Manufacturer
Samsung
Model Number
UN40J520DAFXZA
Description
Led Tv,un40j520daf,40,united States,uae
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSEMBLY BOARD P-FUNCTION TACT |
|
|
ASSEMBLY CHASSIS FRONT P |
| BN96-37795K | ASSEMBLY COVER P-REAR |
|
|
ASSEMBLY GUIDE P-STAND |
|
|
ASSEMBLY HOLDER P-RING |
| BN96-33321A | ASSEMBLY OPEN CELL |
|
|
ASSEMBLY PCB MAIN-MAIN |
| BN96-30337D | ASSEMBLY SPEAKER P-FRONT |
|
|
ASSEMBLY STAND P-BOTTOM |
|
|
ASSY LED BAR P;39.5_FHD_FCOM_MODULE,ALUM |
| 6902-001063 | BAG PE |
| BH69-00418A | BAG PE-WRAPPING FILM |
| 4301-000121 | BATTERY-MN |
|
|
BEAD-SMD |
| 3301-001364 | BEAD-SMD |
| 3301-000314 | BEAD-SMD |
| 2203-007544 | C-CER,CHIP |
| 2203-007513 | C-CER,CHIP |
| 2203-007176 | C-CER,CHIP |
| 2203-006348 | C-CER,CHIP |
| 2203-006158 | C-CER,CHIP |
| 2203-006126 | C-CER,CHIP |
| 2203-006048 | C-CER,CHIP |
| 2203-005968 | C-CER,CHIP |
| 2203-005344 | C-CER,CHIP |
| 2203-005249 | C-CER,CHIP |
| 2203-002711 | C-CER,CHIP |
| 2203-002285 | C-CER,CHIP |
| 2203-000627 | C-CER,CHIP |
| 2203-000575 | C-CER,CHIP |
|
|
CBF-POWER CORD |
| 3701-001861 | CONNECTOR-HDMI |
| 3707-001106 | CONNECTOR-OPTICAL |
| 2801-003773 | CRYSTAL-SMD |
|
|
DC VSS-PD BOARD |
| 0404-001881 | DIODE-SCHOTTKY |
| 0404-001404 | DIODE-SCHOTTKY |
| 0401-001056 | DIODE-SWITCHING |
| 0406-001635 | DIODE-TVS |
| 0406-001628 | DIODE-TVS |
| 0403-001797 | DIODE-ZENER |
| 0403-001785 | DIODE-ZENER |
| 0403-001552 | DIODE-ZENER |
| 0505-003397 | FET-SILICON |
| 0505-003205 | FET-SILICON |
| 0505-002893 | FET-SILICON |
| 0505-002560 | FET-SILICON |
| BN96-36273X | FFC CABLE |
| BN63-00515A | GASKET |
| AA63-00969A | GASKET |
|
|
HEADER-BOARD TO CABLE |
|
|
HEADER-BOARD TO CABLE |
| 3711-008131 | HEADER-BOARD TO CABLE |
|
|
HOLDER-BOLT |
|
|
HOLDER-WIRE STAND |
| 1201-003690 | IC-AUDIO AMP |
| 1203-008183 | IC-DC/DC CONVERTER |
| 1203-008118 | IC-DC/DC CONVERTER |
| 1203-007984 | IC-DC/DC CONVERTER |
| 1105-002529 | IC-DDR3 SDRAM |
| 1103-001487 | IC-EEPROM |
| 1107-002374 | IC-EMMC |
| 1107-002226 | IC-NOR FLASH |
| 1203-007242 | IC-POSI.ADJUST REG. |
| 1203-006130 | IC-POSI.FIXED REG. |
| 1203-006330 | IC-POWER SUPERVISOR |
| 1205-004983 | IC-SWITCH |
| 1205-004447 | IC-SWITCH |
| 1204-003558 | IC-VIDEO PROCESS |
| 1203-006017 | IC-VOL. DETECTOR |
| 1203-004363 | IC-VOL. DETECTOR |
| 2703-003930 | INDUCTOR-SMD |
| 2703-003790 | INDUCTOR-SMD |
| 2703-003713 | INDUCTOR-SMD |
| 2703-000158 | INDUCTOR-SMD |
| 3722-003229 | JACK-MODULAR |
| 3722-003667 | JACK-PHONE |
|
|
JACK-PIN |
|
|
JACK-USB |
| BN68-00513A | LABEL-E, PASS |
| BN39-01885C | LEAD CONNECTOR |
| BN39-02125A | LEAD CONNECTOR-BLU |
|
|
NETWORK-WI-FI MODULE |
| BN95-02347A | PRODUCT LCD-INX |
| 2007-008779 | R-CHIP |
| 2007-008298 | R-CHIP |
| 2007-008294 | R-CHIP |
| 2007-008015 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-007720 | R-CHIP |
| 2007-001168 | R-CHIP |
| 2007-000803 | R-CHIP |
| 2007-000726 | R-CHIP |
| 2007-000583 | R-CHIP |
| 2007-000265 | R-CHIP |
| 2007-000256 | R-CHIP |
| 2011-001527 | R-NETWORK |
| 2011-001506 | R-NETWORK |
| 2011-001449 | R-NETWORK |
|
|
REMOTE CONTROL |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
| BN63-05199H | SHEET-COVER |
| 0203-001602 | TAPE-OPP MASKING |
| 0501-000467 | TR-SMALL SIGNAL |
| 0501-000445 | TR-SMALL SIGNAL |
|
|
TUNER |
|
|
VARISTOR |
