Manufacturer
International Comfort Products
Model Number
PGS436090KGP0C1
Description
Quietcomfort 14 Packaged Gas Furnace/air Condition
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1178355 | BAFFLE FLUE |
| 1179562 | BASE PAN CONDENSER SML |
| 1178014 | BASE RAIL |
| 1178013 | BASE RAIL |
| 1178012 | BASE RAIL |
| 1173815 | BLOWER WHEEL |
| 1177729 | BRACKET BURNER |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1178357 | BRACKET SWITCH |
| 1171087 | BURNER ASSEMBLY. |
| 1171095 | BURNERS |
| 1175999 | CAP HOOD |
| 1178358 | CIRCUIT BOARD |
| 1178373 | COIL CONDENSER AL/CU |
| 1178372 | COIL CONDENSER AL/CU |
| 1178754 | COIL EVAPORATOR TIN PLATED |
| 1172472 | CONTACTOR |
| 1173177 | CORE VALVE |
| 1175990 | COVER ASSEMBLY DUCT |
| 1185584 | DISTRIBUTOR |
| 1173679 | DRIER FILTER |
| 1185847 | ECM X-13 MTR CONTROL 3/4 HP |
| 1177890 | FAN C 24-INCH 3B 1/2-INCH 24 INT |
| 1178437 | GRILLE ASSEMBLY; 18 IN. FR/RT HG |
| 1178440 | GRILLE ASSEMBLY; 18 IN. SM BK HG |
| 1178446 | GRILLE ASSEMBLY; 18 IN. SM LF HG |
| 1178443 | GRILLE ASSEMBLY; 18 IN. SM RT HG |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1177736 | HEIL QUAKER 2 TON TX VALVE |
| 1178430 | HOUSING ASSEMBLY INDUCER FAN |
| 1177661 | IGNITION CONTROL MODULE |
| 1177663 | IGNITOR |
| 1184079 | INSUL ASSEMBLY ACCESS PANEL |
| 1178425 | INSUL ASSEMBLY BLOWER PANEL |
| 1178010 | INSUL ASSEMBLY BLOWER PANEL |
| 1178739 | INSUL ASSEMBLY COIL PARTITION SM |
| 1178737 | INSUL ASSEMBLY COIL PARTITION SM |
| 1178745 | INSUL ASSEMBLY FAN PARTITION SM |
| 1178959 | INSUL ASSEMBLY PANEL COIL SMALL |
| 1178958 | INSUL ASSEMBLY PANEL DUCT SMALL |
| 1175988 | INSUL ASSEMBLY TOP EVAP |
| 1177726 | INSULATION ASY FLUE BOX 90K |
| 1175958 | KIT BLW MTR MTG |
| 1172300 | LUG GROUND |
| 1178416 | MANIFOLD 3 SPUD |
| 1178421 | MOTOR ASSEMBLY INDUCER |
| 1177999 | MOTOR BLOWER 1/208-230 3/4 600-1200 |
| 1172235 | ORIFICE MAIN 38 |
| 1178011 | OUTLET GRILLE |
| 1171357 | PAINT HAZ -HAZ- |
| 1178008 | PANEL COMP ACCESS SML |
| 1177347 | PANEL CORNER 18-INCH COND |
| 1177348 | PANEL CORNER 18-INCH HDR |
| 1178016 | PLATE ASSEMBLY FAN |
| 1178018 | PLATE FAN |
| 1176000 | PLATE INSUL |
| 1177318 | PLUG COMP |
| 1178424 | RACEWAY OFM 13-INCH |
| 1176010 | SCROLL |
| 1177662 | SENSOR FLAME |
| 1177731 | SUPPORT BURNER |
| 1176103 | SWITCH LIMIT 155-55 |
| 1177658 | SWITCH TEMP O320 C270 |
| 1172197 | SWITCH VENT PRESS |
| 1171484 | SWITCH, TEMP-ACT |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1178005 | TOP COVER SML |
| 1173691 | TRANSFORMER 40VA |
| 1178417 | TUBE VENT PRESSURE-2 FT |
| 1175976 | VALVE N HIS SNAP WR 36G22512 |
| 1175873 | WHEEL,BLOWER (IDM) |
| 1177654 | WIRE ASY INGNITION |
