5,W5,EVA-
BN60-00288D SPACER-EVA;43PD490,EVA,L810,T1.5,W5,EVA-
BN60-00476A SPACER-FELT;ALL MODELS,FELT,L70,T0.5,W30
BN61-02429P STUD-PEM;M4,D8,L11,SUM24L,PRESS,ZPC(SIL)
BN61-02429S STUD-PEM;PD490,SUM24L,PRESS,ZPC(SIL),SUM
BN61-04731D TAPE-DOUBLE FACE;ACRYL,T1.1,W20,L30M,WHI
0203-001586 TAPE-FILAMENT;FILAMENT,#893,T0.12,W50,N/
0203-001602 TAPE-SINGLE FACE;OPP,#232,T0.14,W15,N/A,
BN74-00008D TAPE-SINGLE FACE;OPP,T0.05,W75,L800M,CLE
BN02-00102B TAPE-SINGLE FACE;OPP,T0.15,W25,L100M,WHI
0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150MW,SOT
BN40-00213A BN40-00213A TUNER-DTV AIR CABLE;DTVS20FVL083A,VSB HA
1405-001271 1405-001271 VARISTOR;35V,20VDC,5A,1005,TP,100V,10PF
Main Menu x
