Manufacturer
International Comfort Products
Model Number
PDD442060K001E1
Description
Performance 14 Gas Furnace/heat Pump Combination
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1178423 | BAFFLE FLUE 24MM |
| 1183373 | BASE PAN CONDENSER (LG CHASSIS) |
| 1178403 | BASE RAIL |
| 1178402 | BASE RAIL |
| 1178014 | BASE RAIL |
| 1177927 | BOARD DEFROST CONTROL |
| 1176085 | BRACKET BLOWER SUPPORT |
| 1177729 | BRACKET BURNER |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1178357 | BRACKET SWITCH |
| 1171087 | BURNER ASSEMBLY. |
| 1171095 | BURNERS |
| 1175999 | CAP HOOD |
| 1188319 | COIL CONDENSER AL/CU |
| 1188318 | COIL CONDENSER AL/CU |
| 1188202 | COIL EVAPORATOR AL/CU |
| 1186721 | COIL RVS 24V |
| ZP36K5E-PFV-830 | COMPRESSOR, SCROLL |
| 1172472 | CONTACTOR |
| 1186861 | CONTROL BOARD, IGNITER |
| 1178426 | CONTROL BOX |
| 1173177 | CORE VALVE |
| 1176062 | COVER ASSEMBLY DUCT |
| 1178480 | COVER TOP COND |
| 1173680 | DRIER BIFLOW 08 CI 3/8 SWEAT |
| 1173661 | FAN BLADE |
| 1177341 | GRILLE ASSEMBLY 24-INCH |
| 1177340 | GRILLE ASSEMBLY 24-INCH |
| 1177339 | GRILLE ASSEMBLY 24-INCH |
| 1178481 | GRILLE OUTLET |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1176042 | HEAT EXCHANGER ASSEMBLY 90K BTU LWNX |
| 1178429 | HOUSING ASY INDUCER FAN |
| 1177663 | IGNITOR |
| 1178464 | INSUL ASSEMBLY BLOWER PANEL |
| 1178743 | INSUL ASSEMBLY FAN PARTITION LG |
| 1178961 | INSUL ASSEMBLY PANEL COIL LARGE |
| 1178960 | INSUL ASSEMBLY PANEL DUCT LARGE |
| 1176083 | INSUL ASSEMBLY TOP EVAP |
| 1178741 | INSUL ASY COIL PARTITION LG |
| 1187174 | INSULATION ASSEMBLY,FLUE BOX |
| 1176088 | KIT BLW MTR MTG LG CHAS |
| 1172300 | LUG GROUND |
| 1178456 | MANIFOLD 3 SPUD |
| 1186359 | MOTOR |
| 1188130 | MOTOR, ECM. 1/2 HP X13 |
| 1186837 | MTR IDF 1/230 1/25 3200 |
| 1175977 | ORIFICE MAIN 44 |
| 1171357 | PAINT HAZ -HAZ- |
| 1178465 | PANEL ACCESS ELEC |
| 1184080 | PANEL ASSEMBLY INSULATED |
| 1178463 | PANEL COMP ACCESS LG |
| 1177350 | PANEL CORNER 24-INCH CND |
| 1177352 | PANEL CORNER 24-INCH HDR |
| 1177351 | PANEL CORNER 24-INCH HDR |
| 1188320 | PISTON 046 |
| 1177021 | PLATE ASY |
| 1176076 | PLATE FAN TOP |
| 1176000 | PLATE INSUL |
| 1177318 | PLUG COMP |
| 1178479 | RACEWAY OFM 14-INCH |
| 1176074 | SCROLL |
| 1177662 | SENSOR FLAME |
| 1177731 | SUPPORT BURNER |
| 1178677 | SWITCH TEMP |
| 1177659 | SWITCH TEMP O130 C100 |
| 1177658 | SWITCH TEMP O320 C270 |
| 1172197 | SWITCH VENT PRESS |
| 1171496 | TRANSFORMER |
| 1178417 | TUBE VENT PRESSURE-2 FT |
| 1188156 | TXV VALVE |
| 1175976 | VALVE N HIS SNAP WR 36G22512 |
| 1175621 | VALVE REVERSING |
| 1177025 | WHEEL 11-10DD CCW |
| 1175971 | WHEEL DD 5X1 CWW |
| 1187169 | WIRE ASSEMBLY, IGNITER CABLE |
