Model Image
Manufacturer

Dacor

Model Number

ECS127SBK

Description

Ecs127sbk - Ovens

Interactive Exploded View

Parts List

Part Number Description
82195 1 2FLEX 90 DGR CONNECTOR;82195,DO130
83340 83340 10 LOCKWASHER;83340,DHD30M967WM
80518 16GA GALVANIZED, STE
80280 18 GA GALVANNEALED S
80517 18GA GALVANIZED, 48"
80509 18GA.VIT,52.5"X96"ST
80522 20 GA 201 SS, 48"X96
80074 20 GA GALVANIZED,48"
80516 20 GA GALVANIZED;80516,"48""X96""",D
80275 20 GA GALVANNEALED S
80550 20 GA,GALVANIZED STE
80139 20GA X 24 375 X 30 575 S;80139,ECD22
80508 22GA VIT STEEL 48X96;80508,DO130
80551 24 GA GALVANIZED STE
80520 24GA 201 SS #4,48X96
83308 6 32 KEPS NUT;83308,DH3006
100852 100852 ACCY SS CLEANER;100852,DCT305B/LP
80434 ALUMINIZED,18 GA, 48
27599 ASY CASE SIDE LEFT;27599,DO130
27600 ASY CASE SIDE RIGHT;27600,DO130
27123S ASY END CAP SST;27123S,ECD227SBK
27595 ASY EXHAUST TUBE SHIELD;27595,ECD227
27727BP ASY INNER LINER 27DOOR;27727BP,ECD22
27126 ASY SUB PANEL 27;27126,ECD227B
27589 ASY SUBCHASSIS 27 OVEN;27589,ECD227B
72148 ASY WINDOW PACK 1THK;72148,DO130
13388S ASY, BEZEL/MEM, ECS127
62721 ASY, WIRE HARNESS,SINGLE
27612B ASY,DOOR FRAME,EC27
36486BP BAFFLE CONVECTION 27OVE;36486BP,ECD2
78945 BAFFLE LFT TRANSITN DUC;78945,ECD227
62636 62636 BAKE ELEMENT 27 OVEN;62636,ECD227B
83540 BALL STUD CATCH;83540,DO130
83539 BALL STUD TRIM PANEL;83539,DO130
26615 BEZEL MTG BRKT LEFT;26615,DO130
26614 BEZEL MTG BRKT RIGHT;26614,DO130
26712B BEZEL TRIM - BLK
106009 BLACK PORCELAIN, DRY
106007 BLACK PORCELAIN, WET
36276 BRACKET HIGH LIMIT SWITC;36276,DO130
38230 BRACKET,INNER LINER
62723 62723 BROIL ELEMENT 8 PASS;62723,ECD227B
36509 BROIL REFLECTOR,FLAT
12530 BROILER PACKAGE OVENS;12530,DR30EFS
83133 BUSHING 1 2 RED CONDUI;83133,DO130
83523 BUSHING 3 8 HOLE;83523,DOP36M86DAM
83056 BUSHING HEYCO SB 875 11;83056,DH3006
83167 CABLE CLAMP CPS127;83167,DH3006
83565 CABLE TIE,NYLON,11" LONG
81086 CARTON, ACCESSORIES
36281 CASE BACK 27 OVEN;36281,ECD227B
26597 CASE BOTTOM;26597,ECD227B
38060 CASE SIDE LEFT;38060,DO130
38061 CASE SIDE RIGHT;38061,DO130
78921 CLIP, INNER LINER
83543 83543 CLOSED END SPLICE 22 14G;83543,ECD22
83152 COIN ENVELOPE S-6285
26420 CONDUIT 1 2 FLEX CUT 60;26420,DO130
26584 CONDUIT BRKT
82377 CONVECTION ELEMENT 240V;82377,DO130
101511 CONVECTION FAN BLADE;101511,DO130
82647 CONVECTION OVEN MOTOR;82647,DO130
82986 COOLING FAN CPO;82986,DO130
78991 CORNER BRKT,DOOR FRM
36279 COVER MEAT PROBE SOCKET;36279,DO130
72510CH DACOR LOGO SMALL;72510CH,DCT305B/LP
72016 DOOR GASKET;72016,ECD227B
82693B DOOR GLASS, 27" CP - BLK
100090 DOOR LATCH,CLASSIC
36337 DOOR VENT,EC27
62691BK END CAP EPICURE HANDLE;62691BK,ECD22
82990S EXHAUST GRILL 27OVEN;82990S,ECD227SB
26602 EXHAUST PLATE BTM;26602,ECD227B
82240 EXHAUST TUBE
83555 FIBER WASHER W ADHESIVE;83555,DO130
82891 82891 FILTER CONVECTION OVEN;82891,DO130
72767 GLIDE RACK 27OVEN;72767,ECD227B
62175 62175 HALOGEN LIGHT,10W,12VDC
36619 HEAT SHIELD 27DOOR;36619,ECD227B
36621B HEAT SHIELD 27SS DOOR B;36621B,ECD22
36105 HEAT SHIELD OVEN LIGHT;36105,ECD227B
102137 HEX NUT CONVECTION FAN E;102137,DO13
36833B HI LIMIT BRACKET BLK;36833B,ECD227B
62775 62775 HIGH LIMIT SWITCH 220F;62775,DO130
82508 HINGE EPICURE DOOR GOLD;82508,DO130
81073 INNER DOOR PROTECTOR
81238 INSERT, DOOR HANDLE
80212 INSULATION 27OUTER LINE;80212,ECD227
80161 INSULATION CELL SIDE;80161,DO130
80168 INSULATION CONV MTR;80168,DO130
80206 INSULATION DOOR;80206,ECD227B
36830B INTAKE GRILL BLK PNT;36830B,ECD227B
85136 LABEL, "MADE WITH PRIDE"
85249 LABEL,"DIELECTRIC TE
85648 LABEL,EXTRU CONTAINER,CP
26598 LATCH PLATE;26598,DO130
36309 LIGHT COVER;36309,ECD227B
72171 MEAT PROBE RECEPT W COVE;72171,ECD22
62713 62713 MEAT PROBE;62713,ECD227B
62682B 62682B MEMBRANE SW PANEL
81070 MICROFOAM,12"X6"X.06 THK
36280 MOUNTING PLATE;36280,ERSD36S
82873 NAMEPLATE SELF CLEAN INF;82873,DO130
83009 NUT KEPS;83009,#10-24,DO130
83418 83418 NUT RETAINER;83418,DO130
27425BP OUTER LINER 27 DOOR BL;27425BP,ECD22
62964 OVEN CONTROL,SNGL
62137 OVEN RACK 27EPICURE CON;62137,ECD227
83538 83538 PCB SUPPORT NYLON;83538,DHD30M967WM
82106 PORCELAIN GRILL;82106,DR30EFS
82107 PORCELAIN PAN;82107,DR30EFS
12157 12157 RANGE BROIL TRAY ASSY;12157,DR30EFS
82851 RECEPTACLE,HINGE
92028 92028 RELAY PCB 105C;92028,ECS127B
83652 83652 RIVET SS;83652,1/8X1/8,DH3006
83618 RUBBER BUMPER;83618,DO130
83553 SCREW HINGE SOCKET HD CP;83553,DO130
83379 SCREW HWH;83379,"#8X1/2,TYPEA",DO130
83331 SCREW PHIL FLAT;83331,#6 X 3/4,DO130
83042 SCREW PHIL PAN;83042,#8 X 5/8,DOP48M
83263 SCREW PHIL WAFER;83263,#8X3/8,DCT305
83023 83023 SCREW SLOT;83023,#10 X 3/8HWH,DO130
83534 83534 SCREW WAFER HD;83534,#8 X 3/8,DH3006
83571 SCREW,PHILLIPS HD #8X3/8
83026 SCREW;83026,#10 X 3/4 SLOT HWH,DO130
83499 SCREW;83499,"#10 X 1/2,PHIL BLK",DO1
83690 SCREW;83690,"#4-40X5/16,#410 S",ECD2
36318 SERVICE PANEL TOP COVER;36318,DO130
36617 SIDE SHIELD LEFT;36617,DO130
36618 SIDE SHIELD RIGHT;36618,DO130
82826 SMOKE ELIMINATOR
62714 SOCKET MEAT PROBE;62714,ECD227B
83189 SPACER 138 IDX 25 OD;83189,DO130
78963 SPILL RAIL, DOOR
26707 STAINLESS BEZEL SKIN;26707,ECD227SBK
26606 STIFFENER BRACKET
82650 SUPPORT RACK-BLK PORCLN
103740 TAPE DBL SIDE;103740,1/2WX.031,DO130
103637 TAPE DBL SIDED 031THK;103637,DO130
83452 TAPE DBL SIDED 3M 4920;83452,E30DD75
62593 62593 TEMPERATURE SENSOR;62593,E30DF74EPS
83037 TIE PUSH MOUNT LOCKING;83037,DH3006
26600 TOP COVER REAR;26600,ECD227B
36311 TOP COVER, FRONT, 27"
62808 62808 TRANSFORMER HALOGEN LIGH;62808,DO130
26371 TRIM DOOR EDGE RIGHT;26371,ECD227SB
27665B TRIM POST LFT SNGL BLK;27665B,DO130
27664B TRIM POST RIGHT SNGL BLK;27664B,DO13
26370 TRIM, DOOR EDGE - LEFT
102136 WASHER CONVECTION FAN E;102136,DO130
36377BP WINDOW MASK BLK PORC;36377BP,ECD227B
82445 WIRE HARNESS MAIN 27CP;82445,ECD227B
