Manufacturer
Epson
Model Number
C11CD16201
Description
Workforce Wf-3640 Aio Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ADF LD,ASSY.;SEC |
|
|
ADF,UNIT,CD19,ASP *DISC 06/15* |
|
|
ADF,UNIT,CD19;C,ASP |
|
|
ADF,UNIT,CD19;C.IEI,ASP |
|
|
BOARD ASSY.,ENCODER |
|
|
BOARD ASSY.,INTERFACE |
|
|
BOARD ASSY.,MAIN |
|
|
BOARD ASSY.,POWER SPLY PRINTER WATT 40.2 |
|
|
BOARD ASSY.,SUB |
|
|
CASSETT,2ND.ASSY.,ASP |
|
|
CASSETTE ASSY.,ASP |
|
|
CIS MODULE |
|
|
CLAMP, TUBE |
|
|
COVER,ADF,ASSY,;IEI |
|
|
COVER,ADF,ASSY,;SEC |
|
|
COVER,CARTRIDGE |
|
|
COVER,FRAME ASSY,ASP |
|
|
COVER,FRAME ASSY,IEI,ASP |
|
|
COVER,FRONT,ADF |
|
|
COVER,REAR,ADF |
|
|
COVER,USB |
|
|
DOCUMENT,SUPPORT,ADF,ASSY,;IEI |
|
|
DOCUMENT,SUPPORT,ADF,ASSY,;SEC |
|
|
DUPLEX ASSY,CD16.;SEC |
|
|
EXTENSION SPRING,2.03 |
|
|
FFC,ASSY.;IEI |
|
|
FOOT |
|
|
FRAME BASE 2ND ASSY.,ASP |
|
|
FRAME BASE 2ND ASSY.IEI.,ASP |
|
|
GREASE G-45 |
|
|
GREASE G-71 STYLUS CX4500 |
|
|
GREASE G-71(BLUE) |
|
|
GREASE G72 |
|
|
GREASE G74 40GR *NO CANADA EXPORT* |
|
|
HINGE ASSEMBLY. |
|
|
HOLDER,BOARD,ASSY.;SEC |
|
|
HOLDER,CAM,ASSY.;SEC |
|
|
HOLDER,STAR,WHEEL,ASSY.;IEI |
|
|
HOLDER,STAR,WHEEL,ASSY.;SEC |
|
|
HOUSING, RIGHT |
|
|
HOUSING,LEFT;ASSY;IEI |
|
|
HOUSING,LEFT;ASSY;SEC |
|
|
HOUSING,UPPER |
|
|
INK SYSTEM,ASSY,;C,IEI |
|
|
INK SYSTEM,ASSY,;C,SEC |
|
|
INK SYSTEM,ASSY,;C,SEC *DISC 02/15* |
|
|
INK SYSTEM,ASSY,;E,SEC *DISC 07/15* |
|
|
INK SYSTEM,ASSY,;F,IEI |
|
|
INK SYSTEM,ASSY,;F,SEC |
|
|
INK SYSTEM,ASSY,;SEC *DISC 07/15* |
|
|
INK SYSTEM,ASSY,;SEC *DISC 11/14* |
|
|
LEAF SENSOR |
|
|
MAT,COVER,DOCUMENT |
|
|
MOTOR,ASSY.,SC |
|
|
MSF ASSY.,SEC |
|
|
PAD,ADF ASSY. |
|
|
PAD,STOPPER,IS - PURCHASE FROM FAGERDALA |
|
|
PANEL ASSY,CD16,;SEC *DISC 05/14* |
|
|
PANEL ASSY.,CD16;D,IEI |
|
|
PANEL ASSY.,CD16;D,SEC |
|
|
PICK UP ASSY. *DISC 05/16* |
|
|
PICKUP,2ND ASSY. |
|
|
POROUS PAD,CR,ASP |
|
|
POROUS PAD,HEAD,U2;C |
|
|
POROUS PAD,PAPER GUIDE,LOWER |
|
|
POWER CABLE - RIGHT ANGLE PLUG |
|
|
PRINT HEAD,ID8560-2 *DISC 11/18* |
|
|
PRINTER MECHANISM,CD19;G,ASP |
|
|
SCALE,CR |
|
|
SCANNER,UNIT,CD19,ASP |
|
|
SHIPPING CLEANING LIQUID, CR02, 1KG |
|
|
SHIPPING CLEANING LIQUID, CR02,18KG |
|
|
SONIC TENSION METER U-505 |
|
|
SONIC TENSION METER U-507 STYLUS C82 |
|
|
SONIC TENSION METER U-508 |
|
|
STACKER ASSY.,SEC |
|
|
STOPPER,HOLDER,IDLE,ROLLER,PF |
|
|
SUPPORT,SHEET,FRAME,BASE,ASP |
|
|
TEFLON TAPE NO.903UL |
|
|
TIMING BELT,CR |
|
|
USER'S GUIDE (ENGLISH) *KITTED* |
|
|
WIRELESS LAN USB MODULE |
