Manufacturer
Epson
Model Number
POWERLITEHOMECINEMA8345
Description
Powerlite Home Cinema 8345 1080p 3lcd Projector
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
"1/4-40X1/4,H.H.,F/NI,O SCREW" |
|
|
"AC LINE CORD,18-3,SJT,10AMP" |
|
|
"BOTTOM, SW, TOP PROJECTOR" |
|
|
"BUTTON, SW, SIDE; ENTER, S PROJECTO" |
|
|
"BUTTON, SW; SIDE, S PROJECTOR" |
|
|
"C.B.P-TITE SCREW 3X10,F/ZB" |
|
|
"C.B.P-TITE SCREW,3X8,F/ZB-3C" |
|
|
"C.B.SCREW, 3X6, F/NI LENS SECURITY" |
|
|
"C.C.P-TITE SCREW,3X8,F/ZN-3C" |
|
|
"C.C.P.TITE SCREW, 3X6, F, ZN" |
|
|
"C.C.SCREW,3X6,F/ZN-3C" |
|
|
"C.P. (S-P1) SCREW, 3X10, F/ZN-3C" |
|
|
"C.P. (S-P1) SCREW, 3X5, F/ZN-3C PRO" |
|
|
"C.P. B-TITE SCREW, 4X10, F/ZN-3C" |
|
|
"C.P.(O)SCREW,4X6,F/NI" |
|
|
"CABLE, AC" |
|
|
"CABLE, BALLAST LAMP" |
|
|
"CABLE, BALLAST" |
|
|
"CABLE, SCI; 1" |
|
|
"CABLE, TH" |
|
|
"CABLE,C;170" |
|
|
"CABLE,SW;AU ROHS COMPLIANT" |
|
|
"CARTON BOX, OPTICAL ENGINE" |
|
|
"CASE UNIT, UPPER; W" |
|
|
"CASE, BALLAST" |
|
|
"CASE, IF; W PROJECTOR" |
|
|
"CASE, LOWER; W" |
|
|
"CASE, SIDE, L; S" |
|
|
"CASE, SIDE; R, S" |
|
|
"CAUTION LABEL, HOT; E PROJECTOR" |
|
|
"COVER, LAMP FAN PROJECTOR" |
|
|
"COVER, UPPER, INNER PROJECTOR" |
|
|
"CUSHION, EXHAUST FAN PROJECTOR" |
|
|
"CUSHION, FLOATING; A PROJECTOR" |
|
|
"CUSHION, LED" |
|
|
"CUSHION,LIGHT VALVE" |
|
|
"DUCT, EXHAUST; INNER PROJECTOR" |
|
|
"DUCT, EXHAUST; LOWER" |
|
|
"DUCT, EXHAUST; PS PROJECTOR" |
|
|
"DUCT, EXHAUST; UPPER" |
|
|
"DUCT, INTAKE, LOWER PROJECTOR" |
|
|
"DUCT, INTAKE, UPPER PROJECTOR" |
|
|
"DUCT, LAMP FAN PROJECTOR" |
|
|
"DUCT, PS FAN PROJECTOR" |
|
|
"EMI, SUPPRESOR PROJECTOR" |
|
|
"FAN, EXHAUST" |
|
|
"FAN, INTAKE;1" |
|
|
"FAN, LAMP DISC 9/12 PROJECTOR" |
|
|
"FAN, PS DISC 6/12 PROJECTOR" |
|
|
"FILTER, RC; B PROJECTOR" |
|
|
"FOOT; A38, SILVER" |
|
|
"FRAME, BALLAST; A" |
|
|
"FRAME, BALLAST; B" |
|
|
"FRAME, PS" |
|
|
"HOLDER FOOT, A" |
|
|
"HOLDER, FAN PROJECTOR" |
|
|
"LABEL, IF; W PROJECTOR" |
|
|
"LABEL, LOGO, EH-TW3000; ASIA PROJEC" |
|
|
"LATCH, LID, LAMP" |
|
|
"LENS, LED; PW PROJECTOR" |
|
|
"LID ASSY., LAMP; W8345" |
|
|
"LID,AIR FILTER; W" |
|
|
"PLATE, CONDUCTION, MA-DR" |
|
|
"PLATE, DIFFUSION PROJECTOR" |
|
|
"PLATE, GND, PS PROJECTOR" |
|
|
"PLATE, MAFASTEN, PS" |
|
|
"PLATE, MAFASTEN; LEFT" |
|
|
"PLATE, MAFASTEN; RIGHT" |
|
|
"PLATE, NUT; M3" |
|
|
"SCREW, CPB-TITE MINI 1.7X4" |
|
|
"SCREW,AI FASTEN" |
|
|
"SEAL, INTAKE; A PROJECTOR" |
|
|
"SEAL, INTAKE; B1" |
|
|
"SEAL, INTAKE; B2" |
|
|
"SEAL, INTAKE; C PROJECTOR" |
|
|
"SEAL, LID LAMP; A PROJECTOR" |
|
|
"SEAL,EX" |
|
|
"SHEET, INSULATION, BALLAST" |
|
|
"SHEET, INSULATION, BALLAST; B" |
|
|
"SHEET, INSULATION, PS" |
|
|
"SHEET, INTAKE FAN 2 PROJECTOR" |
|
|
"SHEET, SHADE, IF" |
|
|
"SHEET, SHADE, LENS SHIFT" |
|
|
"SHEET,PJ LENS" |
|
|
"SHEILD PLATE, CASE, LOWER PROJECTOR" |
|
|
"SPRING, LATCH, LID LAMP PROJECTOR" |
|
|
"SPRING, MLB FASTEN" |
|
|
"WARNING LABEL, LOOK INTO LENS; E PR" |
|
|
"WARNING LABEL,LAMP REPLACEMENT; LP4" |
|
|
AIR FILTER |
|
|
AIR PACKING BAG |
|
|
ALL MANUAL SET *DISCONTINUED* |
|
|
AUTO IRIS ASSY; AS |
|
|
BALLAST UNIT4; E *DISC 7/12* |
|
|
BASE LOGO PLATE ASSY; AS PROJECTOR |
|
|
CABLE RCR;FIF |
|
|
DECORATION PLATE; L PROJECTOR |
|
|
DECORATION PLATE; R PROJECTOR |
|
|
FOCUS RING; S |
|
|
FRAME CF ASSY; AS |
|
|
GASKET 10_10_20 PROJECTOR |
|
|
GASKET 6_10_10 PROJECTOR |
|
|
INSULOCK TIE T-18 |
|
|
LAMP ASSY; AS (V13H010L49) |
|
|
LENS CAP |
|
|
MERCURY-CONTAINING DISPLAY LABEL;US |
|
|
MOTOR CF ASSY; AS |
|
|
OPTICAL ENGINE AND MAB SET; W (IHR) |
|
|
PCB ASSY.; RCF_R2 |
|
|
PCB ASSY.; RCR_R2 |
|
|
PCB ASSY.; SW1_R2 |
|
|
PCB ASSY.; SW2_R2 |
|
|
PCB ASSY.; TH_R2 |
|
|
PLATE MA |
|
|
POLYVINYL BAG FOR OPTICAL ENGINE |
|
|
POWER SUPPLY UNIT (526 WATT) |
|
|
PROTECTION RING FOR PROJECTION LENS |
|
|
REMOTE CONTROLLER; W |
|
|
ROAD SERVICE STICKER |
|
|
RUBBER FOOT; A PROJECTOR |
|
|
SW CF ASSY; AS |
|
|
ZOOM RING |
