Manufacturer
Samsung
Model Number
RF23BB860012AA
Description
23 Cu. Ft. Bespoke 4-door French Door Refrigerator
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 0201-002906 | ADHESIVE-EMEL;PA-53,WHITE,4560CPS/25 |
| 0201-003797 | ADHESIVE-SEALANT;LOCKSEAL7700,111CPS,LOK |
| 0201-003450 | ADHESIVE-SEALANT;LOCKSEAL7700,LOKPREP |
| 0201-001523 | ADHESIVE-SIL |
| DA61-14455A | ANGLE SHELF-REF MIDDLE |
|
|
ASSEMBLY ACCESSORY-CUSTOM PANEL |
|
|
ASSEMBLY ACCESSORY-CUSTOM PANEL |
| DA97-23061A | ASSEMBLY CABI FORM-CABI MODULE;RF8000BC,4D,U |
| DA97-23017F | ASSEMBLY CABI FRAME-REAR;RF8000B/BC,BASIC |
| DA90-13349A | ASSEMBLY CABINET FORM;RF8000BC,4D,BSC,URBAN |
|
|
ASSEMBLY CAP-DRAIN |
| DA97-22987A | ASSEMBLY CASE CONVERTIBLE;RF8000BC,CD |
| DA97-23026A | ASSEMBLY CASE FILTER |
| DA97-08006L | ASSEMBLY CASE FILTER;H920G |
|
|
ASSEMBLY CASE ICE |
|
|
ASSEMBLY CASE ICE |
| DA97-23081A | ASSEMBLY CASE ICE |
| DA97-15972C | ASSEMBLY CONDENSER-MAIN |
| DA97-21788A | ASSEMBLY COVER BASKET |
| DA97-12749N | ASSEMBLY COVER COMP |
|
|
ASSEMBLY COVER CONTROL |
| DA97-22974A | ASSEMBLY COVER EVAP-FRE |
| DA97-22973A | ASSEMBLY COVER EVAP-REF |
| DA97-21951B | ASSEMBLY COVER LAMP-REF |
| DA97-23225A | ASSEMBLY COVER PIPE WATER |
| DA90-13367B | ASSEMBLY CYCLE , RF8000B,110V,F9 |
| DA82-03364W | ASSEMBLY DOOR FOAM-MIDDLE |
| DA82-03364L | ASSEMBLY DOOR FOAM-REF OUT LEFT |
| DA90-13378K | ASSEMBLY DOOR REF-LEFT;RF8000B,4D,12(CLEAN W |
| DA90-13379K | ASSEMBLY DOOR REF-RIGHT;RF8000B,4D,12(CLEAN |
| DA93-01230E | ASSEMBLY DOOR SUB-REF LEFT;RF8000B,4DOOR,FDS |
| DA93-01231E | ASSEMBLY DOOR SUB-REF OUT LEFT;RF8000B,4DOOR |
| DA93-01232F | ASSEMBLY DOOR SUB-REF RIGHT;RF8000B,4DOOR,BS |
| DA97-23224B | ASSEMBLY DRAIN HOSE-REF , RF8000B |
| DA96-01509A | ASSEMBLY EVAP-FRE EVAP MODULE |
| DA96-01002C | ASSEMBLY EVAP-REF EVAP MODULE |
| DA97-20572A | ASSEMBLY FIXER-UP |
| DA97-22008A | ASSEMBLY GASKET |
|
|
ASSEMBLY GASKET-FRE |
| DA97-23011A | ASSEMBLY GASKET-MIDDLE |
|
|
ASSEMBLY GASKET-REF |
| DA97-21912E | ASSEMBLY GUARD-REF |
| DA97-21914E | ASSEMBLY GUARD-REF LOW |
| DA97-21960E | ASSEMBLY GUARD-REF MIDDLE |
| DA97-21916B | ASSEMBLY GUARD-REF UP |
| DA97-22006J | ASSEMBLY GUIDE HOSE , RF8000B,CD |
|
|
ASSEMBLY HINGE UP LEFT |
| DA97-20039C | ASSEMBLY HINGE UP LEFT |
|
|
ASSEMBLY HINGE UP RIGHT |
| DA97-20041B | ASSEMBLY HINGE-LOW LEFT |
| DA90-13371B | ASSEMBLY ICE MAKER , RF8000BC,DUAL I/M |
| DA90-13369H | ASSEMBLY INSERT;RF8000BC,110V,4D,BSC |
|
|
ASSEMBLY LAMP LED |
| DA96-01119E | ASSEMBLY LAMP LED |
|
|
ASSEMBLY LEVER-AUTO CLOSE |
| DA94-06475A | ASSEMBLY LINER;RF8000BC,4D,BSC,110V,WHITE |
| DA97-24019E | ASSEMBLY MAGNET;RF8000 4D,FRE GLASS,T3.0,W20 |
| DA97-24019D | ASSEMBLY MAGNET;RF8000 4D,MID GLASS,T3.0,W20 |
| DA97-24019C | ASSEMBLY MAGNET;RF8000 4D,REF GLASS,T3.0,W20 |
|
|
ASSEMBLY MODULE |
|
|
ASSEMBLY MODULE |
| DA90-13374H | ASSEMBLY PACKING;RF8000BC,BSC,AMERICA |
| DA97-23021A | ASSEMBLY PARTITION;RF8000BC,ASSEMBLY,CD |
| DA97-22985A | ASSEMBLY PIPE HOT;RF8000BC,4DOOR COUNTER DEP |
| DA97-22977C | ASSEMBLY PIPE SUCTION;RF8000B,TDM, 2CAPI, A1 |
|
|
ASSEMBLY PIPE WATER ICE |
|
|
ASSEMBLY PIPE WATER ICE |
| DA90-13383Q | ASSEMBLY PRINTING;RF23BB860012AA |
|
|
ASSEMBLY RAIL |
| DA97-13261D | ASSEMBLY RAIL-LOW LEFT |
| DA97-13779E | ASSEMBLY RAIL-MIDDLE LEFT |
| DA97-13778E | ASSEMBLY RAIL-MIDDLE RIGHT |
| DA97-23068A | ASSEMBLY ROLLER |
| DA97-19988A | ASSEMBLY ROLLER;RF9000K,29 |
| DA90-13372C | ASSEMBLY SHELF , RF8000BC,4D |
| DA97-22970A | ASSEMBLY SHELF INSERT-REF FIX |
| DA97-21895A | ASSEMBLY SHELF QUICK SPACE |
| DA97-21902L | ASSEMBLY SHELF VEG-LOW |
| DA97-21902M | ASSEMBLY SHELF VEG-LOW , RF8000BC,COVER VEG-UP |
| DA97-21898A | ASSEMBLY SHELF-REF UP |
| DA97-23024A | ASSEMBLY STOPPER |
| DA97-20372B | ASSEMBLY SUPPORT-FRONT , RF8000B,T4.0 |
|
|
ASSEMBLY TOP TABLE |
| DA97-23028A | ASSEMBLY TRAY DRAWER |
| DA97-23245B | ASSEMBLY TRAY DRAWER-BOX DRAWER MODULE;RF800 |
| DA97-22996A | ASSEMBLY TRAY-FRE UP |
| DA97-23064G | ASSEMBLY URETHANE CABI , RF8000BC,CD,K-139,SID |
| DA97-02465C | ASSEMBLY URETHANE- |
| DA96-01466A | ASSEMBLY WIRE HARNESS TOP |
| DA96-01170A | ASSEMBLY WIRE HARNESS-COMP |
|
|
ASSEMBLY WIRE HARNESS-EARTH |
| DA97-05372V | ASSY CABINET-MID FRONT;AW3-PJT,SNOW WHIT |
| DA97-17399U | ASSY CASE INNER |
| DA97-22588C | ASSY CASE PBA;AW, RF8000 |
| DA97-21878F | ASSY CASE VEG-LOW;RF9000AC,CD,CRISPER+,I |
| DA97-21878M | ASSY CASE VEG;RF9000AC,CD, INDIA |
| DA97-21261H | ASSY CASE WATER FILTRE |
| DA97-12557K | ASSY CHASSIS COMP;RF6000T,GI-SGCC,T1.2,9 |
| DA97-22520A | ASSY COVER PCB-MAIN;AW,NO F-HUB, TIM |
| DA98-00165B | ASSY CUSHION BOTTOM;AW4-CD,DUAL DENSITY |
| DA90-13366A | ASSY DAMPER;RF8000B,4D,METAL COOLING(Y) |
| DA90-13376H | ASSY DOOR LOW;RF8000B,4D,12(CLEAN WHITE) |
| DA90-13375H | ASSY DOOR MID;RF8000B,12(CLEAN WHITE),VI |
| DA93-01226A | ASSY DOOR SUB-FRE DOOR MODULE;RF8000B,4D |
| DA93-01236D | ASSY DOOR SUB-FRE;RF8000B,4DOOR,12(CLEAN |
| DA93-01225A | ASSY DOOR SUB-MIDDLE DOOR MODULE;RF8000B |
| DA93-01235D | ASSY DOOR SUB-MIDDLE;RF8000B,4DOOR,12(CL |
| DA93-01228A | ASSY DOOR SUB-REF IN LEFT DOOR MODULE;RF |
| DA93-01262A | ASSY DOOR SUB-REF IN LEFT;RF8000B,4DOOR, |
| DA93-01227A | ASSY DOOR SUB-REF OUT LEFT DOOR MODULE;R |
| DA93-01222A | ASSY DOOR SUB-REF RIGHT DOOR MODULE;RF80 |
| DA97-20085A | ASSY DRAIN HOSE-FRE;RFF310N,HDPE,T1.5 |
| DA97-13825A | ASSY DUCT-A;AW4-4D,LEFT |
| DA97-22980A | ASSY DUCT-B;RF8000B |
| DA97-11489B | ASSY FIXER HOUSING-VALVE WATER;AW2-11,NT |
| DA97-22252A | ASSY FIXER-FRE;RF7000AC |
| DA97-22257B | ASSY FIXER-UP;RF9000A,BLACK,RECYCLE |
| DA97-22978A | ASSY FIXER;RF8000B,LOKRING PIPE |
| DA97-21952A | ASSY GROMMET;RF9000A,FIXER PIPE HANGER |
| DA97-25013A | ASSY HINGE-MIDDLE LEFT;RF9000D,GROMMET(C |
| DA97-25014A | ASSY HINGE-MIDDLE RIGHT;RF9000D,GROMMET( |
| DA59-00392A | ASSY ICE MAKER-ICE MODULE;SWAA,DC 12V, |
| DA97-21804C | ASSY ICE MAKER;RF8000BC,BRACKET |
| DA99-03258A | ASSY LABEL-INSTALLER CHECK LIST;AW-PJT,A |
| DA96-01474A | ASSY LAMP LED;1,FR-1,17*17,WHITE,UNDER 8 |
| DA97-22004A | ASSY LED LAMP;RF9000A,BEVERAGE SHOW CASE |
| DA97-17297F | ASSY LEVER DISPENSER;RF9000A,NO PRINT, U |
| DA97-22986A | ASSY LEVER HANDLE;RF8000B,DARK GRAY,4D |
| DA97-22967A | ASSY LEVER HANDLE;RF9000A,LEFT |
| DA98-03263A | ASSY MANUAL;RF8000B/BC, RF29B, RF23B,AA, |
| DA92-01482A | ASSY MICOM;RF8000B,MAIN MICOM HEX CODE,H |
| DA90-13373A | ASSY OUTER;RF8000B,GRAY,BASIC |
| DA97-21887A | ASSY PANEL;RF7000AC,NON MOVING GUARD |
| DA92-01137D | ASSY PBA MODULE;LED,RF8000B,209*36,6KEY, |
| DA97-15974A | ASSY PIPE CONNECT-B;PFC,-,-,-,-,-,- |
| DA97-15975A | ASSY PIPE CONNECT;PFC,-,-,-,-,-,- |
| DA97-23002A | ASSY PLATE DOOR-E;RF8000B,4DOOR,BESPOKE, |
| DA97-23003A | ASSY PLATE DOOR-FRE;RF8000B,4DOOR,BESPOK |
| DA97-23004A | ASSY PLATE DOOR-REF OUT LEFT;RF8000B,4DO |
| DA97-23005A | ASSY PLATE DOOR-REF RIGHT;RF8000B,4DOOR, |
| DA97-21876B | ASSY RAIL-MIDDLE LEFT;RF9000AC,DELETE RO |
| DA97-21971A | ASSY RAIL-REF LOW LEFT;RF9000AC |
| DA97-21970A | ASSY RAIL-REF LOW RIGHT;RF9000AC |
| DA97-06920Y | ASSY REINF-CABI FLANGE UP;RF9000T |
| DA97-05214A | ASSY REINF-GUIDE FRENCH;AW-PJT, |
| DA97-16179B | ASSY REINF-MIDDLE FRONT;RF8000B,T1.6,PO- |
| DA97-23065B | ASSY SEAL CABI;RF8000B,FS,BSC |
| DA97-13830B | ASSY SUPPORT-MIDDLE;RF9000A |
| DA97-13854D | ASSY TANK WATER-REF;RS5000RC,PP,T3.5,NAT |
| DA97-23066B | ASSY TAPE CABI;RF8000B,FS,BSC |
| DA97-15978N | ASSY TRAY DRAIN WATER;RF9000C,T2,GEAR BO |
| DA97-17400A | ASSY VALVE WATER-HOSE;RF8000MC |
| DA96-01508A | ASSY WIRE HARNESS-CABI;RF8000B,DUAL_ICEM |
| DA96-01471C | ASSY WIRE HARNESS-DISPENSER;ALL,DISPLAY, |
| DA96-01507C | ASSY WIRE HARNESS-DOOR;RF8000B(BC),4DOOR |
| DA96-01506C | ASSY WIRE HARNESS-MAIN;RF8000B(BC),4DOOR |
| DA96-00685B | ASSY WIRE HARNESS-SENSOR;RF8000B(BC),MID |
| DA97-12475A | ASSY-GROMMET FRENCH;MOUTON |
| 6902-002371 | BAG PE;HDPE,T0.015,W200,L300,TRP,RECYCLE |
| 6902-003050 | BAG PE;HDPE,T0.03,W250,L400,TRP,RECYCLE+ |
| 6902-002307 | BAG PE;HDPE/PE FOAM,T0.012/T0.5,W500,L50 |
| 6902-003053 | BAG ROLL;HDPE,T0.012,W1900,L1000,TRP,REC |
| 6902-000336 | BAG ZIPPER |
| 6922-000003 | BAND |
| 3301-002113 | BEAD-SMD;470 OHM/100MHZ 470 OHM/100MHZ,2 |
|
|
BOLT-ETC |
| 6011-001694 | BOLT-ETC |
|
|
BOLT-HEX |
| 6011-007289 | BOLT-HEX |
| DA61-15475A | BRACKET CONDENSER-LOW;RF9000B,PP,BLACK |
| DA61-16192A | BRACKET HOUSING;RF9000D,GL-SGLCC,T0.3, |
| 2401-003069 | C-AL |
| 2402-001254 | C-AL, SMD |
| 2402-001268 | C-AL, SMD |
| 2402-001303 | C-AL, SMD |
| 2402-001398 | C-AL, SMD |
| 2401-004721 | C-AL;680UF,20%,250V,BK,30X30MM,10MM,-25T |
| 2401-004553 | C-AL;820UF,20%,25V,TP,10X20MM,5MM,-40TO+ |
| 2203-002285 | C-CER, CHIP |
| 2203-005135 | C-CER, CHIP |
| 2203-005968 | C-CER, CHIP |
| 2203-006158 | C-CER, CHIP |
| 2203-006377 | C-CER, CHIP |
| 2203-007306 | C-CER, CHIP |
| 2203-007456 | C-CER, CHIP |
| 2203-007544 | C-CER, CHIP |
| 2203-008315 | C-CER, CHIP |
| 2203-006457 | C-CER,CHIP |
| 2203-010495 | C-CER,CHIP;2.2UF,10%,25V,X7R,TP,2012,T1. |
| 2203-010033 | C-CER,CHIP;220NF,10%,25V,X5R,TP,1005,T0. |
| 2203-010496 | C-CER,CHIP;4.7UF,10%,25V,X7R,TP,2012,T1. |
| 2201-002429 | C-CERAMIC,DISC;10NF,+80-20%,2000V,Y5U,TP |
| 2201-002709 | C-CERAMIC,DISC;33PF,5%,1000V,SL,TP,6.3X5 |
| 2201-002711 | C-CERAMIC,DISC;470PF,10%,400VAC,Y5P,TP,1 |
| 2201-002335 | C-CERAMIC,DISC;68PF,10%,2000V,SL,TP,8X5M |
| 2301-002483 | C-FILM,LEAD-MPPF;330NF,10%,275VAC,BK,18X |
| 2301-002484 | C-FILM,LEAD-MPPF;470NF,10%,275VAC,BK,18X |
| 2301-002011 | C-FILM,LEAD-PPF;2.2NF,5%,630V,TP,13X11X6 |
| DA01-02220A | C/STEEL-CABI , AW4 C/D,GI-SGCC,21 CABINET |
| DA01-01876C | C/STEEL-DOOR;RF7000AC,EGI-SECC,BLACK CAV |
| DA01-02014C | C/STEEL-DOOR;RF8000B 4D,GL-SGLCC,0.5MM |
| DA01-02014D | C/STEEL-DOOR;RF8000B 4D,GL-SGLCC,0.5MM |
| DA01-02014E | C/STEEL-DOOR;RF8000B 4D,GL-SGLCC,0.5MM |
| DA01-02014F | C/STEEL-DOOR;RF8000B 4D,GL-SGLCC,0.5MM |
| DA01-01875C | C/STEEL;RF7000AC,EGI-SECC,MATT DOI METAL |
| DA64-02233S | CABI FRAME-MIDDLE FRONT;RF9000K,EGI-SECC |
| DA64-07034A | CABI FRAME-REAR;RF8000B/BC,GL-SGLCC,T0.3 |
| DA64-07042A | CABI FRAME;RB8000BC,GI-SGCC,T0.4,21 CA |
| DA64-02233H | CABINET-MID FRONT;AW3,EGI-SECC,T1,SNOW |
|
|
CABLE TIE |
| DA66-00950B | CAM AUTO CLOSE-LEFT |
| DA66-00951B | CAM AUTO CLOSE-RIGHT |
| DA66-01710A | CAM RISER-LOW LEFT;RF9000D,POM,BLACK, |
| DA66-01711A | CAM RISER-LOW RIGHT;RF9000D,POM,BLACK, |
| DA66-01714A | CAM RISER-UP LEFT;RF9000D,PA66,BLACK, |
| DA66-01715A | CAM RISER-UP RIGHT;RF9000D,PA66,BLACK, |
| DA67-03717A | CAP DISPENSER;3050 PJT,LDPE,HB,MB9500,NA |
| DA67-05405B | CAP DOOR-FRE LOW;RF8000B,ABS,T2.3,CNTK |
| DA67-05405A | CAP DOOR-FRE LOW;RF8000B,ABS,T2.3,VE-0 |
| DA67-05404A | CAP DOOR-FRE UP;RF8000B,ABS,T3,HG-0760 |
| DA67-05403A | CAP DOOR-MIDDLE UP;RF8000B,ABS,T3,HG-0 |
| DA67-05399A | CAP DOOR-REF LOW LEFT;RF8000B,ABS,T2.3, |
| DA67-05397A | CAP DOOR-REF LOW RIGHT;RF8000B,ABS,T2.3, |
| DA67-05398A | CAP DOOR-REF UP LEFT;RF8000B,ABS,T2.3, |
| DA67-05402A | CAP DOOR-REF UP LEFT;RF8000B,ABS,T2.3, |
| DA67-05396B | CAP DOOR-REF UP RIGHT;RF8000B,ABS,T2.3, |
| DA67-04504D | CAP FIXER-TUBE |
| DA67-05151A | CAP FIXER;RF9000A,SI,T2,NEO VICTORY GRAY |
| DA67-03358A | CAP GUIDE FRENCH-UP;AW4,POM,500P,NAT |
| DA67-05051A | CAP HOLE-FRE;RF9000T,ABS,T1.5,GP-35,EBON |
| DA67-04961A | CAP SCREW |
| DA67-30266Q | CAP SCREW |
| DA67-04331A | CAP SHAFT;RF9000K,POM,K300,NATURAL |
| DA67-04732A | CAP TANK;RS5000RC,PP,T3.5,J370,NATURAL |
|
|
CAP-CASE FRENCH |
|
|
CAP-CASE FRENCH MID |
|
|
CAP-DRAIN |
| DA67-03091B | CAP-FIXER HOUSING VALVE WATER;AW2-11,HIP |
| DA67-00189A | CAP-HOME BAR;ABS,HG-0760H,SNOW WHITE |
| DA67-02795C | CAP-SHAFT HOLE |
| DA67-03399A | CAP-TUBE;HM12,PP,HB,BJ750,NATURAL |
| DA61-15172A | CASE BASKET-FRE UP , RF80000BC,PP,T2.5,COO |
| DA61-14440A | CASE BASKET-LOW;RF9000A,HIPS,T2.5,NEO VI |
| DA61-14149A | CASE BASKET-MIDDLE;RF9900T,HIPS,T3,COOL |
| DA61-15174A | CASE BASKET-UP |
| DA61-14441A | CASE BASKET-UP;RF9000A,ABS,T3,NEO VICTOR |
| DA61-13987A | CASE COCK |
| DA61-15163A | CASE CONVERTIBLE |
| DA61-11735A | CASE DISPENSER-IN;RF8000MC,ABS,EBONY B |
| DA61-14461A | CASE FILTER-LEFT;RF9000AC,HIPS,T2,NATURA |
| DA61-14163B | CASE FILTER-OUT;RF9000A,HIPS,T2.5,NEO VI |
| DA61-14552A | CASE FILTER-OUT;RF9000AC,HIPS,T2.5,NATUR |
| DA61-14462A | CASE FILTER-RIGHT;RF9000AC,HIPS,T2,NATUR |
| DA61-15091A | CASE FILTER;RF9000A,GPPS,T2.5,TP GRAY,G- |
| DA61-08301A | CASE FRENCH-FRONT;MOUTON,ABS,COOL WHIT |
| DA61-08300A | CASE FRENCH;MOUTON,ABS,COOL WHITE,SD |
| DA61-15293A | CASE FRENCH;RF8000B,ABS,T2.5,COOL WHITE, |
| DA61-14540A | CASE HEATER-FRENCH;RF7000AC,ABS,NATURAL, |
| DA61-14309A | CASE ICE SCOOP |
| DA61-15138A | CASE ICE-CUBE , RF8000BC,GPPS,T2.5,TP GRAY |
| DA61-07581A | CASE LAMP-LED;POLARIS,GPPS,20.4,20.4,TP |
| DA61-15171A | CASE LAMP;RB8000B,ABS,T2.3,COOL WHITE, |
| DA61-15147A | CASE LAMP;RF8000B/BC,PP,T1.5,BLACK,RM6 |
| DA61-13653A | CASE LOCK-A;RF9000R,ABS,T2.5,INOX GRAY,A |
| DA61-15404A | CASE PBA-MAIN;RF9000B,PP,T2.5,NATURAL, |
| DA61-14524B | CASE VEG-LOW |
| DA61-14174B | CASE WATER TANK;RF8000BC,PCT,T2,TP GRAY, |
| DA61-13315A | CASE WATER TANK;RS5000RC,PP,T3.5,NATURAL |
| DA61-05524A | CASE-FILTER IN;SSEDA,POM,NATURAL,- |
| DA61-05523A | CASE-FILTER OUT;SSEDA,POM,NATURAL, |
| DA61-05954A | CASE-HOUSING CONV LINER;AW3,PP,-,NATURAL |
| DA61-01729A | CASE-ROLLER VEG |
|
|
CASTER-FRONT |
|
|
CASTER-REAR |
| DA02-40003A | CH-BLOWING AGE |
| DA64-04152K | CHASSIS COMP;RF6000T,GI-SGCC,T1.2,W908, |
| DA02-00132A | CHEMICALS-CATALYST |
|
|
CLIP-FITTING LOCK |
| DA61-15114A | CLIP;RF6000T,POM,T2,NATURAL,F20-03,LOCKI |
| NO14C9151AKD01 | CMP,COMP,REFRIGERATOR,R600A |
| DA02-00235A | COATING-ECO PRO;ECO PRO,12.7,TRANSPARENC |
| DA27-00063A | COIL CHOKE;150UH,6A,11MMX10MM,MN-ZN,4P,D |
| DA27-00062A | COIL CHOKE;18MH,6A,16MMX18MM,MN-ZN,4P,DI |
| DA27-00061A | COIL CHOKE;4.5MH,6A,15MMX10MM,MN-ZN,4P,D |
| 3711-000262 | CONNECTOR-HEADER |
|
|
COVER ASSEMBLY SWITCH |
|
|
COVER ASSEMBLY-SENSOR FRE |
|
|
COVER ASSEMBLY-TUBE FILTER |
| DA63-09639A | COVER CAP DOOR |
| DA91-05369B | COVER CAP DOOR |
| DA63-11580A | COVER CASE;RF8000B,ABS,T2.5,NEO VICTOR |
| DA63-06954E | COVER COMP;RF8000B/BC,GL-SGLCC,T0.25, |
| DA63-11272A | COVER DOOR-LEFT |
| DA63-11573A | COVER EVAP-FRE REAR;RF8000B,PP,T1.5,NA |
| DA63-11575A | COVER EVAP-FRE;RF8000B,PP,T2,NATURAL, |
| DA63-11572A | COVER EVAP-REAR;RF8000B,PP,T1.5,NATURA |
| DA63-11574A | COVER EVAP-REF;RF8000B,HIPS,T2,COOL WH |
| DA63-11209A | COVER FILTER |
| DA63-05403B | COVER FILTER;AW3,PP,T2.5,INNER GRAY,NF-6 |
| DA63-11210A | COVER FILTER;RF9000AC,HIPS,T2.5,COOL WHI |
| DA63-11585A | COVER FIXER MAGNET |
| DA63-11587A | COVER FRONT-UP |
| DA63-11515A | COVER HANDLE-LEFT;RF9000A,ABS,T1.8,EBO |
| DA63-11577A | COVER HANDLE;RF8000B,ABS,DARK GRAY, |
| DA63-11686A | COVER LAMP |
| DA63-06505A | COVER LAMP-LED;POLARIS,ABS,HB,NATURAL,TX |
| DA63-11218A | COVER LAMP-REF;RF9000A,ABS,COOL WHITE,HG |
|
|
COVER LOCK |
| DA63-11401A | COVER PBA-REAR;AW,GL-SGLCC,T0.4 |
| DA63-11634A | COVER PIPE;RF8000B,PP,T2,BLACK,RM60, |
| DA63-11681A | COVER RAIL-LOW LEFT , RF8000B,ABS,T2.5,HB, |
| DA63-11682A | COVER RAIL-LOW RIGHT , RF8000B,ABS,T2.5,HB |
| DA63-07515A | COVER RAIL-MIDDLE LEFT |
| DA63-11579A | COVER RAIL-MIDDLE RIGHT |
|
|
COVER REED SWITCH |
| DA63-06122A | COVER RELAY |
|
|
COVER SENSOR-FRE |
| DA63-11197A | COVER SENSOR;RF9000A,PP,T2.5,COOL WHITE, |
| DA63-09321A | COVER SENSOR;RS8000NC,PP,T2,COOL WHITE,B |
| DA63-11677A | COVER SHEET;RF8000B,AL,NATURAL,T |
| DA63-11685A | COVER SHEET;RF8000B,AL,NATURAL,T |
| DA63-11207A | COVER VEG-FRONT LOW;RF9000A,GPPS,TP GRAY |
| DA63-11207B | COVER VEG-FRONT LOW;RF9000A,GPPS,TP GRAY |
| DA63-11228A | COVER VEG-UP |
| DA63-09907B | COVER WATER TANK;RF9000A,HIPS,T2.5,NEO V |
| DA63-11211A | COVER WINDOW;RF9000A,ABS,BSC BEIGE SOLID |
| DA63-11285A | COVER-AUTOFILL;RF9000A,ABS,T2.5,NEO VICT |
| DA63-11217A | COVER-AUTOFILL;RF9000A,HIPS,T2,NEO VICTO |
|
|
COVER-CAP DOOR LED |
| DA63-06383B | COVER-FIXER HOUSING FRE;OPUS,HIPS,-,-,NA |
|
|
COVER-HEATER FRENCH |
| DA63-11590A | COVER-REAR |
| DA63-03809A | COVER-URETHANE |
| DA69-02308A | CUSHION BOTTOM;AW4-CD,EPS,W958,L762,H146 |
| DA69-00698B | CUSHION CORNER-FRONT;REF_ALL,EPS,W95,L14 |
| DA69-01420A | CUSHION CORNER-REAR;REF_ALL,EPS,W95,L95, |
| DA69-02680A | CUSHION DOOR-FRONT;RF8000BC,EPS,W550,L15 |
| DA69-02681A | CUSHION SHELF;RF8000BC,EPS,W500,L650,H21 |
| DA69-02596A | CUSHION TOP;AW4-CD,EPS,W960,L764,H105.6, |
|
|
CUSTOM PANEL |
| 0402-001224 | DIODE-BRIDGE |
| 0402-001472 | DIODE-RECTIFIER |
|
|
DIODE-RECTIFIER |
| 0402-000553 | DIODE-SCHOTTKY |
| 0401-001099 | DIODE-SWITCHING |
| 0407-000113 | DIODE-SWITCHING |
| 0406-001239 | DIODE-TVS |
| 0406-001865 | DIODE-TVS;SMBJ17CA,18.9V,20.9V,5MAV,100A |
| 0406-001906 | DIODE-TVS;SMF200A,224V,SOD-123FL,200W,TP |
| 0403-000461 | DIODE-ZENER |
| DA64-07030A | DOOR-FRONT UP;RF8000B,ABS,T3,W448.4,L909 |
| DA67-05445A | DRAIN-CONNECT;RF8000B,PP,BLACK,SSPP-64 |
| DA67-04812A | DRAIN-HOSE FRE;RFF310N,HDPE,NATURAL |
|
|
DRYER |
| DA67-03703A | DUCT-LEFT;AW4-4D,HDPE,YR5100B,NATURAL,SC |
| DA67-05393A | DUCT-RIGHT;RF8000B,HDPE,YR5100B,NATURAL, |
| DA59-00636A | EVAPORATOR-FRE;FIN TUBE,RF8000B,2,A1070, |
| DA59-00558B | EVAPORATOR-REF;FIN TUBE,RF8000B,1,A1070, |
|
|
FASTENER-HINGE |
| DA60-00314B | FASTENER-HINGE |
|
|
FASTENER-HINGE |
| DA60-00314D | FASTENER-HINGE |
|
|
FASTENER-RIVET |
| DA60-00163A | FASTENER;AW-PJT,SK5,OD4.2 |
| 0505-002598 | FET-SILICON |
| 0505-003755 | FET-SILICON;AOD2910E,N,100V,37A,23MOHM,7 |
| 0505-003960 | FET-SILICON;IPD60R360PFD7S,N,650V,10A,36 |
| DA63-08839B | FILTER-WATER;RF8000MC,PP,COOL WHITE,CART |
| DA60-00371C | FITTING LOCK RING;A6061,ID5.75,SILVER, |
| DA60-00407B | FITTING LOCK RING;A6061,ID9.1,SILVER,O |
| DA60-00367B | FITTING LOCK RING;SMF4030,ID5.2,COND OUT |
| DA60-00366A | FITTING LOCK SLEEVE;SMF4030,PIPE HOT(4.2 |
| DA60-00393A | FITTING TUBE |
| DA60-00403A | FITTING TUBE;POM,ID1/4,NATURAL,F20-03,OD |
| DA60-00404A | FITTING TUBE;POM,ID1/4,NATURAL,F20-03,OD |
| DA62-03914G | FITTING TUBE;POM,ID1/4,NATURAL,K300,OD1/ |
|
|
FITTING-TUBE |
| DA61-11032A | FIXER |
| DA61-11034A | FIXER |
| DA61-09533A | FIXER CASE-PBA;OPUS1-14,ABS,NATURAL, |
| DA61-12488B | FIXER COVER;AW3,HIPS,INNER GRAY,CNTK H30 |
| DA61-14999A | FIXER HANDLE-A;RF9000A,GI-SGCC,T1, |
| DA61-12180B | FIXER HOSE;BRF8000M,POM,-,BLACK,-,F20-03 |
| DA61-14663B | FIXER HOSE;RF9000A,PP,BLACK,CNTK-P101,RE |
| DA61-15739A | FIXER HOSE;RR9000,POM,T2,NATURAL,F20-0 |
| DA61-14658A | FIXER HOUSING-FRE;RF7000AC,HIPS,NATURAL, |
| DA61-14677A | FIXER HOUSING-REF RIGHT;RF9000A,HIPS,T2, |
| DA61-10758C | FIXER LOCKER;ABS,T2.5,EBONY BLACK,HG-076 |
| DA61-12188A | FIXER PIPE |
| DA61-14479A | FIXER SENSOR;RF9000A,PE FOAM,NATURAL,B40 |
| DA61-12990A | FIXER SENSOR;RS8000NC,PE FOAM, |
| DA61-13459A | FIXER SHELF;FDR,POM,T2.5,NATURAL,K300,LE |
| DA61-13460A | FIXER SHELF;FDR,POM,T2.5,NATURAL,K300,RI |
| DA61-06013B | FIXER WIRE |
| DA61-12195A | FIXER WIRE;RF8000MC,ABS,NATURAL,HG-0760G |
| DA61-13585A | FIXER-BIMETAL;RF9000R,PP,T1.5,NATURAL,1, |
|
|
FIXER-CASTER |
| DA61-05780A | FIXER-COLLAR;SSEDA,POM,NATURAL,- |
| DA61-05781A | FIXER-COLLET;SSEDA,POM,INNER GRAY,F2 |
|
|
FIXER-DRAIN |
| DA61-04235A | FIXER-EVAP |
| DA61-05525A | FIXER-FILTER;SSEDA,PP,COOL WHITE |
|
|
FIXER-GEAR |
| DA61-15131A | FIXER-HEATER |
|
|
FIXER-HINGE |
| DA61-07554B | FIXER-HOUSING VALVE WATER;AW2-11,HIPS, |
|
|
FIXER-ROLLER |
|
|
FIXER-SENSER |
| DA61-05570A | FIXER-SHAFT GUIDE;SSEDA,POM,NATU |
| DA61-05526A | FIXER-SHAFT;SSEDA,POM,NATURAL,F20-03 |
| DA61-07130A | FIXER-SUCTION;AW3-PJT,PP,T0.5,NATURAL,BJ |
| DA61-15292A | FIXER-SUCTION;RF8000B,PP,T2,BLACK,SSPP |
| DA61-15146A | FIXER-SUCTION;RF8000B,PP,T2,NATURAL,BJ |
| DA71-20265A | FIXER-THERMO FUSE |
| DA61-11296B | FIXER;AW3,HIPS,INNER GRAY,CNTK H304,RECY |
| 0204-004665 | FLUX;KSP-70M-S,MIXTURE,NO,FLUX,13% |
|
|
FOOT |
|
|
FOOT-FRONT |
| DA97-12684G | FRENCH ASSY |
| 3601-001336 | FUSE-AXIAL LEAD |
| 3601-001978 | FUSE-AXIAL LEAD;250V,10A,SLOW-BLOW,BK,5. |
| 3601-001927 | FUSE-AXIAL LEAD;250V,2A,TIME-LAG,CERAMIC |
| DA63-08421A | GASKET FRENCH-LOW |
| DA63-09908B | GASKET-TANK;RF9000A,SI,NEO VICTORY GRAY, |
| DA66-00750B | GEAR |
| DA66-00751B | GEAR;AW3-14,POM,NATURAL,500P,RAIL LEFT |
| DA64-06603B | GLASS-DOOR;RF8000B,GLASS,T3.2,W446.6,L90 |
| DA64-06603C | GLASS-DOOR;RF8000B,GLASS,T3.2,W904.6,L16 |
| DA64-06603D | GLASS-DOOR;RF8000B,GLASS,T3.2,W904.6,L56 |
| DA64-06509A | GLASS-SHELF FRONT;RF9000AC,GLASS,T3.2,W3 |
| DA64-05969A | GLASS-SHELF REAR;AW4_CD,GLASS,T3.2,W375, |
| DA64-07027A | GLASS-SHELF REF FIX , RF8000BC,GLASS,T3.2, |
| DA64-06513N | GLASS-SHELF REF LOW;RF9000AC,GLASS,T3.2, |
| DA64-06511B | GLASS-SHELF REF UP;RF9000AC,GLASS,T5,W82 |
| 0205-000121 | GREASE-SILICON |
| 0205-000131 | GREASE-SILICON;G501,1L |
|
|
GROMMET COMP;REF,IIR,ALL BLACK |
| DA63-02750B | GROMMET COVER SLIDE |
| DA63-09942A | GROMMET DOOR |
| DA63-11374A | GROMMET DOOR |
|
|
GROMMET HINGE-MIDDLE |
| DA63-07925A | GROMMET HINGE-UP;AW4,PA66,NATURAL,101F |
| DA63-11491A | GROMMET RING;RR9000A,NBR,BLACK,D 3/16 |
| DA63-11592A | GROMMET-A |
| DA63-07969A | GROMMET-A;FSR,PP+GLF15%,NATURAL |
| DA63-11593A | GROMMET-B |
| DA63-04825B | GROMMET-CAP DOOR |
| DA63-02761A | GROMMET-DRAIN |
| DA63-11235A | GROMMET-FIXER;RF9000A,PP,NATURAL,FRONT |
| DA63-03447A | GROMMET-FRENCH |
| DA63-03049A | GROMMET-HOT PIPE |
| DA63-07323A | GROMMET-IMMERSION PIPE B |
| DA63-05349A | GROMMET-RING SHAFT GUIDE;SSEDA,NBR,- |
| DA63-05350A | GROMMET-RING SHAFT;SSEDA,NBR,N |
| DA63-05351A | GROMMET-RING;SSEDA,NBR,NATURAL |
|
|
GROMMET-SUCT PIPE A |
| DA63-05447A | GROMMET-SUCTION PIPE;AW2,NBR,BLACK |
| DA63-09665A | GROMMET-UP RIGHT;RF9000R(B),SI,BLACK,B-P |
| DA63-07746A | GROMMET;AW3-14,SI,NATURAL |
| DA63-11260A | GUARD-REF MIDDLE;RF9000A,SAN,T3,TP GRAY, |
| DA63-11220A | GUARD-REF SUB;RF9000A,SAN,T3,TP GRAY,BSC |
| DA63-11222A | GUARD-REF UP;RF7000AC,GPPS,T3,TP GRAY |
| DA63-11219A | GUARD-REF;RF9000A,GPPS,T3,TP GRAY,BASIC |
| DA61-15144A | GUIDE AIR-REF;RF8000B,HIPS,T1.5,CNTK H |
| DA61-15859A | GUIDE FRENCH;RF9000C,PC+ABS,T2,HR-1008 |
| DA61-15281A | GUIDE HOSE , RF9000A,HDPE,T1.5,YR5100B,N |
| DA61-15286A | GUIDE HOSE-FRONT;RF8000B/BC,HIPS,T1.5, |
| DA61-15142A | GUIDE HOSE-IN;RF8000BC,PP,T2,SSPP-640, |
| DA61-15143A | GUIDE HOSE-IN;RF8000BC,PP,T2,SSPP-640, |
| DA61-15141A | GUIDE HOSE-OUT;RF8000B,PP,T2,SSPP-640, |
| DA61-10404A | GUIDE HOSE;PP,HB,BJ750,COOL WHITE,L |
| DA61-15112A | GUIDE HOSE;RF6000T,PP,T2,J370,NATURAL |
| DA61-14661A | GUIDE ICE |
| DA61-13492A | GUIDE RAIL;RF9000R,ABS,NATURAL,GP-35 |
| DA61-15176A | GUIDE TRAY-FRE |
| DA61-15161A | GUIDE TRAY-MIDDLE |
| DA61-14987A | GUIDE-FRE;AW3-14,PP,T1.2,SSPP-640,BLACK |
| DA61-09100A | GUIDE-TUBE C;3050,PP,J550S,NATURAL |
| DA02-40012D | H-ISOCYANATE |
| DA64-07029A | HANDLE RECESS;RF8000B,ABS,HG-0760GP,DARK |
| DA61-09248A | HANGER-FRONT MIDDLE LEFT |
| DA61-09249A | HANGER-FRONT MIDDLE RIGHT |
| DA61-13449B | HANGER-LEFT |
| DA61-09187A | HANGER-MIDDLE LEFT;AW4-4D(C/D),EGI-SECC, |
| DA61-09186A | HANGER-MIDDLE RIGHT;AW4-4D (C/D),EGI-SEC |
|
|
HANGER-RAIL FRONT L |
|
|
HANGER-RAIL FRONT R |
| DA61-05189A | HANGER-RAIL LOW L , AW2 CD,EGI-SECC,COOL W |
| DA61-05190A | HANGER-RAIL LOW R , AW2 CD,EGI-SECC,COOL W |
| DA61-13451B | HANGER-RIGHT |
| DA61-15135A | HANGER-RIGHT , RF8000BC,GI-SGCC,T2.0 |
| 3711-000315 | HEADER-BOARD TO CABLE |
| 3711-001038 | HEADER-BOARD TO CABLE |
| 3711-001084 | HEADER-BOARD TO CABLE |
| 3711-002001 | HEADER-BOARD TO CABLE |
| 3711-008032 | HEADER-BOARD TO CABLE;1WALL,2P,1R,7.92MM |
| 3711-008034 | HEADER-BOARD TO CABLE;1WALL,3P,1R,7.92MM |
| 3711-009460 | HEADER-BOARD TO CABLE;1WALL,4P,1R,7.92MM |
| 3711-009393 | HEADER-BOARD TO CABLE;BOX,24P,2R,2.0MM,S |
| 3711-009394 | HEADER-BOARD TO CABLE;BOX,26P,2R,2.0MM,S |
| 3711-009395 | HEADER-BOARD TO CABLE;BOX,28P,2R,2.0MM,S |
| DA47-00245T | HEATER CORD-FRENCH;AC120V,AW4-4D, 1440OH |
| DA47-00550A | HEATER CORD-WATER PIPE;DC12V,2.3W,PVC, |
| DA47-00541B | HEATER FILM-DOOR;AC120V,1309 OHM,11W,AG |
| DA47-00318V | HEATER METAL SHEATH |
|
|
HINGE-FRENCH |
| DA61-13446B | HINGE-LOW LEFT;RF9000R,PO-SPHC,T4, |
| DA61-16173A | HINGE-MIDDLE LEFT;RF9000D,ZN,T8, |
| DA61-16174A | HINGE-MIDDLE RIGHT;RF9000D,ZN,T8, |
| DA61-13411A | HINGE-UP LEFT;RF9000R,PO-SPHC,T3, |
| DA61-13413B | HINGE-UP LEFT;RF9000R,PO-SPHC,T4, |
| DA61-13412A | HINGE-UP RIGHT;RF9000R,PO-SPHC,T3, |
| DB61-00206A | HOLDER-WIRE |
| DA67-05512A | HOSE DRAIN , RF8000B,HDPE,NATURAL,YR5100 |
| 1001-001942 | IC-ANALOG SWITCH |
| 1205-004722 | IC-CONTROLLER;TCA9535PWR,TSSOP,24P,7.8*4 |
| 1003-000113 | IC-CURRENT DRIVER |
| 1203-009429 | IC-DC/DC CONVERTER;SYU812C1,SOT23-6,6P,3 |
| 1103-001228 | IC-EEPROM |
| 0903-002203 | IC-MICROCONTROLLER;HART-M320,MQFP,100P,2 |
| 0903-002279 | IC-MICROCONTROLLER;STM32G431RBT3,LQFP,64 |
| 1003-003175 | IC-MOTOR DRIVER;6EDL04N06PT,PG |
| 1003-002899 | IC-MOTOR DRIVER;DRV8848L,16P,H |
| 1003-002900 | IC-MOTOR DRIVER;DRV8848PWPR,16 |
| 1201-004191 | IC-OP AMP;9064,TSSOP,TP,14P,5X4.4X1.2MM, |
| 1203-002722 | IC-POSI.FIXED REG. |
| 1203-009642 | IC-PWM CONTROLLER;SC1551C-H084-TL,24P,SO |
| 1203-001211 | IC-VOL. DETECTOR |
| 1203-006245 | IC-VOL. DETECTOR |
| 2703-004724 | INDUCTOR-SMD |
| DA27-00051A | INDUCTOR-SMD;1MH,20%,12.2X12.2MM,T8,1.59 |
| DA64-06855X | INLAY CONTROL;RF8000B,PC,T0.38,W,L, |
| DA62-05859A | INSULATION COVER EVAP-FRE;RF8000B,EPS,T8 |
| DA62-05851A | INSULATION COVER EVAP-REF;RF8000B,EPS,T8 |
| DA62-05856A | INSULATION-A , RF8000BC,EPS,S-450,NATURA |
| DA62-05862A | INSULATION-B;RF8000BC,EPS,S-450,NATURA |
| DA62-03665A | INSULATION-FRENCH LOW;MOUTON,EPS,SE300,S |
| DA62-03664A | INSULATION-FRENCH;MOUTON,EPS,SE300,S-450 |
| DA62-05857A | INSULATION-MULTI REF A;RF8000BC,EPS,S- |
| DA62-05858A | INSULATION-MULTI REF B;RF8000BC,EPS,S- |
| DA62-05896A | INSULATION-MULTI REF C;RF8000B,EPS,S-4 |
| DA02-00087A | ISOCYANATE;ISOCYANATE B1001 B1001,100%,I |
| DA68-11081D | LABEL |
| DB68-05458A | LABEL BAR CODE;AM9000H,PAPER,W17.5,L18 |
| DA68-01797W | LABEL CAUTION;ALL USA,AA,ART,OPP, R-600A |
| DA68-04411C | LABEL ENERGY;RF8000BC, 4D, RF23BB8600**, |
| DA68-02986T | LABEL INSTRUCTION;RF8000B(BC), A3LCCAR21 |
| DA68-02785B | LABEL INSTRUCTION;ROMANEE CONTI,DOM,ART, |
| 6812-000145 | LABEL INTEGRATION QR;PET,LAMINATE COATED |
| DA68-04412L | LABEL RATING;RF8000BC, 4D,RF23BB860012,A |
| DA68-00007D | LABEL SERIAL |
| DA68-02869A | LABEL TAG;ALL,AA, XAC,MOJO,200G,W140,L21 |
| DA68-01173B | LABEL-BAR CODE |
| DA68-10376D | LABEL-BAR CODE |
| DA68-00122E | LABEL-PRINT |
| 0601-002345 | LED |
| DA66-01342A | LEVER |
| DA66-01246A | LEVER CASE DISPENSER;RF8000MC,ABS, |
| DA66-01559A | LEVER HANDLE;RF8000B,POM,K300,NATU |
| DA66-00952A | LEVER-AUTO CLOSE;AW4,POM,500P,BLACK,BLAC |
| DA66-01345A | LEVER;RF9000R,ZNDC,T6,W15,L38,ZNDC2,NATU |
| DA61-15133A | LINER;RF8000BC-4D,ABS,QU-0191S,COOL WH |
|
|
MAGNET |
|
|
MAGNET ASSEMBLY |
|
|
MAGNET-A |
| DA68-02659J | MANUAL INSTRUCTION;RF8000B/BC, RF23/24/2 |
| DA68-04540A | MANUAL USERS , RF8000B,AA,EN/MES/FR,MOJO,W |
|
|
MOTOR BLDC FAN |
| DA31-00348A | MOTOR BLDC FAN;Z19W12MS1A5-52K |
| DA31-00346A | MOTOR GEARED DC DAMPER;NSBY001TP1,DC12V, |
| 6021-000258 | NUT-HEXAGON |
| 0205-000127 | OIL-SILICON |
| DA69-02305Q | PACKING CASE , RF8000BC,CB,DW2,L766,W962,H |
| DA69-01740P | PAD PACKING-BOTTOM;AW2 CD,PP,T3,W958,D76 |
| DA62-04618U | PAD-FOAM , REF_ALL,EPE,T30,W40,L150,NON- |
| DA62-04618R | PAD-FOAM;REF_ALL,EPE,T10,W20,L100,SET, |
| DA64-07032A | PANEL-FRE;RF8000B,ABS,T1,W881.4,L578.2, |
| DA64-07031A | PANEL-MIDDLE;RF8000B,ABS,T1,W881.4,L180. |
| DA64-06500A | PANEL-REF LEFT;RF7000AC,ABS,W383.2,L773. |
| DA64-06499A | PANEL-REF LEFT;RF7000AC,ABS,W430.7,L847. |
| DA64-06501A | PANEL-REF RIGHT;RF7000AC,ABS,W429.7,L847 |
| DA67-05386A | PARTITION-LOW;RF8000B,HIPS,NATURAL,S |
| DA67-05387A | PARTITION-UP;RF8000B,HIPS,COOL WHITE, |
| 0604-001405 | PHOTO-COUPLER;TR,200-400%,200MW,SOP,TP |
| DA62-04396F | PIPE CAPILLARY;ARAM13,CU,OD2.05,ID0.75, |
| DA62-05882B | PIPE CAPILLARY;RF8000B,AL,OD1.9,T0.54, |
| DA62-05882A | PIPE CAPILLARY;RF8000B,AL,OD2.05,T0.65, |
| DA62-04396C | PIPE CAPILLARY;RS8000NC,CU,OD1.9,T0.54,I |
| DA62-05866A | PIPE CLUSTER-REAR;RF8000B/BC,TSW,OD4.2,T |
|
|
PIPE CONNECT-SUCTION |
| DA62-05884G | PIPE CONNECT;RF9000C,AL,OD8,T0.8,A |
| DA62-05870A | PIPE HOT;RF8000BC,TSW,OD4.2,T0.5,4 |
| DA62-04609B | PIPE IMMERGING-IN;RF9000B,TSW,OD4.76,T0. |
| DA62-04610C | PIPE IMMERGING-OUT;RF9000,TSW,OD4.76,T0. |
| DA62-04847A | PIPE WATER-FRA A;BRR9000M,PP,OD13.5,-,NA |
| DA62-04965A | PIPE WATER-FRE;BRF8000M,AL,A3003 |
| DA62-05754A | PIPE WATER-FRE;RR9000A,POM,OD6.25,T2.5,N |
| DA62-05319A | PIPE WATER-LINE;RF9000R,LDPE,OD4.76,T0.8 |
| DA62-05883A | PIPE-AL;RF8000B,AL,OD8,T0.8,A1070S |
|
|
PIPE-CONNECT DISC, B |
| DA62-04605A | PIPE-IN;AL,A3003 |
| DA62-04601A | PIPE-MIDDLE;AL,T1.2,A3003 |
| DA62-04600A | PIPE-SUB;AL,A3003 |
| DA97-05803A | PIPE-WATER LINE |
| DA62-01368B | PIPE-WATER LINE |
| DA62-03154A | PIPE-WATER LINE |
| DA62-04623C | PIPE;ALL,CU,OD7.94,T0.4,C1220T-OL |
| DA61-16178D | PLATE CABINET-BOTTOM FRONT;RF8000,EGI-SE |
| DA61-10697B | PLATE CONDENSER |
| DA61-15136A | PLATE COOLING-REF;RF8000B,AL,T0.5, |
| DA61-13772A | PLATE COVER-FRE;RF9000JC,GL-SAZCC,T0.25, |
| DA61-15152A | PLATE DOOR-FRE;RF8000B,GL-SGLCC,T0.5, |
| DA61-15151A | PLATE DOOR-MIDDLE;RF8000B,GL-SGLCC,T0.5, |
| DA61-14536B | PLATE DOOR-REF LEFT;RF7000AC,EGI-SECC,T0 |
| DA61-15153A | PLATE DOOR-REF LEFT;RF8000B,GL-SGLCC,T0. |
| DA61-14537B | PLATE DOOR-REF RIGHT;RF7000AC,EGI-SECC,T |
| DA61-15160A | PLATE DOOR-REF RIGHT;RF8000B,GL-SGLCC,T0 |
| DA61-15139A | PLATE EVAP-FRE LEFT;RF8000B,AL,T0.6, |
| DA61-15140A | PLATE EVAP-FRE RIGHT;RF8000B,AL,T0.6, |
| DA61-13961A | PLATE HEATER;RF9000K,A1100,T1,A1100P-H14 |
| DA61-11675A | PLATE INS-FRE;RF8000MC,GL-SGLCC,T0.3 |
| DA61-11737C | PLATE LEVER;RF8000MC,STS304,T0.5,REAL |
| DA61-10700B | PLATE STEEL;AL,B10%,T0.08,W16,LA+CE A300 |
| DA01-02040A | PLATE STEEL;RF8000B/BC,GL-SGLCC,L1800,0. |
| DA61-10696A | PLATE-CORNER;AL,T1.5 |
| DA61-05842A | PLATE-DRAIN FRE;AW3-PJT,GL-SGLCC,T0.3, |
| DA61-08673A | PLATE-EVAP REF L;ROMANEE CONTI,A1100,T0. |
| DA61-08674A | PLATE-EVAP REF R;ROMANEE CONTI,A1100,T0. |
| DA61-08302A | PLATE-FRENCH;MOUTON,EGI-SECC,T0.8,THAI S |
| DA61-10371A | PLATE-UP FRONT;ROMANEE CONTI,AL,T0.3,ALD |
| DA67-90108D | PLUG COMP TUBE;SILICON RUBBER,-,-,-,-,OD |
| 0204-005065 | POLYOL;KONIX DP-1950S,POLYEHER POLYOL,90 |
| 0204-009079 | POLYOL;RST-530,ROH,100% |
|
|
POWER CORD-AT |
| 2007-000033 | R-CHIP |
| 2007-000279 | R-CHIP |
| 2007-000293 | R-CHIP |
| 2007-000297 | R-CHIP |
| 2007-000312 | R-CHIP |
| 2007-000352 | R-CHIP |
| 2007-000476 | R-CHIP |
| 2007-000571 | R-CHIP |
| 2007-000762 | R-CHIP |
| 2007-000928 | R-CHIP |
| 2007-000938 | R-CHIP |
| 2007-000944 | R-CHIP |
| 2007-001297 | R-CHIP |
| 2007-007306 | R-CHIP |
| 2007-007336 | R-CHIP |
| 2007-007699 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-008175 | R-CHIP |
| 2007-008231 | R-CHIP |
| 2007-008269 | R-CHIP |
| 2007-008354 | R-CHIP |
| 2007-008485 | R-CHIP |
| 2007-008779 | R-CHIP |
| 2007-008791 | R-CHIP |
| 2007-010245 | R-CHIP;0.01OHM,1%,2W,TP,6432 |
| 2007-012276 | R-CHIP;0.09OHM,1%,2W,TP,6432,T0.55,GENER |
| DA61-08818B | RAIL SLIDE-MIDDLE LEFT;RF8000BC,CR-SPCC, |
| DA61-08819B | RAIL SLIDE-MIDDLE RIGHT;RF8000BC,CR-SPCC |
| DA61-07193A | RAIL-BALL A;AW-PJT,STS304,T1.5,- |
| DA61-02264A | RAIL-BRACKET,RIVET;HNR3117/XAA,C3771BE,- |
| DA61-08758A | RAIL-CENTER MEMBER LOW;AW2-CD,SCP1,T2, |
| DA61-08761A | RAIL-CENTER RETAINER;AW2-CD,PP,NATURAL,B |
| DA61-09208B | RAIL-FRE UP LEFT , RF8000B,NEW,HIPS,NATURA |
| DA61-09204B | RAIL-FRE UP RIGHT , RF8000B,NEW,HIPS,NATUR |
| DA61-08759A | RAIL-INNER MEMBER LOW;AW2-CD,SCP1,T2,Z |
| DA61-15178A | RAIL-LEFT |
| DA61-14528B | RAIL-MIDDLE LEFT;RF9000AC,HIPS,COOL WH |
| DA61-08757A | RAIL-OUTER MEMBER LOW;AW2-CD,SCP1,T2.3, |
| DA61-08760A | RAIL-OUTER RETAINER;AW2-CD,PP,NATURAL,BJ |
| DA61-14469A | RAIL-REF LOW LEFT;RF9000A,HIPS,COOL WHIT |
| DA61-14468A | RAIL-REF LOW RIGHT;RF9000A,HIPS,COOL WHI |
| DA61-07937A | RAIL-SELF CLOSING BODY L;MOUTON,POM,BLAC |
| DA61-07961A | RAIL-SELF CLOSING BODY R;MOUTON,POM,BLAC |
| DA61-08013A | RAIL-SELF CLOSING GUIDE PIN;MOUTON,PA66, |
| DA61-07938A | RAIL-SELF CLOSING GUIDE;MOUTON,PA66,BLAC |
| DA61-07939A | RAIL-SELF CLOSING LOCK GUIDE L;MOUTON,PA |
| DA61-07955A | RAIL-SELF CLOSING LOCK GUIDE R;MOUTON,PA |
| DA61-08012A | RAIL-SELF CLOSING SPRING;MOUTON,STS304,0 |
| DA61-08818A | RAIL-SLIDE LOW L |
|
|
RAIL-SLIDE LOW R |
| DA67-04727B | REFLECTOR;AW3,4_FACE LIFT,ABS, |
| DA61-10849A | REINF CABI-MIDDLE FRONT;RF9000K,PO-SPHC, |
| DA61-14359A | REINF CABI-UP;RF9900T,PO-SPHC,T2, |
| DA61-13467A | REINF DOOR-REF LOW;RF9000R,PO-SPHC,T2,OU |
| DA61-14560A | REINF DOOR-REF;RF7000AC,PO-SPHC,T2,L782, |
| DA61-01376T | REINF DOOR-REF;RH9000M,HGI-SGHC,T1.4,L69 |
| DA61-15299A | REINF DOOR;RF8000B,ABS,HG-0760GP,NATUR |
| DA61-15158A | REINF HANDLE;RF8000B,GI-SGCC,T1.6, |
| DA61-15065A | REINF HANGER;AW2-F/L,ABS,HG-0760GP,NAT |
| DA71-00025B | REINF-BOTT FRAME |
| DA61-05923A | REINF-EARTH;HGI-SGHC,T3 |
| DA61-03206A | REINF-GUIDE FRENCH;AW-PJT,HGI-SGHC,T1 |
| DA61-04910A | REINF-HINGE UP R;HAEMIL-PJT,GI-SGCC,T3 |
| DA71-10490C | REINF-HINGE UPP |
| DA61-13408A | REINF-LOW RIGHT;RF9000R,PO-SPHC,T2 |
| DA61-03744A | REINF-PANEL FRE |
| DA61-14659A | REINF-REF;RF7000AC,GI-SGCC,T2,BSC, |
| DA61-14660A | REINF-REF;RF9000A,GI-SGCC,T1.6,BSC |
| DA61-13582A | REINF-UP LEFT;FDSR,PO-SPHC,T3 |
|
|
RELAY-MINIATURE |
| 0103-007539 | RESIN PP;SSPP-640/BLACK,BLACK,BK0001,REC |
| 0103-002817 | RESIN-ABS |
| 2802-001211 | RESONATOR-CERAMIC |
| 6130-000386 | RETAINER |
| 6130-000387 | RETAINER |
|
|
ROLLER-AUTO CLOSE |
| DA97-22036A | ROLLER-FRE |
|
|
ROLLER-TRAY FRE UPP |
| DA66-00276B | ROLLER-VEG |
| DA66-01339A | ROLLER;POM,OD29,NATURAL |
|
|
RUBBER-CAP HOSE |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
|
|
SCREW-SPECIAL |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000234 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000244 | SCREW-TAPPING |
| 6002-000473 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000643 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-001547 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000581 | SCREW-TAPPING;SWRCH18A,ZPC(WHT),L16,M4,F |
| 6002-001521 | SCREW-TAPPING;TH,+,NO,2S,M3,L10,PASS,STS |
| DA62-05853A | SEAL CASE LAMP-TOP;RF8000B/BC,PU FOAM,T1 |
| DA62-05622A | SEAL CASE-HEATER;RF9000A,PU FOAM,T5,L150 |
| DA62-06129A | SEAL COND |
| DA62-06129C | SEAL COND |
| DA62-06130A | SEAL COND |
| DA62-05898A | SEAL COVER-WATER;RF8000B,PE FOAM,T5,W66, |
| DA62-01129B | SEAL CUTT |
| DA62-01134C | SEAL CUTT |
| DA62-01134E | SEAL CUTT |
| DA62-01134H | SEAL CUTT |
| DA62-01135R | SEAL CUTT |
| DA62-01136A | SEAL CUTT |
| DA62-01136S | SEAL CUTT |
| DA62-01136T | SEAL CUTT |
| DA62-01137V | SEAL CUTT |
| DA62-01138D | SEAL CUTT |
| DA62-01139C | SEAL CUTT |
| DA62-01139D | SEAL CUTT |
| DA62-01140D | SEAL CUTT |
| DA62-01140F | SEAL CUTT |
| DA62-01140Z | SEAL CUTT |
| DA62-01141B | SEAL CUTT |
| DA62-01141D | SEAL CUTT |
| DA62-01141F | SEAL CUTT |
| DA62-01141H | SEAL CUTT |
| DA62-01141M | SEAL CUTT |
| DA62-01141Q | SEAL CUTT |
| DA62-01141X | SEAL CUTT |
| DA62-01141Z | SEAL CUTT |
| DA62-01142B | SEAL CUTT |
| DA62-01142F | SEAL CUTT |
| DA62-01142H | SEAL CUTT |
| DA62-01142L | SEAL CUTT |
| DA62-01142Q | SEAL CUTT |
| DA62-01142R | SEAL CUTT |
| DA62-01142S | SEAL CUTT |
| DA72-00033B | SEAL CUTT FOAM PE |
| DA62-01603V | SEAL CUTT SPONGE |
| DA62-00110E | SEAL CUTT SPONGE;ROMANEE CONTI,PU FOAM,T |
| DA62-01492Z | SEAL CUTT-FOAM PE |
| DA72-60106V | SEAL CUTT-FOAM PE |
| DA62-02351E | SEAL CUTT-FOAM PE;ARAM09,PE FOAM,T10,W30 |
| DA62-03033R | SEAL CUTT-FOAM PE;HAEMIL,PE FOAM,T3,W20 |
| DA62-02589W | SEAL CUTT-FORM PE;ARAM10,PE FOAM,T10,W30 |
| DA72-60040C | SEAL CUTT-RUBBER;RF6000T,RUBBER,T4,W45,L |
| DA72-60267Q | SEAL CUTT-SPONGE;-,PU FOAM,T20,W20,L1000 |
| DA62-01921A | SEAL CUTT;GUGGENHEIM,PE OPEN CELL,T5,W70 |
| DA62-01139A | SEAL CUTT;PE OPEN CELL,T3,W10,L1000,OJC- |
| DA62-01140B | SEAL CUTT;PU FOAM,T3,W10,L1000,V-0,INCOM |
| DA62-01135M | SEAL CUTT;RB7300T,PE FOAM,T5,W10,L1000 |
| DA62-01140Y | SEAL CUTT;RF8000A,PU FOAM,T5,W10,L1000,- |
| DA62-02480E | SEAL DRAIN , RF8000B,PU FOAM,T10,W120,L75, |
| DA62-05863A | SEAL DUCT-FRE UP;RF8000B,PE OPEN CELL,T5 |
| DA62-04262A | SEAL DUCT;AW4-4D,PU FOAM,T10,NATURAL,DIN |
| DA62-04263A | SEAL DUCT;AW4-4D,PU FOAM,T7,DINKING |
| DA62-05690A | SEAL FIXER HOUSING;RF9000A,PU FOAM,T3,L8 |
| DA62-06177A | SEAL GUIDE;RF8000,PU FOAM,T7,W100,L118, |
| DA62-05903A | SEAL GUIDE;RF8000B/BC,PU FOAM,T5,L100, |
| DA62-05877A | SEAL PARTITION-LOW;RF8000BC,PE OPEN CELL |
| DA62-05628B | SEAL PARTITION-SIDE;RF8000B/BC,AL/NONWOV |
| DA62-05890A | SEAL PARTITION-SIDE;RF8000BC,AL/NONWOVEN |
| DA62-05865A | SEAL PIPE;RF8000B,PU FOAM,T15,W5, |
| DA62-04261A | SEAL SUPPORT TUBE FILTER-REAR;AW4 4DOOR, |
| DA62-05672A | SEAL TUBE-REAR;RF9000A,PU FOAM,T10,W70,L |
| DA62-05889A | SEAL TUBE;RF8000B,PE FOAM,T6,W4,L200, |
| DA62-00232B | SEAL WATER HOSE;RF9000A,PU FOAM,T10,DINK |
| DA62-05899A | SEAL WATER;RF8000B,PE FOAM,T5,W50,L85, |
| DA62-05855A | SEAL-B;RF8000B/BC,PU FOAM,T5,W90,L196, |
| DA62-01406C | SEAL-CABI MID FRONT;ALL,AL/PE FOAM,T5,W2 |
| DA62-02534B | SEAL-CASE HEATER FRENCH;OPUS1,PU FOAM,T1 |
| DA62-02523A | SEAL-CASE HOUSING CONV LINER;AW3,LEX FOA |
| DA62-00091A | SEAL-CUTT FOAM, PE |
| DA72-00238B | SEAL-DRAIN HOSE |
| DA62-02455A | SEAL-DRAIN HOSE;RF9000K,PU FOAM,T7,W120, |
| DA62-03171A | SEAL-FIXER HOUSING FRE;OPUS1,PE FOAM,T3, |
| DA62-03262A | SEAL-FIXER HOUSING VALVE WATER;AW2-11,PU |
| DA62-05678A | SEAL-FIXER TUBE;RF9000A/AC, RF7000AC,PU |
| DA62-05606A | SEAL-GROMMET FIXER;RF9000A,PU FOAM,T3,W8 |
| DA62-01500A | SEAL-GUIDE FRENCH;AW-PJT,PE FOAM,T2,DING |
| DA62-02864A | SEAL-MID FRONT;AW3-PJT,PU FOAM,T5,+AL,DI |
| DA62-02684A | SEAL-MID FRONT;AW3-PJT,PU FOAM,T5,W41.4, |
| DA62-00495A | SEAL-MOTOR DAMPER |
| DA72-00387A | SEAL-PIPE, WATER |
| DA62-04159A | SEAL-PLATE DOOR;ROMANEE CONTI,PU FOAM,T5 |
| DA62-00079A | SEAL-SUPPORT MOTOR |
| DA62-03420A | SEAL-SUPT TUBE FILTER;AW2-11,PE FOAM,T5 |
| DA62-00959A | SEAL-TUBE WATER |
| DA62-02536A | SEAL;FDSR,LEX FOAM,T15,NON-COMBUSTIBLE S |
| DA62-05854A | SEAL;RF8000B/BC,PU FOAM,T5,W160,L110, |
| DA32-00088A | SENSOR HUMIDITY;5V,0~100%RH,4.5%,100MM,4 |
|
|
SENSOR TEMP |
|
|
SENSOR TEMP |
|
|
SENSOR TEMP |
|
|
SENSOR TEMP |
|
|
SENSOR TEMP |
| DA32-00075D | SENSOR-CAPACITANCE;5V,NEO VICTORY GRAY,U |
| DA32-00063B | SENSOR-ELECTRODE;5V,CLIPPING TYPE,UL1007 |
| DA66-00437H | SHAFT |
| DA66-00733B | SHAFT |
| DA66-01048A | SHAFT HINGE-A;FOOD SHOW CASE,SWRCH10A, |
| DA66-01549A | SHAFT HINGE-A;RF9000A,HSWR,L191.2,OD3.0 |
| DA66-00960A | SHAFT HINGE-UPP;AW4-PJT,CR-SPCC,ID18.0,T |
|
|
SHAFT-CASTER |
| DA66-01562A | SHAFT-HANDLE;RF8000B,HSWR,L170.6, |
| DA66-00793A | SHAFT-LEG FRONT |
| DA66-01561A | SHAFT;RF8000B,ABS,DARK GRAY,D8,H |
| DA66-01368A | SHAFT;RF9000R,ZNDC,L429,D8,ZNDC2, LEFT |
| DA63-07282A | SHEET ABS-PANEL REF;RF8000B,ABS,T1.7,QU- |
| DA63-09241A | SHEET-REF;AW4-CD,ABS,T3.6,QU-0191S,COOL |
| DA67-05162A | SHELF FOLDER-FRONT;RF9000AC,PP,COOL WHIT |
| DA67-05391A | SHELF FOLDER-REAR;RF8000BC,PP,COOL WHITE |
| DA67-05153A | SHELF VEGETABLE-LOW;RF9000AC,HIPS,COOL W |
| DA67-05390A | SHELF-REF FIX , RF8000BC,PP,COOL WHITE,B |
|
|
SHIM-HINGE UPP |
| DA66-01560A | SLIDER HANDLE;RF8000B,POM,CREAMY STS,K |
| 2007-007107 | SMG PART |
| 2007-007136 | SMG PART |
| 2007-007139 | SMG PART |
| 2007-007142 | SMG PART |
| 2007-007309 | SMG PART |
| 2007-007311 | SMG PART |
| 2007-007312 | SMG PART |
| 2007-007313 | SMG PART |
| 2007-007316 | SMG PART |
| 2007-007317 | SMG PART |
| 2007-007318 | SMG PART |
| 2007-007319 | SMG PART |
| 2007-007528 | SMG PART |
| 2007-007589 | SMG PART |
| 2007-007590 | SMG PART |
| 2007-007627 | SMG PART |
| 2007-007671 | SMG PART |
| 2007-007766 | SMG PART |
| 2007-007861 | SMG PART |
| 2007-007943 | SMG PART |
| 2007-008117 | SMG PART |
| 2203-000233 | SMG PART |
| 2203-000438 | SMG PART |
| 2203-000489 | SMG PART |
| 2203-000585 | SMG PART |
| 2203-000714 | SMG PART |
| 2203-000812 | SMG PART |
| 2203-007392 | SMG PART |
| 2203-007393 | SMG PART |
| 2203-007795 | SMG PART |
| 2203-007809 | SMG PART |
| DA41-00867F | SMG PART |
| DA64-07585C | SMG PART |
| DA97-23018G | SMG PART |
| DA97-23067G | SMG PART |
| DA97-24990A | SMG PART |
| DA97-25035D | SMG PART |
| DA02-00202A | SOLDER RING;ID6.4,91.75CU/6.25P/2.0AG,NU |
| DA02-00202D | SOLDER RING;ID:2.1,91.75CU/6.25P/2.0AG,N |
| DA02-00202H | SOLDER RING;ID:3.55,91.75CU/6.25P/2.0AG, |
| DA02-00202C | SOLDER RING;ID:7.99,91.75CU/6.25P/2.0AG, |
| DA02-00202F | SOLDER RING;YSS26,D0.6,26AG/41CU/33ZN,NU |
| 0202-001338 | SOLDER-BAR |
| 0202-001976 | SOLDER-CREAM;LST-309M-K21 (PWM-118),D20~ |
| 0202-001463 | SOLDER-WIRE |
| 0204-005794 | SOLVENT;S-1000,(CH3)2CHOH,100%,0.79 |
| DA61-08315A | SPRING ETC-ETC CAP GUIDE |
| DA61-05782A | SPRING ETC-INNER;SSEDA,STS304,0.8,3.9,5. |
| DA61-05783A | SPRING ETC-SHAFT;SSEDA,STS304,0.5,5.2,6. |
| DA61-08314B | SPRING FRENCH;RFH920G,STS304 |
| DA61-15159A | SPRING HANDLE;RF8000B,STS304,ID5.5,OD6.5 |
| DA61-13565A | SPRING LEVER;RF9000R,STS304,ID0.8,OD8,LE |
| 3502-001087 | SSR;DC12V,2A,9.6-25MV,-30TO+80C,0.028A,A |
| 0101-002926 | STEEL PLATE;GI,SGCC,0.35MM,290MM,Z12,NC |
| DA61-13384A | STOPPER DOOR REF LOW |
| DA61-13422A | STOPPER DOOR REF LOW |
|
|
STOPPER DOOR-REF |
| DA61-15185A | STOPPER ROLLER;RF8000,POM,K300,NATURAL |
| DA61-10712B | STOPPER ROLLER;RF9000K,SWRCH10A,VE |
| DA61-15184A | STOPPER-FRE;RF8000,POM,K300,NATURAL, |
| DA61-06756A | STOPPER-RAIL MID;ARAM10-PJT,RUBBER,OD12, |
|
|
SUPPORT DOOR-CLOSE |
|
|
SUPPORT ICE MAKER |
| DA61-09179A | SUPPORT TUBE;AW4 F/S,PP,MU30HP,NATURAL |
| DA61-10293A | SUPPORT WIRE-UP;PP,T1.5,BJ750,NATURAL |
|
|
SUPPORT-CIRCUIT MOTOR |
| DA61-15290A | SUPPORT-REF , RF8000B-3D-FS,PO-SPHC,T4, |
| 4715-001217 | SURGE ABSORBER;3600V,20%,3000A,AXIAL |
|
|
SWITCH PRESSURE |
|
|
SWITCH REED |
|
|
SWITCH REED |
| DA34-00043M | SWITCH REED |
|
|
SWITCH-MICRO |
| DA02-10014A | TAPE ETC-AL |
| DA02-10004G | TAPE ETC-PAPER |
| DA02-10013B | TAPE-AL |
| 0203-000444 | TAPE-AL FOIL |
| 0203-001152 | TAPE-AL FOIL |
| 0203-006491 | TAPE-AL FOIL;AL,T0.03,W20,N/A,SILVER |
| DA02-10015A | TAPE-BINDER |
| 0203-001810 | TAPE-COTTON |
| DA02-10007A | TAPE-DOUBLE FACE |
| 0203-006381 | TAPE-DOUBLE FACE;T0.4,W15,L33M,WHITE |
| DA02-10005A | TAPE-MASKING |
| DA02-10010A | TAPE-OPP |
| 0203-006630 | TAPE-OPP MASKING;OPP,T0.065,W50,WHITE,CA |
| 0203-001308 | TAPE-PAPER |
| DA02-10004C | TAPE-PAPER |
| DA02-10150A | TAPE-PAPER |
| DA02-10012A | TAPE-PET |
| 0203-001367 | TAPE-POLY |
| 0203-001812 | TAPE-POLY |
| 0203-006796 | TAPE-POLY |
| 0203-006800 | TAPE-POLY |
| 0203-000338 | TAPE-POLY;OPP,T0.072,W35,L50M,BLUE |
| 0203-006795 | TAPE-POLY;PP,GRADE 64294,T0.11,W50,WHITE |
| 0203-006797 | TAPE-POLY;PP,T0.11,W25,N/A,WHITE,TPP(TEN |
| 0203-006329 | TAPE-SINGLE FACE;COTTON,T0.24,W40,L50M,W |
| 0203-001060 | TAPE-SINGLE FACE;OPP,T0.065,W72,N/A,CLEA |
| 0203-007366 | TAPE-SINGLE FACE;PET,T0.037,W130,N/A,CLE |
| 0203-006521 | TAPE-SINGLE FACE;PET,T0.037,W80,N/A,CLEA |
| DA02-00038A | TETRAFLUOROETHANE |
| 1404-001544 | THERMISTOR-NTC;10KOHM,1%,3435K,3.7MWC,TP |
| 1404-001872 | THERMISTOR-PTC |
|
|
THERMO FUSE-ASSEMBLY |
| DA64-05949E | TOP TABLE;RF9000A,ABS,INOX GRAY,NO PRINT |
| 0506-000175 | TR-ARRAY |
| 0504-001080 | TR-DIGITAL |
| 0502-001250 | TR-POWER |
| 0501-000465 | TR-SMALL SIGNAL |
| 0501-000467 | TR-SMALL SIGNAL |
| DA26-00058C | TRANS SWITCHING;AC85-265V,3400MA,200MA,1 |
| DA63-12053A | TRAY DRAIN-WATER;RF9000C,PP,T2,HB,INNER |
| DA63-11569A | TRAY DRAWER-FRE , RF80000BC,PP,T2.5,COOL |
| DA63-11232A | TRAY ICE;RF9000A,PP,T1,NATURAL |
| DA63-09323A | TRAY ICE;RS8000NC,PP,T1,NATURAL |
| DA63-09788A | TRAY WATER;RF6000T,HIPS,T2.5,COOL WHITE |
| DA64-06367B | TRIM COVER-REF;RF9000A,HIPS,S834S1,NEO V |
| DA64-06448A | TRIM DOOR-LOW;RQ9500T(B),ABS,HG-0760GP,I |
| DA64-06222A | TRIM DOOR-REF;RF9000R(B),ABS,HG-0760GP,I |
| DA64-07001A | TRIM DOOR-UP;RF9000A,ABS,HG-0760GP,INO |
| DA64-03784A | TRIM SHELF |
| DA64-06487B | TRIM SHELF-FRONT;RF8000B,ABS,HG-0760GP,T |
| DA64-05903E | TRIM SHELF-REAR;RF8000B,HIPS,S834S1,T5,C |
| DA64-04915E | TRIM SHELF-REF FRONT;RF9000R,ABS,HG-0760 |
| DA64-04915F | TRIM SHELF-REF FRONT;RF9000R,ABS,HG-0760 |
| DA64-06490A | TRIM SHELF-REF;RF9000A/AC,ABS,HG-0760GP, |
| DA62-05881B | TUBE , RF8000B,HDPE,OD5.3,L80,ID4.2, |
| DA62-01266B | TUBE PVC |
| DA62-04606B | TUBE-AL;AL,L520,T0.34, LA+CE |
| DA62-02414A | TUBE-FITTING L |
| DA62-04299A | TUBE-LEFT;AW-CD,LDPE,L0.1,MB9500,NAT |
| DA62-05651J | TUBE;-,HDPE,OD16.2,L175,ID15,HOTME |
| DA62-05651E | TUBE;PO,OD16.2,L120,ID15,HOTMELT(EVA), B |
| DA62-06054J | TUBE;RF9000,PO,OD11.6,L180,ID10.2, |
| DA62-06054K | TUBE;RF9000,PO,OD11.6,L200,ID10.2, |
| DA62-06178E | TUBE;RF9000,PO,OD6.6,L100,ID5.7, |
|
|
VALVE STEP |
| DA62-04030D | VALVE WATER;AC110-127V,RF6000T,L-WIRE, |
|
|
VALVE-FITTING NUT |
|
|
VALVE-FITTING PU |
| 1405-001239 | VARISTOR;680V,560VDC,6000A,17X10MM,TP,11 |
| 4709-002960 | W-LAN MODULE |
| DA69-01982Q | WRAP VINYL , REF_ALL,LDPE,T0.05,W60,L1000, |
| DA69-01982K | WRAP VINYL;ALL MODEL,LDPE,T0.04,W130,ROL |
| DA69-01982F | WRAP VINYL;LDPE,T0.04,W130,ROLL,ADHESIVE |
| DA69-01981Q | WRAP VINYL;LDPE,T0.04,W200,ROLL,ADHESIVE |
| DA69-01981C | WRAP VINYL;LDPE,T0.04,W40,ROLL,ADHESIVE |
| DA69-01981X | WRAP VINYL;LDPE,T0.04,W400,ROLL,ADHESIVE |
| DA69-01981E | WRAP VINYL;LDPE,T0.04,W50,ROLL,ADHESIVE |
| DA69-01981R | WRAP VINYL;LDPE,T0.04,W60,ROLL,ADHESIVE |
| DA69-01982D | WRAP VINYL;LDPE,T0.04,W600,ROLL,ADHESIVE |
| DA69-01981H | WRAP VINYL;LDPE,T0.04,W90,ROLL,ADHESIVE |
| DA69-01982G | WRAP VINYL;LDPE,T0.04,W90,ROLL,ADHESIVE |
| DA69-01982Z | WRAP VINYL;REF_ALL,LDPE,T0.05,W200,L1000 |
| DA69-02483F | WRAP VINYL;REF_ALL,LDPE,T0.05,W30,L1000, |
| DA69-01982U | WRAP VINYL;REF_ALL,LDPE,T0.05,W90,L1000, |
| DA69-02254A | WRAP VINYL;REF_ALL,LDPE,T0.095,W30,L1000 |
| DA61-16266A | |
| DA91-05462T | |
| DA91-06106C | |
| DA93-01671A | |
| DA92-01773A | |
| DA94-09410A |
