Model Image
Manufacturer

LG

Model Number

42LD340HUA

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
AAN73211208 AAN73211208 BASE ASSEMBLY
EBT61734201 EBT61734201 BPR TOTAL ASSEMBLY
ABA73831202 ABA73831202 BRACKET ASSEMBLY
ABA73131909 ABA73131909 BRACKET ASSEMBLY
ABJ65528410 ABJ65528410 CABINET ASSEMBLY
EAD32659602 EAD32659602 CABLE,ASSEMBLY
EAD36955301 EAD36955301 CABLE,ASSEMBLY
EAD61807808 EAD61807808 CABLE,FFC
0CE476WH6DC 0CE476WH6DC CAPACITOR,AL,CHIP
0CE476SF6DC 0CE476SF6DC CAPACITOR,AL,CHIP
0CE476VH6DC 0CE476VH6DC CAPACITOR,AL,CHIP
0CC102CK41A 0CC102CK41A CAPACITOR,CERAMIC,CHIP
0CK474EK66A 0CK474EK66A CAPACITOR,CERAMIC,CHIP
EAE32166601 EAE32166601 CAPACITOR,CERAMIC,CHIP
0CK223CK56A 0CK223CK56A CAPACITOR,CERAMIC,CHIP
EAE50191801 EAE50191801 CAPACITOR,CERAMIC,CHIP
0CK222BKG6A 0CK222BKG6A CAPACITOR,CERAMIC,CHIP
EAE58111501 EAE58111501 CAPACITOR,CERAMIC,CHIP
EAE33831901 EAE33831901 CAPACITOR,CERAMIC,CHIP
EAE42868301 EAE42868301 CAPACITOR,CERAMIC,CHIP
0CC270BK61A 0CC270BK61A CAPACITOR,CERAMIC,CHIP
EAE33970001 EAE33970001 CAPACITOR,CERAMIC,CHIP
0CK475CC94A 0CK475CC94A CAPACITOR,CERAMIC,CHIP
0CK105DH56A 0CK105DH56A CAPACITOR,CERAMIC,CHIP
0CK475EF56A 0CK475EF56A CAPACITOR,CERAMIC,CHIP
0CK103CK56A 0CK103CK56A CAPACITOR,CERAMIC,CHIP
EAE32166101 EAE32166101 CAPACITOR,CERAMIC,CHIP
0CK471CK56A 0CK471CK56A CAPACITOR,CERAMIC,CHIP
0CK105CF94A 0CK105CF94A CAPACITOR,CERAMIC,CHIP
0CC470CK41A 0CC470CK41A CAPACITOR,CERAMIC,CHIP
0CH5470K618 0CH5470K618 CAPACITOR,CERAMIC,CHIP
0CK474CH94A 0CK474CH94A CAPACITOR,CERAMIC,CHIP
0CK222DK56A 0CK222DK56A CAPACITOR,CERAMIC,CHIP
0CK104CK56A 0CK104CK56A CAPACITOR,CERAMIC,CHIP
EAE31992101 EAE31992101 CAPACITOR,CERAMIC,CHIP
0CK106EF56A 0CK106EF56A CAPACITOR,CERAMIC,CHIP
0CZZB00110A 0CZZB00110A CAPACITOR,CERAMIC,CHIP
EAE38454201 EAE38454201 CAPACITOR,CERAMIC,CHIP
0CK224DK46A 0CK224DK46A CAPACITOR,CERAMIC,CHIP
0CK103BH56A 0CK103BH56A CAPACITOR,CERAMIC,CHIP
0CK102BK56A 0CK102BK56A CAPACITOR,CERAMIC,CHIP
0CK104CF56A 0CK104CF56A CAPACITOR,CERAMIC,CHIP
0CK106DC67A 0CK106DC67A CAPACITOR,CERAMIC,CHIP
0CC180BKFAA 0CC180BKFAA CAPACITOR,CERAMIC,CHIP
0CK225DD66A 0CK225DD66A CAPACITOR,CERAMIC,CHIP
EAE52158501 EAE52158501 CAPACITOR,CERAMIC,CHIP
0CC221BKFAA 0CC221BKFAA CAPACITOR,CERAMIC,CHIP
EAE32246001 EAE32246001 CAPACITOR,CERAMIC,CHIP
0CK101BK4EA 0CK101BK4EA CAPACITOR,CERAMIC,CHIP
0CK104BF56A 0CK104BF56A CAPACITOR,CERAMIC,CHIP
EAG61233701 EAG61233701 CONNECTOR,BTOB
6630TGA004Q 6630TGA004Q CONNECTOR,DSUB
6630G00001E 6630G00001E CONNECTOR,DSUB
EAG60692001 EAG60692001 CONNECTOR,FFC/FPC/PIC
EAG41945401 EAG41945401 CONNECTOR,USB
6602T25009C 6602T25009C CONNECTOR,WAFER
EAG60670701 EAG60670701 CONNECTOR,WAFER
6602T20008C 6602T20008C CONNECTOR,WAFER
EAG58732903 EAG58732903 CONNECTOR,WAFER
EAG58732902 EAG58732902 CONNECTOR,WAFER
6602T20008K 6602T20008K CONNECTOR,WAFER
MCK57046202 MCK57046202 COVER
ACQ77091633 ACQ77091633 COVER ASSEMBLY,REAR
EAW30067102 EAW30067102 CRYSTAL
0DD184009AA 0DD184009AA DIODE ASSEMBLY
0DSDI00078A 0DSDI00078A DIODE,SCHOTTKY
0DSON00108A 0DSON00108A DIODE,SCHOTTKY
0DSIH00028A 0DSIH00028A DIODE,SWITCHING
EAH42720601 EAH42720601 DIODE,TVS
0DRSE00038A 0DRSE00038A DIODE,TVS
EAH39491701 EAH39491701 DIODE,TVS
EAH39491601 EAH39491601 DIODE,TVS
0DZRM00178A 0DZRM00178A DIODE,ZENER
0DZ360009EB 0DZ360009EB DIODE,ZENER
EBK32756101 EBK32756101 FET
0TR830009BA 0TR830009BA FET
EAM60352205 EAM60352205 FILTER,AC LINE
EAM38769501 EAM38769501 FILTER,BEAD
EAM58113401 EAM58113401 FILTER,BEAD
EAM32500902 EAM32500902 FILTER,BEAD
EAM32500203 EAM32500203 FILTER,BEAD
EAM38769505 EAM38769505 FILTER,BEAD
0LCML00003B 0LCML00003B FILTER,BEAD
EAM32500903 EAM32500903 FILTER,BEAD
EAM44020101 EAM44020101 FILTER,BEAD
EAD60676304 EAD60676304 HARNESS,SINGLE
EAD39295756 EAD39295756 HARNESS,SINGLE
EAD35983005 EAD35983005 HARNESS,SINGLE
EAD60673302 EAD60673302 HARNESS,SINGLE
6631T20020Q 6631T20020Q HARNESS,SINGLE
EAD35908414 EAD35908414 HARNESS,SINGLE
EAN61132201 EAN61132201 IC,CHARGE PUMP
EAN61000301 EAN61000301 IC,CMOS
EAN60660501 EAN60660501 IC,DC,DC CONVERTER
EAN57653801 EAN57653801 IC,DC,DC CONVERTER
EAN31346002 EAN31346002 IC,DC,DC CONVERTER
EAN60660801 EAN60660801 IC,DC,DC CONVERTER
EAN61828901 EAN61828901 IC,DDR3 SDRAM
0IMMRRA001B 0IMMRRA001B IC,FRAM
EAN61015301 EAN61015301 IC,MICROCONTROLLERS
EAN60708701 EAN60708701 IC,NAND FLASH MEMORY
EAN38068401 EAN38068401 IC,PLD
EAN60670101 EAN60670101 IC,RESET
EAN43245301 EAN43245301 IC,RESET
EAN41348201 EAN41348201 IC,TX/RX
EAP61008401 EAP61008401 INDUCTOR,WIRE WOUND,CHIP
EAP32842802 EAP32842802 INDUCTOR,WIRE WOUND,CHIP
EAP32842806 EAP32842806 INDUCTOR,WIRE WOUND,CHIP
6612E00043A 6612E00043A JACK,MODULAR
6612E00008C 6612E00008C JACK,MODULAR
EAG60841807 EAG60841807 JACK,PHONE
CRD30876801 CRD30876801 LCD,MODULE-TFT
EAV44273501 EAV44273501 LED,CHIP
0DL210009GC 0DL210009GC LED,CHIP
MFL62194612 MFL62194612 MANUAL,OWNERS
6204B62705A 6204B62705A OSCILLATOR,CRYSTAL
AGF73983608 AGF73983608 PACKAGE ASSEMBLY
AGF76491601 AGF76491601 PACKAGE ASSEMBLY
49509K0179E 49509K0179E PLATE
49509K0178G 49509K0178G PLATE
EAD60817903 EAD60817903 POWER CORD
EAV59155102 EAV59155102 RECEIVER MODULE
AKB74115501 AKB74115501 REMOTE CONTROLLER ASSEMBLY
EBC32260404 EBC32260404 RESISTOR,ARRAY
0RJ0222C692 0RJ0222C692 RESISTOR,ARRAY
0RJ1801C678 0RJ1801C678 RESISTOR,CHIP
0RJ5101D677 0RJ5101D677 RESISTOR,CHIP
0RJ2001D677 0RJ2001D677 RESISTOR,CHIP
0RJ0122D677 0RJ0122D677 RESISTOR,CHIP
0RJ0822C678 0RJ0822C678 RESISTOR,CHIP
0RJ4700D677 0RJ4700D677 RESISTOR,CHIP
0RJ1201C678 0RJ1201C678 RESISTOR,CHIP
0RJ0101D677 0RJ0101D677 RESISTOR,CHIP
0RJ1501D477 0RJ1501D477 RESISTOR,CHIP
0RJ5102D677 0RJ5102D677 RESISTOR,CHIP
0RJ1002D477 0RJ1002D477 RESISTOR,CHIP
0RJ4701D477 0RJ4701D477 RESISTOR,CHIP
0RJ2702D477 0RJ2702D477 RESISTOR,CHIP
0RJ1102D677 0RJ1102D677 RESISTOR,CHIP
0RJ5601C678 0RJ5601C678 RESISTOR,CHIP
0RJ0102D477 0RJ0102D477 RESISTOR,CHIP
0RJ2202C678 0RJ2202C678 RESISTOR,CHIP
0RJ6201C477 0RJ6201C477 RESISTOR,CHIP
0RJ1002C478 0RJ1002C478 RESISTOR,CHIP
0RJ1801D677 0RJ1801D677 RESISTOR,CHIP
0RJ2700D677 0RJ2700D677 RESISTOR,CHIP
0RJ0222D677 0RJ0222D677 RESISTOR,CHIP
0RJ1004C478 0RJ1004C478 RESISTOR,CHIP
0RJ0332C678 0RJ0332C678 RESISTOR,CHIP
0RJ1000D677 0RJ1000D677 RESISTOR,CHIP
0RJ3300D677 0RJ3300D677 RESISTOR,CHIP
0RJ4701C478 0RJ4701C478 RESISTOR,CHIP
0RJ4700C678 0RJ4700C678 RESISTOR,CHIP
0RJ1003C678 0RJ1003C678 RESISTOR,CHIP
0RJ4702C678 0RJ4702C678 RESISTOR,CHIP
0RJ1001E478 0RJ1001E478 RESISTOR,CHIP
0RJ1502D477 0RJ1502D477 RESISTOR,CHIP
0RJ4702D677 0RJ4702D677 RESISTOR,CHIP
0RJ1003D477 0RJ1003D477 RESISTOR,CHIP
0RJ2002C478 0RJ2002C478 RESISTOR,CHIP
0RJ3300C678 0RJ3300C678 RESISTOR,CHIP
0RJ0472C678 0RJ0472C678 RESISTOR,CHIP
0RJ2201D677 0RJ2201D677 RESISTOR,CHIP
0RJ0000D677 0RJ0000D677 RESISTOR,CHIP
0RJ4702C478 0RJ4702C478 RESISTOR,CHIP
EBC60973201 EBC60973201 RESISTOR,CHIP
0RJ2201C678 0RJ2201C678 RESISTOR,CHIP
0RJ3301C678 0RJ3301C678 RESISTOR,CHIP
0RJ0102C678 0RJ0102C678 RESISTOR,CHIP
0RH2400C422 0RH2400C422 RESISTOR,CHIP
0RJ9101D677 0RJ9101D677 RESISTOR,CHIP
0RJ4701C678 0RJ4701C678 RESISTOR,CHIP
0RJ3301D677 0RJ3301D677 RESISTOR,CHIP
0RJ3001D677 0RJ3001D677 RESISTOR,CHIP
0RJ0222C678 0RJ0222C678 RESISTOR,CHIP
0RJ1502C678 0RJ1502C678 RESISTOR,CHIP
0RJ3901C678 0RJ3901C678 RESISTOR,CHIP
0RJ4702D477 0RJ4702D477 RESISTOR,CHIP
0RJ1002D677 0RJ1002D677 RESISTOR,CHIP
0RJ1202C678 0RJ1202C678 RESISTOR,CHIP
0RJ1001C678 0RJ1001C678 RESISTOR,CHIP
0RJ1002C678 0RJ1002C678 RESISTOR,CHIP
0RJ4703C678 0RJ4703C678 RESISTOR,CHIP
0RJ0000C678 0RJ0000C678 RESISTOR,CHIP
0RH0000D622 0RH0000D622 RESISTOR,CHIP
FAB30016431 FAB30016431 SCREW ASSEMBLY
EAY61209501 EAY61209501 SMPS,AC/DC
RAC31704101 RAC31704101 SOLDER SOLDERING
EAB58534502 EAB58534502 SPEAKER,FULL RANGE
MJH55273401 MJH55273401 SUPPORTER
MJH61995502 MJH61995502 SUPPORTER
MJH61995402 MJH61995402 SUPPORTER
MJH55273001 MJH55273001 SUPPORTER
MJH41408301 MJH41408301 SUPPORTER
6600VR1004A 6600VR1004A SWITCH,TACT
140-313B 140-313B SWITCH,TACT
0TRIY80001A 0TRIY80001A TR,BIPOLAR
0TR102009AG 0TR102009AG TR,BIPOLAR
EBK58172301 EBK58172301 TR,BIPOLAR
0TR390609DC 0TR390609DC TR,BIPOLAR
0TR103009AG 0TR103009AG TR,BIPOLAR
