Model Image
Manufacturer

Carrier

Model Number

50HCQD081A

Description

Packaged Rooftop High Efficiency Heat Pump Units

Interactive Exploded View

Parts List

Part Number Description
32LT660004 32LT660004 208/230V 1PH MOTORMASTER DRIVE
HN52TC040 HN52TC040 24V COIL 2P 40AMP CONT
EF19ZG239 EF19ZG239 24V REV VALVE COIL
HN52TC024 HN52TC024 2P 32AMP 24V CONTACTOR
HK02SB027 HK02SB027 44-27# LOW PRESSURE SWITCH
HK02SB029 HK02SB029 44-27# LOW PRESSURE SWITCH
EC31EZ212 EC31EZ212 5/8-INCH CHECK VALVE
HC39GE577 HC39GE577 575V1PH 1/4HP 1100RPM MOTOR
HD56FE575 HD56FE575 575V3PH 1725RPM 56Y MOTOR
HD58FE576 HD58FE576 575V3PH 1725RPM 56Y MOTOR
HK02SA440 HK02SA440 660/505# HIGH PRESSURE CUTOUT
KH71KP162 KH71KP162 ACCUMULATOR 5-INCH X .08
50HJ402076 50HJ402076 BASE PAN ASSY
50DK503370 50DK503370 BASE RAIL
50DK503371 50DK503371 BASE RAIL
50DK503372 50DK503372 BASE RAIL
KT61DZ060 KT61DZ060 BEARING
48HG500422 48HG500422 BEARING BRACKET
P463-A48 P463-A48 BELT
50HJ441157 50HJ441157 BLOWER ASSEMBLY;
50HJ542488 50HJ542488 BLOWER BRACKET
LA22LA125 LA22LA125 BLOWER WHEEL
AH19AB552 AH19AB552 BOLT
50DK500523 50DK500523 BRACKET
50DK502263 50DK502263 BRACKET
50DK502805 50DK502805 BRACKET
50HJ542489 50HJ542489 BRACKET MOTOR ADJUST
50HJ542491 50HJ542491 BRACKET MOTOR ADJUST
48TM503400 48TM503400 BRACKET SENSOR
HY93NH063 HY93NH063 BUSHING
HY93NH081 HY93NH081 BUSHING
P281-0021 P281-0021 CAPACITOR STRAP
AH19AB198 AH19AB198 CARRIAGE BOLT
AH20AB204 AH20AB204 CARRIAGE BOLT
48TMHSRAM-1A00 48TMHSRAM-1A00 CARRIER 48TMHSRAM-1A00 HARNESS ASSY
50HJ501200 50HJ501200 CARRIER 50HJ501200 OUTLET GRILL FAN GUAR
EA660005 EA660005 CARRIER EA660005 KIT TXV VALVE W/INSULAT
EC31EZ120 EC31EZ120 CARRIER EC31EZ120 CHECK VALVE
HK02SA420 HK02SA420 CARRIER HK02SA420 PRESSURE SWITCH
KH11NH074 KH11NH074 CARRIER KH11NH074 STRAINER
48TM400813 48TM400813 CENTER POST CONTROL BOX
50DK502637 50DK502637 COIL BRACKET
48TM400369C 48TM400369C COIL COND AL/CU E-COAT
48TM400371 48TM400371 COIL.COND AL/CU VINYL
48TM402498 48TM402498 COIL.EVAP AL/CU
HC40GE233 HC40GE233 COND FAN MOTOR
50DK407017 50DK407017 CONDENSATE PAN
48TM400369 48TM400369 CONDENSER COIL
48TM500285 48TM500285 CONTROL BOX ACCESS PANEL
HL38MG029 HL38MG029 CONTROL HUMIDISTAT
HL39ZZ008 HL39ZZ008 CONTROLLER CONDENSATE S
48TM400584 48TM400584 CORNER POST INSULATION A
48TM400811 48TM400811 CORNER POST ISULATION AS
50DK400833 50DK400833 COVER
50DK400832 50DK400832 COVER ASSEMBLY
48TM504178 48TM504178 COVER CONTROL BOX
HK32EA005 HK32EA005 DEFROST CONTROL BOARD
HH18HA281 HH18HA281 DEFROST TEMP SWITCH
48TMFSRBWD-AL0 48TMFSRBWD-AL0 DISCONNECT
48TM402938 48TM402938 DISTR ASSYUPPER
CRECOMZR021A03 CRECOMZR021A03 ECONOMIZER
50HJ400345 50HJ400345 ECONOMIZER BYPASS PLUG
HH57AC078 HH57AC078 ENTHALPY SENSOR
50DK500688 50DK500688 FAN DECK
LA01RA044 LA01RA044 FAN PROP 3 BLADES
48HG501457 48HG501457 FAN SHAFT
KH43LE102 KH43LE102 FILTER DRIER
50DK406603 50DK406603 FILTER FRAME ASSEMBLY
50DK506598 50DK506598 FILTER RETAINER
50DK506601 50DK506601 FILTER RETAINER
99CC409372 99CC409372 FLARE CAP
DD02CA101 DD02CA101 FLARE NUT
KA56ZZ150 KA56ZZ150 GROMMET
KA56TR057 KA56TR057 GROMMET COMPRESSOR
KA56DS001 KA56DS001 GROMMET WIRE
HY90AZ009 HY90AZ009 GROUND LUG
CRLVHLGD016A00 CRLVHLGD016A00 HAIL GUARD
329799-401 329799-401 HANDLE
48TMHSRAH-2A00 48TMHSRAH-2A00 HARNESS
48TM403898 48TM403898 HARNESS ASSY
48TM400923 48TM400923 HARNESS ASY IFM
48TM400225 48TM400225 HEADER ASSEMBLY
48TM400270 48TM400270 HEADER ASSEMBLY
50DK500944 50DK500944 HEATER BRACKET
HT32TC943 HT32TC943 HEATER CRANKCASE
HY06ZZ025 HY06ZZ025 HY06ZZ025 PLUG COMPRESSOR
50DK401017 50DK401017 INDOOR BASE PAN
50HC660003 50HC660003 INSULATION KIT TXV BULB
AW01DA096 AW01DA096 KEY BLOWER SHAFT (5 PACK)
HH18SA261 HH18SA261 L80F-50 DEFROST TEMPERATURE
HH18HA199 HH18HA199 LIMIT SWITCHES
50HJ542452 50HJ542452 LOUVER PANEL
50HJ542454 50HJ542454 LOUVER PANEL
CRMANDPR002A03 CRMANDPR002A03 MANUAL DAMPER
HD56FR575 HD56FR575 MOTOR
HD56FR579 HD56FR579 MOTOR BLR 1.7 HP
HD56FE577 HD56FE577 MOTOR BLR 2.4 HP
HD58FE577 HD58FE577 MOTOR BLR 3.7 HP
50HJ542490 50HJ542490 MOTOR BRACKET
50HJ542487 50HJ542487 MOTOR MOUNT
P461-3706 P461-3706 MOTORPULLEY 7/8-INCH BORE3.4-4.4-INCH
33ZCSENOAT 33ZCSENOAT OUTDOOR AIR SENSOR
48TM500190 48TM500190 OUTDOOR PANEL
313974-751 313974-751 PAINT STERLING
50DK502826 50DK502826 PANEL
50HJ441620 50HJ441620 PANEL ASSEMBLY
50HJ442448 50HJ442448 PANEL ASSY
48TM400574 48TM400574 PANEL ASSY BLOWER ACCESS
P461-3507 P461-3507 PD PULLEY
EA52PH080 EA52PH080 PISTON
99CC503153 99CC503153 PISTON BODY
HY06ZZ026 HY06ZZ026 PLUG ASSEMBLY/WIRING HARNESS
KA51PC175 KA51PC175 PLUG BUTTON
48TM400809 48TM400809 POST CORNER
48TM500272 48TM500272 POST CORNER
CRPWREXH022A01 CRPWREXH022A01 POWER EXHAUST
KR11AZ712 KR11AZ712 PULLEY
P461-3505 P461-3505 PULLEY 4X5/8 IN
HN61KK324 HN61KK324 RELAY
HN61PC005 HN61PC005 RELAY 240V 14A
KA99ZT003 KA99ZT003 REMOTE TEST STAT KIT
EF17BG270 EF17BG270 REVERSING VALVE W/COIL
50DK501626 50DK501626 SCROLL
50DK500235 50DK500235 SEAL DRAIN LINE
50DK500432 50DK500432 SEAL INDOOR COIL/PARTITI ON
32LT660001 32LT660001 SENSOR FOR MOTOR CONTROLLER
KR11AZ002 KR11AZ002 SHAFT BLOWER WHEEL
50DK501625 50DK501625 SIDEPLATE FAN BACK SIDE
50DK501624 50DK501624 SIDEPLATE FAN DRIVE SIDE
48TM400980 48TM400980 SMOKE DETECTOR
48TM400979 48TM400979 SMOKE DETECTOR WITH BRACKET
33ZCT56SPT 33ZCT56SPT SPACESENSORW/OVERRIDEBUTTON
50DK506758 50DK506758 SUPPORT TRACK
48TMHSRAST-A00 48TMHSRAST-A00 TEL-AIRE SMOKE HARNESS
33ZCT55SPT 33ZCT55SPT TEMP SENSOR
33ZCT59SPT 33ZCT59SPT TEMP SENSOR W/OVERRIDE DIGITAL
HT01AH859 HT01AH859 TRANSFORMER
HT01BD902 HT01BD902 TRANSFORMER
EC39EZ065 EC39EZ065 VALVE BODY
EC39EZ067 EC39EZ067 VALVE CORE
HH79NZ074 HH79NZ074 VVT4 ZONE SENSOR
P291-0553 P291-0553 XS CAPACITOR 27L426;
