Manufacturer
Samsung
Model Number
QN75QN800AFXZA
Description
75-inch Class Qn800a Neo Qled 8k Smart Tv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| BN81-08159Z | A/S PART SET-ELEC W/I;LED TV ELEC SPEC-C |
| BN81-20468C | A/S PART SET-MECH W/I;QAQN800B,Q75AB* |
| BN81-21246A | A/S-ASSY PCB-SOURCE(B-L);ASSY PCB-SOURCE |
| BN81-21247A | A/S-ASSY PCB-SOURCE(B-R);ASSY PCB-SOURCE |
| BN81-21244A | A/S-ASSY PCB-SOURCE(F-L);ASSY PCB-SOURCE |
| BN81-21245A | A/S-ASSY PCB-SOURCE(F-R);ASSY PCB-SOURCE |
| BN81-20624A | A/S-FPC;FPC,39TL200000002N,ST7461E03-1,S |
| BN81-20619A | A/S-IC DRIVER SOURCE;IC DRIVER SOURCE,33 |
| BN81-20625A | A/S-POLARIZER-C/F;POLARIZER-C/F,313070Q3 |
| BN81-20626A | A/S-POLARIZER-TFT;POLARIZER-TFT,313070GD |
| 0201-003279 | ADHESIVE-AA;UPUV,CLEAR |
| 0201-003555 | ADHESIVE-SILICON;A,CLEAR |
| 0201-003554 | ADHESIVE-SILICON;B,CLEAR |
| 0201-003543 | ADHESIVE-STR;FH7028,GREEN,30,000~60,000M |
| 0201-003164 | ADHESIVE-UV;190024,CLEAR,UV, ACRYLIC |
| BN96-53533K | ASSY ACCESSORY MANUAL CABLE;QAQN800B |
| BN96-49314B | ASSY ACCESSORY-SCREW;65QAQN900A,ALL,W/W, |
| BN92-30052G | ASSY ACCESSORY;QAQN800B |
| BN90-12007L | ASSY BACK LIGHT UNIT;QAQ800B |
| BN92-30048W | ASSY BOX;QAQN800B |
| BN96-52765A | ASSY CHASSIS FRONT P;75QAQN800B,STS304 |
| BN96-52769B | ASSY CHASSIS REAR P;75QAQN800B,EGI-SECC |
| BN91-23486H | ASSY CHASSIS;QAQN700C |
| BN96-53240B | ASSY COVER P-OC BOTTOM;75QAQN900A,PC,V-0 |
| BN96-53264A | ASSY COVER P-OC CABLE;65QAQN900A,PC+ABS, |
| BN96-53239A | ASSY COVER P-OC TOP;65QAQ900A,PC+ABS,V-0 |
| BN96-53294A | ASSY COVER P-REAR;75QAQN800B,PC+GF30%,V- |
| BN90-12120L | ASSY COVER REAR;QAQN800B |
| BN97-18254A | ASSY DRM;OSCAR-P OC,ATSC3.0(US),NAGSAM, |
| BN96-52760A | ASSY FRAME P-MIDDLE BOTTOM;75QAQN800B,PC |
| BN96-52767A | ASSY FRAME P-MIDDLE LEFT RIGHT;75QAQN800 |
| BN96-52766A | ASSY FRAME P-MIDDLE TOP;75QAQN800B,PC+GF |
| BN96-53284C | ASSY HOLDER P-OC CABLE;65QAQN900A,ABS,TP |
| BN96-53283A | ASSY HOLDER P-RING;65QAQN900A,ABS,BK0007 |
| BN92-30047Y | ASSY LABEL;QAQN800B |
| BN95-07340A | ASSY LED BAR-75Q800A LED PLATE;Q800A,N/A |
| BN97-18962A | ASSY MICOM;75S1ZE0TA,75Q800A DRAG IMPROV |
| BN97-18304A | ASSY MICOM;INV4799,QAQN800B,1107-002226( |
| BN97-18303A | ASSY MICOM;OSPMICOM_OCJP,QAQN800B,1107-0 |
| BN97-18259A | ASSY MICOM;OSPMICOM_OCTV,QAQN800B,1107-0 |
| BN97-18201A | ASSY MICOM;Q900A,Q800A,1107-002566,BN94- |
| BN97-18261A | ASSY MICOM;T-OCPAKUC,ASSY MICOM_MAIN,QAQ |
| BN91-23243B | ASSY ONE CONNECT;QAQN800B |
| BN91-23123C | ASSY OPEN CELL-DECORATION;BN63-18505B,Y2 |
| BN92-30050B | ASSY P/MATERIAL;QAQN800B |
| BN96-53876A | ASSY PACKING P-CUSHION SET;75QAQN800B,EP |
| BN96-51422U | ASSY PACKING P-CUSHION SET;Y20 |
| BN94-17514U | ASSY PCB MAIN;QAQN800B |
| BN94-16862B | ASSY PCB OC;QAQN900A |
| BN91-23235G | ASSY SHIELD;QAQN800B |
| BN97-18060A | ASSY SMD BIN-Q800 75;Q800 75,QT,SAMEX, S |
| BN97-18554B | ASSY SMD BOTTOM;QAQN800B |
| BN97-19543A | ASSY SMD TOP;QAQN800B |
| BN97-18200A | ASSY SMD;Q900A,Q800A,21Y_AM_LED_FPGA,4L, |
| BN97-18200F | ASSY SMD;QAQN900A |
|
|
ASSY SPEAKER P-FRONT;TV-SPK,75QAQ800B,4. |
| BN96-53205A | ASSY STAND P-COVER NECK;75QAQN900A,HGI,N |
| BN96-53203C | ASSY STAND P-COVER TOP;75QAQN800B,HGI,NA |
| BN96-53200A | ASSY STAND P-GUIDE;65QAQN900A,PP+GF40%,B |
| BN90-12116B | ASSY STAND;QAQN800B |
| BN90-12115L | ASSY W/I;QAQN800B |
| 6902-003542 | BAG ACCESSORY;HDPE/PE FOAM,T0.015/T0.5,W |
| 6902-003557 | BAG ACCESSORY;LDPE,T0.06,W180,L240,TRP,R |
| 6902-003616 | BAG ACCESSORY;LDPE,T0.06,W450,L450,TRP,R |
| 6902-003541 | BAG ACCESSORY;LDPE,T0.07,W400,L500,TRP,R |
| 6902-003503 | BAG ACCESSORY;LDPE,T0.07,W480,L300,TRP,R |
| 6902-003511 | BAG PE;HDPE/PE FOAM,T0.015/T0.5,W120,L40 |
| 6902-003626 | BAG SCREW;LDPE,T0.06,W60,L80,TRP,RECYCLE |
| 6902-003049 | BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,RECYCL |
| 6922-000421 | BAND;PP,T0.8,W18,L2300,TRP,RECYCLED PIR_ |
| 6922-000001 | BAND;PP,T0.8,W18,YEL,RECYCLED PIR_50% |
|
|
BEAD-SMD;26OHM/100MHZ,1.6X0.8MM,TP,7MOHM |
| BN69-22163B | BOX UNIT-IN;75QAQN800B,CB,DW1,C1,L2194,W |
| BN69-22162A | BOX UNIT-OUT;75QAQ800B,CB,DW4,F3,L1857,W |
| BN61-16777A | BRACKET-PUSH PIN GUIDE;65QTQ950SA,SK5,T0 |
| BN61-17656A | BRACKET-STAND LINK;65QAQN900A,SUM24L,BLA |
| BN61-17543A | BRACKET-STAND NECK LEFT;65QAQN900A,HGI,T |
| BN61-17540A | BRACKET-STAND NECK RIGHT;65QAQN900A,HGI, |
| BN61-17539A | BRACKET-STAND NECK;75QAQN900A,HGI,T4,NAT |
| BN61-17284A | BRACKET-WALL;65QAQN900A,CR-SPCC,BLACK,M8 |
| BN61-15737B | BRACKET-WALL;65QAQN900A,CR-SPCC,T1,BLACK |
| BN61-13557Z | BRACKET-WIRE;27ST77Q,SW-C,T1,SILVER,L162 |
| BN61-13557X | BRACKET-WIRE;65UNU7100X,SW-C,T1,SILVER,L |
| BN61-13557P | BRACKET-WIRE;75QNQ8CB,SW-C,T1,SILVER,L66 |
| 2203-006048 | C-CER,CHIP;100NF,10%,10V,X7R,TP,1005,T0. |
| 2203-006158 | C-CER,CHIP;100NF,10%,16V,X7R,TP,1005,T0. |
| 2203-002711 | C-CER,CHIP;100NF,10%,25V,X7R,TP,1608,55 |
| 2203-007544 | C-CER,CHIP;100NF,10%,50V,X7R,TP,1005,T0. |
| 2203-006005 | C-CER,CHIP;10NF,10%,100V,X7R,TP,1608,55 |
| 2203-002285 | C-CER,CHIP;10NF,10%,50V,X7R,TP,1005,55T |
| 2203-007176 | C-CER,CHIP;10UF,10%,16V,X5R,TP,2012,T1.2 |
| 2203-007306 | C-CER,CHIP;10UF,10%,25V,X5R,TP,2012,T1.2 |
| 2203-007423 | C-CER,CHIP;10UF,10%,35V,X7R,TP,3216,55T |
| 2203-007456 | C-CER,CHIP;1UF,10%,25V,X5R,TP,1005,T0.5, |
| 2203-006348 | C-CER,CHIP;1UF,10%,25V,X5R,TP,1608,T0.8, |
| 2203-006698 | C-CER,CHIP;1UF,10%,25V,X7R,TP,1608,T0.8, |
| 2203-007486 | C-CER,CHIP;1UF,10%,50V,X5R,TP,1608,55TO |
| 2203-006460 | C-CER,CHIP;2.2UF,10%,16V,X5R,TP,1608,55 |
| 2203-008096 | C-CER,CHIP;2.2UF,10%,50V,X5R,TP,2012,T1. |
| 2203-005083 | C-CER,CHIP;220NF,10%,50V,X7R,TP,1608,T0. |
| 2203-000627 | C-CER,CHIP;22PF,5%,50V,C0G,TP,1005,T0.5, |
| 2203-008315 | C-CER,CHIP;22UF,20%,25V,X5R,TP,2012,T1.2 |
| 2203-008412 | C-CER,CHIP;4.7UF,10%,50V,X5R,TP,2012,T1. |
| 2203-006378 | C-CER,CHIP;4.7UF,10%,6.3V,X5R,TP,1608,5 |
| 2203-006844 | C-CER,CHIP;470NF,10%,10V,X5R,TP,1005,55 |
| 2203-006741 | C-CER,CHIP;470NF,10%,25V,X5R,TP,1608,T0. |
| 2203-001428 | C-CER,CHIP;470NF,10%,50V,X7R,TP,2012,55 |
| 2203-006126 | C-CER,CHIP;47NF,10%,16V,X7R,TP,1005,T0.5 |
| 2409-001213 | C-ORGANIC,SMD;150UF,20%,6.3V,TP,3.5X2.8X |
| 2409-001240 | C-ORGANIC,SMD;33UF,20%,25V,LR,TP,7343 |
| BN64-04545A | CHASSIS-FRONT;75QAQN800B,STS304,T0.8,STA |
| BN64-04557A | CHASSIS-REAR;75QAQN900A,EGI-SECC,T1,NATU |
|
|
CONNECTOR-FPC/FFC/PIC;51P,0.5MM,SMD-A,AU |
|
|
CONNECTOR-FPC/FFC/PIC;96P,0.5MM,SMD-A,AU |
|
|
CONNECTOR-FPC/FFC/PIC;TP,SMD-A,24P,0.5MM |
| 3708-003356 | CONNECTOR-FPC/FFC/PIC;TP,SMD-A,30P,0.5MM |
| 3708-003176 | CONNECTOR-FPC/FFC/PIC;TP,SMD-A,68P,0.5MM |
| 3701-002024 | CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5MM,BLK |
| 3711-009538 | CONNECTOR-HEADER;BOX,16P,2R,2MM,ANGLE,SN |
| 3707-001143 | CONNECTOR-OPTICAL;ANGLE,SPDIF,WAVELESS,2 |
| 3710-004473 | CONNECTOR-SOCKET;34P,2R,0.8MM,SMD-A,AU,B |
| 3710-004474 | CONNECTOR-SOCKET;35P,1R,0.8MM,SMD-A,AU,B |
| BN63-18505B | COVER-DECORATION;75QAQN800B,STS430J1L,T0 |
| BN63-19359B | COVER-OC BOTTOM;65QAQN900A,PC,V-0,TP0116 |
| BN63-19365A | COVER-OC CABLE;65QAQN900A,PC+ABS,V-0,BK0 |
| BN63-19358A | COVER-OC TOP;65QAQN900A,PC+ABS,V-0,BK000 |
| BN63-19362A | COVER-REAR;75QAQN800B,PC+GF30%,T0.8,V-0, |
| BN63-19325A | COVER-STAND NECK FRONT;65QAQN900A,ABS,T3 |
| BN63-19323A | COVER-STAND NECK REAR;65QAQN900A,ABS,T3, |
| BN63-19326B | COVER-STAND TOP;75QAQN800B,HGI,T5,NATURA |
| 2801-000102 | CRYSTAL-SMD;12MHZ,30PPM,12PF,100OHM,TP |
| 2801-005372 | CRYSTAL-SMD;24.576MHZ,20PPM,HCX-3SB,12PF |
| 2801-004938 | CRYSTAL-SMD;24MHZ,20PPM,12PF,60OHM,20PPM |
| 2801-004678 | CRYSTAL-SMD;25MHZ,30PPM,18PF,25OHM,TP |
| 2801-005504 | CRYSTAL-SMD;26MHZ,7PPM,SMD,11.1PF,30OHM, |
| BN63-19070A | CUSHION RUBBER;Q950ST,SI,T5,W10,L25,LIGH |
| BN69-21867A | CUSHION-SET SIDE;75QAQN800B,EPS,16.7G/L, |
| BN69-21866A | CUSHION-SET;75QAQN800B,EPS,16.7G/L,WHITE |
| BN44-01130A | DC VSS-DRIVER BOARD;L75SB9NB_AHS,DC/DC,1 |
| BN44-01127A | DC VSS-POWER BOARD;P65SB9N_AHS,AC/DC,480 |
| BN61-17835A | DIFFUSER PLATE;21Y_Q800A_75INCH_DP,PMMA, |
| 0404-001953 | DIODE-SCHOTTKY;MBRA340F-HAF,40V,3000MA,S |
| 0404-001640 | DIODE-SCHOTTKY;SS1060HEWS,60V,1000MA,SOD |
| 0404-001881 | DIODE-SCHOTTKY;SS3040-HE,40V,3000MA,SOD- |
| 0404-001976 | DIODE-SCHOTTKY;SV540,40V,5000MA,TO-277,T |
| 0401-001056 | DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO |
| 0406-001886 | DIODE-TVS;AZ1123-04F,5V,DFN2510,65W,TR |
| 0406-001823 | DIODE-TVS;PJUSB208,85V,0.1MAV,0.715VPA,2 |
| 0406-001778 | DIODE-TVS;PUSB3FR4,6V,9V,0.2MAV,0.7VPA,0 |
| 0406-001438 | DIODE-TVS;SMCJ14A,15.6V,17.2V,1MAV,6.5VP |
| 0406-001718 | DIODE-TVS;SMF36A,40V,44.2V,3.8MAV,1.25VP |
| 0406-001635 | DIODE-TVS;SMF5.0A,6.4V,6.7V,7V,200MAV,20 |
| 0403-001783 | DIODE-ZENER;BZB84-C6V2,5.8~6.6V,300MW,SO |
| 0403-002014 | DIODE-ZENER;KDZ16B,16.2~18.3V,1000MW,SOD |
| 0403-000489 | DIODE-ZENER;MMSZ5228B,3.705~4.095V,500MW |
| 0403-001779 | DIODE-ZENER;MMSZ5234BT1G,5.89~6.51V,500M |
| 0403-001797 | DIODE-ZENER;NZH3V0B,2.85~3.15V,500MW,SOD |
| 0403-001785 | DIODE-ZENER;NZH5V1B,5.1V,4.94/5.2V,500MW |
| 0505-003397 | FET-SILICON;2N7002K,N,60V,0.38A,1.19OHM, |
| 0505-001089 | FET-SILICON;AO3409L,P,30V,2.6A,0.097/0 |
| 0505-002893 | FET-SILICON;AO4801AS,P,30V,5A,2W,SOIC-8 |
| 0505-003755 | FET-SILICON;AOD2910E,N,100V,37A,23MOHM,7 |
| 0505-003752 | FET-SILICON;AONR21321,P,30V,50A,0.035OHM |
| 0505-002598 | FET-SILICON;AP2317GN,P,20V,4.2A,0.052OH |
| 0505-002660 | FET-SILICON;SI2308BDS,N,60V,2.3A,0.156OH |
|
|
FFC;65QN800A, 75QN800A,WRINKLE,L170,96P, |
| BN96-52822A | FFC;75Q900A,STRAIGHT,L170,68P, |
| BN96-53513A | FFC;8K-75" #8,FOLD,L1000,51P |
| BN96-53512A | FFC;8K-75"#6,FOLD,L860,51P |
| BN96-53467A | FFC;8K-75#1,FOLD,L800,51P,EMI SHIELD |
| BN96-53474A | FFC;8K-75#10,FOLD,L820,51P,EMI SHIELD |
| BN96-53468A | FFC;8K-75#2,FOLD,L510,51P,EMI SHIELD |
| BN96-53470A | FFC;8K-75#3,FOLD,L300,51P,EMI SHIELD |
| BN96-53469A | FFC;8K-75#4,FOLD,L470,51P,EMI SHIELD |
| BN96-53472A | FFC;8K-75#5,FOLD,L760,51P,EMI SHIELD |
| BN96-53471A | FFC;8K-75#7,FOLD,L570,51P,EMI SHIELD |
| BN96-53473A | FFC;8K-75#9,FOLD,L540,51P,EMI SHIELD |
| BN96-53320A | FFC;QN900A/800A,FOLD,L260,24P |
|
|
FFC;QN900A/800A,FOLD,L300,68P,BLACK FFC |
| BN96-53274A | FFC;QN900A/800A,FOLD,L440,68P |
| BN96-53377A | FFC;QN900A/800A,FOLD,L950,30P |
| BN67-00459A | FOOT-RUBBER;STAND,RUBBER,GRAY,T2 |
| BN61-17686A | FRAME-CHASSIS REAR BOTTOM;75QAQN800B,PC+ |
| BN61-17688A | FRAME-CHASSIS REAR LEFT RIGHT;75QAQN800B |
| BN61-17685A | FRAME-CHASSIS REAR TOP;75QAQN800B,PC+GF1 |
| BN61-17689A | FRAME-MIDDLE BOTTOM;75QAQN800B,PC+GF10%, |
| BN61-17690A | FRAME-MIDDLE LEFT RIGHT;75QAQN800B,PC+GF |
| BN61-17687A | FRAME-MIDDLE TOP;75QAQN800B,PC+GF10%,V-2 |
| BN61-17610B | FRAME-REAR BOTTOM;75QAQN800B,PC+GF10%,V- |
| BN61-17619A | FRAME-REAR CENTER LEFT;75QAQN900A,PC+GF1 |
| BN61-17627A | FRAME-REAR CENTER RIGHT;75QAQN900A,PC+GF |
| BN61-17613B | FRAME-REAR LEFT;75QAQN800B,PC+GF10%,V-2, |
| BN61-17623A | FRAME-REAR MIDDLE LEFT;75QAQN900A,PC+GF1 |
| BN61-17629A | FRAME-REAR MIDDLE RIGHT;75QAQN900A,PC+GF |
| BN61-17631A | FRAME-REAR OC;65QAQN900A,PC+GF10%,V-2,BK |
| BN61-17617B | FRAME-REAR RIGHT;75QAQN800B,PC+GF10%,V-2 |
| BN61-17608B | FRAME-REAR TOP;75QAQN800B,PC+GF10%,V-2,B |
|
|
FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,HI |
| BN63-00044A | GASKET-EMI;1503FP,FABRIC,T19,W11,L35,GRA |
| AA63-01413S | GASKET-EMI;42Q7,FABRIC,T2,W10,L135,GRAY |
| BN63-00520A | GASKET-EMI;APPOLO_PAL,FABRIC,T0.13,W10,L |
| 6302-001232 | GASKET-EMI;SMT GASKET,FABRIC,T3.5,W4,L3, |
| BN63-02996A | GASKET-TAPE;EMI SHIELDING,FABRIC,T0.13,W |
| BN61-17542A | GUIDE-STAND;65QAQN900A,PP+GF40%,HB,BK002 |
| 3711-009653 | HEADER-BOARD TO CABLE;TP,STRAIGHT,2R,24P |
| BN62-00927A | HEAT SINK-HEAT PIPE MODULE;QN900A/800A,A |
| BN62-00928A | HEAT SINK-PS;QN900A/800A,AL,W100,L110,BL |
| BN61-17814A | HOLDER-BOLT;65QAQN900A,SWRCH18A,BLACK,FH |
| BN61-14713B | HOLDER-COVER;65QAQN900A,SI,BLACK,HS80-> |
| BN61-16910A | HOLDER-OC CABLE JACK;65QTQ950SA,PA66,BLA |
| BN61-17632A | HOLDER-OC CABLE;65QAQN900A,ABS,BK0007,HB |
| BN61-17730A | HOLDER-SOURCE PCB;65QAQN800B,PC+GF10%,WT |
| BN61-17537A | HOLDER-STAND CABLE;65QAQN900A,ABS,T3,BK0 |
| BN61-17813A | HOLDER-WALL RING;65QAQN900A,ABS,BK0007,H |
| 1001-002118 | IC-ANALOG MULTIPLEX;TMUX1308QDYYRQ1,16P, |
| 1001-001545 | IC-ANALOG MULTIPLEX;TS3USB221ERSER,R-PQF |
| 1201-004306 | IC-AUDIO AMP;SN005826M,TP,9.7X4.4X1.2MM, |
| 0801-003580 | IC-CMOS LOGIC;TC7WB66CFK,SSOP,8P,2.0X2.3 |
| 1203-009652 | IC-DC/DC CONVERTER;MP8795HGLE-Z,21P,QFN- |
| 1203-009194 | IC-DC/DC CONVERTER;SYD104IADC,TSOT23-6,6 |
| 1203-009312 | IC-DC/DC CONVERTER;SYD105I,TSOT23-6,6P,2 |
| 1203-009193 | IC-DC/DC CONVERTER;SYD113IADC,TSOT23-6,6 |
| 1203-009367 | IC-DC/DC CONVERTER;TPS566235,VQFN,13P,3X |
| 1203-009377 | IC-DC/DC CONVERTER;TPS56C230,VQFN,20P,3X |
| 1203-009063 | IC-DC/DC CONVERTER;VPM2SM,QFN,56P,7X7X0. |
| 1203-009494 | IC-DC/DC CONVERTER;VPMS3SM,72P,QFN,TP,8X |
| 1105-003132 | IC-DDR4 SDRAM;K4F2E3S4HA-MGCL,WFBGA,200P |
| 1105-003131 | IC-DDR4 SDRAM;K4F8E3S4HD-MGCL,FBGA,200P, |
| 1204-003821 | IC-DECODER;QUANTUM PROCESSOR 8K III,TR,3 |
| 1204-003778 | IC-DECODER;SDP1805S,FCBGA,490P,21X21X1.5 |
| 1204-003822 | IC-DECODER;SDP20813,TR,27X27X1.78MM,10T |
| 1006-001595 | IC-DRIVER/RECEIVER;UT3221G-P16-R,TSSOP-1 |
| 1103-001584 | IC-EEPROM;M24512-DFMN6TP,512KBIT,64K X 8 |
| 1107-002590 | IC-EMMC;KLM8G1GETF-B041007,8GBYTE,64GBX1 |
| 1301-002295 | IC-FPGA;XC7S50-1FTGB196C,BGA,196P,TP,15X |
| 1003-003203 | IC-LED DRIVER;SDP20822,18P,WLP,TP,1.863X |
| 1003-003204 | IC-LED DRIVER;SDP20823,128P,LQFP,TP,16.0 |
| 1003-003207 | IC-LEVEL DRIVER;TPS2490DGSR,TP,5.0X3.0X1 |
| 1107-002587 | IC-NOR FLASH;EN25QH16B,16MBIT,SOP,8P,2.7 |
| 1107-002547 | IC-NOR FLASH;W25Q16JVSSIQ,SOP,8P,TR,7.90 |
| 1107-002566 | IC-NOR FLASH;W25Q32JVSSIQ,32MBIT,16384X2 |
| 1107-002226 | IC-NOR FLASH;W25Q40CLSSIP,4MBIT,SOIC,8P, |
| 1203-009186 | IC-POSI.ADJUST REG.;TLV759P01PDRVR,TP,6P |
| 1203-009504 | IC-POSI.FIXED REG.;RT9058-50GVL,3P,SOT-2 |
| 1205-005519 | IC-SWITCH;ET20163,SOT23-5,5P,2.95X3.02MM |
| 1205-005749 | IC-SWITCH;G2897KD1U,TDFN2X3-14,14P,2X3MM |
| 0904-002882 | IC-USC;GL852G-OHY38,QFN,28P,5X5MM,12MHZ, |
| 1001-002117 | IC-VIDEO SWITCH;AD55/066Z-0RL,QFN,108P,T |
| 1203-009188 | IC-VOL. DETECTOR;G623F11U,TP,8P,4.9X6X1. |
| 1203-006288 | IC-VOL. DETECTOR;RT9818B-18GV,SOT-23-3,3 |
| 2703-005782 | INDUCTOR-SMD;1.5UH,20%,6060,T2.8,0.017OH |
| 2703-005191 | INDUCTOR-SMD;1.5UH,20%,6060,T4.5,0.02OHM |
| 2703-005780 | INDUCTOR-SMD;10UH,20%,2012,T1.25,0.91OHM |
| 2703-003862 | INDUCTOR-SMD;10UH,20%,6060,0.065OHM,1900 |
| 2703-003488 | INDUCTOR-SMD;10UH,20%,6965,T2.8,0.071OHM |
| 2703-003937 | INDUCTOR-SMD;1UH,20%,70647,T3,0.008OHM,9 |
| 2703-005783 | INDUCTOR-SMD;2.2UH,20%,6060,T2.8,0.026OH |
| 2703-005193 | INDUCTOR-SMD;2.2UH,20%,6060,T4.5,0.024OH |
| 2703-003747 | INDUCTOR-SMD;22UH,20%,6060,0.135OHM,1300 |
| 2703-003637 | INDUCTOR-SMD;22UH,20%,7070,0.18OHM,2000M |
| 2703-005786 | INDUCTOR-SMD;3.3UH,20%,6060,T2.6,0.033OH |
| 2703-005194 | INDUCTOR-SMD;3.3UH,20%,6060,T4.5,0.03OHM |
| 2703-003930 | INDUCTOR-SMD;4.7UH,20%,0.072OHM,2450MA,W |
| 2703-004226 | INDUCTOR-SMD;8.2UH,20%,10.7X10MM,T3.8,0. |
| BN64-04592A | INLAY-TERMINAL SIDE;65QAQN900A,PET,T0.12 |
| BN63-19563A | INSULATOR-LD;Q900/800A,PC,BLACK,L354,W30 |
| BN63-19842A | INSULATOR-LED PCB;Q700A,OPP,WHITE,L696.4 |
| BN63-19556A | INSULATOR-LED PCB;Q700A,OPP,WHITE,L944.5 |
| BN63-19498A | INSULATOR-SMPS;65QAQ900A,PC,BLACK,L230.5 |
| BN63-19435A | INSULATOR-SMPS;65QAQ900A,PC,BLACK,L313.3 |
| BN63-19561A | INSULATOR-SMPS;Q900/800A,PC,BLACK,L224,W |
| BN63-19562A | INSULATOR-SMPS;Q900/800A,PC,BLACK,L288,W |
| BN63-19690A | INSULATOR-SOURCE PCB;PET,BLACK,L819.62,W |
| 3722-003199 | JACK-MODULAR;8P/8C,Y,ANGLE,NONE,AU,1PORT |
| 3722-003216 | JACK-PHONE;1P/7C,AU,BLK,SMD-A,3.6PI,10.2 |
|
|
JACK-USB;4P/1C,NI,BLK,ANGLE,A,2.0,13.1X1 |
| 3722-003524 | JACK-USB;4P/2C,AU/NI,BLK,ANGLE,A,2.0,15. |
| BN46-00109H | KEY CODE-CERTIFICATION;MAC,TV/AV,GENERAL |
| BN46-00110P | KEY CODE-CERTIFICATION;MIRACAST(HDCP2.2) |
| BN46-01525A | KEY CODE;Y21_OSCAR-P,NAGRA CSC DATA,T-OS |
| BN46-01524A | KEY CODE;Y21_OSCAR-P,Y21_WIDEVINE DATA,Y |
| BH68-00697A | LABEL BOX;ALL,ART,W60,L100,WHT,NO SILK,9 |
| BN68-09258B | LABEL ETC;ALL MODEL,PET,T0.05,W40,L40,YW |
| BN68-04746A | LABEL ETC;ALL,PET,W25.4,L9.53,POLYESTER, |
| BN68-05595A | LABEL ETC;UF6P,ART,T0.08,W80,L23,WHITE,W |
| BN68-02422B | LABEL WARNING;ALL,ART,T0.05,W240,L100,WH |
| BN68-00513A | LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W |
| BN68-08730A | LABEL-E PASS;QTV,WW,ART,T0.161,W60,L15,P |
| BN68-12098A | LABEL-ENERGY;QN75QN800AFXZA,ZA,PET,T0.1, |
| BN68-07104D | LABEL-RATING;ALL,WW,PP,T0.1,W90,L50,DARK |
| BN68-10927A | LABEL-RATING;QTQ950SA,WW,PP,T0.3,W150,L4 |
| BN68-08112A | LABEL-SECURITY;ALL,PET,T0.05,W55,L52,GLO |
| BN68-00970A | LABEL-SECURITY;ALL,PET,T0.05,W60,L60,SEA |
| BN68-07835Q | LABEL-STICKER LICENSE;65QNQ8CB,PET,T0.12 |
| BN68-05381A | LABEL-STICKER;UF6P,ART,T0.08,W20,L50,WHI |
| BN39-02706A | LEAD CONNECTOR-POWER;QN900A/QN800A/QN95A |
| BN68-12979A | LEAFLET-PROMOTION;Y21 SOUNDBAR (Q SERIES |
| BN68-12591A | LEAFLET-QUICK SETUP GUIDE;8K(QN700A/800A |
| BN68-09371B | LEAFLET-REGULATORY GUIDE;QT/UT,W/W,MOJO, |
| BN68-11568A | LEAFLET-REMOTE CONTROL;QLED, LS03,ZA,MOJ |
| BN68-10628A | LEAFLET-WARRANTY;QT/UT,ZA,MOJO,1 COLOR,1 |
| 0601-003915 | LED-BIN;SMD(TOP VIEW),BLU,WATER DIFF.,0X |
|
|
LED-IR;SMD ANGLE TYPE,1.4MM,200MW,5V,940 |
| BN61-17136C | MAGNET FERRITE;65QAQN900A,FERRITE,T0.5,W |
| BN68-12039A | MANUAL USERS;Q900A Q800A Q850A,ZA,NORTH |
|
|
NETWORK-WLAN CLIENT;WCA943M,85.63X34.14X |
|
|
ONECONNECT CABLE;QAQN800B,35P/34P,L2500, |
|
|
ONECONNECT CABLE;QAQN800B,35P/34P,L300,U |
| BN61-17838A | OPTICAL SHEET-COMPLEX;21Y_Q800A_75INCH_C |
| BN61-17828A | OPTICAL SHEET-HIGH COLOR;21Y_Q85A_75INCH |
| BN61-17832A | OPTICAL SHEET-REFLECTOR;21Y_Q900A_75INCH |
| 2804-001595 | OSCILLATOR-CLOCK;27MHZ,50PPM,10TTL,15PF, |
| BN69-22747A | PACKING ANGLE;75QAQN800B,PAPER,T5,W50,L1 |
| BN69-17053P | PACKING ANGLE;ALL,PAPER,T3,W2200,L50,YEL |
| BN62-00935B | PAD GAP-THERMAL;QN900/800/700/95A,SI,T9, |
| BN62-00932A | PAD GAP-THERMAL;QN900A/800A,SI,T1,L100,H |
| BN62-00931A | PAD GAP-THERMAL;QN900A/800A/95A,SI,T3,L4 |
|
|
PAD GAP-THERMAL;UE32B6000VWXXC,T3,L35,H3 |
| BN69-22217A | PAD-AIR CUSHION;65QAQS900A,LDPE,T5,W370, |
| BN41-02851A | PCB-FPGA;AM_LED_FPGA,FR-4,4L,T1.2,1,COLO |
| BN41-02825A | PCB-LED MODULE;75,FR-4,2L,T0.6,1,327.28M |
| BN41-02854C | PCB-MAIN;21Y Q800A/900A,FR-4,6L,T1.2,1,2 |
| BN41-02863A | PCB-OC;Q900A,FR-4,4L,T1.2,2,21Y OCL,313X |
|
|
POWER CORD-DT;USA,3P-F,125V,10A,BLK,L150 |
| BN95-07315G | PRODUCT LCD-CSOT;CY-TA075JMHV3H/V,QAQN80 |
| 2007-008596 | R-CHIP;0.1OHM,1%,1/4W,TP,3216 |
| 2007-000039 | R-CHIP;0OHM,1%,1/10W,TP,1608 |
| 2007-008779 | R-CHIP;0OHM,5%,1/16W,TP,1005,T0.35,GENER |
| 2007-000219 | R-CHIP;1.2KOHM,1%,1/10W,TP,1608 |
| 2007-009322 | R-CHIP;1.3KOHM,1%,1/16W,TP,1005 |
| 2007-000287 | R-CHIP;100OHM,1%,1/10W,TP,1608 |
| 2007-000052 | R-CHIP;10KOHM,1%,1/10W,TP,1608 |
| 2007-002899 | R-CHIP;10OHM,1%,1/10W,TP,1608 |
| 2007-008167 | R-CHIP;120KOHM,1%,1/16W,TP,1005,T0.35 |
| 2007-000063 | R-CHIP;150KOHM,1%,1/10W,TP,1608 |
| 2007-000043 | R-CHIP;1KOHM,1%,1/10W,TP,1608 |
| 2007-000078 | R-CHIP;1KOHM,5%,1/10W,TP,1608 |
| 2007-007992 | R-CHIP;1OHM,1%,1/10W,TP,1608 |
| 2007-008661 | R-CHIP;2.1KOHM,1%,1/10W,TP,1608 |
| 2007-000501 | R-CHIP;2.2OHM,1%,1/10W,TP,1608 |
| 2007-002906 | R-CHIP;200KOHM,1%,1/10W,TP,1608 |
| 2007-007767 | R-CHIP;200OHM,1%,1/16W,TP,1005 |
| 2007-000066 | R-CHIP;20KOHM,1%,1/10W,TP,1608 |
| 2007-007520 | R-CHIP;20OHM,1%,1/10W,TP,1608 |
| 2007-000633 | R-CHIP;270KOHM,1%,1/10W,TP,1608 |
| 2007-000779 | R-CHIP;33OHM,1%,1/10W,TP,1608 |
| 2007-008294 | R-CHIP;33OHM,1%,1/16W,TP,1005,T0.35 |
| 2007-000857 | R-CHIP;4.3KOHM,1%,1/10W,TP,1608 |
| 2007-000979 | R-CHIP;5.6KOHM,1%,1/10W,TP,1608 |
| 2007-007736 | R-CHIP;510KOHM,1%,1/10W,TP,1608 |
| 2007-001007 | R-CHIP;51KOHM,1%,1/10W,TP,1608 |
| 2007-008269 | R-CHIP;51KOHM,1%,1/16W,TP,1005,T0.35 |
| 2007-007721 | R-CHIP;560OHM,1%,1/10W,TP,1608 |
| 2007-001058 | R-CHIP;6.2OHM,1%,1/10W,TP,1608 |
| 2007-001116 | R-CHIP;680OHM,1%,1/10W,TP,1608 |
| 2007-001125 | R-CHIP;68KOHM,1%,1/10W,TP,1608 |
| 2007-008015 | R-CHIP;75OHM,1%,1/16W,TP,1005,T0.35 |
| 2011-001587 | R-NETWORK;100OHM,5%,1/16W,L,CHIP,4P,TP,1 |
| 2011-001264 | R-NETWORK;10OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 2011-001519 | R-NETWORK;33OHM,5%,1/16W,L,CHIP,4P,TP,1. |
| 2011-001590 | R-NETWORK;47KOHM,5%,1/16W,L,CHIP,4P,TP,1 |
|
|
REMOCON-ECO SMART CONTROL;2021 TV,SAMSUN |
| 6001-002789 | SCREW-MACHINE;BH,+,M4,L6,ZPC(WHT),SWRCH1 |
| 6001-003424 | SCREW-MACHINE;SWRCH18A,ZPC(BLK),L2,M3,CH |
| 6001-003432 | SCREW-MACHINE;SWRCH18A,ZPC(WHT),L12,M3,C |
|
|
SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),SWR |
|
|
SCREW-TAPTYPE;BH,+,B,M3,L8,ZPC(BLK),SW |
| 6003-001906 | SCREW-TAPTYPE;BH,+,S,M4,L12,ZPC(BLK),SWR |
| 6003-001914 | SCREW-TAPTYPE;CH,+,M3,L5,ZPC(BLK),SWRCH1 |
|
|
SCREW-TAPTYPE;FH,+,B,M4,L8,ZPC(BLK),SWRC |
| 6003-000264 | SCREW-TAPTYPE;PWH,+,B,M3,L6,ZPC(WHT),S |
| BN63-19496A | SHEET-PC;65QAQ900A,PC,T0.43,W18,L111,BLA |
| BN63-19446A | SHEET-PC;75QAQ800B,PC,T0.8,W960,L1680,BL |
| BN63-12848F | SHEET-PROTECTION COVER;27CF591,PO,T0.048 |
| BN63-19569H | SHEET-PROTECTION COVER;LH75OHA,PO,T0.05, |
| BN63-07229A | SHEET-PROTECTION COVER;ROSE70",PET,T0.05 |
| BN63-19500A | SHEET-THERMAL;65QAQ900A,GRAPHITE,T0.5,W3 |
| BN63-19499A | SHEET-THERMAL;65QAQ900A,GRAPHITE,T1,W306 |
| BN63-19567A | SHEET-THERMAL;Q900/800A,GRAPHITE,T0.2,W3 |
| BN63-19364A | SHIELD-OC BOTTOM;65QAQN900A,EGI-SECC,T0. |
| BN63-19363A | SHIELD-OC TOP;65QAQN900A,EGI-SECC,T0.5 |
| 0202-001976 | SOLDER-CREAM;LST-309M-K21 (PWM-118),D20~ |
| 0202-002133 | SOLDER-CREAM;M705-SVD1 TYPE5,D15~25UM,96 |
| 0202-001608 | SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3SN/0. |
| BN60-01689A | SPACER-FOAM;65QAQN900A,PU FOAM,L0,BLACK, |
| BN60-00162V | SPACER-FOAM;PE FOAM,L50M,GRAY,T0.5,W10 |
| BN60-01690A | SPACER-FOAM;PU FOAM,L0,BLACK,T0.5,W3.5 |
| BN60-01459A | SPACER-SILICONE;55PMF,SI,L10,WHITE,T1.8, |
| BN61-02430S | STUD-PEM;82QTQ800B,SUM24L,L4,ZPC(SIL) |
| BN61-02428E | STUD-PEM;HAYDN,SUM24L,T0.5,L10,PRESS,ZPC |
| BN61-17866A | SUPPORT-PLATE;65QAQN900A,PA66,V-0,WHITE, |
| BN02-00554B | TAPE SINGLE FACE;QN800,PET,T0.05,W15,L35 |
| BN02-00616A | TAPE SINGLE FACE;QTQ950SA,PET,T0.2,W13,L |
| 0203-001085 | TAPE-DOUBLE FACE;ACRYL,#706BH,T0.64,W12, |
| BN61-05728D | TAPE-DOUBLE FACE;ACRYL,T0.4,W18,L33M,GRA |
| BN61-05728J | TAPE-DOUBLE FACE;ACRYL,T0.4,W6,L33M,GRAY |
| BN02-00611A | TAPE-DOUBLE FACE;PU FOAM,T0.5,W3.2,N/A,B |
| BN02-00639A | TAPE-SINGLE FACE;CONDUCTIVE FABRIC,T0.07 |
| BN02-00102K | TAPE-SINGLE FACE;FILAMENT,T0.15,W25,ROLL |
| 0203-006894 | TAPE-SINGLE FACE;OPP,3M, #3675,T0.05,W75 |
| BN02-00319B | TAPE-SINGLE FACE;OPP,T0.05,W75,L800M,CLE |
| BN02-00102B | TAPE-SINGLE FACE;OPP,T0.15,W25,L50M,WHIT |
| BN74-00053G | TAPE-SINGLE FACE;PAPER,3M2307,T0.14,W10, |
| BN02-00352E | TAPE-SINGLE FACE;PET,T0.05,W15,L50M,BLAC |
| 0203-007085 | TAPE-SINGLE FACE;PET,T0.05,W20,L100M,CLE |
| BN02-00173C | TAPE-SINGLE FACE;PET,T0.05,W40,BLACK |
| 1404-001731 | THERMISTOR-NTC;33KOHM,4050K,1MWC,TP,1.6X |
| 0501-000445 | TR-SMALL SIGNAL;KTC3875S-Y,NPN,150MW,SOT |
| 0501-000462 | TR-SMALL SIGNAL;MMBT2907A,PNP,350MW,SOT- |
| BN40-00337A | TUNER-DTV AIR CABLE;GVX-8C81,ATSC 3.0,45 |
| 1405-001452 | VARISTOR;15V,12VDC,8A,1608,TP,46V,18PF |
| 1405-001382 | VARISTOR;24.5V,16VDC,120A,2012,TP,42V,40 |
|
|
VARISTOR;35V,20VDC,5A,1005,TP,100V,10PF |
| 1405-001185 | VARISTOR;500V,24VDC,1608,TP,150V,0.055PF |
| 1405-001232 | VARISTOR;6.4V,5.6VDC,30A,1608,TP,19V,200 |
| BH69-00418A | WRAP;762,1828M,SAMEX FACTORY |
