Manufacturer
International Comfort Products
Model Number
PAJ342000K000B1
Description
Performance 13 Packaged Narrow Lot Heat Pump
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1176617 | ACCESS PANEL |
| 1176615 | ACCESS PANEL |
| 1176032 | BARRIER 24V |
| 1176607 | BASEPAN ASSEMBLY |
| 1174169 | BRACKET BLOWER SUPPORT |
| 1179600 | COIL ASSEMBLY CONDENSER FRMD |
| 1179605 | COIL ASSEMBLY EVAP |
| 1172472 | CONTACTOR |
| 1173177 | CORE VALVE |
| 1185846 | ECM X-13 MTR CONTROL 1/2 HP |
| 1176619 | ELECTRICAL PANEL |
| 1173706 | FAN BLADE |
| 1172009 | FILTER DRIER |
| 1179638 | FLANGE DUCT 14-INCH X 20-INCH |
| 1179620 | GASKET CONDENSER COIL SEAL |
| 1173832 | GRILLE OUTLET |
| 1176613 | GROMMET |
| 1171737 | GROMMET |
| 1171269 | GROMMET |
| 1176614 | GROMMET 12PK |
| 1179583 | HARNESS ASSEMBLY PAC |
| 1184153 | HOUSING BLOWER 9-INCH |
| 1179616 | INSUL ASSEMBLY SIDE WRAPPER 34-INCH |
| 1172300 | LUG GROUND |
| 1174017 | METERING DEVICE |
| 1173700 | MOTOR 1/4HP 1PH |
| 1179595 | MOTOR BLOWER 1/208-230 1/2 600-1200 |
| 1174295 | MOUNT KIT BLOWER MOTOR |
| 1171357 | PAINT HAZ -HAZ- |
| 1179637 | PANEL BLOCKOFF |
| 1173642 | RACEWAY |
| 1174176 | RING,AIR DUCT METAL |
| 1179630 | SEAL DRAIN |
| 1174407 | SWITCH,PRESS HI |
| 1176609 | TOP COVER ASY |
| 1173691 | TRANSFORMER 40VA |
| 1171742 | WHEEL BLOWER |
| 1179612 | WRAPPER SIDE LOUVER 34-INCH |
