Model Image
Manufacturer

Samsung

Model Number

UN82MU8000FXZA

Description

82-inch Uhd 4k Hdr Led Smart Hdtv

Interactive Exploded View
Exploded View

Parts List

Part Number Description
BN96-39802C BN96-39802C ASSY BOARD P-FUNCTION TACT;KS7000/7500/K
BN96-43718B ASSY CHASSIS FRONT P;82MU7000,AL,MOON DA
BN96-43023A ASSY COVER P-CLEAN BACK AC INLET;82MU700
BN96-43018A ASSY COVER P-CLEAN BACK TERMINAL;75MU700
BN96-43719B ASSY COVER P-DECORATION;82MU7000,PC+ABS+
BN96-43897A ASSY COVER P-REAR;82MU7000,PC+ABS+ED20%,
BN96-43169A BN96-43169A ASSY HOLDER P-RING;65Q8C,ABS,BLACK,HB
BN96-44183A BN96-44183A ASSY ONE CONNECT MINI;MU7000,55,BN91-187
BN94-12552A BN94-12552A ASSY PCB MAIN;MU7/8/9K , PCB B VER.
BN94-12361A ASSY PCB OCM;MU,BN94-11965A
BN96-44749H ASSY PCB P-TCON;BN95-04323A,FR-1,SDC MU7
BN96-42489B BN96-42489B ASSY SPEAKER P-FRONT;TV-SPK,MU7000,6OHM,
BN96-42789A ASSY STAND P-COVER BOTTOM LEFT;82MU7000,
BN96-42788A ASSY STAND P-COVER BOTTOM RIGHT;82MU7000
3301-002039 3301-002039 BEAD-SMD;26OHM,1608,TP
BN61-13557A BRACKET-WIRE;55KS7000,SW-C,T1,SILVER,L62
BN61-13557K BRACKET-WIRE;55KS7000,SW-C,T1,SILVER,ZIN
BN61-13557D BRACKET-WIRE;55KS7000,SW-C,T1,SILVER,ZIN
BN61-13557C BRACKET-WIRE;55KS7000,SW-C,T1,SILVER,ZIN
2203-001851 C-CER,CHIP;0.016NF,5%,50V,C0G,TP,1608
2203-005642 C-CER,CHIP;0.22NF,5%,50V,C0G,TP,1005,T0.
2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
2203-007513 C-CER,CHIP;10000NF,10%,10V,X5R,TP,1608,T
2203-007176 C-CER,CHIP;10000NF,10%,16V,X5R,TP,2012,T
2203-007306 C-CER,CHIP;10000NF,10%,25V,X5R,TP,2012,T
2203-007423 C-CER,CHIP;10000NF,10%,35V,X7R,TP,3216
2203-006348 C-CER,CHIP;1000NF,10%,25V,X5R,TP,1608,T0
2203-006698 C-CER,CHIP;1000NF,10%,25V,X7R,TP,1608,T0
2203-006960 C-CER,CHIP;1000NF,10%,50V,X7R,TP,2012
2203-006399 C-CER,CHIP;1000NF,10%,6.3V,X5R,TP,1005
2203-006048 C-CER,CHIP;100NF,10%,10V,X7R,TP,1005
2203-006158 C-CER,CHIP;100NF,10%,16V,X7R,TP,1005,T0.
2203-007544 C-CER,CHIP;100NF,10%,50V,X7R,TP,1005,T0.
2203-002285 C-CER,CHIP;10NF,10%,50V,X7R,TP,1005
2203-000491 C-CER,CHIP;2.2NF,10%,50V,X7R,TP,1608
2203-005344 C-CER,CHIP;22NF,10%,25V,X7R,TP,1005,T0.5
2203-006088 C-CER,CHIP;330NF,10%,10V,X7R,TP,1608
2203-005968 C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005,T0.
2203-006377 C-CER,CHIP;4700NF,10%,25V,X5R,TP,2012
2203-006844 C-CER,CHIP;470NF,10%,10V,X5R,TP,1005
2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005,T0.5
2409-001240 C-ORGANIC,SMD;33UF,20%,25V,LR,TP,7343(1.
3708-003176 CONNECTOR-FPC/FFC/PIC;68P,0.5MM,SMD-A,AU
3701-001967 CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5MM,BLK
3711-009090 CONNECTOR-HEADER;BOX,16P,1R,1.25MM,SMD-A
3711-009106 CONNECTOR-HEADER;BOX,20P,2R,2MM,ANGLE,SN
3707-001104 CONNECTOR-OPTICAL;ANGLE,SPDIF
3710-004144 CONNECTOR-SOCKET;44P,1R,0.5MM,SMD-A,AU,B
BN63-15074H COVER-OC BOTTOM;55MU7000,PC+ABS,V-0,BK00
BN63-16640A COVER-TERMINAL SIDE;55MU7000,HIPS,HB,BK0
2801-000102 CRYSTAL-SMD;12MHZ,30PPM,12PF,100OHM,TP
2801-004021 CRYSTAL-SMD;24.576MHZ,20PPM,28-AAN,12PF,
2801-005324 CRYSTAL-SMD;27MHZ,30PPM,CERAMIC SMD(4PIN
BN44-00913A BN44-00913A DC VSS-PD BOARD;L78E8NR_MSM,AC/DC,305W,A
0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200MA,SOT-23,
0404-001953 DIODE-SCHOTTKY;MBRA340F-HAF,40V,3000MA,S
0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000MA,SOD
0404-001881 DIODE-SCHOTTKY;SS3040-HE,40V,3000MA,SOD-
0404-001307 DIODE-SCHOTTKY;SSC54,40V,5000MA,DO-214AB
0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO
0406-001786 DIODE-TVS;PJEC5V0V6TM,5V,7V,8V,0.1MAV,9V
0406-001778 DIODE-TVS;PUSB3FR4,6V,9V,0.2MAV,0.7VPA,0
0406-001691 DIODE-TVS;SESD8008MUTAG,5.5V,7V,8.5V,0.5
0406-001438 DIODE-TVS;SMCJ14A,15.6V,17.2V,1MAV,6.5VP
0406-001635 DIODE-TVS;SMF5.0A,6.4V,6.7V,7V,200MAV,20
0403-001831 DIODE-ZENER;KDZ12B,12~13.5V,1000MW,SOD-1
0403-000489 DIODE-ZENER;MMSZ5228B,3.705~4.095V,500MW
0403-001164 DIODE-ZENER;MMSZ5232B,5.32~5.88V,500MW,S
0505-003397 FET-SILICON;2N7002K,N,60V,0.38A,1.19OHM,
0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2
0505-002560 FET-SILICON;AO6415,P,20V,-3.3A,0.15OHM,1
0505-003391 FET-SILICON;AOD2922,N,100V,8A,140MOHM,18
0505-002598 FET-SILICON;AP2317GN,P,20V,-4.2A,0.052OH
0505-003205 FET-SILICON;DMG4435SSS-13,P,30V,-7.3A,1.
0505-002660 FET-SILICON;SI2308BDS,N,60V,2.3A,0.156OH
0505-001844 FET-SILICON;SI4435DDY-T1-GE3,P,30V,-11.4
BN96-39821B BN96-39821B FFC CABLE;49KS7500,FOLD,L350,96P
2901-001362 FILTER-EMI/ESD
3601-001061 3601-001061 FUSE-SURFACE MOUNT;125V,10A,FAST-ACTING,
3601-001376 3601-001376 FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,HI
3711-007803 HEADER-BOARD TO CABLE;BOX,12P,1R,1.25MM,
3711-008488 HEADER-BOARD TO CABLE;BOX,14P,2R,2MM,ANG
3711-009033 HEADER-BOARD TO CABLE;BOX,16P,1R,2MM,SMD
3711-008453 HEADER-BOARD TO CABLE;BOX,18P,2R,2MM,ANG
BN62-00574A HEAT SINK-ES;F7000,A6063,W28,L14,BLACK,T
AA61-20285C HOLDER-BOX;ALL,PP,BLACK,HB,HB,17.5G
BN13-00070A IC ASIC;UEI1702,UEI1702,20P,3.3V,-20TO+7
1001-002047 IC-ANALOG MULTIPLEX;TS3USB3031,QFN,12P,1
1201-004003 IC-AUDIO AMP;TAS880021,TSSOP,48P,12.5X6.
0801-003604 IC-CMOS LOGIC;NL17SZ17DFT2G,SC-70,5P,TP,
0801-003580 IC-CMOS LOGIC;TC7WB66CFK,SSOP,8P,2.0X2.3
1203-008746 IC-DC/DC CONVERTER;AOZ2264QI-11,QFN,23,4
1203-007695 IC-DC/DC CONVERTER;AOZ3018,SO-8,8,4.96X3
1203-008917 IC-DC/DC CONVERTER;G5334CQT1U,QFN4,23P,4
1203-008664 IC-DC/DC CONVERTER;RT6935BGQW,WQFN,56,7X
1203-008522 IC-DC/DC CONVERTER;SN1501019DDCR,SOT-23,
1203-008920 IC-DC/DC CONVERTER;SYD105ADC,TSOT23,6P,2
1203-008082 IC-DC/DC CONVERTER;TPS54627DDAR,SOP 8P,8
1203-008777 IC-DC/DC CONVERTER;TPS563201,SOT-23,6,1.
1105-002772 IC-DDR3 SDRAM;K4B1G1646I-BCMA,-,1GBIT,64
1105-002751 IC-DDR4 SDRAM;K4F2E3S4HM-MGCJ,LPDDR4-SDR
1204-003743 IC-DECODER;SDP1602,FCBGA,319P,15.5X15.5X
1204-003742 IC-DECODER;SDP1603,FCBGA,1147P,31X31X2.2
1006-001595 IC-DRIVER/RECEIVER;UT3221G-P16-R,TSSOP-1
1103-001564 IC-EEPROM;S-24C512CI-J800,512KBIT,64KX8,
1107-002515 IC-EMMC;KLM8G1GEME-B041,8GBYTE,64GBX2,BG
1107-002223 IC-NOR FLASH;W25Q16DVSSIG,16MBIT,2MBITX8
1107-002226 IC-NOR FLASH;W25Q40CLSSIP,4MBIT,SOIC,8P,
1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10
1203-008933 IC-POSI.ADJUST REG.;G942F11U,SOP,8P,4.9X
1205-005706 IC-RECEIVER;SN65LVDS4,UQFN,10P,1.50X2.00
1205-005537 IC-REPEATER;TCA9517,VSSOP,8P,3.00X3.00MM
1209-002183 1209-002183 IC-SENSOR;S-5851AAA-M6T1U,SOT,6Z30,2.9X1
1205-005519 IC-SWITCH;ET20163,SOT23-5,5P,2.95X3.02MM
1205-005749 IC-SWITCH;G2897KD1U,TDFN2X3-14,14P,2X3MM
1205-004692 IC-SWITCH;TPS2069CDBVR,SOT-23,5P,2.9X2.8
0904-002882 IC-USC;GL852G-OHY38,QFN,28P,5X5MM,12MHZ,
1203-008392 IC-VOL. DETECTOR;S-6414AAB-L800X,TSOT-23
1203-004363 IC-VOL. DETECTOR;SOT-23,3Z30,2.9X1.6MM,P
2703-005191 INDUCTOR-SMD;1.5UH,20%,6060,T4.5,0.02OHM
2703-003713 INDUCTOR-SMD;1.5UH,20%,7366,T3,0.015OHM,
2703-005376 INDUCTOR-SMD;10UH,20%,10.7X10MM,T3.8,0.0
2703-003862 INDUCTOR-SMD;10UH,20%,6060,0.065OHM,1900
2703-003937 INDUCTOR-SMD;1UH,20%,70647,T3,0.008OHM,9
2703-005193 INDUCTOR-SMD;2.2UH,20%,6060,T4.5,0.024OH
2703-003747 INDUCTOR-SMD;22UH,20%,6060,0.135OHM,1300
2703-005194 INDUCTOR-SMD;3.3UH,20%,6060,T4.5,0.03OHM
2703-003803 INDUCTOR-SMD;4.7UH,20%,6060,0.031OHM,270
2703-004724 INDUCTOR-SMD;8.2UH,20%,5050,T4,0.072OHM,
3722-003199 JACK-MODULAR;8P/8C,Y,ANGLE,NONE,AU,1PORT
3722-003216 JACK-PHONE;1P/7C,AU,BLK,SMD-A,3.6PI,10.2
3722-003457 3722-003457 JACK-USB;4P/1C,NI,BLK,ANGLE,A,2.0,13.1X1
BN39-02322B LEAD CONNECTOR-DIMMING;65MU7,UL21016,18P
BN39-02249D LEAD CONNECTOR-DIMMING;75MU7000,UL21016,
BN39-02207H LEAD CONNECTOR-POWER;65MU7,UL21016,20P,4
BN39-02211E LEAD CONNECTOR-SUB ASSY;65KS9800,UL21451
BN39-02231E LEAD CONNECTOR-SUB ASSY;82MU7000,UL21016
BN59-01264A BN59-01264A NETWORK-WLAN CLIENT;WCM730Q,78.3X29.3X7.
BN39-02210C BN39-02210C ONECONNECTMINI CABLE;MU9000~MU7000,44P,L
3903-001173 3903-001173 POWER CORD-DT;USA,2P-F,125V,7A,GRY,L3000
BN95-04409C BN95-04409C PRODUCT LCD-SDC;CY-SM082FLLV3V/H,MU7000,
2007-008596 R-CHIP;0.1OHM,1%,1/4W,TP,3216
2007-012045 R-CHIP;0OHM,1%,1/4W,TP,3216
2007-000219 R-CHIP;1.2KOHM,1%,1/10W,TP,1608
2007-009322 R-CHIP;1.3KOHM,1%,1/16W,TP,1005
2007-000052 R-CHIP;10KOHM,1%,1/10W,TP,1608
2007-010387 R-CHIP;10KOHM,1%,1/16W,TP,1005
2007-002899 R-CHIP;10OHM,1%,1/10W,TP,1608
2007-000308 R-CHIP;10OHM,5%,1/8W,TP,2012
2007-008134 R-CHIP;12.4KOHM,1%,1/16W,TP,1005
2007-007305 R-CHIP;120OHM,1%,1/16W,TP,1005
2007-000109 R-CHIP;1MOHM,5%,1/10W,TP,1608
2007-003015 R-CHIP;2.2OHM,5%,1/16W,TP,1005
2007-007767 R-CHIP;200OHM,1%,1/16W,TP,1005
2007-000066 R-CHIP;20KOHM,1%,1/10W,TP,1608
2007-007520 R-CHIP;20OHM,1%,1/10W,TP,1608
2007-008067 R-CHIP;21KOHM,1%,1/10W,TP,1608
2007-008563 R-CHIP;270OHM,1%,1/16W,TP,1005
2007-007650 R-CHIP;274OHM,1%,1/10W,TP,1608
2007-000683 R-CHIP;3.3KOHM,1%,1/10W,TP,1608
2007-008294 R-CHIP;33OHM,1%,1/16W,TP,1005
2007-000084 R-CHIP;4.7KOHM,5%,1/10W,TP,1608
2007-009777 R-CHIP;4.99KOHM,1%,1/16W,TP,1005
2007-008298 R-CHIP;49.9OHM,1%,1/16W,TP,1005
2007-007736 R-CHIP;510KOHM,1%,1/10W,TP,1608
2007-008269 R-CHIP;51KOHM,1%,1/16W,TP,1005
2007-001116 R-CHIP;680OHM,1%,1/10W,TP,1608
2007-001125 R-CHIP;68KOHM,1%,1/10W,TP,1608
2007-008015 R-CHIP;75OHM,1%,1/16W,TP,1005
2011-001427 R-NETWORK;0OHM,5%,1/16W,L,CHIP,8P,TP,2.0
2011-001587 R-NETWORK;100OHM,5%,1/16W,L,CHIP,4P,TP,1
2011-001448 R-NETWORK;10OHM,5%,1/16W,L,4P,TP,1.0X1.0
2011-001264 R-NETWORK;10OHM,5%,1/16W,L,CHIP,8P,TP,2.
2011-001586 R-NETWORK;1KOHM,5%,1/16W,L,CHIP,4P,TP,1.
2011-001527 R-NETWORK;4.7KOHM,5%,1/16W,L,CHIP,4P,TP,
BN59-01266A BN59-01266A REMOCON-SMART CONTROL;2017 TV,SAMSUNG,14
6001-002755 6001-002755 SCREW-MACHINE;BH,M3,L6,ZPC(BLK),SWRCH1
6001-003016 6001-003016 SCREW-MACHINE;PWH,M3,L5.0,ZPC(WHT),SWR
6003-001449 SCREW-TAPTYPE;BH,B,M2.6,L6,NI PLT,SWRC
0504-000126 TR-DIGITAL;KSR1101,NPN,200MW,4.7K/4.7K,S
0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200MW,SC-59
0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150MW,SOT
0501-000465 TR-SMALL SIGNAL;MMBT3904,NPN,350MW,SOT-2
BN40-00329B BN40-00329B TUNER-DTV AIR CABLE;GVTH-7A21,VSB HALF,4
1405-001381 VARISTOR;11V,8VDC,30A,1608,TP,25V,500PF
1405-001382 VARISTOR;24.5V,16VDC,120A,2012,TP,42V,40
1405-001271 1405-001271 VARISTOR;35V,20VDC,5A,1005,TP,100V,10PF
1405-001232 VARISTOR;6.4V,5.6VDC,30A,1608,TP,19V,200
