Manufacturer
International Comfort Products
Model Number
PHJ442000KTP0A1
Description
Performance 14 Packaged Narrow Lot Heat Pump
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1176618 | ACCESS PANEL |
| 1176616 | ACCESS PANEL |
| 1176032 | BARRIER 24V |
| 1176607 | BASEPAN ASSEMBLY |
| 1177927 | BOARD DEFROST CONTROL |
| 1174169 | BRACKET BLOWER SUPPORT |
| 1187140 | COIL CONDENSER AL/CU |
| 1187133 | COIL EVAPORATOR AL/CU TP |
| 1172619 | COIL REV VALVE 24V |
| ABG036KAB | COMPRESSOR |
| 1172472 | CONTACTOR |
| 1173177 | CORE VALVE |
| 1176620 | ELECTRICAL PANEL |
| 1173706 | FAN BLADE |
| 1190245 | FAN PROPELLER |
| 1187319 | FILTER, DRIER |
| 1179638 | FLANGE DUCT 14-INCH X 20-INCH |
| 1179619 | GASKET COND COIL SEAL |
| 1173832 | GRILLE OUTLET |
| 1176613 | GROMMET |
| 1171737 | GROMMET |
| 1171269 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1179704 | HARNESS ASSEMBLY SPP HP |
| 1184153 | HOUSING BLOWER 9-INCH |
| 1179723 | INSUL ASSEMBLY SIDE WRAPPER 42-INCH |
| 1172300 | LUG GROUND |
| 1173673 | METERING DEVICE .076 |
| 1179595 | MOTOR BLOWER 1/208-230 1/2 600-1200 |
| 1174295 | MOUNT KIT BLOWER MOTOR |
| 1171357 | PAINT HAZ -HAZ- |
| 1179637 | PANEL BLOCKOFF |
| 1179726 | PARTITION COIL 42-INCH |
| 1173871 | PISTON .059 |
| 1173642 | RACEWAY |
| 1174176 | RING,AIR DUCT METAL |
| 1179630 | SEAL DRAIN |
| 1187153 | SWITCH TEMPERATURE ACTUATED |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1176609 | TOP COVER ASY |
| 1173691 | TRANSFORMER 40VA |
| 1175621 | VALVE REVERSING |
| 1171742 | WHEEL BLOWER |
| 1179613 | WRAPPER SIDE LOUVER 42-INCH |
