Manufacturer
Carrier
Model Number
48HCSD1735A
Description
Single Package Rooftop Gas Heating Electric Coolin
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
#51 BURNER ORIFICE SPUD |
|
|
1000VA 240/480VPRIM120/240VSEC |
|
|
11 7/8"X 10 11/16" CW WHEEL |
|
|
117/054# LOW PRESSURE SWITCH |
|
|
15.5X15 BLOWER WHEEL |
|
|
1GRV SHEAVE,8.75-INCH OD,1 3/16BORE |
|
|
2 GROOVE SHEAVES 13/16 BORE |
|
|
2.834-INCH SAMPLING TUBE |
|
|
230/460V3PH 5.25HP 1745RPM MTR |
|
|
24V 2-10VDC 180# ACTUATOR |
|
|
24V 3.5" WC NAT 1/8" GAS VALVE |
|
|
24V COIL 2P 40AMP CONT |
|
|
5' CABLE ASSEMBLY |
|
|
50DJ404793 DOOR LATCH |
|
|
50DJ504652 HINGE |
|
|
6 PIN CONNECTOR PLUG |
|
|
660/505# HIGH PRESSURE SWITCH |
|
|
ACCESS PANEL |
|
|
ACCESS PANEL |
|
|
ACCESS PANEL |
|
|
ACCESS PANEL |
|
|
ACCESS PANEL INSULATED |
|
|
ACCESS PANEL INSULATED |
|
|
ACCESS PNL |
|
|
ACTUATOR MOTOR |
|
|
ACTUATOR MOTOR |
|
|
ACTUATOR REPLACEMENT KIT |
|
|
AIR DAMPER VENT |
|
|
ANGLE IFM MOUNTING |
|
|
ANGLE MOUNTING |
|
|
ANGLE SUPPORT |
|
|
ANGLE SUPPORT |
|
|
AT96AB170 CAGE NUT |
|
|
BARO RELIEF ANGLE |
|
|
BARO RELIEF DOOR |
|
|
BARO RELIEF HINGE |
|
|
BASE PAN OUTDOOR INSULATED |
|
|
BASE RAIL BACK |
|
|
BASE RAIL END |
|
|
BASE RAIL FRONT |
|
|
BEARING |
|
|
BEARING BRACKET |
|
|
BEARING BRACKET |
|
|
BELT |
|
|
BELTDRIVEBLOWERMOTOR 4.9HP230V |
|
|
BLANK OFF |
|
|
BLANKOFF |
|
|
BLOCKOFF |
|
|
BLOCKOFF |
|
|
BOLT HEX HEAD |
|
|
BOX COVER |
|
|
BRACKET |
|
|
BRACKET |
|
|
BRACKET BASE |
|
|
BRACKET COND SWITCH |
|
|
BRACKET CONTROLLER |
|
|
BRACKET GUARD |
|
|
BRACKET MOTOR CHANNEL |
|
|
BRACKET MOUNT |
|
|
BRACKET MOUNT |
|
|
BRACKET ROLL OUT |
|
|
BRACKET SMOKE SENSOR |
|
|
BRACKET SUPPORT |
|
|
BREAKER CIRCUIT |
|
|
BURNER |
|
|
BURNER ASSY |
|
|
BURNER BRACKET |
|
|
BURNER ORIFICE, NATURAL GAS |
|
|
BURNER SPUD |
|
|
BURNER SUPPORT |
|
|
BUSHING |
|
|
CABLE ASSEMBLY FOR SUPPLY SENS |
|
|
CARRIER 50HE401986 DRAIN PAN |
|
|
CARRIER 50HJ501200 OUTLET GRILL FAN GUAR |
|
|
CARRIER AU02AB171 PLATE WASHER |
|
|
CARRIER AU11AS171 LOCK WASHER |
|
|
CARRIER HVAC PART |
|
|
CARRIER HVAC PART |
|
|
CARRIER HVAC PART |
|
|
CARRIER HVAC PART |
|
|
CARRIER HVAC PART |
|
|
CARRIER HVAC PART |
|
|
CARRIER HVAC PART |
|
|
CARRIER HVAC PART |
|
|
CARRIER LH32RF120 ORIFICE |
|
|
CARRIER LH32RF129 SPUD ORIFICE |
|
|
CHANNEL |
|
|
CHANNEL |
|
|
CHECK VALVE |
|
|
CIRCUIT BREAKER |
|
|
CIRCUIT BREAKER |
|
|
CIRCUIT BREAKER |
|
|
CLAMP |
|
|
CLAMP FILTER DRIER |
|
|
COIL |
|
|
COIL CENTER POST INSUL ASSY |
|
|
COIL COND.AL/CU E-COAT |
|
|
COIL CONDENSER AL/CU |
|
|
COIL CONDENSER AL/CU |
|
|
COIL CONDENSER CKT B CU/CU |
|
|
COIL CONDENSER CU/CU |
|
|
COIL CONDENSER CU/CU |
|
|
COIL.COND AL/CU E-COAT |
|
|
COIL.COND AL/CU PRE-COAT |
|
|
COIL.EVAP AL/CU |
|
|
COMPRESSION FITTING |
|
|
COND FAN MOTOR |
|
|
CONDENSOR FAN MOTOR |
|
|
CONNECTOR |
|
|
CONNECTOR |
|
|
CONTROL BOARD |
|
|
CONTROL BOARD, RTU-OPEN |
|
|
CONTROLLER |
|
|
CONTROLLER CONDENSATE S |
|
|
CORNER BRACE |
|
|
COUPLING |
|
|
COVENIENCE OUTLET |
|
|
COVER HEAT |
|
|
COVER INNER CONTROL BOX |
|
|
COVER INNER CONTROL BOX HNG |
|
|
CRANK CASE HEATER |
|
|
DAMPER ASSEMBLY |
|
|
DECK BLOWER |
|
|
DISTRIBUTOR 12 CKT |
|
|
DOOR & FRAME ASY INSULA TED |
|
|
DOOR ACCESS INSULATED |
|
|
DRAIN PAN EXTENSION |
|
|
DUCT EXHAUST GAS |
|
|
DUCT EXHAUST GAS |
|
|
ECON HOOD ANGLE |
|
|
ECON HOOD BRACKET |
|
|
ECONOMIZER |
|
|
ECONOMIZER |
|
|
ECONOMIZER ACTUATOR |
|
|
ECONOMIZER ASSEMBLY |
|
|
ECONOMIZER CONTROL |
|
|
ECONOMIZER CONTROL |
|
|
ECONOMIZER WIRE HARNESS |
|
|
END STOP |
|
|
ENTHALPY SENSOR |
|
|
ENTHALPY SWITCH |
|
|
ERV WHEEL MOTOR |
|
|
EXHAUST HOOD ASSY |
|
|
FAN PROP 3 BLADES |
|
|
FAN SIDE PLATE |
|
|
FAN SIDE PLATE |
|
|
FILTER |
|
|
FILTER BRACKET |
|
|
FILTER BRACKET |
|
|
FILTER DOOR BRACKET |
|
|
FILTER DRIER |
|
|
FILTER TRACK |
|
|
FILTER TRACK BOTTOM |
|
|
FILTER TRACK TOP |
|
|
FLARE CAP |
|
|
FLEXIBLE TUBE |
|
|
FLEXIBLE TUBE |
|
|
FREEZE THERMOSTAT |
|
|
FUSE |
|
|
FUSE BRACKET |
|
|
FUSE COVER |
|
|
FUSE HOLDER |
|
|
GAS CNTR POST INSUL ASS Y |
|
|
GROMMET |
|
|
GROMMET |
|
|
GROMMET |
|
|
GROMMET COMPRESSOR |
|
|
GROMMET PARTITION |
|
|
GROMMET WIRE |
|
|
GUARD COIL HAIL END |
|
|
HANDLE |
|
|
HARNESS ASSY |
|
|
HARNESS ASY |
|
|
HARNESS ASY ECON |
|
|
HARNESS ASY MBB TO LDV/ RDV/ |
|
|
HARNESS WIRE |
|
|
HEAT EXCHANGER 5 CELL SS |
|
|
HEAT EXCHANGER SS |
|
|
HINGE PIN (PIVOT SCREW) QTY 2 |
|
|
HOOD ASSY PACKAGE |
|
|
HOOD SIDE |
|
|
HOOD SIDE |
|
|
HOOD SIDE |
|
|
HOOD SIDE |
|
|
IFM PANEL BRACKET |
|
|
IGC BOARD |
|
|
IGNITION BOARD |
|
|
IGNITOR |
|
|
IGNITOR ASSEMBLY |
|
|
INDUCER ASSEMBLY |
|
|
INDUCER BLOWER WHEEL |
|
|
INDUCER HOUSING |
|
|
INDUCER MOTOR |
|
|
INSUL ASY ACCESS PANEL |
|
|
INSUL ASY ACCESS PANEL |
|
|
INSUL ASY ACCESS PANEL |
|
|
INSUL ASY CENTER POST |
|
|
INSUL ASY CORNER POST |
|
|
INSUL ASY CORNER POST |
|
|
INSUL ASY FAN DECK |
|
|
INSUL ASY PANEL ACCESS |
|
|
INSUL ASY PANEL ACCESS |
|
|
INSUL ASY PARTITION |
|
|
INSUL ASY RETURN PAN |
|
|
INSUL ASY SUPPLY PAN |
|
|
INSUL ASY TOP COVER |
|
|
INSUL ASY TOP COVER |
|
|
INSULATED PANEL |
|
|
INSULATED PANEL |
|
|
JADE TEMP.SENSOR(20K NTC) |
|
|
KA99AA001 PIN |
|
|
KEY (PULLEY) |
|
|
L140F-40 LIMIT SWITCH |
|
|
LATCH PLATE |
|
|
LOW AMBIENT SENSOR |
|
|
LP PRESSURE SWITCH |
|
|
MAIN BASE CONTROL BOARD |
|
|
MANIFOLD 5 CELL |
|
|
MOTOR |
|
|
MOTOR |
|
|
MOTOR & WHEEL ASY |
|
|
MOTOR BAND |
|
|
MOTOR CHANNEL |
|
|
MOTOR CHANNEL |
|
|
MOTOR MASTER CONTROLLER |
|
|
MOTOR MOUNT ARM |
|
|
MOTOR,208/230-460V,3-PHASE,5 HP,1725 RPM |
|
|
MOUNT BRACKET |
|
|
NATURAL GAS ORIFICE #48 SIZE |
|
|
NATURAL TO LP GAS VALVE CONVERSION KIT |
|
|
NOZZLE |
|
|
OUTDOOR AIR FAN ASY 230 |
|
|
OUTSIDE AIR SENSOR |
|
|
PAINT STERLING |
|
|
PAN BASE CONDENSER |
|
|
PANEL ACCESS |
|
|
PANEL ACCESS RTPF |
|
|
PANEL ASSEMBLY LOWERINSULAT |
|
|
PANEL ASSEMBLY UPPERINSULAT |
|
|
PANEL ASSEMBLY UPPERINSULAT |
|
|
PANEL ASY CENTER POST |
|
|
PANEL ASY DOOR HINGED |
|
|
PANEL ASY DOOR HINGED |
|
|
PANEL ASY DOOR HINGED |
|
|
PANEL ASY GAS ACCESS |
|
|
PANEL END INSULATED |
|
|
PANEL INSULATED |
|
|
PHOTOELECTRIC DUCT SMOKE SENSR |
|
|
PICK-UP TUBE |
|
|
PLATE ASY COMPR MTG |
|
|
PLATE ASY COMPR MTG |
|
|
PLUG ASSY |
|
|
PLUG BUTTON |
|
|
POST CORNER |
|
|
PREMIER LINK BOARD |
|
|
PRESSURE SWITCH |
|
|
PRESSURE SWITCH |
|
|
PRESSURE SWITCH |
|
|
PROTECTOR |
|
|
PULLEY |
|
|
RECEPTACLE WHITE |
|
|
REHEAT BOARD |
|
|
RELAY |
|
|
RELAY |
|
|
RELAY |
|
|
RELAY 240V 14A |
|
|
RELAY SOCKET |
|
|
RELAY3PDT 24V |
|
|
RESISTOR |
|
|
RING INSERT |
|
|
ROLLOUT SWITCH |
|
|
SCHRAEDER VALVE CORE |
|
|
SCREW |
|
|
SCROLL FAN |
|
|
SCROLL PANEL |
|
|
SEAL CONDENSATE OUTLET |
|
|
SEAL STRIP KIT HEAT EXCH ANGER |
|
|
SENSOR |
|
|
SENSOR WITHOUT DISPLAY |
|
|
SHAFT FAN |
|
|
SHROUD ASSEMBLY LOW LEAK ECON |
|
|
SIDE PLATE |
|
|
SMOKE DETECTOR CONTROL W/WIRE |
|
|
SPUD |
|
|
SPUD |
|
|
SPUD |
|
|
SPUD |
|
|
SPUD |
|
|
SPUD ASSEMBLY |
|
|
STRIP GROMMET 100FT LEN GTH |
|
|
SUPPORT BRACKET |
|
|
SUPPORT BRACKET |
|
|
SUPPORT HEAT |
|
|
SUPPORT-COIL |
|
|
SWITCH ADJ DIFF. PRESSURE |
|
|
SWITCH LOW PRESSURE |
|
|
SWITCH TOGGLE |
|
|
TAB |
|
|
TEMPERATURE SENSOR |
|
|
TEMPERATURE SWITCH |
|
|
TERMINAL BOARD |
|
|
TERMINAL BOARD |
|
|
TERMINAL BOARD |
|
|
TERMINAL BOARD |
|
|
THERMISTER SENSOR OAT |
|
|
THERMISTOR |
|
|
THERMISTOR OAT/SAT |
|
|
THERMISTOR PROBE |
|
|
TIME DELAY |
|
|
TIME DELAY; COMPRESSOR |
|
|
TOP HOOD |
|
|
TOP HOOD |
|
|
TOP PANEL |
|
|
TRANSDUCER |
|
|
TRANSDUCER PRESS. 5.0 I |
|
|
TRANSFORMER |
|
|
TXV |
|
|
UTILITY BOX |
|
|
VALVE BODY |
|
|
VALVE BODY |
|
|
VALVE CORE |
|
|
VARIABLE FREQUENCY DRIVE |
|
|
VESTIBULE PLATE ANGLE |
|
|
VESTIBULE PLATE ANGLE |
|
|
VVT4 ZONE SENSOR |
|
|
WIND CAP ASSY |
|
|
WINTER START PACK |
|
|
WIRE GUARD |
|
|
WIRE HARNESS CONTROL |
|
|
WIRE HARNESS IFC TO IFC B |
|
|
WIRE HARNESS OUTDOOR FAN RE |
|
|
WIRING HARNESS |
|
|
WIRING HARNESS |
|
|
ZEE BRACKET |
|
|
ZEE BRACKET |
