Manufacturer
Carrier
Model Number
CA16NA04200GBABA
Description
3.5 Ton 16 Seer Residential Air Conditioner Conden
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
2 CAPS 1.18HEX |
|
|
208-230V 1/5HP 810RPM MOTOR |
|
|
3 8 24V LIQUID LINE SOLENOID VALVE KIT |
|
|
3 BLADE FAN PROPELLER |
|
|
610-420# PRESSURE SWITCH |
|
|
7/8-INCH SUCTION SERVICE VALVE |
|
|
95-50# LOW PRESSURE SWITCH |
|
|
BELT 6-7-INCH DIA 60-INCH LEADS HEATER |
|
|
BODY COUPLING |
|
|
CAP-STEM (LIQUID) 3/8-INCH |
|
|
CARRIER KSALA0301410 LOW AMBIENT PRESSUR |
|
|
CESO130062-00 TIME DELAY RELAY |
|
|
CHECK VALVE |
|
|
CLAMP 2 1/2-INCH OD |
|
|
COMPRESSOR PLUG |
|
|
CONTACTOR 1 POLE 40 AM |
|
|
CONTROL BOX |
|
|
COVER |
|
|
CRANKCASE HEATER |
|
|
EXPANSION VALVE |
|
|
FAN GUARD |
|
|
FILTER DRIER, SUCTION |
|
|
FLARE NUT |
|
|
GASKET |
|
|
GROMMET COMPRESSOR |
|
|
GROUND LUG |
|
|
HARD START KIT |
|
|
HIGH PRESSURE SWITCH |
|
|
HIGH PRESSURE SWITCH KIT |
|
|
KIT-REPLACEMENT COIL |
|
|
LIQUID LINE SERVICE VALVE |
|
|
LOW PRESSURE SWITCH KIT |
|
|
MOTORMASTER LOW AMBIENT CONTROL |
|
|
PAINT |
|
|
PISTON |
|
|
RELAY TIME DELAY |
|
|
START ASSIST |
|
|
STRAP |
|
|
TEMPERATURE LIMIT SWITCH |
|
|
TIME DELAY; COMPRESSOR |
|
|
TOP COVER ASSEMBLY |
|
|
TXV KIT PURON 4 TON |
|
|
VALVE-SOLENOID |
|
|
WINTER START CONTL-RESIDENTIAL |
|
|
WIRING HARNESS |
