Manufacturer
Bowers &Wilkins
Model Number
ISW8
Description
In-wall Subwoofer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BACK BOX ASSEMBLY 350X1680X84 TIMBER |
|
|
BAG POLY SELF SEAL 115X100 |
|
|
CABINET REAR SPACER PLATE ISW-8 |
|
|
CARTON ISW - 8 |
|
|
CARTON ISW-8 BACK BOX |
|
|
CLAMP DOG HOUSING 18.0MM O/D X 70.0MM |
|
|
CLAMPING DOG CCM7 |
|
|
CONTROLLED LEAK ASSEMBLY |
|
|
DECOUPLING FIXING MOUNT ASSY LH LOWER |
|
|
DECOUPLING FIXING MOUNT ASSY RH LOWER |
|
|
DECOUPLING FIXING MOUNT ASSY UPPER |
|
|
EPE BAG 420(OEPN)X 460MM |
|
|
EPE BAG 500(OEPN)X550MM |
|
|
FIXING BRACKET 90DEG LH |
|
|
FIXING BRACKET 90DEG RH |
|
|
GASKET - BACKBOX CENTRE ISW-8 |
|
|
GASKET - BACKBOX FRONT LOWER - ISW8 |
|
|
GASKET - BACKBOX FRONT UPPER - ISW8 |
|
|
GASKET - BACKBOX REAR - ISW8 |
|
|
GASKET - BAFFLE SEALING TO CABINET |
|
|
GASKET - BAFFLE TO BACKBOX SIDE - ISW8 |
|
|
GASKET - CONTROLLER LEAK SEALING |
|
|
GASKET CABINET OUTER ISW-8 |
|
|
GASKET GRILLE FRAME TO GRILLE INSERT |
|
|
GASKET INFILL DOUBLE SKIN |
|
|
GASKET INFILL SINGLE SKIN |
|
|
GASKET MOUNTING BAFFLE TO BACKBOX |
|
|
GASKET REAR SPACER PLATE TO CAB ISW-8 |
|
|
GASKET SEALING BAFFLE TO DRIVER |
|
|
GASKET SEALING BAFFLE TO MOUNTING BAFFLE |
|
|
GASKET TERMINAL TRAY TO BACKBOX |
|
|
GENERIC WARRANTY LEAFLET 5YR |
|
|
GRILLE ASSEMBLY ISW-8 |
|
|
GRILLE FRAME INSERT 12 INCH DOUBLE SKIN |
|
|
GRILLE MESH ISW-8 |
|
|
ISW-8 BB INSTALLATION GUIDE |
|
|
ISW-8 CUTTING TEMPLATE |
|
|
ISW-8 INSTALLATION GUIDE |
|
|
ISW-8 PROTECTIVE DRIVER COVER |
|
|
LF 12 INCH LF SHALLOW DEPTH |
|
|
MOUNTING BAFFLE LF 74X260X15 |
|
|
NUT CAPTIVE ABS 12MM A/F |
|
|
PAINT MASK 12 INCH LF DRIVER |
|
|
PE BAG 150(OPEN)X200MM |
|
|
PLASTER UPTO PLUG - PLASTIC - ISW8 |
|
|
POLY BOTTOM LEFT ISW-8 |
|
|
POLY BOTTOM RIGHT ISW-8 |
|
|
POLY ISW-8 DRIVE |
|
|
POLY TOP LEFT ISW-8 |
|
|
POLY TOP RIGHT ISW-8 |
|
|
SCR M3 X 8 PAN POZI BLK THREAD FORMING |
|
|
SCR M4X8 CAP HD CR3 BLACK |
|
|
SCREW 3.0X16 CSK WOOD SCREW Z/B |
|
|
SCREW 3X6 PAN POZI Z/C PRST30 SELF-TAP |
|
|
SCREW 5X10 PANPOZI Z/B W-5-10-PRST30-TC1 |
|
|
SCREW 5X20 CSK TORX Z/B |
|
|
SCREW M4 X 12 CSK HD POZI Z/B |
|
|
SCREW M4 X 12 CSK TORX ZB |
|
|
SCREW M5X12 PAN HD POZI BLACK |
|
|
SCREW M6 X 16 PAN HD TORZ ZB |
|
|
SCREW M6X16 CSK TORX Z/B |
|
|
SCREW NO8 X 3 INCH PAN PHILIPS BLACK |
|
|
SEALING BAFFLE 12 INCH LF DRIVER |
|
|
TERMINAL BRASS BLK HYH 12MM LONG THREAD |
|
|
TERMINAL BRASS RED HYH 12MM LONG THREAD |
|
|
TERMINAL TRAY 2 POST ANGLED |
