Model Image
Manufacturer

Carrier

Model Number

59SC5A080S171116

Description

95% Carrier Gas Furnace

Interactive Exploded View

Parts List

Part Number Description
323751-702 323751-702 1.30MM GAS ORIFICE KIT
LA22LA019 LA22LA019 1/2-INCHBORE CW 11 7/8-INCHDIA WHEEL
HC45TQ125 HC45TQ125 115V1PH3/4HP5SPEED 1075 RPM MOTOR
HH12HA142 HH12HA142 140F M/R LIMIT SWITCH
337938-774-CBP 337938-774-CBP 337938-774-CBP INDUCER ASSEMBLY
HR54ZA008 HR54ZA008 BLOWER DOOR SWITCH
338106-754-CBP 338106-754-CBP BLOWER HOUSING KIT
336807-704 336807-704 BLOWER SHELF ASSY
336688-401 336688-401 BOX AUX J
336843-401 336843-401 BRACKET SWITCH
337564-401 337564-401 BRACKET, BLOWER MTG
336842-753-CBP 336842-753-CBP BURNER KIT
323269-704 323269-704 BURNER ORIFICE FOR LP GAS
336859-703 336859-703 BURNER SUPPORT ASSY
HC91PD005 HC91PD005 CAPAC 5 MFD 250V RECTANGLE
KGAHT0101CFP KGAHT0101CFP CONDENSATE FREEZE PROTECTION KIT
336836-751 336836-751 CONDENSATE TRAP KIT
HK42FZ036 HK42FZ036 CONTROL BOARD
337533-752-CBP 337533-752-CBP COUPLING BOX KIT
KGAVT0701CVT KGAVT0701CVT DIFFUSER KIT
336829-402 336829-402 DOOR BRACKET
336835-402 336835-402 DRAIN PLUG
337691-751-CBP 337691-751-CBP DRAIN TUBE Z KIT
HK06NB020 HK06NB020 DUAL PRESSURE SWITCH FURNACE
337932-703 337932-703 FITTINGS CONVERSION KIT
336819-403 336819-403 FRONT CELL PANEL GASKET
323269-703 323269-703 GAS ORIFICE KIT 7 SPUDS
337563-401 337563-401 GASKET
336828-401 336828-401 GASKET PNL SUPPORT
327957-701 327957-701 HARNESS ASSY
336771-764 336771-764 HEAT EXCHANGER PRIMARY
HH18HA495 HH18HA495 HI LIMIT
LH33ZG001 LH33ZG001 HOT SURFACE IGNITOR
336774-754-CBP 336774-754-CBP HX KIT CONDENSING
337679-401 337679-401 IGNITOR BRACKET
337554-401 337554-401 INDICATOR
337682-401 337682-401 INDUCER INLET CHOKE PLAT
337683-401 337683-401 INDUCER OUTLET CHOKE PLA
KGADC0101BVC KGADC0101BVC INTERNAL VENT KIT
338096-702 338096-702 LIMIT SWITCH ASSEMBLY
312250-407 312250-407 LOGO BRAND
337668-701 337668-701 LOOSE PARTS BAG
323272-702 323272-702 LP BURNER ORIFICE #56
HK02LB008 HK02LB008 LP PRESSURE SWITCH
EF39ZW037 EF39ZW037 LP->NAT GAS CONVERSION KIT
336847-403 336847-403 MANIFOLD
327753-401 327753-401 MOTOR MOUNT KIT
336542-401 336542-401 MOUNTING BRKT
323267-702 323267-702 NAT BURNER ORIFICE #43
323267-703 323267-703 NAT BURNER ORIFICE (QTY-1)
323267-704 323267-704 NAT GAS BURNER ORIFICE 7 PACK
EF39ZW023 EF39ZW023 NATURAL TO LP GAS VALVE CONVERSION KIT
323267-701 323267-701 NATURALORIFICEFORMANIFOLD
327595-401 327595-401 NYLON HARNESS RETAINER CLIP
323269-701 323269-701 ORIFICE ON MANIFOLD KIT(QTY 1)
337673-702 337673-702 PANEL FILLER
LA660002 LA660002 PLASTIC WHEEL
336846-702 336846-702 PLATE ASSY TOP
338484-753 338484-753 PLUG BUTTON KIT
338484-752 338484-752 PLUG BUTTON KIT
338484-751 338484-751 PLUG BUTTON KIT
336818-403 336818-403 REAR CELL PANEL GASKET
337690-401 337690-401 RUBBER ELBOW
337699-751-CBP 337699-751-CBP RUBBER PARTS KIT
338637-751 338637-751 SCREW 8-32 X 3/8 PACK/50
337532-407 337532-407 STRIP SEAL
KGASB0201ALL KGASB0201ALL SUBBASE KIT FOR DOWNFLOW GAS FURNACE
661858 661858 TAUPE METALLIC TOUCH-UP PAINT
336820-401 336820-401 TURBULATOR
325531-402 325531-402 UNFRAMED FILTER
EF32CW213 EF32CW213 VALVE GAS;
337534-751 337534-751 VENT ELBOW KIT
338501-701 338501-701 WIRE HARNESS ASSEMBLY
