Manufacturer
Carrier
Model Number
286BNA036000DBAA
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
1/2"X7/8"ODF 24V REVERSING VALVE |
|
|
2 CAPS 1.18HEX |
|
|
208-230V1PH 1/5HP 810 RPM MOTOR |
|
|
3/8" 24V SOLENOID VALVE |
|
|
40VA 208/230V->24V TRANSFORMER |
|
|
6 PC SNOW STAND KIT |
|
|
ADAPTER ASSEMBLY |
|
|
BELT 6-7"DIA 60" LEADS HEATER |
|
|
CAP-STEM (LIQUID) 3/8" |
|
|
CAPILLARY ASSY |
|
|
CHECK VALVE |
|
|
COMPRESSOR PLUG |
|
|
CONTACTOR 1 POLE 40 AM |
|
|
CONTROL BOX |
|
|
COVER TERMINAL |
|
|
DISTR ASSY |
|
|
DISTRIBUTOR |
|
|
FAN |
|
|
FILTER DRIER, SUCTION |
|
|
GROMMET |
|
|
HIGH PRESSURE SWITCH |
|
|
ISOLATOR VIBRATION |
|
|
LIQUID LINE SOLENOID VALVE KIT |
|
|
LOUVER PANEL ASSY; |
|
|
LOW PRESSURE SWITCH |
|
|
MODULE PLUG |
|
|
MUFFLER S/T TYPE |
|
|
NAMEPLATE |
|
|
PISTON |
|
|
PISTON RETAINER |
|
|
PISTON SERVICE TOOL |
|
|
PRESS SW ASSY |
|
|
RELAY |
|
|
SCHRAEDER VALVE CORE |
|
|
SOUND BLANKET |
|
|
STRAP DUAL CAPACITOR |
|
|
SUPPORT-COIL |
|
|
SWITCH ASY PRESSURE |
|
|
TEMP SW ASSY DISCH. |
|
|
TEMP SWITCH |
|
|
TEMPERATURE LIMIT SWITCH |
|
|
THERMISTOR OAT/OCT |
|
|
TOUCH UP PAINT DUSK BROWN |
|
|
WIRE HARNESS |
|
|
WIRING HARNESS |
