Manufacturer
Samsung
Model Number
UN50J5000AFXZA
Description
Led Tv,un50j5000af,50,united States,unb
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSEMBLY BOARD P-FUNCTION TACT |
| BN96-37146A | ASSEMBLY CHASSIS FRONT P |
| BN96-37797C | ASSEMBLY COVER P-REAR |
|
|
ASSEMBLY GUIDE P-STAND |
|
|
ASSEMBLY SPEAKER P-FRONT |
|
|
ASSEMBLY STAND P-BOTTOM |
|
|
ASSEMBLY T CON P |
| 6902-001063 | BAG PE |
| BH69-00418A | BAG PE-WRAPPING FILM |
| 4301-000121 | BATTERY-MN |
|
|
BEAD-SMD |
| 3301-001364 | BEAD-SMD |
| 2203-007544 | C-CER,CHIP |
| 2203-007513 | C-CER,CHIP |
| 2203-007176 | C-CER,CHIP |
| 2203-006698 | C-CER,CHIP |
| 2203-006348 | C-CER,CHIP |
| 2203-006158 | C-CER,CHIP |
| 2203-006126 | C-CER,CHIP |
| 2203-006048 | C-CER,CHIP |
| 2203-005249 | C-CER,CHIP |
| 2203-002982 | C-CER,CHIP |
| 2203-002720 | C-CER,CHIP |
| 2203-002285 | C-CER,CHIP |
| 2203-001683 | C-CER,CHIP |
| 2203-001391 | C-CER,CHIP |
|
|
CBF-POWER CORD |
| 3701-001861 | CONNECTOR-HDMI |
| 3711-007585 | CONNECTOR-HEADER |
| 3707-001106 | CONNECTOR-OPTICAL |
| 2801-004774 | CRYSTAL-SMD |
| 2801-003778 | CRYSTAL-SMD |
|
|
DC VSS-PD BOARD |
| 0404-001404 | DIODE-SCHOTTKY |
| 0407-000114 | DIODE-SWITCHING |
| 0401-001166 | DIODE-SWITCHING |
| 0406-001635 | DIODE-TVS |
| 0403-001785 | DIODE-ZENER |
| 0505-003397 | FET-SILICON |
| 0505-002560 | FET-SILICON |
| BN96-36274X | FFC CABLE |
| BN63-00520A | GASKET |
| BN63-00135A | GASKET |
|
|
HEADER-BOARD TO CABLE |
| 3711-008521 | HEADER-BOARD TO CABLE |
|
|
HOLDER-BOLT |
|
|
HOLDER-WIRE STAND |
| 1001-001545 | IC-ANALOG MULTIPLEX |
| 1201-003891 | IC-AUDIO AMP |
| 1203-008183 | IC-DC/DC CONVERTER |
| 1203-008119 | IC-DC/DC CONVERTER |
| 1107-002248 | IC-NOR FLASH |
| 1203-006118 | IC-POSI.FIXED REG. |
| 1203-006109 | IC-POSI.FIXED REG. |
| 1205-004447 | IC-SWITCH |
| 1204-003562 | IC-TUNER |
| 1203-006017 | IC-VOL. DETECTOR |
| 1203-004364 | IC-VOL. DETECTOR |
| 2703-003930 | INDUCTOR-SMD |
| 2703-003135 | INDUCTOR-SMD |
| 2703-002238 | INDUCTOR-SMD |
| 2703-000158 | INDUCTOR-SMD |
|
|
JACK-PIN |
|
|
JACK-USB |
| BN68-00513A | LABEL-E, PASS |
| BN39-02136A | LEAD CONNECTOR-BLU |
|
|
LEAD CONNECTOR-POWER |
|
|
PRODUCT LCD-INX |
| 2007-008649 | R-CHIP |
| 2007-008015 | R-CHIP |
| 2007-007668 | R-CHIP |
| 2007-000931 | R-CHIP |
| 2007-000695 | R-CHIP |
| 2007-000691 | R-CHIP |
| 2007-000063 | R-CHIP |
| 2007-000060 | R-CHIP |
| 2007-000052 | R-CHIP |
| 2011-001449 | R-NETWORK |
|
|
REMOTE CONTROL |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
| BN63-05199H | SHEET-COVER |
| 0203-001602 | TAPE-OPP MASKING |
| 0501-000445 | TR-SMALL SIGNAL |
| 0501-000279 | TR-SMALL SIGNAL |
|
|
VARISTOR |
