Manufacturer
International Comfort Products
Model Number
PGS436060LGS1C1
Description
Quietcomfort 14 Packaged Gas Furnace/air Condition
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1178423 | BAFFLE FLUE 24MM |
| 1178356 | BAFFLE NOX |
| 1178014 | BASE RAIL |
| 1178013 | BASE RAIL |
| 1178012 | BASE RAIL |
| 1178400 | BLOWER MOTOR 1/230 3/4 600-1200 |
| 1173815 | BLOWER WHEEL |
| 1177728 | BRACKET BURNER |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1178357 | BRACKET SWITCH |
| 1171095 | BURNERS |
| 1175999 | CAP HOOD |
| 1178358 | CIRCUIT BOARD |
| 1178373 | COIL CONDENSER AL/CU |
| 1178372 | COIL CONDENSER AL/CU |
| 1177995 | COIL EVAPORATOR AL/CU |
| 1178391 | CONDENSER MOTOR 1/460 1/5 825 |
| 1173177 | CORE VALVE |
| 1175990 | COVER ASSEMBLY DUCT |
| 1173679 | DRIER FILTER |
| 1177890 | FAN C 24-INCH 3B 1/2-INCH 24 INT |
| 1178437 | GRILLE ASSEMBLY; 18 IN. FR/RT HG |
| 1178440 | GRILLE ASSEMBLY; 18 IN. SM BK HG |
| 1178446 | GRILLE ASSEMBLY; 18 IN. SM LF HG |
| 1178443 | GRILLE ASSEMBLY; 18 IN. SM RT HG |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1177736 | HEIL QUAKER 2 TON TX VALVE |
| 1178429 | HOUSING ASY INDUCER FAN |
| 1177804 | IGNITION CONTROL MODULE 460V |
| 1177663 | IGNITOR |
| 1178425 | INSUL ASSEMBLY BLOWER PANEL |
| 1178010 | INSUL ASSEMBLY BLOWER PANEL |
| 1175988 | INSUL ASSEMBLY TOP EVAP |
| 1177727 | INSULATION ASSEMBLY FLUE BOX 60K |
| 1175958 | KIT BLW MTR MTG |
| 1172300 | LUG GROUND |
| 1178415 | MANIFOLD 2 SPUD |
| 1178557 | MOTOR ASSEMBLY INDUCER |
| 1177803 | MTR IDF 1/460V 1/15 3300 |
| 1172235 | ORIFICE MAIN 38 |
| 1178011 | OUTLET GRILLE |
| 1171357 | PAINT HAZ -HAZ- |
| 1178009 | PANEL COIL ACCESS SML |
| 1178008 | PANEL COMP ACCESS SML |
| 1177347 | PANEL CORNER 18-INCH COND |
| 1177348 | PANEL CORNER 18-INCH HDR |
| 1175994 | PANEL DUCT |
| 1176005 | PANEL GAS |
| 1178016 | PLATE ASSEMBLY FAN |
| 1178018 | PLATE FAN |
| 1177022 | PLUG COMPRESSOR |
| 1171405 | PLUG, ECONOMIZER |
| 1178424 | RACEWAY OFM 13-INCH |
| 1176010 | SCROLL |
| 1177662 | SENSOR FLAME |
| 1177731 | SUPPORT BURNER |
| 1176103 | SWITCH LIMIT 155-55 |
| 1177658 | SWITCH TEMP O320 C270 |
| 1172197 | SWITCH VENT PRESS |
| 1171484 | SWITCH, TEMP-ACT |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1178005 | TOP COVER SML |
| 1177023 | TRANS STEP DOWN 460 230V |
| 1175310 | TRANSFORMER |
| 1178417 | TUBE VENT PRESSURE-2 FT |
| 1175976 | VALVE N HIS SNAP WR 36G22512 |
| 1175971 | WHEEL DD 5X1 CWW |
| 1177654 | WIRE ASY INGNITION |
