Manufacturer
Electrolux
Model Number
56-4884-10-03
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BUTTON,CLOCK/TIMER ,BLACK |
|
|
CONTAINER,ICE BIN |
|
|
CONTROL,TEMPERATURE |
|
|
CONTROL-HUMIDITY |
|
|
COVER-CRISPER PAN |
|
|
DAMPER,HUMIDITY CONT. |
|
|
DIFFUSER,AIR ,BOTTOM |
|
|
DISPENSER-CAN,CLEAR |
|
|
END CAP-SHELF,PROTECTOR ,FRZR SHELF |
|
|
INSULATION-DOOR |
|
|
KNOB,TEMP CONTROL |
|
|
LIGHT BULB/LAMP,A-15 ,CLEAR ,40 W ,120 V,MINIATURE |
|
|
LOCK-HANDLE TRIM,STICK-ON |
|
|
PAN,CRISPER ,(2) |
|
|
PANEL,PAN COVER ,GLASS |
|
|
SCREW |
|
|
SCREW, NO.8 TRUSS HD, 10-32CA X 0.500 |
|
|
SCREW,HANGER/RLR MTG ,8-10 X 0.438 |
|
|
SCREW,HEX WASHER HEAD ,8-15A X 0.625 , |
|
|
SCREW-SUPPORT |
|
|
SOCKET-LIGHT/LAMP |
|
|
SPACER,SHELF |
|
|
SUPPORT, DOOR RACK, LH |
|
|
SWITCH,LIGHT/LAMP |
|
|
TRACK,MEAT PAN HANGER ,LH |
|
|
TRACK,MEAT PAN HANGER ,RH |
|
|
TRAY,ICE CUBE ,PLASTIC |
|
|
WASHER, NYLON |
