Manufacturer
Carrier
Model Number
CA16NW06100GBAAA
Description
5 Ton, 16 Seer, Residential Air Conditioner Conden
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
2 CAPS 1.18HEX |
|
|
208-230V1PH 1/4HP 825 RPM MOTOR |
|
|
26-INCHDIA 29DEG 1/2-INCH CW 3BLD FAN |
|
|
3 8 24V LIQUID LINE SOLENOID VALVE KIT |
|
|
7/8-INCH SUCTION SERVICE VALVE |
|
|
95-50# LOW PRESSURE SWITCH |
|
|
BELT 6-7-INCH DIA 60-INCH LEADS HEATER |
|
|
CAP-STEM (LIQUID) 3/8-INCH |
|
|
CARRIER KSALA0301410 LOW AMBIENT PRESSUR |
|
|
CHECK VALVE |
|
|
CLAMP 2 1/2-INCH OD |
|
|
COMPRESSOR BLANKET |
|
|
CONDENSER MOTOR (208-230V, 1 PH, 1/4 HP, 825 RPM) |
|
|
CONTACTOR |
|
|
CONTROL BOX |
|
|
DEFROST STAT |
|
|
EXPANSION VALVE |
|
|
FAN BLADE |
|
|
FAN GUARD |
|
|
FILTER DRIER, SUCTION |
|
|
GRILLE INLET LRG BALTIC GRY |
|
|
GROMMET COMPRESSOR |
|
|
GROUND LUG |
|
|
HARD START KIT |
|
|
HIGH PRESSURE SWITCH KIT |
|
|
LIQUID LINE SERVICE VALVE |
|
|
LOW PRESSURE SWITCH KIT |
|
|
MOTOR FAN ECM |
|
|
MOTORMASTER LOW AMBIENT CONTROL |
|
|
PAINT |
|
|
R410A 4-5TON TXV KIT |
|
|
RELAY TIME DELAY |
|
|
REPLACEMENT COIL KIT |
|
|
SERVICE PANEL |
|
|
START ASSIST |
|
|
STRAP |
|
|
TEMPERATURE LIMIT SWITCH |
|
|
TOP COVER ASSEMBLY |
|
|
TXV KIT PURON 4 TON |
|
|
WINTER START CONTL-RESIDENTIAL |
|
|
WIRING HARNESS |
