Manufacturer
Dacor
Model Number
ESG366SCP
Description
Esg366scp - Cooktops
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 80518 | 16GA GALVANIZED, STE |
| 80208 | 18 GA GALVANIZED STE |
| 80509 | 18GA.VIT,52.5"X96"ST |
| 80310 | 20 GA 201 SS, 36"X10 |
| 80522 | 20 GA 201 SS, 48"X96 |
| 80074 | 20 GA GALVANIZED,48" |
| 80516 | 20 GA GALVANIZED;80516,"48""X96""",D |
| 80550 | 20 GA,GALVANIZED STE |
|
|
ACCY SS CLEANER;100852,DCT305B/LP |
| 86567BR | ASSY BULLNOSE;86567BR,ESG366S |
| 86567CP | ASSY BULLNOSE;86567CP,ESG366S |
| 86567S | ASSY BULLNOSE;86567S,ESG366S |
| 27473 | ASY BOT CONT PANEL REA;27473,ESG366S |
| 27551 | ASY BRKT SPARK BOX MTG;27551,ESG366S |
| 66833SCP | ASY BULLNOSE W CPR CAPS;66833SCP,DAC |
| 62954 | ASY DBURNER HEAD;62954,EGR30S06BK |
| 62285 | ASY MANIFOLD NG;62285,ESG366SBR |
| 27397 | ASY SIDE SUPPORT LH;27397,ESG366SBK/ |
| 27400 | ASY SIDE SUPPORT RH;27400,ESG366SBK/ |
| 62394 | ASY, BURNER TUBE (NG) |
| 62034 | ASY, HARNESS |
| 27396 | ASY,BRNR,MTG CHANNEL |
| 86567BK | ASY,BULLNOSE W/BLK CAPS |
| 66833SBK | ASY,BULLNOSE W/BLK CAPS |
| 66833SBR | ASY,BULLNOSE W/BRS CAPS |
| 86567CH | ASY,BULLNOSE W/CHR CAPS |
| 27703 | ASY,RR TRIM,ESG366 |
| 106009 | BLACK PORCELAIN, DRY |
| 106007 | BLACK PORCELAIN, WET |
| 83383 | BOLT HE;83383,1/4-20 X 1.50,DRT304S/ |
| 36011 | BRACKET MANGAS PIPE;36011,ESG366SBK/ |
|
|
BRASS NUT CB HEAD;86405,DTCT304GB/LP |
| 82564 | BURNER RING D BURNER;82564,EGR30S06B |
|
|
BURNER TUBE BASE FRONT;62144,DTCT304 |
| 83056 | BUSHING HEYCO SB 875 11;83056,DH3006 |
| 83141 | BUSHING STRAIN RELIEF;83141,DCT305B/ |
| 92125 | BYPASS ORIFICE, SGM |
| 86373 | C AIR SHUTTER;86373,DTCT304GB/LP |
| 83138 | CABLE TIE 4054 RT 350;83138,DCT305B/ |
| 81248 | CARTON,LOWER-ESG366 |
| 26931 | CHASSIS WRAP;26931,ESG366SBK/LP |
| 83152 | COIN ENVELOPE S-6285 |
| 76034 | CONE DOUBLE SGM365E;76034,E30DF74EPS |
| 105538 | CONNECTOR SGM;105538,EGR30S06BK |
| 26968 | CONTROL PANEL BOT FRONT;26968,ESG366 |
| 13728BR | CONTROL PANEL WLOGO;13728BR,ESG366S |
| 13728CH | CONTROL PANEL WLOGO;13728CH,ESG366S |
| 13728CP | CONTROL PANEL WLOGO;13728CP,ESG366S |
| 13728S | CONTROL PANEL WLOGO;13728S,ESG366S |
| 26911E | CONTROL PANEL, ETCHED |
| 86918 | D BURNER RING SNGL 5 FG;86918,DTCT30 |
| 72510CP | DACOR LOGO SMALL;72510CP,ECD230SCP |
| 105604 | ELECTRODE, BURNER HE |
| 62712 | END CAP BULL NOSE;62712,EGR30S06BK |
| 62712CP | END CAP,BULL NOSE-COPPER |
| 62323 | FRONT BURNER TUBE 38;62323,ESG366S |
| 72433SB | GRATE PACK 10 GRATES;72433SB,ERD36SB |
| 72434SB | GRATE PACK,14" GRATES |
| 27426 | GRATE SUPPORT PAD;27426,ESG366S |
| 62296 | GRIDDLE |
| 83209 | HOOK LOOP PAIR 2 X 3;83209,DR30GFS/L |
|
|
IGNITER ASSY KIT SINGLE;76482-001,ER |
| 62933 | IGNITOR WIRE JACKET;62933,DTCT304GB/ |
| 62036 | INDICATOR LIGHT BLUE NEO;62036,DCT30 |
| 62021B | KNOB, EPICURE |
| 85136 | LABEL, "MADE WITH PRIDE" |
| 85249 | LABEL,"DIELECTRIC TE |
| 26925 | LEFT TRIM;26925,ESG366S |
| 62327 | MANIFOLD ASSY LPHA;62327,ESG366S |
|
|
MICROSWITCH ER30G;103789,DOP36M86DAM |
| 76033 | NUT COMPRESSION;76033,E30DF74EPS |
| 83048 | NUT HEX KEPS;83048,#8-32,DCT305B/LP |
| 83009 | NUT KEPS;83009,#10-24,DO130 |
| 105555 | O RING 9MM OD;105555,DOP36M86DAM |
|
|
O RING D BURNER;86395,DTCT304GB/LP |
| 105614 | O-RING, 5 MM ID |
| 86936 | O-RING, ELECTRODE |
| 72427-185 | ORIFICE, NUT, ESG |
| 62592 | PLASTIC SPATULA W/ LOGO |
| 82562 | POWER SUPPLY CORD;82562,EOG303 |
| 38204 | REAR TRIM;38204,ESG366SBK/LP |
| 85046 | REGULATOR LABEL, GGC |
| 85047 | REGULATOR TAG, GGC |
| 62320 | REGULATOR;62320,"3-6 W.C.,NG",DTCT46 |
| 105588 | RETAINER RING, ELECT |
| 83024 | SCREW PHIL TRS;83024,#8 X 3/8,DR30EF |
| 83306 | SCREW PHIL TRS;83306,#8 X 3/8,DCT305 |
|
|
SCREW PHIL;83007,#8-32 X 1/4,DOP36M9 |
|
|
SCREW WAFER HD;83534,#8 X 3/8,DH3006 |
| 83313 | SCREW,PHIL PAN, #8 X |
| 83137 | SCREW,WELD,#8-32 X1/2,ST |
| 105587 | SCREW;105587,M4X0.7X12,ESG366SBR |
| 83026 | SCREW;83026,#10 X 3/4 SLOT HWH,DO130 |
|
|
SCREW;83505,#8 X 3/8 TYPE A,DHD30M96 |
|
|
SET GRATE SUPPORTPAD KIT;66916,ERD36 |
| 36548 | SIDE TRIM,LH |
| 36543 | SIDE TRIM,RH |
| 105541 | SLEEVING TUBE, FIBER |
| 86528 | SPARK MODULE 6 POINT KIT;86528,ERD36 |
| 82318 | SPARK MODULE, 6 POINT |
| 62807 | SPARK WIRE WIRE HARNESS;62807,ESG366 |
| 26959BP | SPILL TRAY BLK PORCLN;26959BP,ERD36S |
| 26959 | SPILL TRAY ERSD ESG36;26959,ERD36SBK |
| 105584 | SPRING ELECTRODE BURNER;105584,DTCT3 |
| 36541BP | SUPPORT SIDE SP TRAY BP;36541BP,ESG3 |
| 36542BP | SUPPORT,FR/RR,SP TRAY,BP |
| 102352 | TERMINAL BLOCK 12 PT;102352,DH3006 |
| 36012 | TIE BRACKET MANGAS PIPE;36012,ESG366 |
| 62020CP | TRIM RING EPICURE COPPE;62020CP,ERD3 |
| 100122CP | TRIM RING KNOB COPPER;100122CP,ERD36 |
| 105592 | VALVE ASSM W SPINDLE;105592,ESG366SB |
| 86551 | VALVE, MANIFOLD (H) |
| 86553 | VALVE, MANIFOLD (LP) |
| 86552 | VALVE, MANIFOLD (LP/H) |
| 86554 | VALVE, MANIFOLD (NG) |
| 83203 | WASHER FLAT;83203,P400 1/4-20,DRT304 |
| 83080 | WASHER NYLON;83080,DO130 |
| 82032K | WOK RING KIT;82032K,EGR30S06BK |
