Manufacturer
Carrier
Model Number
CA13NA02400GBBAA
Description
Split System Outdoor Condensing Unit
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
18-INCHDIA 27DEG 1/2-INCH CW 3BLADE FAN |
|
|
208-230V1PH 1/10HP 1100RPM MTR |
|
|
24V 3/8-INCH SOLENOID VALVE |
|
|
2TON R410A 3/8XFLR TXV VALVE |
|
|
3 8 24V LIQUID LINE SOLENOID VALVE KIT |
|
|
610-420# PRESSURE SWITCH |
|
|
95-50# LOW PRESSURE SWITCH |
|
|
BASE PAN ASSEMBLY |
|
|
BODY COUPLING |
|
|
CARRIER KSALA0301410 LOW AMBIENT PRESSUR |
|
|
CESO130062-00 TIME DELAY RELAY |
|
|
CHECK VALVE |
|
|
CONDENSER COIL REPLACEMENT KIT |
|
|
CONTACTOR 1 POLE 40 AM |
|
|
CONTROL BOX |
|
|
COVER |
|
|
CRANKCASE HEATER |
|
|
CRANKCASE HEATER (018-036) |
|
|
FAN GUARD |
|
|
FLARE NUT |
|
|
GASKET |
|
|
GROMMET COMPRESSOR |
|
|
GROUND LUG |
|
|
HARD START KIT |
|
|
HIGH PRESSURE SWITCH |
|
|
HIGH PRESSURE SWITCH KIT |
|
|
INLET GRILLE |
|
|
LOW PRESSURE SWITCH KIT |
|
|
MOTOR REPLACES HC33GE235 |
|
|
MOTORMASTER LOW AMBIENT CONTROL |
|
|
PAINT |
|
|
PISTON |
|
|
RELAY TIME DELAY |
|
|
SCROLL COMPRESSOR |
|
|
START ASSIST |
|
|
STRAP |
|
|
STRAP DUAL CAPACITOR |
|
|
SUCTION LINE FILTER DRIER |
|
|
TIME DELAY; COMPRESSOR |
|
|
TOP COVER |
|
|
TXV KIT PURON 1.5 - 2.5 TON |
|
|
WINTER START CONTL-RESIDENTIAL |
|
|
WIRING HARNESS |
