Manufacturer
Bowers &Wilkins
Model Number
FP31062
Description
M-1 2-way Bookshelf Speaker
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
210 X 210 GLOBAL CRM BOOK |
|
|
ADHESIVE 3M EC847 |
|
|
BAFFLE GRILLE ASSEMBLY M-1 MATT WHITE |
|
|
BAG 230 X 320MM A4 SELF GRIP POLYTHENE |
|
|
BAG PARAFOAM 170 X 120 (OPEN END) |
|
|
BAG PARAFOAM 225 X 290 (OPEN END) |
|
|
BASS MID 4" GLASS FIBRE M-1 |
|
|
CABINET CASTING M-1 MATT WHITE |
|
|
CABLE TIE 2.5 WIDE, 1 THICK ,114.8 LONG |
|
|
CLAMP POLE PIECE M-1 SMALL |
|
|
COVER WALL BRACKET WHITE M-1 MK2 |
|
|
DESK STEM (2ND TOOL) SILVER |
|
|
DESK-TOP STAND ASSY M-1 CLEAR ANODISED |
|
|
DESK-TOP STAND MAT M-1 GREY |
|
|
FP PHANTOM GROUP M-1 |
|
|
GASKET FOAM 1.5X710X6.5 |
|
|
GASKET M1 BASS UNIT 4" |
|
|
GASKET NEOPRENE 1.2X50X8 |
|
|
GASKET RA106 FOAM 25MM X 16MM X 2MM |
|
|
GASKET RING 10X6X1.5 |
|
|
GENERIC WARRANTY LEAFLET 5YR |
|
|
GRILLE ASSEMBLY M-1 MATTE WHITE |
|
|
HARNESS M-1 STEM |
|
|
JACK SOCKET STEREO |
|
|
M-1 MASTER CARTON 5-PACK |
|
|
M-1S CARTON |
|
|
M-1S QSG |
|
|
M1 BAFFLE (POP RIVET VERSION) |
|
|
M6X20 SOCKET CAP HEAD STAINLESS |
|
|
PARAFOAM SHEET PROTECTION 260X765X0.5 |
|
|
POLY BOTTOM M-1 (MKII) |
|
|
POLY FOAM PROTECTION 200X312X10MM |
|
|
POLY TOP M-1 (MKII) |
|
|
PORT MANIFOLD - M-1 WHITE |
|
|
REAR STEM COVER WHITE M-1 |
|
|
SALIPT ?3.0 HEAT SHRINKABLE TUBING |
|
|
SCR NO 6X1/2 PAN POZI Z/C |
|
|
SCR NO4 X 1/4 CSK HD POZI BLACK |
|
|
SCREW M5X20 SOC CAP HD Z/C |
|
|
SERIAL LABEL M-1 (MKII) |
|
|
SHROUD -STEM CONNECTOR |
|
|
STEM CLAMP M-1 MATTE |
|
|
T15 TORX X 10 CAP HD STAINLESS STEEL |
|
|
T15 TORX X 20 CAP HD STAINLESS STEEL |
|
|
TORX KEY T15 |
|
|
TUBE HF M-1 MATTE |
|
|
TWEETER M-1 MATTE |
|
|
WADDING (HF TUBE) 90X20X10 |
|
|
WADDING 90X70X25 |
|
|
WALL BRACKET ASSEMBLY M-1 MKII |
|
|
WASHER M6 INTERNAL SHAKEPROOF ZINC |
|
|
X/OVER M-1 MATTE |
