Manufacturer
International Comfort Products
Model Number
PDD460130K000C1
Description
Performance 14 Gas Furnace/heat Pump Combination
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1172327 | ACCUMULATOR 216 7/8 |
| 1178331 | BAFFLE FLUE |
| 1183373 | BASE PAN CONDENSER (LG CHASSIS) |
| 1178403 | BASE RAIL |
| 1178402 | BASE RAIL |
| 1178014 | BASE RAIL |
| 1176085 | BRACKET BLOWER SUPPORT |
| 1177729 | BRACKET BURNER |
| 1178357 | BRACKET SWITCH |
| 1171087 | BURNER ASSEMBLY. |
| 1171095 | BURNERS |
| 1175999 | CAP HOOD |
| 1178358 | CIRCUIT BOARD |
| 1179579 | COIL CONDENSER AL/CU FRMD |
| 1179578 | COIL CONDENSER AL/CU FRMD |
| 1178361 | COIL EVAPORATOR AL/CU |
| 1172619 | COIL REV VALVE 24V |
| 1178964 | CONDENSER MOTOR 1/208-230 1/4 825 |
| 1173690 | CONTACTOR |
| 1178426 | CONTROL BOX |
| 1173177 | CORE VALVE |
| 1176062 | COVER ASSEMBLY DUCT |
| 1178480 | COVER TOP COND |
| 1174240 | DISTRIBUTOR 4 CIRCUIT |
| 1179564 | DISTRIBUTOR 6 CKT |
| 1185852 | ECM X-13 MOTOR CONTROL 1 HP |
| 1172716 | FAN BLADE |
| 1172311 | FILTER DRIER |
| 1177341 | GRILLE ASSEMBLY 24-INCH |
| 1177340 | GRILLE ASSEMBLY 24-INCH |
| 1177339 | GRILLE ASSEMBLY 24-INCH |
| 1178481 | GRILLE OUTLET |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1184083 | HEATER CC WP 40W 240V CH196 |
| 1178430 | HOUSING ASSEMBLY INDUCER FAN |
| 1177661 | IGNITION CONTROL MODULE |
| 1177663 | IGNITOR |
| 1178464 | INSUL ASSEMBLY BLOWER PANEL |
| 1178743 | INSUL ASSEMBLY FAN PARTITION LG |
| 1176124 | INSUL ASSEMBLY FLUE BOX |
| 1178961 | INSUL ASSEMBLY PANEL COIL LARGE |
| 1178960 | INSUL ASSEMBLY PANEL DUCT LARGE |
| 1176083 | INSUL ASSEMBLY TOP EVAP |
| 1178741 | INSUL ASY COIL PARTITION LG |
| 1176088 | KIT BLW MTR MTG LG CHAS |
| 1172300 | LUG GROUND |
| 1178456 | MANIFOLD 3 SPUD |
| 1178421 | MOTOR ASSEMBLY INDUCER |
| 1178394 | MOTOR BLOWER 1/230 1 600-1200 |
| 1177799 | MTR IDF 1/230V 1/16 3450 |
| 1171462 | ORIFICE MAIN 31 |
| 1171357 | PAINT HAZ -HAZ- |
| 1178465 | PANEL ACCESS ELEC |
| 1184080 | PANEL ASSEMBLY INSULATED |
| 1178463 | PANEL COMP ACCESS LG |
| 1177350 | PANEL CORNER 24-INCH CND |
| 1177352 | PANEL CORNER 24-INCH HDR |
| 1177351 | PANEL CORNER 24-INCH HDR |
| 1176112 | PARTITION COIL EVAP |
| 1173868 | PISTON .049 |
| 1177021 | PLATE ASY |
| 1176076 | PLATE FAN TOP |
| 1176000 | PLATE INSUL |
| 1177353 | PLUG ASSEMBLY COMP |
| 1178479 | RACEWAY OFM 14-INCH |
| 1176074 | SCROLL |
| 1177662 | SENSOR FLAME |
| 1177731 | SUPPORT BURNER |
| 1178677 | SWITCH TEMP |
| 1177659 | SWITCH TEMP O130 C100 |
| 1177658 | SWITCH TEMP O320 C270 |
| 1172197 | SWITCH VENT PRESS |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1171496 | TRANSFORMER |
| 1178417 | TUBE VENT PRESSURE-2 FT |
| 1175976 | VALVE N HIS SNAP WR 36G22512 |
| 1176871 | VALVE TXV 6.0 TON R410A |
| 1177025 | WHEEL 11-10DD CCW |
| 1175873 | WHEEL,BLOWER (IDM) |
| 1177654 | WIRE ASY INGNITION |
| 1184077 | WIRE HARNESS ASSEMBLY DF |
