Manufacturer
Blomberg
Model Number
8700000784
Description
Refrigerator Brfb1532ss
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
70CM COMPRESSOR TRAVERS GROUP |
|
|
ADJUSTABLE FOOT ASSEMBLY ASEAN RAL7039 |
|
|
AIR SENSOR ASSEMBLY |
|
|
ALUMINIUM FOIL TAPE 70MMX70MM |
|
|
ASEAN 60CM CRISPER RAIL 550PN RIGHT COMB |
|
|
ASEAN_60CM_CRISPER_RAIL_550PN_LEFT_COMBI |
|
|
ASEAN_K70415N_DRAWER_BODY_165MM |
|
|
ASEAN_REED_SENSOR_FRONT_COVER_HIPS |
|
|
ASSEMBLY GLASS TOP CRISPER D70 |
|
|
ASSEMBLY_CRISPER_K70 |
|
|
ASSEMBLY_DRAWER_K70_FRZ_BOTTOM_GRUNDIG |
|
|
ASSEMBLY_DRAWER_K70_FRZ_MIDDLE_GRUNDIG |
|
|
ASSEMBLY_DRAWER_K70_FRZ_TOP_GRUNDIG |
|
|
BACK COVER 70CM |
|
|
BLOMBERG DAMLA LOGO 23 |
|
|
BOTTOM_HINGE_ASSEMBLY_ASEAN_D70_SPOT |
|
|
CHARGING TUBE_L-SHAPE_INV_UL |
|
|
COMPRESSOR_RUBBER_NON_INVERTER_ASSEMBLY |
|
|
CONTROL_CARD_U-1_V02R05 |
|
|
CRISPER_TOP_GLASS_BACK_PROFILE_K70 |
|
|
CRISPER_TOP_GLASS_FRNT_PROFLE_D70_ARCP1 |
|
|
DISPLAY CARD GROUP |
|
|
DOOR BOTTOM CAP HINGE BEARING |
|
|
DOOR SHELF FF 70CM 100MM GRNDIG T215-3-5 |
|
|
DOOR SHELF FF 70CM 55MM GRUNDIG T215-3-5 |
|
|
DRAWER COVER |
|
|
DRAWER COVER 180MM K70 GRUNDIG T215 |
|
|
DRYER T-D XH-7 10GR T0,4 2, 1UL |
|
|
EMBRACO_EVAP_TRAY_HB_BLK |
|
|
EVA COVER STR PLUG |
|
|
EVAP. COVER CAP WHITE |
|
|
EVA_COVER_STR |
|
|
FAN MOTOR ASSEMBLY NIDEC |
|
|
FF_LIGHTINING_ASSEMBLY LEFT |
|
|
FF_LIGHTINING_ASSEMBLY RIGHT |
|
|
FRZ FINNED EVAP ASSEMBLY K70 A++ 120V UL |
|
|
FRZ_FAN_ASSEMBLY_PANA_BLDC_115MM |
|
|
GLASS SHELF BACK PROFILE FF D70_HIPS |
|
|
GLASS SHELF BACK PROFILE FRZ D70_HIPS |
|
|
GLASS TOP CRISPER D70 |
|
|
GLASS_SHELF_FRONT_PROFILE_FF_D70_ARCP1 |
|
|
GLASS_SHELF_K70_FRZ_BOTTOM_ASSEMBLY |
|
|
GLASS_SHELF_K70_FRZ_TOP_ASSEMBLY |
|
|
HALF_WINE_RACK_550MM |
|
|
HINGE_STOPPER_STEEL |
|
|
HOSE STRAP |
|
|
ICE CUBE TRAY |
|
|
INVERTER_ASSEMBLY_VEMC9C_USA |
|
|
K70 FRZ EVAPORATOR ASSEMBLY _USA |
|
|
K70415 SMALL DRAWER BODY 180MM |
|
|
K70415N FF DOOR ASSEMBLY STNRY BH PEARL USA |
|
|
K70415N FF EVAPORATOR COVER GR |
|
|
K70415N FRZ DOOR ASSEMBLY BH PEARL USA |
|
|
K70415N_COMBI_FF_EVAP_COVER_IONI0_FILT0 |
|
|
K70415N_CRISPER_BODY_UNILLUMINATED |
|
|
K70415N_LARGE_DRAWER_BODY_180MM |
|
|
K70415_FF_SLOT_IN_GASKET_RIB_LIGHT GRAY |
|
|
K70415_FRZ_SLOT_IN_GASKET_RIB_LIGHT GRAY |
|
|
K70_DRAIN HEATER_120V 30W_UL |
|
|
LED_LAMP_CARD_SHORT |
|
|
LOWER DOOR TOP CAP HINGE BEARING |
|
|
MIDDLE HINGE ASSEMBLY ASEAN AUTO CLOSE |
|
|
MIDDLE HINGE COVER ARCP1 |
|
|
MIDDLE HINGE COVER RAL7039 |
|
|
MIDLE_HINGE_HOLE_PLUG_ARCP1_H6.4 |
|
|
PCB COVER ASSEMBLY PVC V2 0.5T |
|
|
PIESA_FIXARE_SENZOR_HIPS_NATURAL |
|
|
PIPE IMMERSION VCC |
|
|
POWER CORD_USA_2150MM_NEW |
|
|
PRINTED GLASS SHELF D70 FF ASSEMBLY |
|
|
PRINTED_GLASS_SHELF_FRZ_BOTTOM_70CM |
|
|
PRINTED_GLASS_SHELF_FRZ_TOP_70CM |
|
|
PRINTED_SQUARE_FAN_COVER_COOLING_BLOMBE |
|
|
PRNT CRISPER CVR GR 185MM T215 70CM |
|
|
REED SWITCH |
|
|
SCREW 3.5_19 |
|
|
SCREW COMPRESSOR |
|
|
SCREW M4X5,5 |
|
|
SCREW TORX HEAD FINE THREAD |
|
|
SEALING_GASKET_KOMBI_K70 |
|
|
SELF WASHERED PT SCREW_4X16 |
|
|
SOUND ISOLATOR FOR REFRIGERANT TUBING |
|
|
THERMAL FUSE ASSEMBLY_USA |
|
|
TOP HINGE ASSEMBLY ASEAN SPOT WELDING |
|
|
TOP HINGE COVER STATIC ASEAN RAL7039 |
|
|
TOP HINGE HOLE PLUG RAL7039 |
|
|
VCC COMPRESSOR VEMC9C |
|
|
VCC INVERTER |
|
|
WATER_DRAINAGE_ELBOW |
