Model Image
Manufacturer

Carrier

Model Number

59MN7A100V211120

Description

97% Carrier Modulating Infinity Series Gas Furnace

Interactive Exploded View

Parts List

Part Number Description
323751-702 323751-702 1.30MM GAS ORIFICE KIT
LA22ZA127 LA22ZA127 11X10 1/2-INCHBORE CW BLOWER WHEEL
338111-701 338111-701 44 FRAME INDUCER HARNESS
323691-401 323691-401 BLOWER CUTOFF
HR54ZA008 HR54ZA008 BLOWER DOOR SWITCH
338106-755-CBP 338106-755-CBP BLOWER HOUSING KIT
336807-706 336807-706 BLOWER SHELF ASSY
337552-701 337552-701 BLOWER WIRE HARNESS ASSY
336688-401 336688-401 BOX AUX J
336829-403 336829-403 BRACKET DOOR
336843-401 336843-401 BRACKET SWITCH
337564-401 337564-401 BRACKET, BLOWER MTG
336859-704 336859-704 BURNER ASSY SUPPORT
336842-754-CBP 336842-754-CBP BURNER KIT
323269-704 323269-704 BURNER ORIFICE FOR LP GAS
336772-756-CBP 336772-756-CBP CELL PANEL KIT
KGAHT0101CFP KGAHT0101CFP CONDENSATE FREEZE PROTECTION KIT
336836-751 336836-751 CONDENSATE TRAP KIT
KGAVT0701CVT KGAVT0701CVT DIFFUSER KIT
336835-402 336835-402 DRAIN PLUG
337691-751-CBP 337691-751-CBP DRAIN TUBE Z KIT
328988-403 328988-403 FILTER RETAINER 21 LONG
337932-703 337932-703 FITTINGS CONVERSION KIT
336819-405 336819-405 FRONT CELL PANEL GASKET
323269-703 323269-703 GAS ORIFICE KIT 7 SPUDS
EF34CW181 EF34CW181 GAS VALVE;
337563-401 337563-401 GASKET
336828-401 336828-401 GASKET PNL SUPPORT
337665-701 337665-701 HARNESS ASSY
347329-756 347329-756 HEAT EXCHANGER, PRIMARY
HH18HA495 HH18HA495 HI LIMIT
LH33ZG001 LH33ZG001 HOT SURFACE IGNITOR
336774-756-CBP 336774-756-CBP HX KIT CONDENSING
336771-756 336771-756 HX KIT PRIMARY
337679-401 337679-401 IGNITOR BRACKET
337554-401 337554-401 INDICATOR
337683-401 337683-401 INDUCER OUTLET CHOKE PLA
KGADC0101BVC KGADC0101BVC INTERNAL VENT KIT
338096-704 338096-704 LIMIT SWITCH
337668-701 337668-701 LOOSE PARTS BAG
323272-702 323272-702 LP BURNER ORIFICE #56
HK02LB008 HK02LB008 LP PRESSURE SWITCH
EF39ZW037 EF39ZW037 LP->NAT GAS CONVERSION KIT
337565-701 337565-701 MAIN HARNESS ASSY
336847-404 336847-404 MANIFOLD
HK70EZ068 HK70EZ068 MODEL PLUG
HK52EA123 HK52EA123 MOTOR CONTROLLER
327754-401 327754-401 MOTOR MOUNT KIT
336542-401 336542-401 MOUNTING BRKT
337684-701 337684-701 NAME PLATE
323267-702 323267-702 NAT BURNER ORIFICE #43
323267-703 323267-703 NAT BURNER ORIFICE (QTY-1)
323267-704 323267-704 NAT GAS BURNER ORIFICE 7 PACK
EF39ZW023 EF39ZW023 NATURAL TO LP GAS VALVE CONVERSION KIT
323267-701 323267-701 NATURALORIFICEFORMANIFOLD
327595-401 327595-401 NYLON HARNESS RETAINER CLIP
323269-701 323269-701 ORIFICE ON MANIFOLD KIT(QTY 1)
337673-703 337673-703 PANEL FILLER
338484-753 338484-753 PLUG BUTTON KIT
338484-752 338484-752 PLUG BUTTON KIT
338484-751 338484-751 PLUG BUTTON KIT
HT08AH115 HT08AH115 POWER CHOKE
336818-404 336818-404 REAR CELL PANEL GASKET
337690-401 337690-401 RUBBER ELBOW
337699-751-CBP 337699-751-CBP RUBBER PARTS KIT
338637-751 338637-751 SCREW 8-32 X 3/8 PACK/50
KGASB0201ALL KGASB0201ALL SUBBASE KIT FOR DOWNFLOW GAS FURNACE
337662-703 337662-703 SWITCH ASY PRESSURE;
661858 661858 TAUPE METALLIC TOUCH-UP PAINT
336846-703 336846-703 TOP PLATE ASSY
328270-409 328270-409 TUBE PRESSURE SWITCH
336820-401 336820-401 TURBULATOR
325531-403 325531-403 UNFRAMED 20 X 25-INCH MESH FILTER
337534-751 337534-751 VENT ELBOW KIT
