Manufacturer
Samsung
Model Number
RF24BB620012AA
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 0201-003423 | ADHESIVE-HM;DJ-391,WHITE,3700C |
| 0201-003578 | ADHESIVE-HM;HT-472,TRANSPARENT |
| 0201-003450 | ADHESIVE-SEALANT;LOCKSEAL7700, |
| 0201-003797 | ADHESIVE-SEALANT;LOCKSEAL7700, |
| DA61-14455B | ANGLE SHELF-REF MIDDLE |
| DA97-23189G | ASSEMBLY CABI FRAME , RF8000BC |
| DA97-12556U | ASSEMBLY CABI-BOTTOM FRONT;RF8 |
| DA97-23014A | ASSEMBLY CABI-BOTTOM REAR , RF |
| DA97-23599A | ASSEMBLY CAP DOOR-FRE LOW;RF80 |
| DA97-23598A | ASSEMBLY CAP DOOR-FRE UP;RF800 |
| DA97-23597A | ASSEMBLY CAP DOOR-REF LOW RIGH |
| DA97-23596A | ASSEMBLY CAP DOOR-REF UP RIGHT |
|
|
ASSEMBLY CAP-DRAIN |
| DA97-23063A | ASSEMBLY CASE FILTER |
| DA97-08006L | ASSEMBLY CASE FILTER;H920G |
|
|
ASSEMBLY CASE ICE |
|
|
ASSEMBLY CASE ICE |
| DA97-23081A | ASSEMBLY CASE ICE |
|
|
ASSEMBLY CASE INNER |
| DA97-22588G | ASSEMBLY CASE PBA-MAIN;RF6500C |
| DA97-23041A | ASSEMBLY CASE VEG-LOW |
| DA97-15972C | ASSEMBLY CONDENSER-MAIN |
| DA97-21005W | ASSEMBLY COVER CONTROL |
| DA97-22974C | ASSEMBLY COVER EVAP-FRE |
| DA97-21951B | ASSEMBLY COVER LAMP-REF |
| DA97-23420A | ASSEMBLY COVER PCB-PANEL |
| DA97-23225A | ASSEMBLY COVER PIPE WATER |
| DA97-23046A | ASSEMBLY COVER RAIL-LEFT |
| DA97-23047A | ASSEMBLY COVER RAIL-RIGHT |
| DA90-13616A | ASSEMBLY DAMPER;RF8000B.3D,MET |
| DA82-03467A | ASSEMBLY DOOR FOAM-FRE |
| DA93-01319A | ASSEMBLY DOOR SUB-FRE DOOR MOD |
| DA93-01332A | ASSEMBLY DOOR SUB-REF RIGHT DO |
| DA97-23384A | ASSEMBLY DRAIN HOSE-REF;RF8000 |
| DA96-01509A | ASSEMBLY EVAP-FRE EVAP MODULE |
| DA96-01002C | ASSEMBLY EVAP-REF EVAP MODULE |
| DA97-20572A | ASSEMBLY FIXER-UP |
| DA97-23074A | ASSEMBLY FRENCH |
|
|
ASSEMBLY GASKET-FRE |
|
|
ASSEMBLY GASKET-REF |
| DA97-21912F | ASSEMBLY GUARD-REF |
| DA97-21913C | ASSEMBLY GUARD-REF LOW |
| DA97-23268C | ASSEMBLY GUARD-REF LOW |
| DA97-21916C | ASSEMBLY GUARD-REF UP |
|
|
ASSEMBLY HINGE UP LEFT |
|
|
ASSEMBLY HINGE UP RIGHT |
| DA90-13627A | ASSEMBLY ICE MAKER;RF8000B,DUA |
| DA97-24137A | ASSEMBLY ICE PACK KIT;RF5000C, |
|
|
ASSEMBLY LAMP LED |
| DA96-01119E | ASSEMBLY LAMP LED |
| DA97-23617A | ASSEMBLY LEVER HANDLE |
| DA97-23030A | ASSEMBLY LEVER HANDLE , RF8000 |
|
|
ASSEMBLY LEVER-AUTO CLOSE |
| DA94-06475H | ASSEMBLY LINER;RF8000BC,3D,AUT |
| DA92-01482B | ASSEMBLY MICOM , RF8000B 3D,MA |
|
|
ASSEMBLY MODULE |
|
|
ASSEMBLY MODULE |
| DA90-13630A | ASSEMBLY OUTER;RF8000B,GRAY,BA |
| DA97-22871B | ASSEMBLY PIPE CONNECT-B |
| DA97-22983A | ASSEMBLY PIPE HOT , RF8000BC,3 |
|
|
ASSEMBLY PIPE WATER ICE |
|
|
ASSEMBLY PIPE WATER ICE |
| DA97-23037A | ASSEMBLY PLATE DOOR-FRE , RF80 |
| DA97-23632A | ASSEMBLY PLATE DOOR-FRE;RF8000 |
| DA97-23033A | ASSEMBLY PLATE DOOR-REF LEFT;R |
| DA97-23032A | ASSEMBLY PLATE DOOR-REF RIGHT; |
| DA97-23633A | ASSEMBLY PLATE DOOR-REF RIGHT; |
|
|
ASSEMBLY RAIL |
| DA97-21876A | ASSEMBLY RAIL MIDDLE LEFT |
| DA97-13261D | ASSEMBLY RAIL-LOW LEFT |
| DA97-23027B | ASSEMBLY REINF-CABI FLANGE UP; |
| DA97-06973A | ASSEMBLY REINF-GUIDE FRENCH;AW |
| DA97-16179C | ASSEMBLY REINF-MIDDLE FRONT;RF |
| DA97-19988A | ASSEMBLY ROLLER;RF9000K,29 |
| DA97-23065A | ASSEMBLY SEAL CABI , RF8000B,F |
| DA97-23050A | ASSEMBLY SHELF PANTRY |
| DA97-21895A | ASSEMBLY SHELF QUICK SPACE |
| DA97-21902L | ASSEMBLY SHELF VEG-LOW |
| DA97-21902M | ASSEMBLY SHELF VEG-LOW , RF800 |
| DA97-21898A | ASSEMBLY SHELF-REF UP |
| DA97-23024A | ASSEMBLY STOPPER |
| DA97-20372B | ASSEMBLY SUPPORT-FRONT , RF800 |
| DA97-23043A | ASSEMBLY SUPPORT-MIDDLE |
| DA97-22441B | ASSEMBLY SUPPORT-MIDDLE;RF8000 |
|
|
ASSEMBLY TOP TABLE |
| DA97-15978C | ASSEMBLY TRAY DRAIN WATER |
| DA97-23028A | ASSEMBLY TRAY DRAWER |
| DA97-23064G | ASSEMBLY URETHANE CABI , RF800 |
| DA97-23626A | ASSEMBLY URETHANE DOOR-FRE;RF8 |
| DA97-23627A | ASSEMBLY URETHANE DOOR-REF;RF8 |
| DA96-01466A | ASSEMBLY WIRE HARNESS TOP |
| DA96-01508C | ASSEMBLY WIRE HARNESS-CABI , R |
| DA96-01507G | ASSEMBLY WIRE HARNESS-DOOR;RF8 |
| DA39-00429D | ASSEMBLY WIRE HARNESS-EARTH |
| DA97-23017A | ASSY CABI FRAME-REAR;RF8000B/B |
| DA97-21261H | ASSY CASE WATER FILTRE |
| DA97-12557K | ASSY CHASSIS COMP;RF6000T,GI-S |
| DA97-22973D | ASSY COVER EVAP |
| DA97-20085A | ASSY DRAIN HOSE-FRE;RFF310N,HD |
| DA97-11489B | ASSY FIXER HOUSING-VALVE WATER |
| DA97-22252A | ASSY FIXER-FRE;RF7000AC |
| DA97-22257B | ASSY FIXER-UP;RF9000A,BLACK,RE |
| DA97-22978A | ASSY FIXER;RF8000B,LOKRING PIP |
| DA97-21952A | ASSY GROMMET;RF9000A,FIXER PIP |
| DA97-14866C | ASSY GUIDE HOSE-BOTTOM;AW3-14, |
| DA97-25013A | ASSY HINGE-MIDDLE LEFT;RF9000D |
| DA97-25014A | ASSY HINGE-MIDDLE RIGHT;RF9000 |
| DA59-00392A | ASSY ICE MAKER-ICE MODULE;SWAA |
| DA97-21804C | ASSY ICE MAKER;RF8000BC,BRACKE |
| DA99-03258A | ASSY LABEL-INSTALLER CHECK LIS |
| DA92-01298C | ASSY PBA MODULE-DISPLAY;LED DI |
| DA97-15974A | ASSY PIPE CONNECT-B;PFC,-,-,-, |
| DA97-15975A | ASSY PIPE CONNECT;PFC,-,-,-,-, |
| DA97-23066B | ASSY TAPE CABI;RF8000B,FS,BSC |
| DA97-12475A | ASSY-GROMMET FRENCH;MOUTON |
| 6902-002371 | BAG PE;HDPE,T0.015,W200,L300,T |
| 6902-000336 | BAG ZIPPER |
| 3301-002113 | BEAD-SMD;470 OHM/100MHZ 470 OH |
|
|
BOLT-ETC |
| 6011-001694 | BOLT-ETC |
|
|
BOLT-HEX |
|
|
BOLT-HEX |
|
|
BOLT-HEX |
| DA61-15475A | BRACKET CONDENSER-LOW;RF9000B, |
| DA61-09703A | BRACKET STEP VALVE;RT6500M,PP, |
| DA61-04736A | BRACKET-BOTT REAR;AW-PJT,GI-SG |
| 2401-003069 | C-AL |
| 2402-001254 | C-AL, SMD |
| 2402-001268 | C-AL, SMD |
| 2402-001303 | C-AL, SMD |
| 2402-001398 | C-AL, SMD |
| 2401-004721 | C-AL;680UF,20%,250V,BK,30X30MM |
| 2401-004553 | C-AL;820UF,20%,25V,TP,10X20MM, |
| 2203-002285 | C-CER, CHIP |
| 2203-005135 | C-CER, CHIP |
| 2203-005968 | C-CER, CHIP |
| 2203-006158 | C-CER, CHIP |
| 2203-006377 | C-CER, CHIP |
| 2203-007306 | C-CER, CHIP |
| 2203-007456 | C-CER, CHIP |
| 2203-007544 | C-CER, CHIP |
| 2203-008315 | C-CER, CHIP |
| 2203-006457 | C-CER,CHIP |
| 2203-010495 | C-CER,CHIP;2.2UF,10%,25V,X7R,T |
| 2203-010033 | C-CER,CHIP;220NF,10%,25V,X5R,T |
| 2203-010496 | C-CER,CHIP;4.7UF,10%,25V,X7R,T |
| 2201-002429 | C-CERAMIC,DISC;10NF,+80-20%,20 |
| 2201-002709 | C-CERAMIC,DISC;33PF,5%,1000V,S |
| 2201-002711 | C-CERAMIC,DISC;470PF,10%,400VA |
| 2201-002335 | C-CERAMIC,DISC;68PF,10%,2000V, |
| 2301-002483 | C-FILM,LEAD-MPPF;330NF,10%,275 |
| 2301-002484 | C-FILM,LEAD-MPPF;470NF,10%,275 |
| 2301-002011 | C-FILM,LEAD-PPF;2.2NF,5%,630V, |
| DA01-02118A | C/STEEL , AW1-12,GL-SGLCC,0.4M |
| DA01-02014G | C/STEEL-DOOR , RF8000B 3D,GL-S |
| DA01-02014F | C/STEEL-DOOR;RF8000B 4D,GL-SGL |
| DA01-01054P | C/STEEL-PLATE BOTTOM L/R;OPUS- |
| DA01-00849S | C/STEEL-REINF PANEL FRE;IBACI, |
| DA01-00491D | C/STEEL;AW(SEM),EGI-SECC,1MM,9 |
| DA01-00491K | C/STEEL;AW(SEM),EGI-SECC,2MM,2 |
| DA01-00492G | C/STEEL;AW(SEM),GI-SGCC,1MM,94 |
| DA01-00492M | C/STEEL;AW(SEM),SGCC,1.6MM,141 |
| DA01-00852D | C/STEEL;AW1-12,HGI-SGHC,3.000M |
| DA01-00852F | C/STEEL;AW1-12,HGI-SGHC,3.000M |
| DA01-00852G | C/STEEL;AW1-12,HGI-SGHC,3.000M |
| DA01-01148A | C/STEEL;GI-SGCC,0.25MM,865MM,C |
| DA01-01180A | C/STEEL;GI-SGCC,0.3,915.5,SHEE |
| DA64-04156A | CABI FRAME-BOTTOM FRONT;AW4,PP |
| DA64-04485P | CABI FRAME-BOTTOM REAR , RF800 |
| DA64-02233V | CABI FRAME-MIDDLE FRONT;AW2 FA |
| DA64-07034A | CABI FRAME-REAR;RF8000B/BC,GL- |
|
|
CABLE TIE |
| DA66-00950B | CAM AUTO CLOSE-LEFT |
| DA66-00951B | CAM AUTO CLOSE-RIGHT |
| DA66-01714A | CAM RISER-UP LEFT;RF9000D,PA66 |
| DA66-01715A | CAM RISER-UP RIGHT;RF9000D,PA6 |
| DA67-03717A | CAP DISPENSER;3050 PJT,LDPE,HB |
| DA67-05405A | CAP DOOR-FRE LOW;RF8000B,ABS,T |
| DA67-05413A | CAP DOOR-FRE UP , RF8000B,ABS, |
| DA67-05411A | CAP DOOR-REF LOW LEFT;RF8000B, |
| DA67-05410A | CAP DOOR-REF LOW RIGHT , RF800 |
| DA67-05394A | CAP DOOR-REF UP LEFT;RF8000B,A |
| DA67-05396A | CAP DOOR-REF UP RIGHT;RF8000B, |
| DA67-04504D | CAP FIXER-TUBE |
| DA67-05151A | CAP FIXER;RF9000A,SI,T2,NEO VI |
| DA67-03358A | CAP GUIDE FRENCH-UP;AW4,POM,50 |
| DA67-05051A | CAP HOLE-FRE;RF9000T,ABS,T1.5, |
| DA67-04961A | CAP SCREW |
| DA67-30266Q | CAP SCREW |
|
|
CAP-CASE FRENCH |
|
|
CAP-CASE FRENCH MID |
|
|
CAP-DRAIN |
| DA67-03091B | CAP-FIXER HOUSING VALVE WATER; |
| DA67-02795B | CAP-SHAFT HOLE |
| DA67-03399A | CAP-TUBE;HM12,PP,HB,BJ750,NATU |
| DA61-15172A | CASE BASKET-FRE UP , RF80000BC |
| DA61-14439A | CASE BASKET-LOW;RF9000A,HIPS,T |
| DA61-14149A | CASE BASKET-MIDDLE;RF9900T,HIP |
| DA61-15174A | CASE BASKET-UP |
| DA61-14438A | CASE BASKET-UP;RF9000A,ABS,T2. |
| DA61-14461A | CASE FILTER-LEFT;RF9000AC,HIPS |
| DA61-14163B | CASE FILTER-OUT;RF9000A,HIPS,T |
| DA61-14552A | CASE FILTER-OUT;RF9000AC,HIPS, |
| DA61-14462A | CASE FILTER-RIGHT;RF9000AC,HIP |
| DA61-15091A | CASE FILTER;RF9000A,GPPS,T2.5, |
| DA61-15196A | CASE FRENCH , RF8000B 3D,ABS,C |
| DA61-15195A | CASE FRENCH-FRONT , RF8000B 3D |
| DA61-14152A | CASE HEATER-FRENCH;RF9000T,ABS |
| DA61-14481A | CASE HEATER;RF9000A,ABS,NATURA |
| DA61-14482A | CASE HEATER;RF9000A,ABS,NATURA |
| DA61-14309A | CASE ICE SCOOP |
| DA61-15138A | CASE ICE-CUBE , RF8000BC,GPPS, |
| DA61-15334A | CASE PBA-MAIN;RF9000B,PP,T2.5, |
| DA61-15209A | CASE VEG-LOW , RF8000BC,PP,T2. |
| DA61-14524A | CASE VEG-LOW;RF9000AC,PP,COOL |
| DA61-14174B | CASE WATER TANK;RF8000BC,PCT,T |
| DA61-05524A | CASE-FILTER IN;SSEDA,POM,NATUR |
| DA61-05523A | CASE-FILTER OUT;SSEDA,POM,NATU |
| DA61-05954A | CASE-HOUSING CONV LINER;AW3,PP |
|
|
CASTER-FRONT |
|
|
CASTER-REAR |
| DA02-40003A | CH-BLOWING AGE |
| DA64-04152K | CHASSIS COMP;RF6000T,GI-SGCC,T |
|
|
CLIP-FITTING LOCK |
| NO14C9151ALTT9 | CMP,COMP,REFRIGERATOR |
| DA02-00235A | COATING-ECO PRO;ECO PRO,12.7,T |
| DA27-00063A | COIL CHOKE;150UH,6A,11MMX10MM, |
| DA27-00062A | COIL CHOKE;18MH,6A,16MMX18MM,M |
| DA27-00061A | COIL CHOKE;4.5MH,6A,15MMX10MM, |
| 3711-000262 | CONNECTOR-HEADER |
|
|
COVER ASSEMBLY COMP |
|
|
COVER ASSEMBLY SWITCH |
|
|
COVER ASSEMBLY-TUBE FILTER |
| DA91-05369B | COVER CAP DOOR |
| DA63-06954B | COVER COMP;POLARIS,GI-SGCC,T0. |
| DA63-11573B | COVER EVAP-FRE REAR;RF8000B,PP |
| DA63-11575A | COVER EVAP-FRE;RF8000B,PP,T2,N |
| DA63-11572A | COVER EVAP-REAR;RF8000B,PP,T1. |
| DA63-11571A | COVER EVAP-REF , RF8000B,PP,T2 |
| DA63-11209A | COVER FILTER |
| DA63-05403B | COVER FILTER;AW3,PP,T2.5,INNER |
| DA63-11210A | COVER FILTER;RF9000AC,HIPS,T2. |
| DA63-11587A | COVER FRONT-UP |
| DA63-11596A | COVER HANDLE , RF8000B,ABS,DAR |
| DA63-11686A | COVER LAMP |
| DA63-11218A | COVER LAMP-REF;RF9000A,ABS,COO |
| DA63-11565A | COVER PCB , AW3,GL-SGLCC,T0.4, |
| DA63-11634A | COVER PIPE;RF8000B,PP,T2,BLACK |
| DA63-11603A | COVER RAIL-LEFT , RF8000BC,HIP |
| DA63-11681B | COVER RAIL-LOW LEFT;RF6500C,AB |
| DA63-11682B | COVER RAIL-LOW RIGHT;RF6500C,A |
| DA63-11604A | COVER RAIL-RIGHT , RF8000BC,HI |
|
|
COVER REED SWITCH |
| DA63-06122A | COVER RELAY |
| DA63-11197A | COVER SENSOR;RF9000A,PP,T2.5,C |
| DA63-09321A | COVER SENSOR;RS8000NC,PP,T2,CO |
| DA63-11739B | COVER SHEET;RF8000B,AL,NATURAL |
| DA63-11739D | COVER SHEET;RF8000B,AL,NATURAL |
| DA63-11750A | COVER SHEET;RF8000B,AL,T0.135 |
| DA63-11750B | COVER SHEET;RF8000B,AL,T0.135 |
| DA63-11750C | COVER SHEET;RF8000B,AL,T0.135 |
| DA63-11600A | COVER VEG-FRONT LOW , RF8000B, |
| DA63-11207A | COVER VEG-FRONT LOW;RF9000A,GP |
| DA63-11207B | COVER VEG-FRONT LOW;RF9000A,GP |
| DA63-11228A | COVER VEG-UP |
| DA63-09907B | COVER WATER TANK;RF9000A,HIPS, |
| DA63-11213A | COVER-AUTOFILL |
|
|
COVER-CAP DOOR LED |
| DA63-06383B | COVER-FIXER HOUSING FRE;OPUS,H |
|
|
COVER-HEATER FRENCH |
| DA63-11590A | COVER-REAR |
|
|
COVER-URETHANE |
| DA69-02491A | CUSHION CORNER-REAR;RS5300T,EP |
| DA69-02710A | CUSHION SHELF;RF8000BC,EPS,W50 |
| 0402-001224 | DIODE-BRIDGE |
| 0402-001472 | DIODE-RECTIFIER |
|
|
DIODE-RECTIFIER |
| 0402-000553 | DIODE-SCHOTTKY |
| 0401-001099 | DIODE-SWITCHING |
| 0407-000113 | DIODE-SWITCHING |
| 0406-001239 | DIODE-TVS |
| 0406-001865 | DIODE-TVS;SMBJ17CA,18.9V,20.9V |
| 0406-001906 | DIODE-TVS;SMF200A,224V,SOD-123 |
| 0403-000461 | DIODE-ZENER |
| DA67-04812A | DRAIN-HOSE FRE;RFF310N,HDPE,NA |
|
|
DRYER |
| DA59-00636A | EVAPORATOR-FRE;FIN TUBE,RF8000 |
| DA59-00558B | EVAPORATOR-REF;FIN TUBE,RF8000 |
|
|
FASTENER-HINGE |
| DA60-00314B | FASTENER-HINGE |
|
|
FASTENER-HINGE |
| DA60-00314D | FASTENER-HINGE |
|
|
FASTENER-RIVET |
| DA60-00163A | FASTENER;AW-PJT,SK5,OD4.2 |
| 0505-002598 | FET-SILICON |
| 0505-003755 | FET-SILICON;AOD2910E,N,100V,37 |
| 0505-003960 | FET-SILICON;IPD60R360PFD7S,N,6 |
| DA63-08839B | FILTER-WATER;RF8000MC,PP,COOL |
| DA60-00371C | FITTING LOCK RING;A6061,ID5.75 |
| DA60-00407B | FITTING LOCK RING;A6061,ID9.1, |
| DA60-00367B | FITTING LOCK RING;SMF4030,ID5. |
| DA60-00368A | FITTING LOCK SLEEVE;SMF4030,CO |
| DA60-00366A | FITTING LOCK SLEEVE;SMF4030,PI |
| DA60-00393A | FITTING TUBE |
| DA62-03914F | FITTING TUBE;POM,ID1/4,NATURAL |
|
|
FITTING-TUBE |
| DA61-11032A | FIXER |
| DA61-11034A | FIXER |
| DA61-09533A | FIXER CASE-PBA;OPUS1-14,ABS,NA |
| DA61-12488B | FIXER COVER;AW3,HIPS,INNER GRA |
|
|
FIXER HINGE-UPP |
| DA61-12180B | FIXER HOSE;BRF8000M,POM,-,BLAC |
| DA61-14663B | FIXER HOSE;RF9000A,PP,BLACK,CN |
| DA61-15739A | FIXER HOSE;RR9000,POM,T2,NATUR |
| DA61-14658A | FIXER HOUSING-FRE;RF7000AC,HIP |
| DA61-14677A | FIXER HOUSING-REF RIGHT;RF9000 |
| DA61-10758C | FIXER LOCKER;ABS,T2.5,EBONY BL |
| DA61-12188A | FIXER PIPE |
| DA61-04805B | FIXER ROLLER |
| DA61-14479A | FIXER SENSOR;RF9000A,PE FOAM,N |
| DA61-12990A | FIXER SENSOR;RS8000NC,PE FOAM, |
| DA61-13218B | FIXER SHELF;RF6500C,POM,NATURA |
| DA61-13219C | FIXER SHELF;RF6500C,POM,T2,NAT |
| DA61-06013B | FIXER WIRE |
| DA61-12195A | FIXER WIRE;RF8000MC,ABS,NATURA |
| DA61-13585A | FIXER-BIMETAL;RF9000R,PP,T1.5, |
|
|
FIXER-CASTER |
| DA61-05780A | FIXER-COLLAR;SSEDA,POM,NATURAL |
| DA61-05781A | FIXER-COLLET;SSEDA,POM,INNER G |
| DA61-04773A | FIXER-DRAIN |
| DA61-04235A | FIXER-EVAP |
| DA61-15282A | FIXER-FILTER;RF8000B,PP,T2,NAT |
| DA61-05525A | FIXER-FILTER;SSEDA,PP,COOL WHI |
| DA61-04801A | FIXER-GEAR |
| DA61-15131A | FIXER-HEATER |
| DA61-07554B | FIXER-HOUSING VALVE WATER;AW2- |
|
|
FIXER-SENSER |
|
|
FIXER-SENSOR |
| DA61-05570A | FIXER-SHAFT GUIDE;SSEDA,POM,NA |
| DA61-05526A | FIXER-SHAFT;SSEDA,POM,NATURAL, |
| DA61-07701A | FIXER-SUCTION;AW-SEM,PP,T2,BLA |
| DA61-15292A | FIXER-SUCTION;RF8000B,PP,T2,BL |
| DA61-15146A | FIXER-SUCTION;RF8000B,PP,T2,NA |
| DA71-20265A | FIXER-THERMO FUSE |
| DA61-11296B | FIXER;AW3,HIPS,INNER GRAY,CNTK |
| DA61-15295A | FIXER;RS8000B,PC,T2.5,NATURAL, |
| 0204-004665 | FLUX;KSP-70M-S,MIXTURE,NO,FLUX |
|
|
FOOT |
|
|
FOOT-FRONT |
| 3601-001336 | FUSE-AXIAL LEAD |
| 3601-001978 | FUSE-AXIAL LEAD;250V,10A,SLOW- |
| 3601-001927 | FUSE-AXIAL LEAD;250V,2A,TIME-L |
|
|
GASKET-FRENCH LOW |
| DA63-09908B | GASKET-TANK;RF9000A,SI,NEO VIC |
| DA66-00750B | GEAR |
| DA66-00751B | GEAR;AW3-14,POM,NATURAL,500P,R |
| DA64-06509A | GLASS-SHELF FRONT;RF9000AC,GLA |
| DA64-05969A | GLASS-SHELF REAR;AW4_CD,GLASS, |
| DA64-07050A | GLASS-SHELF REF , RF8000B,GLAS |
| DA64-07027A | GLASS-SHELF REF FIX , RF8000BC |
| DA64-06513N | GLASS-SHELF REF LOW;RF9000AC,G |
| DA64-06511B | GLASS-SHELF REF UP;RF9000AC,GL |
| 0205-000121 | GREASE-SILICON |
| 0205-000131 | GREASE-SILICON;G501,1L |
| DA63-02617C | GROMMET COMP |
| DA63-11374A | GROMMET DOOR |
| DA63-07925A | GROMMET HINGE-UP;AW4,PA66,NATU |
| DA63-11491A | GROMMET RING;RR9000A,NBR,BLACK |
| DA63-03634C | GROMMET SCREW;3050-PJT,PP+GLF1 |
| DA63-11592A | GROMMET-A |
| DA63-07969A | GROMMET-A;FSR,PP+GLF15%,NATURA |
| DA63-11593A | GROMMET-B |
| DA63-04825B | GROMMET-CAP DOOR |
| DA63-04424A | GROMMET-COND SUB |
| DA63-02761A | GROMMET-DRAIN |
| DA63-11235A | GROMMET-FIXER;RF9000A,PP,NATUR |
| DA63-03447A | GROMMET-FRENCH |
| DA63-00009A | GROMMET-HARNESS;T3-PJT,PP,NATU |
| DA63-03049A | GROMMET-HOT PIPE |
| DA63-07323A | GROMMET-IMMERSION PIPE B |
| DA63-06103A | GROMMET-PIPE;W07,NBR,BLACK,ALL |
| DA63-05349A | GROMMET-RING SHAFT GUIDE;SSEDA |
| DA63-05350A | GROMMET-RING SHAFT;SSEDA,NBR,N |
| DA63-05351A | GROMMET-RING;SSEDA,NBR,NATURAL |
| DA63-04571C | GROMMET-SCREW;AW-PJT,ABS,INNER |
|
|
GROMMET-SUCT PIPE A |
| DA63-09665A | GROMMET-UP RIGHT;RF9000R(B),SI |
| DA63-07746A | GROMMET;AW3-14,SI,NATURAL |
| DA63-11624A | GUARD-REF LOW , RF8000B,GPPS,T |
| DA63-11230B | GUARD-REF LOW;RF8000B,GPPS,T3, |
| DA63-11222A | GUARD-REF UP;RF7000AC,GPPS,T3, |
| DA63-11219A | GUARD-REF;RF9000A,GPPS,T3,TP G |
| DA61-15144B | GUIDE AIR-REF |
| DA61-15345A | GUIDE HOSE-FRONT;RF8000B,HIPS, |
| DA61-15142A | GUIDE HOSE-IN;RF8000BC,PP,T2,S |
| DA61-15143A | GUIDE HOSE-IN;RF8000BC,PP,T2,S |
| DA61-15141A | GUIDE HOSE-OUT;RF8000B,PP,T2,S |
| DA61-10404A | GUIDE HOSE;PP,HB,BJ750,COOL WH |
| DA61-14503A | GUIDE HOSE;RF7000AC / RF9000A |
| DA61-14661A | GUIDE ICE |
| DA61-15176A | GUIDE TRAY-FRE |
| DA61-14987A | GUIDE-FRE;AW3-14,PP,T1.2,SSPP- |
|
|
GUIDE-FRENCH |
| DA61-09100A | GUIDE-TUBE C;3050,PP,J550S,NAT |
| DA02-40012D | H-ISOCYANATE |
| DA64-07040A | HANDLE RECESS , RF8000B,ABS,HG |
| DA61-13449B | HANGER-LEFT |
|
|
HANGER-RAIL FRONT L |
|
|
HANGER-RAIL FRONT R |
| DA61-05189A | HANGER-RAIL LOW L , AW2 CD,EGI |
| DA61-05190A | HANGER-RAIL LOW R , AW2 CD,EGI |
| DA61-13451B | HANGER-RIGHT |
| DA61-15135C | HANGER-RIGHT;RF6500CC,GI-SGCC, |
| 3711-000315 | HEADER-BOARD TO CABLE |
| 3711-001038 | HEADER-BOARD TO CABLE |
| 3711-001084 | HEADER-BOARD TO CABLE |
| 3711-002001 | HEADER-BOARD TO CABLE |
| 3711-008032 | HEADER-BOARD TO CABLE;1WALL,2P |
| 3711-008034 | HEADER-BOARD TO CABLE;1WALL,3P |
| 3711-009460 | HEADER-BOARD TO CABLE;1WALL,4P |
| 3711-009393 | HEADER-BOARD TO CABLE;BOX,24P, |
| 3711-009394 | HEADER-BOARD TO CABLE;BOX,26P, |
| 3711-009395 | HEADER-BOARD TO CABLE;BOX,28P, |
| DA47-00549A | HEATER CORD-FRENCH , AC120V,12 |
| DA47-00550A | HEATER CORD-WATER PIPE;DC12V,2 |
| DA47-00318V | HEATER METAL SHEATH |
|
|
HINGE-FRENCH |
| DA61-13411A | HINGE-UP LEFT;RF9000R,PO-SPHC, |
| DA61-13412A | HINGE-UP RIGHT;RF9000R,PO-SPHC |
| DB61-00206A | HOLDER-WIRE |
| DA67-05468A | HOSE DRAIN;RF8000B/BC,HDPE,NAT |
| 1001-001942 | IC-ANALOG SWITCH |
| 1205-004722 | IC-CONTROLLER;TCA9535PWR,TSSOP |
| 1003-000113 | IC-CURRENT DRIVER |
| 1203-009429 | IC-DC/DC CONVERTER;SYU812C1,SO |
| 1103-001228 | IC-EEPROM |
| 0903-002203 | IC-MICROCONTROLLER;HART-M320,M |
| 0903-002279 | IC-MICROCONTROLLER;STM32G431RB |
| 1003-003175 | IC-MOTOR DRIVER;6EDL04N06PT,PG |
| 1003-002900 | IC-MOTOR DRIVER;DRV8848PWPR,16 |
| 1201-004191 | IC-OP AMP;9064,TSSOP,TP,14P,5X |
| 1203-002722 | IC-POSI.FIXED REG. |
| 1203-009642 | IC-PWM CONTROLLER;SC1551C-H084 |
| 1203-001211 | IC-VOL. DETECTOR |
| 1203-006245 | IC-VOL. DETECTOR |
| 2703-004724 | INDUCTOR-SMD |
| DA27-00051A | INDUCTOR-SMD;1MH,20%,12.2X12.2 |
| DA64-06406U | INLAY CONTROL , RF8000B,PC,PEA |
| DA62-05864A | INSULATION COVER EVAP-FRE SUB |
| DA62-05859A | INSULATION COVER EVAP-FRE;RF80 |
| DA62-05851A | INSULATION COVER EVAP-REF;RF80 |
| DA62-05856A | INSULATION-A , RF8000BC,EPS,S- |
| DA62-05880A | INSULATION-LOW , RF8000B,EPS,S |
| DA62-05878A | INSULATION-UP , RF8000B,EPS,SE |
| DC68-02060A | LABEL BAR CODE |
| DA68-01814A | LABEL BAR CODE-LINER;ALL,ART,L |
| DC68-02415A | LABEL BAR CODE;-,SEM,YUPO,W30, |
| DC68-04352A | LABEL BAR CODE;WW5000T,WW80T40 |
| DA68-01797W | LABEL CAUTION;ALL USA,AA,ART,O |
| DA68-02785B | LABEL INSTRUCTION;ROMANEE CONT |
| 6812-000145 | LABEL INTEGRATION QR;PET,LAMIN |
| DA68-03947A | LABEL RATING;AW2 F/L,AA,PET,33 |
| DA68-02869A | LABEL TAG;ALL,AA, XAC,MOJO,200 |
| DA68-01173B | LABEL-BAR CODE |
| DA68-10376D | LABEL-BAR CODE |
| DA68-00122A | LABEL-PRINT |
| 0601-002345 | LED |
| DA66-01565A | LEVER HANDLE , RF8000B,POM,K30 |
| DA66-00952A | LEVER-AUTO CLOSE;AW4,POM,500P, |
| DA61-15215A | LINER , RF8000BC-3D,ABS,QU-019 |
|
|
MAGNET |
|
|
MAGNET ASSEMBLY |
|
|
MAGNET-A |
| DA61-15470D | MAGNET-FRE;RF8000B,FERRITE,3D/ |
| DA61-15470E | MAGNET-FRE;RF8000B,FERRITE,3D/ |
| DA61-15470A | MAGNET-REF;RF8000B,FERRITE,3D, |
| DA61-15470C | MAGNET-REF;RF8000B,FERRITE,4D, |
| DA68-02659J | MANUAL INSTRUCTION;RF8000B/BC, |
| DA68-04540A | MANUAL USERS , RF8000B,AA,EN/M |
| 0103-007638 | MASTERBATCH-HIPS;SW-187,WT0057 |
| 0103-007830 | MASTERBATCH-POM;05-A274,KTL GR |
| 0103-002987 | MASTERBATCH-POM;06-900A,BLACK, |
| 0103-002992 | MASTERBATCH-PP;01-0032,WT0057, |
|
|
MOTOR BLDC FAN |
| DA31-00348A | MOTOR BLDC FAN;Z19W12MS1A5-52K |
| 6021-000258 | NUT-HEXAGON |
|
|
NUT-HEXAGON |
| DA69-01639D | PACKING CASE SHRINKAGE;IBACI,L |
| DA61-02733Q | PACKING SUPPORT;RF8000B FDSR,P |
| DA69-02811A | PAD CUSHION;REF_ALL,EPS,T10,W2 |
| DA69-02482G | PAD CUSHION;REF_ALL,EPS,T15,W5 |
| DA72-00250G | PAD CUSHION;REF_ALL,EPS,T15,W6 |
| DA69-02794B | PAD CUSHION;RF5000C,EPS,T15,W1 |
| DA62-04618R | PAD-FOAM;REF_ALL,EPE,T10,W20,L |
| DA62-04618J | PAD-FOAM;REF_ALL,EPE,T5,W60,L8 |
| DA64-07032A | PANEL-FRE;RF8000B,ABS,T1,W881. |
| DA64-07044A | PANEL-REF LEFT;RF8000B 3D,ABS, |
| DA64-07045A | PANEL-REF RIGHT , RF8000B 3D,A |
| 0604-001405 | PHOTO-COUPLER;TR,200-400%,200M |
| DA62-04396F | PIPE CAPILLARY;ARAM13,CU,OD2.0 |
| DA62-05882B | PIPE CAPILLARY;RF8000B,AL,OD1. |
| DA62-05882A | PIPE CAPILLARY;RF8000B,AL,OD2. |
| DA62-04396C | PIPE CAPILLARY;RS8000NC,CU,OD1 |
| DA62-05866A | PIPE CLUSTER-REAR;RF8000B/BC,T |
|
|
PIPE CONNECT-SUCTION |
| DA62-05884G | PIPE CONNECT;RF9000C,AL,OD8,T0 |
| DA62-05868A | PIPE HOT , RF8000B,TSW,OD4.2,T |
| DA62-04609A | PIPE IMMERGING-IN;FSR,TSW,OD4. |
| DA62-04610A | PIPE IMMERGING-OUT;FSR,TSW,OD4 |
| DA62-04847A | PIPE WATER-FRA A;BRR9000M,PP,O |
| DA62-04965A | PIPE WATER-FRE;BRF8000M,AL,A30 |
| DA62-05754A | PIPE WATER-FRE;RR9000A,POM,OD6 |
| DA62-05319A | PIPE WATER-LINE;RF9000R,LDPE,O |
| DA62-05883A | PIPE-AL;RF8000B,AL,OD8,T0.8,A1 |
|
|
PIPE-CONNECT |
| DA62-04605A | PIPE-IN;AL,A3003 |
| DA62-04601A | PIPE-MIDDLE;AL,T1.2,A3003 |
| DA62-04318A | PIPE-STEEL;ALL,TSW,OD4.2,THK0. |
| DA62-04600A | PIPE-SUB;AL,A3003 |
| DA97-05803A | PIPE-WATER LINE |
| DA62-01368B | PIPE-WATER LINE |
| DA62-03154A | PIPE-WATER LINE |
| DA62-04623C | PIPE;ALL,CU,OD7.94,T0.4,C1220T |
| DA61-10697B | PLATE CONDENSER |
| DA61-13772A | PLATE COVER-FRE;RF9000JC,GL-SA |
| DA61-15206A | PLATE DOOR-FRE , RF8000B,GL-SG |
| DA61-15505A | PLATE DOOR-FRE;RF8000B,GL-SGLC |
| DA61-15198A | PLATE DOOR-REF LEFT;RF8000B,GL |
| DA61-15197A | PLATE DOOR-REF RIGHT;RF8000B,G |
| DA61-15506A | PLATE DOOR-REF RIGHT;RF8000B,G |
| DA61-15139A | PLATE EVAP-FRE LEFT;RF8000B,AL |
| DA61-15140A | PLATE EVAP-FRE RIGHT;RF8000B,A |
| DA61-13961A | PLATE HEATER;RF9000K,A1100,T1, |
| DA61-11675B | PLATE INS-FRE;RF8000B,GL-SGLCC |
| DA61-10700B | PLATE STEEL;AL,B10%,T0.08,W16, |
| DA01-00852R | PLATE STEEL;AW1-12,CR-SPCC,1.4 |
| DA01-01147A | PLATE STEEL;EGI-SECC,,0.4MM,87 |
| DA01-01166A | PLATE STEEL;EGI-SECC,1.6MM,383 |
| DA01-02198A | PLATE STEEL;RF8000B,ALCOAT-SA1 |
| DA01-02202A | PLATE STEEL;RF8000B,EGI-SECC,, |
| DA01-02181A | PLATE STEEL;RF8000B,EGI-SECC,2 |
| DA01-02206A | PLATE STEEL;RF8000B,GI-SGCC,,1 |
| DA01-02207A | PLATE STEEL;RF8000B,GI-SGCC,,1 |
| DA01-02208A | PLATE STEEL;RF8000B,GI-SGCC,,2 |
| DA01-02182A | PLATE STEEL;RF8000B,GI-SGCC,2M |
| DA01-02211A | PLATE STEEL;RF8000B,GL-SGLCC,, |
| DA01-02040B | PLATE STEEL;RF8000B,GL-SGLCC,L |
| DA01-02214A | PLATE STEEL;RF8000B,HGI-SGHC,, |
| DA01-02200A | PLATE STEEL;RF8000B,PO-SPHC,,1 |
| DA01-02201A | PLATE STEEL;RF8000B,PO-SPHC,,2 |
| DA01-02215A | PLATE STEEL;RF8000B,PO-SPHC,,3 |
| DA01-02219A | PLATE STEEL;RF8000B,PO-SPHC,,4 |
| DA01-02188B | PLATE STEEL;RF8000B/C,GI-SGCC, |
| DA01-02193B | PLATE STEEL;RF8000B/C,GL-SGLCC |
| DA61-08177V | PLATE-BOTTOM FRONT;AW FACE LIF |
| DA61-05921F | PLATE-BOTTOM REAR LEFT;RF7500J |
| DA61-05924G | PLATE-BOTTOM REAR RIGHT;RF7500 |
| DA61-10696A | PLATE-CORNER;AL,T1.5 |
| DA61-05842A | PLATE-DRAIN FRE;AW3-PJT,GL-SGL |
| DA61-08673A | PLATE-EVAP REF L;ROMANEE CONTI |
| DA61-08674A | PLATE-EVAP REF R;ROMANEE CONTI |
| DA61-15207A | PLATE-FRENCH , RF8000B,EGI-SEC |
| DA61-10371A | PLATE-UP FRONT;ROMANEE CONTI,A |
| DA67-90108D | PLUG COMP TUBE;SILICON RUBBER, |
| 0204-007545 | POLYOL;ELASTOCOOL MX 2030/118, |
|
|
POWER CORD-AT |
| 2007-000033 | R-CHIP |
| 2007-000279 | R-CHIP |
| 2007-000293 | R-CHIP |
| 2007-000297 | R-CHIP |
| 2007-000312 | R-CHIP |
| 2007-000352 | R-CHIP |
| 2007-000476 | R-CHIP |
| 2007-000571 | R-CHIP |
| 2007-000762 | R-CHIP |
| 2007-000928 | R-CHIP |
| 2007-000938 | R-CHIP |
| 2007-000944 | R-CHIP |
| 2007-001297 | R-CHIP |
| 2007-007306 | R-CHIP |
| 2007-007336 | R-CHIP |
| 2007-007699 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-008175 | R-CHIP |
| 2007-008231 | R-CHIP |
| 2007-008269 | R-CHIP |
| 2007-008354 | R-CHIP |
| 2007-008485 | R-CHIP |
| 2007-008779 | R-CHIP |
| 2007-008791 | R-CHIP |
| 2007-010245 | R-CHIP;0.01OHM,1%,2W,TP,6432 |
| 2007-012276 | R-CHIP;0.09OHM,1%,2W,TP,6432,T |
| DA61-07193A | RAIL-BALL A;AW-PJT,STS304,T1.5 |
| DA61-02264A | RAIL-BRACKET,RIVET;HNR3117/XAA |
| DA61-08758A | RAIL-CENTER MEMBER LOW;AW2-CD, |
| DA61-08761A | RAIL-CENTER RETAINER;AW2-CD,PP |
|
|
RAIL-FRE UP LEFT |
|
|
RAIL-FRE UP RIGHT |
| DA61-08759A | RAIL-INNER MEMBER LOW;AW2-CD,S |
| DA61-15178A | RAIL-LEFT |
| DA61-14528A | RAIL-MIDDLE LEFT;RF9000AC,HIPS |
| DA61-08757A | RAIL-OUTER MEMBER LOW;AW2-CD,S |
| DA61-08760A | RAIL-OUTER RETAINER;AW2-CD,PP, |
| DA61-07937A | RAIL-SELF CLOSING BODY L;MOUTO |
| DA61-07961A | RAIL-SELF CLOSING BODY R;MOUTO |
| DA61-08013A | RAIL-SELF CLOSING GUIDE PIN;MO |
| DA61-07938A | RAIL-SELF CLOSING GUIDE;MOUTON |
| DA61-07939A | RAIL-SELF CLOSING LOCK GUIDE L |
| DA61-07955A | RAIL-SELF CLOSING LOCK GUIDE R |
| DA61-08012A | RAIL-SELF CLOSING SPRING;MOUTO |
| DA61-08818A | RAIL-SLIDE LOW L |
|
|
RAIL-SLIDE LOW R |
| DA67-05072A | REFLECTOR;RB7300T,ABS,IN, SIMP |
| DA61-15182A | REINF CABI-BOTTOM FRONT;FDR,HG |
| DA61-15454A | REINF CABI-FLANGE UP;RF8000B,P |
| DA61-10849A | REINF CABI-MIDDLE FRONT;RF9000 |
| DA61-15158A | REINF HANDLE;RF8000B,GI-SGCC,T |
| DA61-15065A | REINF HANGER;AW2-F/L,ABS,HG-07 |
| DA61-05923A | REINF-EARTH;HGI-SGHC,T3 |
| DA61-04726A | REINF-GUIDE FRENCH;AW-PJT,GA-S |
| DA61-04910A | REINF-HINGE UP R;HAEMIL-PJT,GI |
| DA71-10490C | REINF-HINGE UPP |
| DA61-15183A | REINF-LOW FRONT;FDR,HGI-SGHC,T |
| DA61-13408A | REINF-LOW RIGHT;RF9000R,PO-SPH |
| DA61-08711A | REINF-PANEL FRE;FDR,CR-SPCC,T1 |
|
|
RELAY-MINIATURE |
| 0103-007625 | RESIN ABS;CNTK A-204/INNER GRA |
| 0103-001477 | RESIN ABS;HF-0660I/COOL WHITE, |
| 0103-003109 | RESIN ABS;HG-0760GP/EBONY BLAC |
| 0103-011604 | RESIN ABS;HG-0760GP/G34160,DAR |
| 0103-009089 | RESIN ABS;HG-0760GP/G41355,INO |
| 0103-002281 | RESIN ABS;HG-0760GP/G71238,NEO |
| 0103-003042 | RESIN ABS;HG-0760GP/NC0001,NAT |
| 0103-004144 | RESIN ABS;HG-0760GP/NC001,NATU |
| 0103-002999 | RESIN ABS;HG-0760GP/WT0057,COO |
| 0103-003217 | RESIN ABS;VE-0856/NTR,NATURAL, |
| 0103-011108 | RESIN ABS;XM-0900/PG1944,VF SI |
| 0103-008912 | RESIN EPS;S-450/NTR,NATURAL,NC |
| 0103-000306 | RESIN GPPS;147F/TP BLUE,TP BLU |
| 0103-011107 | RESIN GPPS;G-116HV/U5680,TP GR |
| 0103-011672 | RESIN HIPS;5470/NATURAL,NATURA |
| 0103-002282 | RESIN HIPS;S834S1/7380,NEO VIC |
| 0103-004130 | RESIN HIPS;S834S1/NTR,NATURAL, |
| 0103-003252 | RESIN HIPS;S834S1/WT0057,COOL |
| 0103-003376 | RESIN LDPE;MB9500,NATURAL,NC00 |
| 0103-002994 | RESIN PA66;101F/NC0001,NATURAL |
| 0103-002975 | RESIN PC ABS;HR-1008B,COOL WHI |
| 0103-002977 | RESIN PC;HF-1023IM,COOL WHITE, |
| 0103-011465 | RESIN PCTG;JN200K/GRY,TP GRAY, |
| 0103-002996 | RESIN POM;500P,NATURAL,NC0001 |
| 0103-000244 | RESIN POM;F20-03,NATURAL,NC000 |
| 0103-004710 | RESIN POM;K300/NATURAL,NATURAL |
| 0103-002641 | RESIN POM;K300/NTR,NATURAL,NC0 |
| 0103-004981 | RESIN PP;BJ73SL/NTR,NATURAL,NC |
| 0103-004141 | RESIN PP;FH44N/NTR,NATURAL,NC0 |
| 0103-012238 | RESIN PP;HFFR-1510NT/NATURAL,N |
| 0103-011415 | RESIN PP;NF-6068R/GRAY,INNER G |
| 0103-007539 | RESIN PP;SSPP-640/BLACK,BLACK, |
| 0103-001344 | RESIN PP;TB53/NTR,NATURAL,NC00 |
| 0103-012009 | RESIN PVC;S32A45/DARK GRAY,DAR |
| 0103-002817 | RESIN-ABS |
| 0103-002442 | RESIN-FRPP |
| 0103-001846 | RESIN-PP |
| 2802-001211 | RESONATOR-CERAMIC |
| 6130-000386 | RETAINER |
| 6130-000387 | RETAINER |
| DA66-00629B | ROLLER-AUTO CLOSE;PA66,BLACK,1 |
|
|
ROLLER-FRE |
| DA97-22036A | ROLLER-FRE |
|
|
ROLLER-TRAY FRE UPP |
| DA66-01339A | ROLLER;POM,OD29,NATURAL |
|
|
SCREW-MACHINE |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000473 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-001547 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000581 | SCREW-TAPPING;SWRCH18A,ZPC(WHT |
| 6002-001521 | SCREW-TAPPING;TH,+,NO,2S,M3,L1 |
| DA62-05898A | SEAL COVER-WATER;RF8000B,PE FO |
| DA62-05511A | SEAL COVER;RF9900T,PU FOAM,T5, |
| DA62-01134C | SEAL CUTT |
| DA62-01134E | SEAL CUTT |
| DA62-01134H | SEAL CUTT |
| DA62-01136A | SEAL CUTT |
| DA62-01136Q | SEAL CUTT |
| DA62-01138D | SEAL CUTT |
| DA62-01139C | SEAL CUTT |
| DA62-01139D | SEAL CUTT |
| DA62-01140F | SEAL CUTT |
| DA62-01140P | SEAL CUTT |
| DA62-01140Z | SEAL CUTT |
| DA62-01141B | SEAL CUTT |
| DA62-01141D | SEAL CUTT |
| DA62-01141F | SEAL CUTT |
| DA62-01141H | SEAL CUTT |
| DA62-01141X | SEAL CUTT |
| DA62-01141Z | SEAL CUTT |
| DA62-01142B | SEAL CUTT |
| DA62-01142D | SEAL CUTT |
| DA62-01142F | SEAL CUTT |
| DA62-01142Q | SEAL CUTT |
| DA62-06172A | SEAL CUTT SPONGE;FDR RF6000T / |
| DA72-60260N | SEAL CUTT-FOAM PE |
| DA62-00919M | SEAL CUTT-FOAM PE;-,PU FOAM,T1 |
| DA62-03033R | SEAL CUTT-FOAM PE;HAEMIL,PE FO |
| DA62-01138T | SEAL CUTT-FOAM PE;RF9000T,PE F |
| DA62-02589W | SEAL CUTT-FORM PE;ARAM10,PE FO |
|
|
SEAL CUTT-RUBBER |
| DA62-00470Z | SEAL CUTT-SPONGE;350,380,PU FO |
| DA62-02132R | SEAL CUTT-SPONGE;AW-SEM,PU FOA |
| DA62-02132T | SEAL CUTT-SPONGE;AW-SEM,PU FOA |
| DA62-02132V | SEAL CUTT-SPONGE;AW-SEM,PU FOA |
| DA62-02139F | SEAL CUTT-SPONGE;AW-SEM,PU FOA |
| DA62-03586A | SEAL CUTT-SPONGE;AW-SEM,PUR SP |
| DA62-00470V | SEAL CUTT-SPONGE;MAX3,PU FOAM, |
| DA62-01128S | SEAL CUTT;ALL,PE FOAM,T3,L1000 |
| DA62-01921A | SEAL CUTT;GUGGENHEIM,PE OPEN C |
| DA62-01140B | SEAL CUTT;PU FOAM,T3,W10,L1000 |
| DA62-01135M | SEAL CUTT;RB7300T,PE FOAM,T5,W |
| DA62-01140Y | SEAL CUTT;RF8000A,PU FOAM,T5,W |
| DA62-02480D | SEAL DRAIN;RF8000BC,PU FOAM,T1 |
| DA62-05863A | SEAL DUCT-FRE UP;RF8000B,PE OP |
| DA62-05690A | SEAL FIXER HOUSING;RF9000A,PU |
| DA62-03888E | SEAL INS PARTITION-MIDDLE;SEMP |
| DA62-05865A | SEAL PIPE;RF8000B,PU FOAM,T15, |
| DA62-04261B | SEAL SUPPORT TUBE FILTER-REAR; |
| DA62-05889A | SEAL TUBE;RF8000B,PE FOAM,T6,W |
| DA62-00232B | SEAL WATER HOSE;RF9000A,PU FOA |
| DA62-05899A | SEAL WATER;RF8000B,PE FOAM,T5, |
| DA62-01097A | SEAL-CABI BOTTOM REAR |
| DA62-03641A | SEAL-CABI;OPUS1-14,PU FOAM,T5, |
| DA62-02534A | SEAL-CASE HEATER FRENCH;SPONGE |
| DA62-02523A | SEAL-CASE HOUSING CONV LINER;A |
| DA62-00091A | SEAL-CUTT FOAM, PE |
| DA72-00238B | SEAL-DRAIN HOSE |
| DA62-02455A | SEAL-DRAIN HOSE;RF9000K,PU FOA |
| DA62-04105A | SEAL-DRYER |
| DA62-03171A | SEAL-FIXER HOUSING FRE;OPUS1,P |
| DA62-03262A | SEAL-FIXER HOUSING VALVE WATER |
| DA62-05678A | SEAL-FIXER TUBE;RF9000A/AC, RF |
| DA62-00302C | SEAL-FOAM PE, DRAIN |
| DA62-05606A | SEAL-GROMMET FIXER;RF9000A,PU |
| DA62-01500A | SEAL-GUIDE FRENCH;AW-PJT,PE FO |
| DA62-01113A | SEAL-GUIDE PIPE, UPP |
| DA62-03018A | SEAL-HANDLE BOTT;FDR / SBS,PE |
| DA62-01410A | SEAL-MID FRONT;AW-PJT,PU FOAM, |
| DA72-00387A | SEAL-PIPE, WATER |
| DA62-02453A | SEAL-REINF CABI MID FRONT;PU F |
| DA62-02323A | SEAL-REINF FLANGE UP;CULLINAN, |
| DA62-00232A | SEAL-SENSOR FRE, DISP |
| DA62-00079A | SEAL-SUPPORT MOTOR |
| DA62-03420A | SEAL-SUPT TUBE FILTER;AW2-11,P |
| DA62-00959A | SEAL-TUBE WATER |
| DA62-02536A | SEAL;FDSR,LEX FOAM,T15,NON-COM |
| DA32-00088A | SENSOR HUMIDITY |
|
|
SENSOR TEMP |
|
|
SENSOR TEMP |
|
|
SENSOR TEMP |
|
|
SENSOR TEMP |
| DA32-00075D | SENSOR-CAPACITANCE;5V,NEO VICT |
| DA32-00063B | SENSOR-ELECTRODE;5V,CLIPPING T |
| DA66-00437H | SHAFT |
| DA66-00960A | SHAFT HINGE-UPP;AW4-PJT,CR-SPC |
|
|
SHAFT-CASTER |
| DA66-01562A | SHAFT-HANDLE;RF8000B,HSWR,L170 |
| DA66-00793A | SHAFT-LEG FRONT |
| DA66-01561A | SHAFT;RF8000B,ABS,DARK GRAY,D8 |
| DA63-11786A | SHEET ABS;RF8000,ABS,T1.3,QU-0 |
| DA63-11783A | SHEET ABS;RF8000,ABS,T1.85,QU- |
| DA63-12040A | SHEET;RF6500C,ABS,T3.7,QU-0191 |
| DA67-05162A | SHELF FOLDER-FRONT;RF9000AC,PP |
| DA67-05391A | SHELF FOLDER-REAR;RF8000BC,PP, |
| DA67-05419A | SHELF PANTRY , RF8000B,HIPS,CO |
| DA67-05153A | SHELF VEGETABLE-LOW;RF9000AC,H |
| DA67-05390A | SHELF-REF FIX , RF8000BC,PP,CO |
|
|
SHIM-HINGE UPP |
| DA66-01566A | SLIDER HANDLE , RF8000B,POM,CR |
| 0103-009131 | SMG PART |
| 0103-012115 | SMG PART |
| 0103-012200 | SMG PART |
| 2007-007107 | SMG PART |
| 2007-007136 | SMG PART |
| 2007-007139 | SMG PART |
| 2007-007142 | SMG PART |
| 2007-007309 | SMG PART |
| 2007-007311 | SMG PART |
| 2007-007312 | SMG PART |
| 2007-007313 | SMG PART |
| 2007-007316 | SMG PART |
| 2007-007317 | SMG PART |
| 2007-007318 | SMG PART |
| 2007-007319 | SMG PART |
| 2007-007528 | SMG PART |
| 2007-007589 | SMG PART |
| 2007-007590 | SMG PART |
| 2007-007627 | SMG PART |
| 2007-007671 | SMG PART |
| 2007-007766 | SMG PART |
| 2007-007861 | SMG PART |
| 2007-007943 | SMG PART |
| 2007-008117 | SMG PART |
| 2203-000233 | SMG PART |
| 2203-000438 | SMG PART |
| 2203-000489 | SMG PART |
| 2203-000585 | SMG PART |
| 2203-000714 | SMG PART |
| 2203-000812 | SMG PART |
| 2203-007392 | SMG PART |
| 2203-007393 | SMG PART |
| 2203-007795 | SMG PART |
| 2203-007809 | SMG PART |
| DA01-01689D | SMG PART |
| DA01-02180A | SMG PART |
| DA41-00867F | SMG PART |
| DA61-15507A | SMG PART |
| DA61-15728F | SMG PART |
| DA61-15728G | SMG PART |
| DA63-11739E | SMG PART |
| DA64-06603E | SMG PART |
| DA64-06603F | SMG PART |
| DA64-07042E | SMG PART |
| DA68-04439B | SMG PART |
| DA68-04514A | SMG PART |
| DA69-02705A | SMG PART |
| DA69-02707A | SMG PART |
| DA69-02858A | SMG PART |
| DA90-13606A | SMG PART |
| DA90-13612A | SMG PART |
| DA90-13619A | SMG PART |
| DA90-13624A | SMG PART |
| DA90-13629A | SMG PART |
| DA90-13632A | SMG PART |
| DA90-13636A | SMG PART |
| DA90-13641A | SMG PART |
| DA90-13649A | SMG PART |
| DA90-13660A | SMG PART |
| DA91-06553A | SMG PART |
| DA91-06627A | SMG PART |
| DA91-06628A | SMG PART |
| DA92-01773D | SMG PART |
| DA93-01320A | SMG PART |
| DA93-01324A | SMG PART |
| DA93-01335A | SMG PART |
| DA93-01343A | SMG PART |
| DA94-09064A | SMG PART |
| DA94-09065A | SMG PART |
| DA94-09428E | SMG PART |
| DA96-01526A | SMG PART |
| DA97-21878N | SMG PART |
| DA97-21878P | SMG PART |
| DA97-22006P | SMG PART |
| DA97-22970D | SMG PART |
| DA97-22977B | SMG PART |
| DA97-22996B | SMG PART |
| DA97-23018K | SMG PART |
| DA97-23533A | SMG PART |
| DA97-23544B | SMG PART |
| DA97-23594A | SMG PART |
| DA97-23595A | SMG PART |
| DA97-23629A | SMG PART |
| DA97-23638A | SMG PART |
| DA97-24019F | SMG PART |
| DA97-24019G | SMG PART |
| DA98-03274A | SMG PART |
| DA98-03276A | SMG PART |
| DA99-05134A | SMG PART |
| DA99-05158A | SMG PART |
| DA02-00202A | SOLDER RING;ID6.4,91.75CU/6.25 |
| DA02-00202D | SOLDER RING;ID:2.1,91.75CU/6.2 |
| DA02-00202H | SOLDER RING;ID:3.55,91.75CU/6. |
| DA02-00202C | SOLDER RING;ID:7.99,91.75CU/6. |
| DA02-00202F | SOLDER RING;YSS26,D0.6,26AG/41 |
| 0202-001976 | SOLDER-CREAM;LST-309M-K21 (PWM |
| 0202-001463 | SOLDER-WIRE |
| DA61-08315A | SPRING ETC-ETC CAP GUIDE |
| DA61-05782A | SPRING ETC-INNER;SSEDA,STS304, |
| DA61-05783A | SPRING ETC-SHAFT;SSEDA,STS304, |
| DA61-08314B | SPRING FRENCH;RFH920G,STS304 |
| DA61-15159A | SPRING HANDLE;RF8000B,STS304,I |
| 3502-001087 | SSR;DC12V,2A,9.6-25MV,-30TO+80 |
| 0101-002926 | STEEL PLATE;GI,SGCC,0.35MM,290 |
| DA61-13422A | STOPPER DOOR REF LOW |
|
|
STOPPER DOOR-REF |
| DA61-15185A | STOPPER ROLLER;RF8000,POM,K300 |
| DA61-10712B | STOPPER ROLLER;RF9000K,SWRCH10 |
| DA61-15184A | STOPPER-FRE;RF8000,POM,K300,NA |
| DA61-06756A | STOPPER-RAIL MID;ARAM10-PJT,RU |
|
|
SUPPORT ICE MAKER |
| DA61-15211A | SUPPORT RAIL , RF8000BC,HIPS,T |
| DA61-14692A | SUPPORT TUBE;RF4500A,PP,RM60,B |
| DA61-10293A | SUPPORT WIRE-UP;PP,T1.5,BJ750, |
|
|
SUPPORT-CIRCUIT MOTOR |
| DA61-15290A | SUPPORT-REF , RF8000B-3D-FS,PO |
| 4715-001217 | SURGE ABSORBER;3600V,20%,3000A |
|
|
SWITCH PRESSURE |
|
|
SWITCH REED |
|
|
SWITCH REED |
| DA34-00043M | SWITCH REED |
| DA02-00250A | TAPE AL;RQ9500R,AL,T0.135,NATU |
| DA02-10014A | TAPE ETC-AL |
| DA02-10005C | TAPE ETC-MASKING |
| DA02-10011D | TAPE ETC-PE |
| DC69-90008A | TAPE OPP |
| 0203-001152 | TAPE-AL FOIL |
| 0203-001481 | TAPE-AL FOIL |
| 0203-005701 | TAPE-AL FOIL;AL,T0.03,W25,N/A, |
| DA02-10015A | TAPE-BINDER |
| 0203-001810 | TAPE-COTTON |
| 0203-001811 | TAPE-COTTON |
| 0203-006327 | TAPE-COTTON;COTTON,T0.24,W50,N |
| DA02-10007A | TAPE-DOUBLE FACE |
| 0203-001523 | TAPE-DOUBLE FACE;ACRYL,T0.15,W |
| 0203-006381 | TAPE-DOUBLE FACE;T0.4,W15,L33M |
| 0203-001545 | TAPE-FILAMENT |
| DA02-10005A | TAPE-MASKING |
| 0203-000143 | TAPE-OPP MASKING |
| 0203-006630 | TAPE-OPP MASKING;OPP,T0.065,W5 |
| 0203-001308 | TAPE-PAPER |
| DA02-10004C | TAPE-PAPER |
| DA02-10011A | TAPE-PE |
| DA02-10011C | TAPE-PE |
| 0203-001678 | TAPE-POLY |
| 0203-006797 | TAPE-POLY;PP,T0.11,W25,N/A,WHI |
| 0203-006425 | TAPE-POLY;TESA 4298,T0.116,W12 |
| 0203-007341 | TAPE-SINGLE FACE , PET,T0.037, |
| 0203-007230 | TAPE-SINGLE FACE;OPP,T0.065,W9 |
| 0203-006428 | TAPE-SINGLE FACE;OPP,T0.12,W30 |
| 0203-006521 | TAPE-SINGLE FACE;PET,T0.037,W8 |
| DA02-00038A | TETRAFLUOROETHANE |
| 1404-001544 | THERMISTOR-NTC;10KOHM,1%,3435K |
| 1404-001872 | THERMISTOR-PTC |
|
|
THERMO FUSE-ASSEMBLY |
| DA64-05949E | TOP TABLE;RF9000A,ABS,INOX GRA |
| 0506-000175 | TR-ARRAY |
| 0504-001080 | TR-DIGITAL |
| 0502-001250 | TR-POWER |
| 0501-000465 | TR-SMALL SIGNAL |
| 0501-000467 | TR-SMALL SIGNAL |
| DA26-00058C | TRANS SWITCHING;AC85-265V,3400 |
| DA63-08236A | TRAY DRAIN-WATER;AW2-14,PP,HB, |
| DA63-11569A | TRAY DRAWER-FRE , RF80000BC,PP |
| DA63-11232A | TRAY ICE;RF9000A,PP,T1,NATURAL |
| DA63-09323A | TRAY ICE;RS8000NC,PP,T1,NATURA |
| DA63-09788A | TRAY WATER;RF6000T,HIPS,T2.5,C |
| DA64-06367B | TRIM COVER-REF;RF9000A,HIPS,S8 |
| DA64-06448A | TRIM DOOR-LOW;RQ9500T(B),ABS,H |
| DA64-06222A | TRIM DOOR-REF;RF9000R(B),ABS,H |
| DA64-07001A | TRIM DOOR-UP;RF9000A,ABS,HG-07 |
| DA64-03784A | TRIM SHELF |
| DA64-06487B | TRIM SHELF-FRONT;RF8000B,ABS,H |
| DA64-05903E | TRIM SHELF-REAR;RF8000B,HIPS,S |
| DA64-04915E | TRIM SHELF-REF FRONT;RF9000R,A |
| DA64-04915F | TRIM SHELF-REF FRONT;RF9000R,A |
| DA64-06490A | TRIM SHELF-REF;RF9000A/AC,ABS, |
| DA62-05650B | TUBE , PO,OD16.2,L60,ID15,HOTM |
| DA62-01266B | TUBE PVC |
| DA62-04606B | TUBE-AL;AL,L520,T0.34, LA+CE |
| DA62-02414A | TUBE-FITTING L |
| DA62-05651J | TUBE;-,HDPE,OD16.2,L175,ID15,H |
| DA62-05651E | TUBE;PO,OD16.2,L120,ID15,HOTME |
| DA62-05881A | TUBE;RF8000B,HDPE,OD5.3,L160,I |
| DA62-06054J | TUBE;RF9000,PO,OD11.6,L180,ID1 |
| DA62-06054K | TUBE;RF9000,PO,OD11.6,L200,ID1 |
| DA62-06178E | TUBE;RF9000,PO,OD6.6,L100,ID5. |
| DA62-05372A | TUBE;UL STANDARD,PO,L1000,ID8, |
|
|
VALVE STEP |
| DA62-04030D | VALVE WATER;AC110-127V,RF6000T |
|
|
VALVE-FITTING NUT |
|
|
VALVE-FITTING PU |
| 1405-001239 | VARISTOR;680V,560VDC,6000A,17X |
| 4709-002960 | W-LAN MODULE |
| DA69-01982Q | WRAP VINYL , REF_ALL,LDPE,T0.0 |
| DA69-01981L | WRAP VINYL;LDPE,T0.04,W130,ROL |
| DA69-01981Q | WRAP VINYL;LDPE,T0.04,W200,ROL |
| DA69-01981C | WRAP VINYL;LDPE,T0.04,W40,ROLL |
