Manufacturer
Dacor
Model Number
EOG52
Description
Out Door Grill
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 72436SB | 14-INCHES SIDE BURNER GRATE |
| 72384 | 3/8 TUBE, FRONT |
| 72654 | 3/8-INCHES TUBE, VALVE REAR |
| 72511CH | 4 1/2 DACOR LOGO |
| 66323 | 4 AMP FUSE |
| 83308 | 6-32 KEPS NUT |
|
|
ACORN NUT 8-32 |
| 83539 | BALL STUD, TRIM PANEL |
| 36365 | BRACKET, TERM BLOCK |
| 72388LPHA | BROIL JET ASSEMBLY. NG SL |
| 72388LPSL | BROIL JET ASSEMBLY. NG SL |
| 2388NGHA | BROIL JET ASSEMBLY. NG SL |
| 72388NGSL | BROIL JET ASSEMBLY. NG SL |
| 72649NGHA | BURNER BASE |
| 72649NGSL | BURNER BASE |
| 72649LPHA | BURNER BASE |
| 72649LPSL | BURNER BASE |
| 72231 | BURNER CAP |
| 72232 | BURNER HEAD |
| 27730 | CANOPY |
| 72158 | CANOPY ARM |
| 38351 | CANOPY FRAME |
| 36696 | CASE SIDE, LEFT |
| 36695 | CASE SIDE, RIGHT |
| 66561NGHA | CENTER GRILL BURNER VALVE |
| 66561NGSL | CENTER GRILL BURNER VALVE |
| 66561LPHA | CENTER GRILL BURNER VALVE |
| 66561LPSL | CENTER GRILL BURNER VALVE |
| 27627 | CHASSIS BOTTOM |
| 38276 | CHASSIS BOTTOM, 52-INCHES |
| 36637 | CHASSIS REAR, 36-INCHES |
| 36549 | CHASSIS SIDE, |
| 36810 | CHASSIS SIDE, RH |
| 27746E | CONTROL PANEL |
| 36625 | CONTROL PLENUM |
| 13541 | CONTROL SUB-PANEL |
| 27637 | COVER, SIDE BURNER |
| 72178 | END CAP, HANDLE |
| 27735 | FIREBOX BACK |
| 27915 | FIREBOX BOTTOM |
| 36676 | FIREBOX LAMP HOUSING |
| 36630 | FIREBOX SIDE RIGHT |
| 36650 | FIREBOX SIDE, LEFT |
| 36629BP | FIREBOX TOP, PORCELAIN |
| 36628 | FLAME SPREADER, LARGE |
| 36661 | FLAME SPREADER, SMALL |
| 100669 | FRONT FRAME FIREBOX |
| 36627 | FRONT TRIM, 36-INCHES |
| 66324 | FUSE HOLDER |
| 27732 | GREASE TRAY EDGE |
| 36626 | GREASE TRAY FACIA |
| 72177 | GRILL, 5 1/2-INCHES, SS |
| 72157 | GRILL, SS, 11-INCHES |
| 72175 | HANDLE, CANOPY |
| 72360 | HANDLE, GREASE TRAY |
| 36674 | HINGE BRACKET, RH |
| 83459 | HINGE PIVOT, 3/8 - 16 |
| 106832 | IGNITER WIRE SET |
|
|
IGNITOR SUPPORT |
| 82343 | IND. LITE, RED, NEON, W/L |
|
|
INDICATOR LIGHT WITH CAMERA LENS |
| 72179 | INFRARED GAS TUBING, 3/8 |
| 72172 | IR BROILER |
| 27652 | IR BROILER IGNITER BOX |
| 62021B | KNOB |
| 66565NGHA | LEFT GRILL BURNER VALVE |
| 66565NGSL | LEFT GRILL BURNER VALVE |
| 66565LPHA | LEFT GRILL BURNER VALVE |
| 66565LPSL | LEFT GRILL BURNER VALVE |
|
|
LIGHT ASSEMBLY |
| 92407 | LIGHT SWITCH |
| 83473 | LOCK NUT 1/4 NPT SS |
| 72174NGHA | MANIFOLD, COMPLETE |
| 72174NGSL | MANIFOLD, COMPLETE |
| 72174LPHA | MANIFOLD, COMPLETE |
| 72174LPSL | MANIFOLD, COMPLETE |
| 83009 | NUT, KEPS, 10 - 24 |
| 72265 | POWER CORD |
| 72310 | REGULATOR LP/SL 11-INCHESWC |
|
|
REGULATOR NG/SL 4-INCHESWC |
| 66569NGHA | RIGHT GRILL BURNER VALVE |
| 66569NGSL | RIGHT GRILL BURNER VALVE |
| 66569LPHA | RIGHT GRILL BURNER VALVE |
| 66569LPSL | RIGHT GRILL BURNER VALVE |
| 135322 | ROTIS MOTOR ASSEMBLY |
| 36675 | ROTIS POCKET |
| 36657 | ROTIS SPIT BRACKET |
| 72165 | RUBBER BUMPER, HI-TEMP |
| 66557NGHA | SAFETY VALVE |
| 66557NGSL | SAFETY VALVE |
| 66557LPHA | SAFETY VALVE |
| 66557LPSL | SAFETY VALVE |
| 83483 | SCREW 6-32 X 5/8 COUNTERSINK |
| 102365 | SCREW PHIL. TRUSS, 8-32 |
|
|
SCREW TRUSS SS |
|
|
SCREW, FLAT HEAD, 4-40 X 1/4 |
| 83479 | SCREW, TRUSS HEAD, 8-32 X 3/8 |
| 83263 | SCREW, WAFER HEAD, SST |
| 83571 | SCREW, WASHER HEAD, 8 X 3/8 |
| 83465 | SELF-CLINCH 10-24 X 3/8 |
| 36808 | SERVICE PANEL, CHASSIS RR |
| 83462 | SHOULDER BOLT, HINGE GUIDE |
| 72386 | SIDE BURNER IGNITER |
| 36699 | SIDE BURNER SUPPORT |
| 66573NGHA | SIDE BURNER VALVE |
| 66573NGSL | SIDE BURNER VALVE |
| 66573LPHA | SIDE BURNER VALVE |
| 66573LPSL | SIDE BURNER VALVE |
| 27738 | SMOKER TRAY |
| 86425 | SPACER MICROSWITCH |
|
|
SPARK ELECTRODE |
| 86528 | SPARK MODULE |
| 36697 | SPILL TRAY |
| AGFS | SPIT ROD FORK, 36-INCHES |
| 72362 | SPIT ROD, 36-INCHES |
| 83472 | STRAIN RELIEF |
| 72184 | TEMP GAUGE TRIM RING |
| 83663 | TEMP GAUGE WASHER |
| 72686 | TEMPERATURE GAUGE |
| 82151 | TERMINAL BLOCK |
| 72176 | THERMOCOUPLE |
| 62057 | TRANSFORMER |
|
|
TRIM RING |
|
|
U-BURNER, BBQ GRILL |
| 72159 | WARMING RACK |
| 72185 | WARMING RACK SUPPORT |
| 36698 | WATER DEFLECTOR |
| 72382 | WIRING HARNESS |
