Manufacturer
International Comfort Products
Model Number
PHD436000L000D1
Description
Performance 14 Packaged Heat Pump
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1178403 | BASE RAIL |
| 1178402 | BASE RAIL |
| 1178014 | BASE RAIL |
| 1179581 | BLOWER MOTOR 1/208-230 3/4 600-1200 |
| 1176085 | BRACKET BLOWER SUPPORT |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1178001 | CIRCUIT BOARD |
| 1179573 | COIL CONDENSER AL/CU FRMD |
| 1179572 | COIL CONDENSER AL/CU FRMD |
| 1178359 | COIL EVAPORATOR AL/CU |
| 1172619 | COIL REV VALVE 24V |
| 1178391 | CONDENSER MOTOR 1/460 1/5 825 |
| 1173177 | CORE VALVE |
| 1176139 | COVER |
| 1176062 | COVER ASSEMBLY DUCT |
| 1178480 | COVER TOP COND |
| 1176158 | DISTRIBUTOR 2 CKT |
| 1173661 | FAN BLADE |
| 1172311 | FILTER DRIER |
| 1178502 | GRILLE ASSEMBLY 14-INCH |
| 1178501 | GRILLE ASSEMBLY 14-INCH |
| 1178435 | GRILLE ASSEMBLY 14-INCH |
| 1178481 | GRILLE OUTLET |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1178552 | HARNESS ASY ECON |
| 1176867 | HEATER CC WP 40 480V TCH268-3 |
| 1178010 | INSUL ASSEMBLY BLOWER PANEL |
| 1178612 | INSUL ASSEMBLY ELEC PANEL LG |
| 1176083 | INSUL ASSEMBLY TOP EVAP |
| 1176140 | INSUL CONTROL PLATE |
| 1176087 | INSUL PANEL RET DUCT |
| 1176088 | KIT BLW MTR MTG LG CHAS |
| 1172300 | LUG GROUND |
| 1174858 | METERING DEVICE |
| 1171357 | PAINT HAZ -HAZ- |
| 1178462 | PANEL COIL ACCESS LG |
| 1178463 | PANEL COMP ACCESS LG |
| 1176022 | PANEL CORNER 14-INCH COND |
| 1176082 | PANEL CRN 14-INCH |
| 1176025 | PANEL CRN 14-INCH HDR |
| 1176066 | PANEL DUCT |
| 1176145 | PANEL SIDE |
| 1177021 | PLATE ASY |
| 1178548 | PLATE COMP MTG |
| 1176143 | PLATE CONTROL |
| 1176076 | PLATE FAN TOP |
| 1177022 | PLUG COMPRESSOR |
| 1178479 | RACEWAY OFM 14-INCH |
| 1174099 | RELAY SPST 6FLA 24V |
| 1176074 | SCROLL |
| 1178677 | SWITCH TEMP |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1177023 | TRANS STEP DOWN 460 230V |
| 1171496 | TRANSFORMER |
| 1173708 | VALVE REVERSING |
| 1176869 | VALVE TXV 3.0 TON R410A |
| 1177025 | WHEEL 11-10DD CCW |
