Manufacturer
Carrier
Model Number
CH16NA04200GBAAA
Description
Split System Heat Pump, Carrier, 16 Seer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
1/2-INCHX7/8-INCHODF 24V REVERSING VALVE |
|
|
2 CAPS 1.18HEX |
|
|
24V SOLENOID COIL |
|
|
3/8-INCH LIQUID SERVICE VALVE |
|
|
55-23# LOW PRESSURE SWITCH |
|
|
6 PC SNOW STAND KIT |
|
|
7/8-INCH SUCTION SERVICE VALVE |
|
|
ACCUMULATOR 7/8-INCH 174CI |
|
|
ADAPTER ASSEMBLY |
|
|
BOARD CONTROL DEFROST |
|
|
CAP-STEM (LIQUID) 3/8-INCH |
|
|
CAPILLARY ASSY |
|
|
CARRIER KSALA0301410 LOW AMBIENT PRESSUR |
|
|
CHECK VALVE |
|
|
CHECK VALVE |
|
|
CLAMP 2 1/2-INCH OD |
|
|
COMPRESSOR BLANKET |
|
|
CONDENSER FAN MOTOR |
|
|
CONTACTOR 1 POLE 40 AM |
|
|
CONTROL BOX |
|
|
CONTROL BOX COVER KIT |
|
|
CRANKCASE HEATER |
|
|
DEFROST STAT |
|
|
FAN GUARD |
|
|
FAN PROP |
|
|
FILTER DRIER SUCTION |
|
|
GRILLE INLET |
|
|
GROMMET |
|
|
GROUND LUG |
|
|
ISOLATION RELAY |
|
|
LIQUID LINE SOLENOID VALVE KIT |
|
|
MOTORMASTER LOW AMBIENT CONTROL |
|
|
MUFFLER |
|
|
PAINT |
|
|
PISTON |
|
|
PISTON SERVICE TOOL |
|
|
RELAY |
|
|
RELAY TIME DELAY |
|
|
RVS PLUG HARNESS ASSEMBLY |
|
|
SCHRAEDER VALVE CORE |
|
|
START ASSIST |
|
|
TEMPERATURE ACTIVATION SWITCH-DEF SENSOR |
|
|
TOP COVER ASSEMBLY |
|
|
TX VALVE VALVE KIT |
|
|
WIRE HARNESS |
