Manufacturer
International Comfort Products
Model Number
PHD424000K000E1
Description
Performance 14 Packaged Heat Pump
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1179562 | BASE PAN CONDENSER SML |
| 1178014 | BASE RAIL |
| 1178013 | BASE RAIL |
| 1178012 | BASE RAIL |
| 1185790 | BOARD CONTROL |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1178001 | CIRCUIT BOARD |
| 1179577 | COIL CONDENSER AL/CU FRMD |
| 1179576 | COIL CONDENSER AL/CU FRMD |
| 1176994 | COIL EVAPORATOR AL/CU |
| 1172619 | COIL REV VALVE 24V |
| ZP20K5E-PFV-830 | COMPRESSOR, SCROLL |
| 1172472 | CONTACTOR |
| 1173177 | CORE VALVE |
| 1176139 | COVER |
| 1175990 | COVER ASSEMBLY DUCT |
| 1185842 | ECM X-13 MTR CONTROL 1/2 HP |
| 1172311 | FILTER DRIER |
| 1176020 | GRILLE ASSEMBLY 16-INCH |
| 1176019 | GRILLE ASSEMBLY 16-INCH |
| 1176018 | GRILLE ASSEMBLY 16-INCH |
| 1176017 | GRILLE ASSEMBLY 16-INCH |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1176161 | HEATER CC WP 40W 240V TCH268 |
| 1178010 | INSUL ASSEMBLY BLOWER PANEL |
| 1178020 | INSUL ASSEMBLY ELEC PANEL |
| 1175988 | INSUL ASSEMBLY TOP EVAP |
| 1176140 | INSUL CONTROL PLATE |
| 1176151 | INSUL RETURN DUCT PANEL |
| 1175958 | KIT BLW MTR MTG |
| 1172300 | LUG GROUND |
| 1177997 | MOTOR BLOWER 1/208-230 1/2 600-1200 |
| 1178390 | MOTOR CONDENSER 1/230 1/10 800 |
| 1178011 | OUTLET GRILLE |
| 1171357 | PAINT HAZ -HAZ- |
| 1176141 | PANEL ACCESS |
| 1178009 | PANEL COIL ACCESS SML |
| 1178008 | PANEL COMP ACCESS SML |
| 1176045 | PANEL CORNER 16-INCH COND |
| 1176046 | PANEL CRN 16-INCH HDR |
| 1175994 | PANEL DUCT |
| 1176159 | PISTON CHATLEFF .032 |
| 1178015 | PLATE ASSEMBLY FAN |
| 1176143 | PLATE CONTROL |
| 1178017 | PLATE FAN |
| 1177318 | PLUG COMP |
| 1178424 | RACEWAY OFM 13-INCH |
| 1176010 | SCROLL |
| 1178677 | SWITCH TEMP |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1178005 | TOP COVER SML |
| 1171496 | TRANSFORMER |
| 1177317 | TXV VALVE 2 TON |
| 1173708 | VALVE REVERSING |
