Manufacturer
Samsung
Model Number
UN60J6200AFXZA
Description
Led Tv,un60j6200af,60,united States,une
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSEMBLY BOARD P-JOG SWITCH & |
|
|
ASSEMBLY CABLE P |
| BN96-34380A | ASSEMBLY CHASSIS TOP P |
|
|
ASSEMBLY COVER P-MIDDLE |
| BN96-37680A | ASSEMBLY COVER P-REAR |
|
|
ASSEMBLY GUIDE P-STAND |
|
|
ASSEMBLY PCB MAIN;UN60J6200AFX |
|
|
ASSEMBLY SPEAKER P |
|
|
ASSEMBLY STAND P-BASE |
|
|
ASSEMBLY T CON |
| 6902-000341 | BAG PE |
| BH69-00418A | BAG PE-WRAPPING FILM |
|
|
BEAD-SMD |
| 3301-001404 | BEAD-SMD |
| 3301-001364 | BEAD-SMD |
| 3301-000314 | BEAD-SMD |
| BN61-04692A | BOSS-PRIMER |
| BN61-07962B | BRACKET-STNAD LINK |
|
|
BRACKET-WALL |
| 2203-008315 | C-CER,CHIP |
| 2203-008096 | C-CER,CHIP |
| 2203-007600 | C-CER,CHIP |
| 2203-007544 | C-CER,CHIP |
| 2203-007513 | C-CER,CHIP |
| 2203-007486 | C-CER,CHIP |
| 2203-007306 | C-CER,CHIP |
| 2203-007176 | C-CER,CHIP |
| 2203-006960 | C-CER,CHIP |
| 2203-006698 | C-CER,CHIP |
| 2203-006377 | C-CER,CHIP |
| 2203-006348 | C-CER,CHIP |
| 2203-006158 | C-CER,CHIP |
| 2203-006126 | C-CER,CHIP |
| 2203-006090 | C-CER,CHIP |
| 2203-006048 | C-CER,CHIP |
| 2203-005968 | C-CER,CHIP |
| 2203-005344 | C-CER,CHIP |
| 2203-005249 | C-CER,CHIP |
| 2203-005221 | C-CER,CHIP |
| 2203-002982 | C-CER,CHIP |
| 2203-002720 | C-CER,CHIP |
| 2203-002711 | C-CER,CHIP |
| 2203-002398 | C-CER,CHIP |
| 2203-002285 | C-CER,CHIP |
| 2203-002050 | C-CER,CHIP |
| 2203-001587 | C-CER,CHIP |
| 2203-000888 | C-CER,CHIP |
| 2203-000627 | C-CER,CHIP |
| 2203-000575 | C-CER,CHIP |
| 2503-001051 | C-NETWORK |
| 2409-001118 | C-POLYMER ,CHIP |
|
|
CBF-POWER CORD |
| 3708-003043 | CONNECTOR-FPC/FFC/PIC |
| 3701-001856 | CONNECTOR-HDMI |
| 3707-001106 | CONNECTOR-OPTICAL |
| BN63-10106A | COVER-MIDDLE |
| BN63-02183D | COVER-SHEET |
| 2801-005324 | CRYSTAL-SMD |
| 2801-003773 | CRYSTAL-SMD |
|
|
DC VSS-LED TV PD BD |
| 0404-001881 | DIODE-SCHOTTKY |
| 0404-001643 | DIODE-SCHOTTKY |
| 0404-001640 | DIODE-SCHOTTKY |
| 0404-001404 | DIODE-SCHOTTKY |
| 0404-001307 | DIODE-SCHOTTKY |
| 0406-001635 | DIODE-TVS |
| 0406-001628 | DIODE-TVS |
| 0406-001445 | DIODE-TVS |
| 0406-001438 | DIODE-TVS |
| 0505-003397 | FET-SILICON |
| 0505-002937 | FET-SILICON |
| 0505-002925 | FET-SILICON |
| 0505-002893 | FET-SILICON |
| 0505-002790 | FET-SILICON |
| 0505-002645 | FET-SILICON |
| 0505-002598 | FET-SILICON |
| 0505-000274 | FET-SILICON |
| 2901-001362 | FILTER-EMI/ESD |
| BN73-00052C | FOOT RUBBER |
| BN63-00119A | GASKET |
|
|
HEADER-BOARD TO CABLE |
| 3711-008453 | HEADER-BOARD TO CABLE |
| 3711-008131 | HEADER-BOARD TO CABLE |
| 3711-005601 | HEADER-BOARD TO CABLE |
|
|
HOLDER-WIRE STAND |
| 1201-003690 | IC-AUDIO AMP |
| 0801-003330 | IC-CMOS LOGIC |
| 1203-008118 | IC-DC/DC CONVERTER |
| 1203-007984 | IC-DC/DC CONVERTER |
| 1203-007552 | IC-DC/DC CONVERTER |
| 1105-002529 | IC-DDR3 SDRAM |
| 1006-001576 | IC-DRIVER/RECEIVER |
| 1103-001487 | IC-EEPROM |
| 1107-002374 | IC-EMMC |
| 1003-002412 | IC-LEVEL DRIVER |
| 1205-004222 | IC-MULTIPLIER |
| 1107-002226 | IC-NOR FLASH |
| 1201-002980 | IC-OP AMP |
| 1203-007242 | IC-POSI.ADJUST REG. |
| 1203-006130 | IC-POSI.FIXED REG. |
|
|
IC-SENSOR |
| 1205-004983 | IC-SWITCH |
| 1205-004447 | IC-SWITCH |
| 1204-003558 | IC-VIDEO PROCESS |
| 1204-003485 | IC-VIDEO PROCESS |
| 1203-006017 | IC-VOL. DETECTOR |
| 1203-004363 | IC-VOL. DETECTOR |
| 2703-004847 | INDUCTOR-SMD |
| 2703-004462 | INDUCTOR-SMD |
| 2703-003937 | INDUCTOR-SMD |
| 2703-003930 | INDUCTOR-SMD |
| 2703-003862 | INDUCTOR-SMD |
| 2703-003803 | INDUCTOR-SMD |
| 2703-003790 | INDUCTOR-SMD |
| 2703-003747 | INDUCTOR-SMD |
| 2703-003713 | INDUCTOR-SMD |
| 2703-000158 | INDUCTOR-SMD |
| 3722-003229 | JACK-MODULAR |
| 3722-003667 | JACK-PHONE |
| 3722-003226 | JACK-PHONE |
|
|
JACK-PIN |
| 3722-003248 | JACK-USB |
| BN68-00513A | LABEL-E, PASS |
|
|
LEAD CONNECTOR |
| BN39-01931D | LEAD CONNECTOR-FUNCTION |
|
|
NETWORK-WIFI MODULE |
| 2007-008779 | R-CHIP |
| 2007-008714 | R-CHIP |
| 2007-008298 | R-CHIP |
| 2007-008294 | R-CHIP |
| 2007-008167 | R-CHIP |
| 2007-008015 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-007767 | R-CHIP |
| 2007-007723 | R-CHIP |
| 2007-007721 | R-CHIP |
| 2007-007651 | R-CHIP |
| 2007-007463 | R-CHIP |
| 2007-007455 | R-CHIP |
| 2007-007431 | R-CHIP |
| 2007-007239 | R-CHIP |
| 2007-007229 | R-CHIP |
| 2007-002768 | R-CHIP |
| 2007-002425 | R-CHIP |
| 2007-001433 | R-CHIP |
| 2007-001237 | R-CHIP |
| 2007-001206 | R-CHIP |
| 2007-001168 | R-CHIP |
| 2007-001125 | R-CHIP |
| 2007-001096 | R-CHIP |
| 2007-001038 | R-CHIP |
| 2007-000910 | R-CHIP |
| 2007-000857 | R-CHIP |
| 2007-000803 | R-CHIP |
| 2007-000779 | R-CHIP |
| 2007-000772 | R-CHIP |
| 2007-000736 | R-CHIP |
| 2007-000726 | R-CHIP |
| 2007-000691 | R-CHIP |
| 2007-000614 | R-CHIP |
| 2007-000583 | R-CHIP |
| 2007-000491 | R-CHIP |
| 2007-000336 | R-CHIP |
| 2007-000265 | R-CHIP |
| 2007-000256 | R-CHIP |
| 2007-000239 | R-CHIP |
| 2007-000231 | R-CHIP |
| 2007-000109 | R-CHIP |
| 2007-000067 | R-CHIP |
| 2007-000066 | R-CHIP |
| 2007-000060 | R-CHIP |
| 2007-000052 | R-CHIP |
| 2007-000043 | R-CHIP |
| 2007-000029 | R-CHIP |
| 2011-001587 | R-NETWORK |
| 2011-001527 | R-NETWORK |
| 2011-001506 | R-NETWORK |
| 2011-001449 | R-NETWORK |
| 2011-001427 | R-NETWORK |
| 2011-001264 | R-NETWORK |
|
|
REMOTE CONTROL |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
| BN61-07527A | STAND, BASE |
| 0203-001602 | TAPE-OPP MASKING |
| 0502-001360 | TR-POWER |
| 0502-001346 | TR-POWER |
| 0502-001331 | TR-POWER |
| 0501-000465 | TR-SMALL SIGNAL |
| 0501-000445 | TR-SMALL SIGNAL |
| 0501-000002 | TR-SMALL SIGNAL |
|
|
TUNER-DTV AIR CABLE |
| 1405-001381 | VARISTOR |
|
|
VARISTOR |
