Manufacturer
International Comfort Products
Model Number
PHR530000KTP0A1
Description
Quietcomfort 15 Packaged Heat Pump
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1174937 | ACCUMULATOR 174 3/4 5-INCH DIA. |
| 1179562 | BASE PAN CONDENSER SML |
| 1178014 | BASE RAIL |
| 1178013 | BASE RAIL |
| 1178012 | BASE RAIL |
| 1185790 | BOARD CONTROL |
| 1185866 | BOARD INDOOR FAN CONTROL |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1186123 | COIL ASSEMBLY CONDENSER FRMD AL/CU RT |
| 1186122 | COIL ASSEMBLY CONDENSER FRMD AL/CU RT |
| 1178749 | COIL ASSEMBLY EVAPORATOR TIN PLT |
| 1173453 | COIL SOLENOID 120V |
| 1172472 | CONTACTOR |
| 1173177 | CORE VALVE |
| 1176139 | COVER |
| 1175990 | COVER ASSEMBLY DUCT |
| 1186208 | FAN PROP |
| 1172311 | FILTER DRIER |
| 1178437 | GRILLE ASSEMBLY; 18 IN. FR/RT HG |
| 1178440 | GRILLE ASSEMBLY; 18 IN. SM BK HG |
| 1178446 | GRILLE ASSEMBLY; 18 IN. SM LF HG |
| 1178443 | GRILLE ASSEMBLY; 18 IN. SM RT HG |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1184078 | HEATER CC WP 40W 240V CH268 |
| 1178010 | INSUL ASSEMBLY BLOWER PANEL |
| 1178739 | INSUL ASSEMBLY COIL PARTITION SM |
| 1178737 | INSUL ASSEMBLY COIL PARTITION SM |
| 1178020 | INSUL ASSEMBLY ELEC PANEL |
| 1178959 | INSUL ASSEMBLY PANEL COIL SMALL |
| 1178958 | INSUL ASSEMBLY PANEL DUCT SMALL |
| 1178914 | INSUL ASSEMBLY SIDE PANEL SM |
| 1175988 | INSUL ASSEMBLY TOP EVAP |
| 1176140 | INSUL CONTROL PLATE |
| 1175958 | KIT BLW MTR MTG |
| 1172300 | LUG GROUND |
| 1173717 | MOTOR 1/8HP 1 PH, CONDENSER |
| 1185670 | MOTOR BLOWER 1/2 HP |
| 1178011 | OUTLET GRILLE |
| 1178008 | PANEL COMP ACCESS SML |
| 1177347 | PANEL CORNER 18-INCH COND |
| 1177348 | PANEL CORNER 18-INCH HDR |
| 1186205 | PISTON |
| 1178015 | PLATE ASSEMBLY FAN |
| 1176143 | PLATE CONTROL |
| 1178017 | PLATE FAN |
| 1177316 | PLUG ASSEMBLY COMP SOL COIL 51-INCH LDS |
| 1177318 | PLUG COMP |
| 1178424 | RACEWAY OFM 13-INCH |
| 1176010 | SCROLL |
| 1178677 | SWITCH TEMP |
| 1173669 | SWITCH TEMP ACT |
| 1174407 | SWITCH,PRESS HI |
| 1174412 | SWITCH,PRESS LO |
| 1178005 | TOP COVER SML |
| 1171496 | TRANSFORMER |
| 1173715 | VALVE REVERSING |
| 1176869 | VALVE TXV 3.0 TON R410A |
