Manufacturer
Epson
Model Number
TMU300C
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
**USE P/N 1042587 *** PRINT HEAD |
|
|
AC ADAPTER |
|
|
BELT |
|
|
BELT,TAKE UP |
|
|
C.B.S-TITE SCREW(M2.5X4) |
|
|
C.P. SCREW (M3X25) |
|
|
C.P.O.SCREW (M3X6) |
|
|
C.P.T.SCREW (M3X14) |
|
|
C.T.B.SCREW (M2.6X6) |
|
|
C.T.P. SCREW (M3X8) |
|
|
C.T.P.S.SCREW |
|
|
CAP, BELT DRIVE |
|
|
CARD SPACER |
|
|
CARRIAGE MOTOR ASSY, B |
|
|
CARRIAGE SUB ASSY, B |
|
|
CASE, LOWER, A |
|
|
CASE,UPPER ASSY.,A |
|
|
CAUTION SEAL A |
|
|
CAUTION SEAL,B |
|
|
COVER OPEN DETECTOR ASSY |
|
|
COVER,NEAR END DETECTOR |
|
|
COVER,TAKE UP,A |
|
|
CR MOTOR CABLE ASS'Y |
|
|
CUP SCREW (M3X5) |
|
|
CUP SCREW (M3X5) |
|
|
CUP SCREW (P TIGHT) (M2.5X6) |
|
|
DRIVER CIRCUIT BOARD ASSY,E |
|
|
EARTH PLATE, PRINT HEAD |
|
|
EARTH PLATE, RIBBON FRAME |
|
|
EARTH WIRE ASS'Y |
|
|
FFC, HEAD |
|
|
FRAME RIBBON ASSY |
|
|
FRAME,TAKE UP ASSY |
|
|
GEAR, INTERMEDIATE |
|
|
GEAR, PAPER FEED |
|
|
GEAR, PAPER FEED REDUCTION |
|
|
GEAR, RIBBON DRIVE |
|
|
GEAR, RIBBON INTERMEDIATE |
|
|
GEAR, RIBBON TRANSMISSION |
|
|
GEAR, TAKE UP |
|
|
GEAR, TAKE UP DRIVE |
|
|
HEAT SINK, CARRIAGE MOTOR |
|
|
HEXAGON LOCK SCREW |
|
|
HOLD PLATE, FFC |
|
|
HOME POSITION SENSOR ASS'Y |
|
|
INTERMEDIATE GEAR FIXING PLATE |
|
|
J FEED ROLLER SHAFT HOLDER L |
|
|
KNOB, PAPER FEED |
|
|
LEVER, RIBBON RELEASE |
|
|
LEVER, RIBBON SWITCH |
|
|
LOCKING CARD SPACER |
|
|
MOTOR, PAPER FEED |
|
|
NEAR END SENSOR ASS'Y |
|
|
NEAR END SENSOR HOLDER |
|
|
NEAR END SENSOR SPRING |
|
|
PAPER DETECTOR SWITCH ASSY. |
|
|
PAPER FEED FRAME ASS'Y |
|
|
PAPER GUIDE |
|
|
PAPER GUIDE SPRING |
|
|
PAPER GUIDE, UPPER |
|
|
PAPER HOLD ROLLER ASS'Y |
|
|
PAPER ROLLING SHAFT ASS'Y C |
|
|
PAPER TAKE-UP ASS'Y A |
|
|
PLATE ASS'Y A |
|
|
PLATE, TENSION ADJUSTMENT |
|
|
PLATE,SUPPORT |
|
|
POWER SWITCH ASS'Y |
|
|
PRINT HEAD MASK ASS'Y |
|
|
PULLEY, BELT TENSION |
|
|
RETAINING RING TYPE-E (2) |
|
|
RETAINING RING TYPE-E (2.3) |
|
|
RETAINING RING TYPE-E (3) |
|
|
RIBBON CASSETTE COVER A |
|
|
RIBBON DRIVING PLATE ASS'Y |
|
|
RIBBON TAKE UP ASS'Y |
|
|
ROLLER, PAPER FEED |
|
|
RUBBER FOOT |
|
|
SCREW (P TIGHT) |
|
|
SHAFT HOLDER, ADJUSTMENT ROLLER |
|
|
SHAFT, CARRIAGE GUIDE A |
|
|
SHAFT, CARRIAGE GUIDE B |
|
|
SPRING, PAPER FEED FRAME L |
|
|
SPRING, PAPER FEED FRAME R |
|
|
SPRING, PAPER HOLD |
|
|
SPRING, PAPER HOLD, R |
|
|
SPRING, RIBBON FRAME |
|
|
SPRING, RIBBON RELEASE |
|
|
SWITCH CIRCUIT BOARD ASS'Y |
|
|
SWITCH PANEL B |
|
|
TAKE-UP GEAR |
|
|
TAKE-UP TORQUE SPRING |
|
|
TENSION PLATE ASSY |
|
|
TERMINAL,NEAR END DETECTOR |
|
|
TM300D MECHANISM ASS'Y,E |
|
|
TRANSISTOR HOLDER |
|
|
USE 2022566 FOR MONO |
