Manufacturer
International Comfort Products
Model Number
PGS442090LGS1C1
Description
Quietcomfort 14 Packaged Gas Furnace/air Condition
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1178350 | BAFFLE FLUE |
| 1178356 | BAFFLE NOX |
| 1178403 | BASE RAIL |
| 1178402 | BASE RAIL |
| 1178014 | BASE RAIL |
| 1176085 | BRACKET BLOWER SUPPORT |
| 1177729 | BRACKET BURNER |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1178357 | BRACKET SWITCH |
| 1171087 | BURNER ASSEMBLY. |
| 1171095 | BURNERS |
| 1175999 | CAP HOOD |
| 1178358 | CIRCUIT BOARD |
| 1178379 | COIL CONDENSER AL/CU |
| 1178374 | COIL CONDENSER AL/CU |
| 1178363 | COIL EVAPORATOR AL/CU |
| 1178391 | CONDENSER MOTOR 1/460 1/5 825 |
| 1173177 | CORE VALVE |
| 1176062 | COVER ASSEMBLY DUCT |
| 1178480 | COVER TOP COND |
| 1173679 | DRIER FILTER |
| 1177890 | FAN C 24-INCH 3B 1/2-INCH 24 INT |
| 1178502 | GRILLE ASSEMBLY 14-INCH |
| 1178501 | GRILLE ASSEMBLY 14-INCH |
| 1178435 | GRILLE ASSEMBLY 14-INCH |
| 1178481 | GRILLE OUTLET |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1178429 | HOUSING ASY INDUCER FAN |
| 1177804 | IGNITION CONTROL MODULE 460V |
| 1177663 | IGNITOR |
| 1178464 | INSUL ASSEMBLY BLOWER PANEL |
| 1176083 | INSUL ASSEMBLY TOP EVAP |
| 1176072 | INSUL PANEL GAS |
| 1176087 | INSUL PANEL RET DUCT |
| 1177726 | INSULATION ASY FLUE BOX 90K |
| 1176088 | KIT BLW MTR MTG LG CHAS |
| 1172300 | LUG GROUND |
| 1178456 | MANIFOLD 3 SPUD |
| 1177599 | MTR BLT 1/230 3/4 VS 600-1200 |
| 1177805 | MTR IDF 1/460V 1/25 3200 |
| 1172235 | ORIFICE MAIN 38 |
| 1171357 | PAINT HAZ -HAZ- |
| 1178465 | PANEL ACCESS ELEC |
| 1178462 | PANEL COIL ACCESS LG |
| 1178463 | PANEL COMP ACCESS LG |
| 1176022 | PANEL CORNER 14-INCH COND |
| 1176082 | PANEL CRN 14-INCH |
| 1176025 | PANEL CRN 14-INCH HDR |
| 1176066 | PANEL DUCT |
| 1176071 | PANEL GAS |
| 1177021 | PLATE ASY |
| 1176076 | PLATE FAN TOP |
| 1177022 | PLUG COMPRESSOR |
| 1171405 | PLUG, ECONOMIZER |
| 1178479 | RACEWAY OFM 14-INCH |
| 1176074 | SCROLL |
| 1177662 | SENSOR FLAME |
| 1177731 | SUPPORT BURNER |
| 1177659 | SWITCH TEMP O130 C100 |
| 1177658 | SWITCH TEMP O320 C270 |
| 1172197 | SWITCH VENT PRESS |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1177023 | TRANS STEP DOWN 460 230V |
| 1175310 | TRANSFORMER |
| 1178417 | TUBE VENT PRESSURE-2 FT |
| 1175976 | VALVE N HIS SNAP WR 36G22512 |
| 1177748 | VALVE TXV 3 TON |
| 1177025 | WHEEL 11-10DD CCW |
| 1175971 | WHEEL DD 5X1 CWW |
| 1177654 | WIRE ASY INGNITION |
