Manufacturer
Dacor
Model Number
ERD36SCP
Description
Erd36scp - Ranges
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 62368 | ASSY 5 TUBE 4 LPH;62368,ERSD36S03/LP |
| 62377 | ASSY 5 TUBE 5 LPH;62377,ERSD36S03/LP |
| 62407 | ASSY 5 TUBE 6 LPH;62407,ERD36S03BK |
| 12470 | ASSY WINDOW PACK 1 INCH1;12470,ERD36 |
| 66831SBK | ASSY-BULLNOSE WITH BLACK;66831SBK,EN |
| 86570SBK | ASSY-BULLNOSE WITH BLACK;86570SBK,EN |
| 66831SBR | ASSY-BULLNOSE WITH BRASS;66831SBR,EN |
| 86570SCH | ASSY-BULLNOSE WITH CHROME;86570SCH,E |
| 86570SCP | ASSY-BULLNOSE WITH COPPER;86570SCP,E |
| 86570SBR | ASSY-ULLNOSE WITH BRASS;86570SBR,END |
| 66995S_L | ASY, 36" OUTER DOOR, NO |
| 62857 | ASY,5"TUBE ASY,#2,NG/H |
| 62856 | ASY,5"TUBE,#1,NG/H |
| 62858 | ASY,5"TUBE,#3,NG/H |
| 62859 | ASY,5"TUBE,#4,NG/H |
| 62860 | ASY,5"TUBE,#5,NG/H |
| 62861 | ASY,5"TUBE,#6,NG/H |
| 66831SCH | ASY,BULLNOSE W/CHR CAPS |
| 66831SCP | ASY,BULLNOSE W/CPR CAPS |
| AERB3603 | BACK GUARD 3;AERB3603,ERSD36S03 |
| AERB3624 | BACKGUARD 24 INCH;AERB3624,ERD36S03B |
| AERB3609 | BACKGUARD 9 INCH;AERB3609,ERD36S03BK |
| 62365 | BURNER TUBE ASY #3,LP-HA |
| 36576BP | CONVECTION BAFFLE;36576BP,ERD36S03BK |
| 62813 | DOOR GASKET;62813,ERD36S03BK |
| 701582 | DOOR LATCH SERVICE KIT |
| 82651 | FAN BLADE CONVECTION MTR;82651,ERD36 |
| 62957 | FITTING ORIFICE LPH;62957,ERSD36S/LP |
| 62969 | FITTING ORIFICE NGH;62969,ERD36S03BK |
| 62883BM | GRATE 10 INCH;62883BM,ERG36SBK |
| 86573 | HALOGEN BULB 10W 12VAC;86573,ERD36S0 |
| 62817 | HARNESS,ERD36 SPARK WIRE |
|
|
IGNITER ASSY KIT SINGLE;76482-001,ER |
| 66628 | IGNITOR SHIELD IR BROILER;66628,ERD3 |
| 86574 | LIGHT SHIELD;86574,ERD36S03BK |
| 62333 | MANIFOLD WITH VALVES LPH;62333,ERSD3 |
| 62968 | MANIFOLD WITH VALVES NGH;62968,ERD36 |
| 66995SBK_L | OUTER DOOR ASSEMBLY;66995SBK/L,ERD36 |
| 66995SBR_L | OUTER DOOR ASSEMBLY;66995SBR/L,ERD36 |
| 66995SCP_L | OUTER DOOR ASSEMBLY;66995SCP/L,ERD36 |
|
|
PLASTIC INSERT LEG;66813,ERD36S03BK |
|
|
SET GRATE SUPPORTPAD KIT;66916,ERD36 |
| 86528 | SPARK MODULE 6 POINT KIT;86528,ERD36 |
| 62784 | SUPPORT RACK;62784,ERD36S03BK |
| 100122CP | TRIM RING KNOB COPPER;100122CP,ERD36 |
| 100122BC | TRIM RING KNOB;100122BC,BLACK,ERD36S |
| 100122BR | TRIM RING, KNOB, BRASS |
| 62374 | TUBE ASSY #1,LP-HA |
| 62371 | TUBE ASSY #2,LP-HA |
| 86564 | VALVE 1;86564,ERD36S03BK |
| 86558 | VALVE LP SL ERSD48;86558,ERD36S03BK |
| 86565 | VALVE LP/HA,ERSD48 |
| 86559 | VALVE LP/SL,ERSD48 |
| 86561 | VALVE NG HA ERSD48;86561,ERD36S03BK |
| 86562 | VALVE NG HA ERSD48;86562,ERD36S03BK |
| 86555 | VALVE NG SL ERSD48;86555,ERD36S03BK |
| 86556 | VALVE NG/SL,ERSD48 |
| 62172 | WIRING HARNESS ASSY. |
