Manufacturer
VIZIO
Model Number
SV420XVT1A
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
AC INLET 0707-1-CN/VHR5P 1617 610MM 1015 115MM |
|
|
ACCESSARY BOX (300W*230D*50H) |
|
|
ACETATE CLOTH TAPE 100X35MM |
|
|
ACETATE CLOTH TAPE 20*45MM |
|
|
ACETATE CLOTH TAPE 27*75MM |
|
|
ACETATE CLOTH TAPE 35*45MM |
|
|
ACETATE CLOTH TAPE 40*80MM |
|
|
ACETATE CLOTH TAPE 60*125MM |
|
|
AUDIO BD ASS'Y (SV42) |
|
|
BASE FOOT (TM-32V) |
|
|
BATTERY ALKALINE 1.5V AAA (LR03) MITSUBISHI LF |
|
|
BOX FOR MB VU42L FHDTV10A-SKD |
|
|
BUBBLE BAG (VS42L FHDTV10A,SKD) |
|
|
BUCKLE-AL PLATE(SV42)(AL T=0.6) |
|
|
CABLE CLIP (VW42L HDTV10A) |
|
|
CARTON JOINT (TM-32V) |
|
|
CARTON PARTITION FOR M/B (SV42LF,SKD)(480*388*160) |
|
|
CARTON TRAY (VW42L FHDTV10A) |
|
|
CARTON VIZIO SV420XVT1A |
|
|
CONN SIDE JACK BD ASS'Y (SV42) |
|
|
D.SIZE POLISHING CLOTH VIZIO |
|
|
DAUGHTER BD ASS'Y (SV42) |
|
|
DISPLAY BD ASS'Y (SV42) |
|
|
DISPLAY KEY(ABS 94-5V)(SV47) |
|
|
EMI BD ASS'Y (SV42) |
|
|
EPE FORM_TOP FOR M/B (VS42L FHDTV10A, SKD) |
|
|
EPS FOAM_BL (SV42) |
|
|
EPS FOAM_BR (SV42) |
|
|
EPS FOAM_TL (SV42) |
|
|
EPS FOAM_TR (SV42) |
|
|
FRONT BEZEL(TECHNOGY)(SV42)(ABS 94-HB/T52013) ASS'Y |
|
|
GASKET BLOCK (10.0W*13.0H*60.0L) |
|
|
GASKET BLOCK (20.0*13.0*10.0) |
|
|
GLUE, 94 PRIMER (FOR FACE PLATE) (M16) |
|
|
GUIDE REVISE SHEET VIZIO |
|
|
HDMI CABLE 1800MM BLACK |
|
|
HDMI CABLE 1800MM BLACK (CLOSED) |
|
|
KNOB COVER ASS'Y(SV42)(ABS 94-5V/T52013) |
|
|
LD-PE BAG (1280*1050*0.07) |
|
|
LED BACKLIGHT 16.72*56*1.5MM(LP1063-S637)580MM LF |
|
|
LED BACKLIGHT 18*34*3 800MM LP1013-S626-WW LF |
|
|
LICENSE: DOLBLY-AC3 TWO-CHANNEL DOLBY DIGITAL DECO |
|
|
LICENSE: HDMI |
|
|
LICENSE: MPEG-LA CONSUMER PRODUCTS |
|
|
MAC. SCREW-MB M3.0*6.0L,BLK-NI |
|
|
MAC. SCREW-MB M3.0*6.0L,NI |
|
|
MAC. SCREW-MB M4.0*4.0L,NI |
|
|
MAC. SCREW-MBGW M4.0*6.0L, NI |
|
|
MAC. SCREW-MF M3.0*8.0L,BLK-NI |
|
|
MAC. SCREW-MFHSFW,M6.0*20.0L,BLK-NI |
|
|
MAC. SCREW-MPSWF M4.0*8.0L,NI |
|
|
MAC.SCREW-MI M3.0*5.0L,NI |
|
|
MAC.SCREW-MI M4.0*5.0L,NI |
|
|
MAC.SCREW-MPSWF M3.0*6.0L NI |
|
|
MYLAR (18.0*28.0*0.6T)(VX32L) |
|
|
PE BAG (120.0*170.0*0.04T)(NO.#6) |
|
|
PE BAG (180W*290L*0.04T)(PE-LD)(ACC.-1) |
|
|
PE BAG 320*230*0.06T |
|
|
POWER BD ASS'Y DPS-284BP A LF |
|
|
POWER CORD 110V UL/CSA 1800MM BLK N.M. (VINC) |
|
|
QSG VIZIO SV420XVT1A |
|
|
REAR COVER (SV42)(ABS 94-5V/T52013) |
|
|
REAR PLATE VIZIO SV42 |
|
|
REGISTER CARD VIZIO SERIES |
|
|
SAFETY STRAP(VM60P HDTV10A) |
|
|
SCREW PHW M3-0.5*6.1 W=7.8 NYLOK |
|
|
SERIAL NO LBL FOR VIZIO VS42L FHDTV10A |
|
|
SERIAL NO.LBL BYD:SIGN |
|
|
SHIELDING AL. TAPE (50.0*40.0) |
|
|
SHIELDING AL.TAPE (50.0W*70.0L)(HP OBI WAN-24) |
|
|
SIDE JACK COVER ASS'Y(SV42)(ABS 94-5V/T52013) |
|
|
SPACER SUPPORT MC-8(GV46L HDTV) |
|
|
SPK 10W 8OHM(120*30*34) W/SPONGE 370MM LF |
|
|
SPK BOX 10W 6OHM(160*73*79) 700/240MM LF |
|
|
SPK COVER (SV42)(ABS 94-HB/T52013) |
|
|
TAP. SCREW-TB #3.0*15.0L,BLK-NI |
|
|
TAP. SCREW-TB #4.0*26.0L, BLK-NI |
|
|
TAP. SCREW-TB #4.0*8.0L, BLK-NI |
|
|
TAP. SCREW-TF #3.0*9.0L,BLK-NI |
|
|
TAP. SCREW-TP #3.0X8.0L, BLK-NI |
|
|
TAP. SCREW-TP #4.0*8.0L,NI |
|
|
TAP. SCREW-TRF #3.0*12.0L,NI |
|
|
TAP.SCREW-TB #3.0*25.0L,BLK-NI |
|
|
TAP.SCREW-TRF #4.0*12.0L,NI |
|
|
VIZIO WARRANTY & REPAIR SHEET (ENGLISH) |
|
|
WALL MOUNT SUPPORT (VO37L HDTV10A)(M6) |
|
|
WH A1251-10P/A1251-10P 1571#28 650MM |
|
|
WH A1251-14/A1251-14 20276#28 250MM+CLAMP |
|
|
WH A1251-4/A1251-3 1571#28 480MM |
|
|
WH A2001-14/A2543-13 1007#24 530MM |
|
|
WH A2001-15/A2001-15 20276#30 300MM |
|
|
WH A2001-4/A2001-4 2547#28+1061#28 520MM+GND*1 |
|
|
WH A2001-6/A2001-6 1061#26 600MM |
|
|
WH A2001-7/A2001-7 2464#26+BRAID+GND*2 150MM |
|
|
WH A2001-8/A2001-8 1061#26 200MM |
|
|
WH A2501-2/A2501-2 1007#24 80MM |
|
|
WH A2501-4/A2543-4 1007#22 400MM+CORE |
|
|
WH A2501-4P/A2501-4P 1007#24 165MM |
|
|
WH A2543-15P/A2001-15P 1007#24 270MM |
|
|
WH FI-RE41HL/PD240315 20276#30 440MM+ABSORBER+CLAM |
|
|
WH FI-RE51HL/PD240320 20276 350MM |
|
|
WH P240420/P240420 20276#30 300MM GND*2 |
|
|
WH PD240320*2 20276#30 200MM+ABSORBER+CLAMP REV1 |
|
|
WH PKS24020P41/PD240315 20276 440MM+CLAMP(AU 4U'') |
|
|
WH PKS24020P51/PD240320 20276 350MM |
|
|
WIRE SADDLE (CH-14) |
