Manufacturer
Dacor
Model Number
EGR30S06BR
Description
Egr30s06br - Ranges
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
10 LOCKWASHER;83340,DHD30M967WM |
| 80518 | 16GA GALVANIZED, STE |
| 80532 | 18 GA 201SST #4 48"X |
| 80208 | 18 GA GALVANIZED STE |
| 80517 | 18GA GALVANIZED, 48" |
| 80509 | 18GA.VIT,52.5"X96"ST |
| 80310 | 20 GA 201 SS, 36"X10 |
| 80522 | 20 GA 201 SS, 48"X96 |
| 80074 | 20 GA GALVANIZED,48" |
| 80516 | 20 GA GALVANIZED;80516,"48""X96""",D |
| 80550 | 20 GA,GALVANIZED STE |
| 80508 | 22GA VIT STEEL 48X96;80508,DO130 |
| 80510 | 22GA.ALUMINIZED STL. |
| 80551 | 24 GA GALVANIZED STE |
| 80013 | 24GA 201 S/S#4 24X32 |
| 80520 | 24GA 201 SS #4,48X96 |
| 72588 | 3 8 TUBE BROIL;72588,EGR30S06BK |
| 72587 | 3 8 TUBE REGULATOR;72587,EGR30S06BK |
| 72586 | 3/8 TUBE,BAKE |
| 72589 | 5 8 TUBE MANIFOLD;72589,EGR30S06BK |
| 83308 | 6 32 KEPS NUT;83308,DH3006 |
|
|
ACCY SS CLEANER;100852,DCT305B/LP |
| 62002 | ADAPTOR, 1/2 MNPT TO 3/8 |
| 36624BP | AIR SHIELD BROILER BLK P;36624BP,EGR |
| 36624 | AIR SHIELD BROILER;36624,EGR30S06BK |
| 80434 | ALUMINIZED,18 GA, 48 |
| 36471B | ANGLE RR SPILL TRAY PAIN;36471B,EGR3 |
| 36245 | ANGLE SIDE SUPPORT RH;36245,E30DF74E |
| 36528BP | ANGLE SPILL TRAY SUPPORT;36528BP,E30 |
| 27646 | ASY AIR BAFFLE;27646,EGR30S06BK |
| 27575 | ASY CASE SIDE LH;27575,EGR30S06BK |
| 27574 | ASY CASE SIDE RH;27574,EGR30S06BK |
| 62954 | ASY DBURNER HEAD;62954,EGR30S06BK |
| 27728BP | ASY INNER LINER 30DOOR;27728BP,DO130 |
| 72005 | ASY IR NG SL ORIFICE;72005,EGR30S06B |
| 27121 | ASY OVEN BOTTOM PAN;27121,EGR30S06BK |
| 72148 | ASY WINDOW PACK 1THK;72148,DO130 |
| 13407SBR | ASY, HANDLE, EC30 SST/BR |
| 27687 | ASY, SIDE SUPPORT-RH |
| 13468 | ASY,BACKSPLASH,ERG30 |
| 27613B | ASY,DOOR FRAME,EC30 |
| 12422 | ASY-INFRARED BURNER |
| 36415 | BACK COVER CHASSIS;36415,E30DF74EPS |
| 36907 | BACK COVER;36907,EGR30S06BK |
| 72599 | BAKE ORIFICE FITTING NG;72599,EGR30S |
| 26239 | BASE BACK COVER;26239,E30DF74EPS |
|
|
BASE BURNER W TUBE;62325,E30DF74EPS |
| 106009 | BLACK PORCELAIN, DRY |
| 106007 | BLACK PORCELAIN, WET |
|
|
BRACKET ANTI TIP RANGE;26041,E30DF74 |
| 36922 | BRACKET BACK COVER;36922,E30DF74EPS |
| 26217 | BRACKET BAKE BURNER HOO;26217,EGR30S |
| 36921 | BRACKET COOLING FAN;36921,EGR30S06BK |
| 36900 | BRACKET FLUE DUCT SEAL;36900,EGR30S0 |
| 26477 | BRACKET KICK PANEL;26477,EGR30S06BK |
| 26477B | BRACKET KICKPANEL BLK;26477B,EGR30S |
| 36431 | BRACKET MTG TRANSFORM FA;36431,EGR30 |
| 36916 | BRACKET REGULATOR;36916,E30DF74EPS |
| 36286 | BRACKET, IGNITOR MTG |
| 26404 | BRACKET, TUBULAR BURNER |
| 26184 | BRACKET, VENT DUCT |
| 36166 | BRACKET,IGNITOR RSG30 |
| 38230 | BRACKET,INNER LINER |
|
|
BRASS NUT CB HEAD;86405,DTCT304GB/LP |
| 26536 | BRKT CELL BOTTOM SUPPOR;26536,EGR30S |
| 26183 | BRKT KICKPANEL SUPPT L;26183,EGR30S |
| 36530 | BULLNOSE |
| 82564 | BURNER RING D BURNER;82564,EGR30S06B |
|
|
BURNER TUBE #1,NG/SL |
| 105627 | BURNER TUBE ELBOW;105627,E30DF74EPS |
|
|
BURNER TUBE;62645,"#2 3,NG/SL",EGR30 |
| 62646 | BURNER TUBE;62646,"#4,NG/SL",EGR30S0 |
|
|
BURNER TUBULAR;82431,EGR30S06BK |
| 83141 | BUSHING STRAIN RELIEF;83141,DCT305B/ |
| 86373 | C AIR SHUTTER;86373,DTCT304GB/LP |
| 83565 | CABLE TIE,NYLON,11" LONG |
| 62058 | CAP 3 8 RSD;62058,EGR30S06BK |
| 81086 | CARTON, ACCESSORIES |
| 36324 | CASE BACK PGR30;36324,EGR30S06BK |
| 26533 | CASE BOTTOM |
| 26127 | CASE BOTTOM COVER;26127,EGR30S06BK |
| 36903 | CASE TOP FRONT;36903,EGR30S06BK |
| 36904 | CASE TOP REAR;36904,EGR30S06BK |
| 36474 | CHASSIS BOX;36474,E30DF74EPS |
| 36897 | CHASSIS TOP;36897,EGR30S06BK |
| 78921 | CLIP, INNER LINER |
| 83152 | COIN ENVELOPE S-6285 |
| 76034 | CONE DOUBLE SGM365E;76034,E30DF74EPS |
| 105538 | CONNECTOR SGM;105538,EGR30S06BK |
| 105608 | CONNECTOR;105608,EGR30S06BK |
|
|
CONTROL PANEL - ETCHED |
| 36951BP | CONVECTION BAFFLE BLK PR;36951BP,EGR |
| 36539BP | CONVECTION BAFFLE TOP;36539BP,EGR30S |
| 101511 | CONVECTION FAN BLADE;101511,DO130 |
| 82647 | CONVECTION OVEN MOTOR;82647,DO130 |
| 78991 | CORNER BRKT,DOOR FRM |
| 81266 | CORNER POST, 3 X 3X.400X |
| 36917 | COVER ERC WIRE;36917,EGR30S06BK |
| 36255 | COVER HALOGEN LIGHT;36255,EGR30S06BK |
| 26560 | COVER PLATE,LIGHT,CP |
| 86918 | D BURNER RING SNGL 5 FG;86918,DTCT30 |
| 72511BR | DACOR LOGO,LARGE |
|
|
DOOR GASKET;72020,DO130 |
| 82216B | DOOR GLASS - BLK |
| 82834 | DOOR LATCH MECHANISM;82834,E30DF74EP |
| 36338 | DOOR VENT EC30;36338,ECD230SBK |
| 105559 | DOUBLE CONE;105559,DR30GFS/LP |
| 105604 | ELECTRODE, BURNER HE |
| 62712BR | END CAP BULL NOSE BRASS;62712BR,EGR3 |
| 62712 | END CAP BULL NOSE;62712,EGR30S06BK |
| 62691BR | END CAP EPICURE HANDLE;62691BR,ECS13 |
| 36911 | EXHAUST DUCT BACK;36911,EGR30S06BK |
| 82229S | EXHAUST GRILL;82229S,E30DF74EPS |
| 36865 | EXHAUST PLATE;36865,E30DF74EPS |
| 82347 | FAN COOLING 110 CFM;82347,DR30D-C/LP |
|
|
FILTER CONVECTION OVEN;82891,DO130 |
| 72915 | GLIDE RACK 30OVEN;72915,ECD230SBK |
| 72434SB | GRATE PACK,14" GRATES |
| 62296 | GRIDDLE |
| 83058 | GROMMET, EPDM RUBBER |
| 62209 | HANDLE 30 S S;62209,ECD230SBK |
| 36956B | HEAT SHIELD 30 DOOR;36956B,EGR30S06B |
| 36147 | HEAT SHIELD MANIFOLD;36147,EGR30S06B |
| 102137 | HEX NUT CONVECTION FAN E;102137,DO13 |
| 82508 | HINGE EPICURE DOOR GOLD;82508,DO130 |
| 83209 | HOOK LOOP PAIR 2 X 3;83209,DR30GFS/L |
| 82473 | HOT SURFACE IGNITER;82473,DR30GFS/LP |
| 62933 | IGNITOR WIRE JACKET;62933,DTCT304GB/ |
|
|
INDICATOR LIGHT BLUE NEO;82086,EGR30 |
| 81073 | INNER DOOR PROTECTOR |
| 81238 | INSERT, DOOR HANDLE |
| 80166 | INSULATION CELL BACK 30;80166,E30DF7 |
| 80174 | INSULATION CELL BOTTOM;80174,EGR30S0 |
| 80176 | INSULATION CELL BOTTOM;80176,EGR30S0 |
| 80161 | INSULATION CELL SIDE;80161,DO130 |
| 80169 | INSULATION CELL TOP 1;80169,EGR30S06 |
| 80180 | INSULATION CELL TOP SID;80180,EGR30S |
| 80094 | INSULATION CELL TOP;80094,EGR30S06BK |
| 80207 | INSULATION DOOR;80207,DO130 |
| 80179 | INSULATION VENT RISER;80179,EGR30S06 |
| 80095 | INSULATION VENTURI;80095,EGR30S06BK |
| 80177 | INSULATION, CELL BOTTOM- |
| 80213 | INSULATION,30"OUTER LINE |
| 80096 | INSULATION,VENT RISER |
| 36901 | INTAKE GRILL |
| 36540 | IR AIR ASSISTANT BOX;36540,EGR30S06B |
| 36426 | ISLAND TRIM, ERD/ERG30 |
| 36910 | KICK PANEL |
| 62021B | KNOB, EPICURE |
| 85136 | LABEL, "MADE WITH PRIDE" |
| 85249 | LABEL,"DIELECTRIC TE |
| 85648 | LABEL,EXTRU CONTAINER,CP |
| 26598 | LATCH PLATE;26598,DO130 |
|
|
LEVELER;83359,1/2-13 X 2-1/2,DR30EFS |
| 36918 | LINER KICK PANEL;36918,EGR30S06BK |
| 83440 | LOCKNUT 3 8 NPT;83440,EGR30S06BK |
| 72427-171 | MAIN JET,1.71 MM,NG SL |
| 62671 | MANIFOLD W VALVE NG SL;62671,EGR30S0 |
| 62802 | MEMBRANE ERG30/36 |
| 81070 | MICROFOAM,12"X6"X.06 THK |
| 36280 | MOUNTING PLATE;36280,ERSD36S |
| 82873 | NAMEPLATE SELF CLEAN INF;82873,DO130 |
|
|
NUT ACORN CAP 8 32 S S;83287,EGR30S0 |
| 76033 | NUT COMPRESSION;76033,E30DF74EPS |
| 105558 | NUT REGULATOR;105558,EGR30S06BK |
|
|
NUT RETAINER;83418,DO130 |
| 83192 | NUT,HEX,8-32 KEPS-SST |
|
|
O RING D BURNER;86395,DTCT304GB/LP |
| 86936 | O-RING, ELECTRODE |
| 27460BP | OUTER LINER ASY 30 BLK;27460BP,ECD23 |
| 27602BP | OVEN CELL BLK PORC;27602BP,EGR30S06B |
| 26449BP | OVEN CELL BOTTOM-BLK POR |
|
|
OVEN CONTROL PGR;62789,EGR30S06BK |
|
|
OVEN RACKS 30;62139,ECD230SBK |
| 26900 | PALLET ANGLE;26900,E30DF74EPS |
| 62592 | PLASTIC SPATULA W/ LOGO |
| 82106 | PORCELAIN GRILL;82106,DR30EFS |
| 82107 | PORCELAIN PAN;82107,DR30EFS |
| 72129 | POWER SUPPLY CORD;72129,"W/3 LOOPS, |
| 62747 | RACK SUPPORT 5 LH;62747,EGR30S06BK |
| 62748 | RACK SUPPORT 5 RH;62748,EGR30S06BK |
|
|
RANGE BROIL TRAY ASSY;12157,DR30EFS |
| 36496 | REAR PANEL;36496,E30DF74EPS |
| 82851 | RECEPTACLE,HINGE |
|
|
REDUCER BUSHING;83458,DCT305B/LP |
| 26441 | REFLECTOR, BAKE BURNER |
|
|
RELAY BOARD, 105C |
| 105588 | RETAINER RING, ELECT |
| 83618 | RUBBER BUMPER;83618,DO130 |
| 83553 | SCREW HINGE SOCKET HD CP;83553,DO130 |
| 83379 | SCREW HWH;83379,"#8X1/2,TYPEA",DO130 |
| 83358 | SCREW PAN HD;83358,8-32 X 3/8,DWD30S |
| 83010 | SCREW PHIL PAN;83010,#8 X 3/4,DTCT30 |
| 83336 | SCREW PHIL PAN;83336,#8-32X1/2,DR30G |
| 83024 | SCREW PHIL TRS;83024,#8 X 3/8,DR30EF |
| 83263 | SCREW PHIL WAFER;83263,#8X3/8,DCT305 |
| 83300 | SCREW PHIL;83300,8-32 X 1/4,EGR30S06 |
| 83019 | SCREW SLOT HWH;83019,#8 X 3/8,DYRP36 |
|
|
SCREW SLOT;83023,#10 X 3/8HWH,DO130 |
|
|
SCREW WAFER HD;83534,#8 X 3/8,DH3006 |
| 83204 | SCREW WELD;83204,"8-32X3/8,SST",DH30 |
| 83137 | SCREW,WELD,#8-32 X1/2,ST |
| 83690 | SCREW;83690,"#4-40X5/16,#410 S",ECD2 |
| 36360 | SHIELD CELL BOTTOM;36360,EGR30S06BK |
| 36899 | SHIELD FLUE DUCT;36899,EGR30S06BK |
| 36737 | SHIELD IGN MTG BRACKET;36737,EGR30S0 |
| 36737BP | SHIELD IGN MTG BRACKET;36737BP,EGR30 |
| 36391BP | SHIELD IGNITOR WIRES;36391BP,EGR30S0 |
| 36679BP | SHIELD KICK PANEL BLK PN;36679BP,E30 |
| 36320BP | SHIELD VENTURI BP;36320BP,EGR30S06BK |
| 36906 | SIDE PANEL LH;36906,EGR30S06BK |
| 36905 | SIDE PANEL,RH |
| 36504 | SIDE SUPPORT LH |
| 38182 | SIDE SUPPORT RH;38182,EGR30S06BK |
| 105541 | SLEEVING TUBE, FIBER |
| 83189 | SPACER 138 IDX 25 OD;83189,DO130 |
| 36275 | SPACER HI LIMITS;36275,EGR30S06BK |
| 82316 | SPARK MODULE, 4 POIN |
| 78963 | SPILL RAIL, DOOR |
| 36896BP | SPILL TRAY,BLK PORC |
| 105584 | SPRING ELECTRODE BURNER;105584,DTCT3 |
| 27048 | STIFFENER ASY BASE RANG;27048,E30DF7 |
| 36266 | SUBPANEL,ERSD30S06 |
| 36902 | SUPPORT RELAY BOARD;36902,EGR30S06BK |
| 36529B | SUPPORT SPILL TRAY FRONT;36529B,EGR3 |
| 83452 | TAPE DBL SIDED 3M 4920;83452,E30DD75 |
| 92387 | TAPE VHB DOUBLE SIDED;92387,DH3006 |
|
|
TEMPERATURE SENSOR;62593,E30DF74EPS |
|
|
THERMAL SW HI TEMP CUTOU;82987,DR30D |
| 83037 | TIE PUSH MOUNT LOCKING;83037,DH3006 |
| 26594 | TRIM COLLAR, VENT DUCT |
| 26371 | TRIM DOOR EDGE RIGHT;26371,ECD227SB |
| 36908 | TRIM POST LH SS;36908,EGR30S06BK |
| 36909 | TRIM POST RH SS;36909,EGR30S06BK |
| 62020BR | TRIM RING EPICURE BRASS;62020BR,EGR3 |
| 26370 | TRIM, DOOR EDGE - LEFT |
| 26831 | TRIM,SIDE TOP,LEFT |
| 26791 | TRIM,SIDE TOP,RIGHT |
| 82429 | VALVE THERMAL DUAL;82429,EGR30S06BK |
| 36895BP | VENT CAP BLK PORC;36895BP,EGR30S06BK |
| 62834 | W C REGULATOR NG;62834,"5/10""",DCT3 |
| 102136 | WASHER CONVECTION FAN E;102136,DO130 |
| 83098 | WASHER FLT;83098,875X1 50X 05,E30DF7 |
| 83369 | WELD NUT, 1/2 - 13 |
| 27879 | WELD VENT DUCT;27879,EGR30S06BK |
| 27820 | WELD,BASE |
| 72585 | WIRE HARNESS |
| 82032K | WOK RING KIT;82032K,EGR30S06BK |
