Manufacturer
Blomberg
Model Number
7278440595
Description
Bufr2715ssim 30-inch Upright Freezer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
167MM CRISPER COVER |
|
|
228MM CRISPER COVER |
|
|
ADJUSTABLE GLIDER GROUP |
|
|
AIR GRILL COVER |
|
|
ALUMINIUM FOIL TAPE |
|
|
ALUMINIUM FOIL TAPE 70MMX70MM |
|
|
AXIAL FAN CCW_145MM (ROHS) |
|
|
BEKO LOGO |
|
|
BITUM |
|
|
BITUM FOR EVAPARATOR TUBES |
|
|
CABLE ASSY_INVERTER |
|
|
CABLE HOLDER |
|
|
CABLE HOLDER |
|
|
CARD BOX COVER GROUP |
|
|
CHARGING TUBE |
|
|
COMPLETE DISPLAY ASSEMBLY |
|
|
COMPRESSOR |
|
|
COMPRESSOR BACK COVER ASSY. |
|
|
COMPRESSOR RUBBER GROMMET |
|
|
COMPRESSOR TRAVERSE GROUP |
|
|
COMPRESSOR WASHER |
|
|
CONDANSER_ASSEMBLY_4MM |
|
|
CONDENSER+FAN HOLDER |
|
|
CONLOK |
|
|
DEEP HINGE PLUG |
|
|
DISPLAY ASSEMBLY |
|
|
DOOR GROUP |
|
|
DOOR_GASKET |
|
|
DOOR_SHELVES_FRZ |
|
|
DOUBLE ENTRY DRAYER |
|
|
EVAP. COVER CAP_ARCP1 |
|
|
EVAPORATOR COVER ASS |
|
|
EVAPORATOR COVER ASS |
|
|
EVAPORATOR_FINNED_ASSEMBLY_F70 |
|
|
EXTRUSION BACK PROFILE |
|
|
FAN FIXING PART |
|
|
FAN MOTOR GROUP |
|
|
FAN MOTOR GROUP |
|
|
FRONT PANEL CONNECTING PLATE |
|
|
FRONT PANEL CONNECTING PLATE |
|
|
FRONT PROFILE FOR GLASS SHELF |
|
|
FRZ AIR SENSOR |
|
|
FRZ EVAPORATOR HEATER F70 |
|
|
GAS LEAK CONTROL PLUG |
|
|
GLASS SHELF |
|
|
GLASS SHELF |
|
|
GLASS SHELF |
|
|
GLASS SHELF |
|
|
GLASS SHELF FRONT PROFILE |
|
|
GLASS SHELF WITH GROOVE |
|
|
GROUND CABLE ASSEMBLY |
|
|
HANDLE GROUP GRUNDIG |
|
|
HEATER HOLDER SPRING(BACK) |
|
|
HEATER SPRING (BACK) |
|
|
HEATER SPRING (FRONT) |
|
|
HINGE HOUSING |
|
|
ICE CUBE MAKER |
|
|
ICE MAKER LEVEL ARM |
|
|
ICE MOTOR FIXING RUBBER |
|
|
ICEBOX |
|
|
ICEBOX SENSOR COVER |
|
|
ICEBOX TOP BODY |
|
|
ICEMATIC MOTOR |
|
|
ICE_MACHINE_WATER_POURING MOUTH |
|
|
INSULATING PART OF ICE CUBE TRAY SENSOR_ |
|
|
JPN FRZ FRAME ASS |
|
|
JPN_FRZ_FRAME_K56300 |
|
|
JPN_FRZ_ICE_DRAWER_D70420 |
|
|
LED CARD F70 |
|
|
LOCK PIN |
|
|
LOWER DOOR STOPER-LINE 2001 |
|
|
LOWER HINGE ASSEMBLY |
|
|
MAGNET COVER |
|
|
MAGNET FOR SIGNAL |
|
|
MECHANISM COVER FUSE |
|
|
PLASTIC SCREW |
|
|
POWER CORD GROUP |
|
|
REAR HANDLE |
|
|
REED SWITCH CARD |
|
|
RUBBER |
|
|
RUBBER HOLDER |
|
|
RUBBER HOLDER |
|
|
RUBBER HOLDER |
|
|
SBS PIPE CLAMP |
|
|
SCREW (3.9_12) |
|
|
SCREW (M5_16) |
|
|
SCREW(M5X12) |
|
|
SELF WASHERED BOLT |
|
|
SELF WASHERED BOLT |
|
|
SELF WASHERED BOLT (M6X16) |
|
|
SENSOR |
|
|
SENSOR |
|
|
SENSOR THINKING BEYAZ 200MM MX35965 |
|
|
SENSOR_COVER |
|
|
SERRATED LOCK WASHER (A4.3 DIN 6798) |
|
|
SOUND SUMMER SQUARE FAN GROUP |
|
|
THERMAL INSURANCE |
|
|
TOP HINGE ASSEMBLY |
|
|
TORX BOLT STAINLESS INOX M4X12 |
|
|
TRUNK CLAMP |
|
|
U2_CONTROL_BOARD_GR |
|
|
U2_CONTROL_BOARD_GR |
|
|
UPPER DOOR BROW BIG COVER |
|
|
UPPER DOOR BROW SMALL COVER |
|
|
UPPER HINGE COVER RAL7039 |
|
|
UPPER HINGE HOLE |
|
|
UST EVA COVER GROUP |
|
|
VACUUMING TUBE |
|
|
VCC INVERTER ASSY(WITH SUPPLY CORD) |
|
|
VEGETABLE GROUP |
|
|
VEGETABLE GROUP |
|
|
VEGETABLE GROUP |
|
|
WATER VALF ASS |
|
|
WATER VALVE CABLE GROUP |
|
|
WATER VALVE SPRING |
|
|
WATER VALVE SPRING |
|
|
WHEEL |
|
|
WHEEL PIN (50MM) |
