Manufacturer
Carrier
Model Number
25HBC560A0030010
Description
Split System Heat Pump
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
1/2-INCHX7/8-INCHODF 24V REVERSING VALVE |
|
|
1/4HP825 RPM208/230/1/60 CW MOTOR |
|
|
175-216MFD 330V STARTCAPACITOR |
|
|
25-INCHDIA 30DEGCW 3BLADE FAN |
|
|
3/8-INCH 24V SOLENOID VALVE |
|
|
55-23# LOW PRESSURE SWITCH |
|
|
6 PC SNOW STAND KIT |
|
|
670-470# HIGH PRESSURE SWITCH |
|
|
ACCUMULATOR |
|
|
ADAPTER ASSEMBLY |
|
|
BELT 6-7-INCHDIA 60-INCH LEADS HEATER |
|
|
BODY COUPLING |
|
|
CAPILLARY ASSY |
|
|
CARRIER KSALA0301410 LOW AMBIENT PRESSUR |
|
|
CHECK VALVE |
|
|
CHECK VALVE |
|
|
CLAMP 2 1/2-INCH OD |
|
|
CONTACTOR |
|
|
CONTROL BOX COVER KIT |
|
|
DISTR ASSY? |
|
|
DISTRIBUTOR |
|
|
EXPANSION VALVE |
|
|
FAN CENTER RELAY |
|
|
FAN GUARD TOP PANEL |
|
|
FILTER DRIER SUCTION |
|
|
FLARE CAP |
|
|
FLARE NUT |
|
|
GROMMET |
|
|
GROMMET COMPRESSOR |
|
|
GROUND LUG |
|
|
HARD START KIT |
|
|
HIGH PRESSURE SWITCH |
|
|
INLET GRILLE |
|
|
LIQUID LINE SOLENOID VALVE KIT |
|
|
LOW VOLTAGE BOARD |
|
|
MOTORMASTER LOW AMBIENT CONTROL |
|
|
MUFFLER |
|
|
P298-001 COMPRESSOR PLUG ASSY. |
|
|
PAINT |
|
|
PISTON RETAINER |
|
|
PISTON SERVICE TOOL |
|
|
PISTON, OUTDOOR (HEAT) |
|
|
PURON DRIER; R410A |
|
|
RELAY |
|
|
RELAY TIME DELAY |
|
|
RVS PLUG HARNESS ASSEMBLY |
|
|
SCHRAEDER VALVE CORE |
|
|
START ASSIST |
|
|
START RELAY |
|
|
STRAP |
|
|
SUPPORT-COIL |
|
|
TEMPERATURE ACTIVATION SWITCH-DEF SENSOR |
|
|
TEMPERATURE LIMIT SWITCH |
|
|
TIME DELAY; COMPRESSOR |
|
|
TOP COVER ASSEMBLY |
|
|
TXV KIT PURON 5 TON |
|
|
WIRE HARNESS |
|
|
WIRING HARNESS |
