Model Image
Manufacturer

Carrier

Model Number

50HCQD12A2A60A0A0

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
HC39GE480 HC39GE480 1/4HP 460V1PH 1100 RPM MOTOR
HD58FR233 HD58FR233 208-230/460V 3PH 1725 RPM 2.9HP
HN52TC040 HN52TC040 24V COIL 2P 40AMP CONT
HT01BD702 HT01BD702 460V PRI 24V SEC TRANSFORMER
50TM400016 50TM400016 50TM400016 DRAIN PAN
HK02SA440 HK02SA440 660/505# HIGH PRESSURE CUTOUT
KH71KJ155 KH71KJ155 ACCUMULATOR
KH01AA365 KH01AA365 AIR FILTER
KT61DZ075 KT61DZ075 BEARING
KR30AE057 KR30AE057 BELT
50TM400529 50TM400529 BLOWER ASSEMBLY
50HJ542488 50HJ542488 BLOWER BRACKET
KR11AH215 KR11AH215 BLOWER PULLEY
LA22LA192 LA22LA192 BLOWER WHEEL
50DK500523 50DK500523 BRACKET
50DK502805 50DK502805 BRACKET
50TM500172 50TM500172 BRACKET ASSEMBLY
50TM401665 50TM401665 BRACKET ASSYCNTL BX
HY93NH016 HY93NH016 BUSHING
HY93NH008 HY93NH008 BUSHING
50HJ501200 50HJ501200 CARRIER 50HJ501200 OUTLET GRILL FAN GUAR
EC31EZ120 EC31EZ120 CARRIER EC31EZ120 CHECK VALVE
KH11NH074 KH11NH074 CARRIER KH11NH074 STRAINER
50TM400894 50TM400894 COIL CONDENSER AL/CU
50TM400895 50TM400895 COIL CONDENSER AL/CU
50TM401044 50TM401044 COIL EVAP AL/CU
50TM400218 50TM400218 CONTROL BOX ACCESS PANEL
50TM400254 50TM400254 CORNER POST
50TM400158 50TM400158 COVER ASY TOP
50TM400579 50TM400579 COVER ASY TOP
50TM400305 50TM400305 COVER ASY, RETURN AIR
HT32TC707 HT32TC707 CRANK CASE HEATER
HK32EA005 HK32EA005 DEFROST CONTROL BOARD
HH18HA281 HH18HA281 DEFROST TEMP SWITCH
50HJ400345 50HJ400345 ECONOMIZER BYPASS PLUG
LA01RA044 LA01RA044 FAN PROP 3 BLADES
50TM500267 50TM500267 FAN SHAFT
50TM400147 50TM400147 FILTER ACESS BASE RAIL
50TM500089 50TM500089 FILTER ACESS BASE RAIL
HH18HB016 HH18HB016 FREEZE THERMOSTAT
KA56ZZ150 KA56ZZ150 GROMMET
KA56TR057 KA56TR057 GROMMET COMPRESSOR
HY90AZ009 HY90AZ009 GROUND LUG
50TM500499 50TM500499 GUARD BASERAIL INDOOR E
329799-401 329799-401 HANDLE
50TM400642 50TM400642 HARNESS ASSY
48TMHSRLF3-A00 48TMHSRLF3-A00 HARNESS ASSY PWR TO IFC
48TMHSRLA--C10 48TMHSRLA--C10 HARNESS ASYPOWER INPUT TB1
AW01DA100 AW01DA100 KEY (PULLEY)
HH18HA199 HH18HA199 LIMIT SWITCHES
KH43LG093 KH43LG093 LIQUID LINE FILTER DRIER
50HJ542490 50HJ542490 MOTOR BRACKET
50TM500219 50TM500219 MOUNT MOTOR
50TM401708 50TM401708 PANEL ACCESSCOMPR
50TM500354 50TM500354 PANEL ACCESSCOMPRSTD
50TM401680 50TM401680 PANEL ACCESSCONTR
50TM400161 50TM400161 PANEL ASSY
50TM400170 50TM400170 PANEL ASY BLOWER ACCESS STD
50TM501493 50TM501493 PANEL ASY LOWER W/O LOUV
50TM400169 50TM400169 PANEL ASYFILTER LOWER
50TM400585 50TM400585 PANEL ASYINDOOR END
50TM500659 50TM500659 PANEL OUTDOOR END
50TM500052 50TM500052 PLATE BLOWER SIDE
50TM500069 50TM500069 PLATE BLOWER SIDE
HY06MP050 HY06MP050 PLUG
KA51PC175 KA51PC175 PLUG BUTTON
HY06ZZ029 HY06ZZ029 PLUG COMPRESSOR
HY06ZZ027 HY06ZZ027 PLUG COMPRESSOR
50TM500138 50TM500138 POST CENTER
50TM500398 50TM500398 POST CENTER COIL MOUNT
50TM500057 50TM500057 POST CENTERFILTER ACCES S SIDE
50TM500077 50TM500077 POST CORNERCOIL
50TM400159 50TM400159 POST CORNERINDOOR END
319421-307 319421-307 RACEWAY, WIRE
50TM500088 50TM500088 RAIL BASE INDOOR FAN ACCESS
50TM500250 50TM500250 RAIL BASE OUTDOOR END
HN61PK052 HN61PK052 RELAY
48TMHSRLH-2A00 48TMHSRLH-2A00 REVERSING VALVE HARNESS
EF17BG270 EF17BG270 REVERSING VALVE W/COIL
50TM500199 50TM500199 SCROLL FAN
50DK500235 50DK500235 SEAL DRAIN LINE
50DK500432 50DK500432 SEAL INDOOR COIL/PARTITI ON
50TM400279 50TM400279 SUPPLY COVER ASSEMBLY
HH18SA265 HH18SA265 SWITCH TEMPERATURE
HY11UC125 HY11UC125 TERMINAL BLOCK
HY84DA008 HY84DA008 TERMINAL BOARD
HK50AA051 HK50AA051 TERMINAL BOARD
50TM500359 50TM500359 TOP MOUNTING RAIL
50TM500352 50TM500352 TRACK SUPPORT
EC39EZ065 EC39EZ065 VALVE BODY
EA36UZ074 EA36UZ074 VALVE TXV
HY89TB014 HY89TB014 WIRE CONNECTOR
48TMHSRLM-1A00 48TMHSRLM-1A00 WIRE HARNESS CLO/COMP 1
48TMHSRLM-2A00 48TMHSRLM-2A00 WIRE HARNESS CLO/COMP 2
