Model Image
Manufacturer

Electrolux

Model Number

ACG130VNLD1

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
5308000296 5308000296 BRACKET
5303001199 5303001199 CLAMP-WIRING HARNES
5308003596 5308003596 CLIP-COMPRESSOR MTG
3206135 3206135 COVER
3205266 3205266 EDGE PROTECTOR
5303270902 5303270902 GASKET-REFR DOOR, MAGNETIC
5308010239 5308010239 HANDLE END
5308009875 5308009875 HANDLE-DOOR
5303206678 5303206678 KNOB-TEMP CONTROL
3206125 3206125 MULLION
5303001348 5303001348 NUT
5303916001 5303916001 PAN RETAINER, KIT, SERVICE
5303209937 5303209937 PAN-CRISPER
5303271483 5303271483 PANEL-INNER DOOR
5303271486 5303271486 PANEL-INNER DOOR
5308000184 5308000184 PIN CENTER HINGE
5303001321 5303001321 PIN, LOWER HINGE
240494004 240494004 PLUG-BUTTON
5303001308 5303001308 PLUG-BUTTON
5303001389 5303001389 PLUG-BUTTON
5303211376 5303211376 RELAY
5303001380 5303001380 SCREW
5308000039 5308000039 SCREW
5304455651 5304455651 SCREW,HEX WASHER HEAD ,8-15A X 0.500
5304455650 5304455650 SCREW,HEX WASHER HEAD ,8-15A X 0.625 ,
5303001260 5303001260 SCREW-CONTROL MTG
241710601 241710601 SCREW-HINGE MTG,HEX HD ,1/4-20 X 0.875
3206141 3206141 SCREW-LEVELING
5303001037 5303001037 SHIM -UPPER HINGE
5303006412 5303006412 STRAP-COVER MTG
215170801 215170801 STRAPMULLION MTG
3206166 3206166 SUPPORT-DOOR RACK, EXTENDS 1.06``, LH
3206165 3206165 SUPPORT-DOOR RACK, EXTENDS 1.06``, RH
3206150 3206150 SUPPORT-DOOR RACK, EXTENDS 1.81``, RH
5309918806 5309918806 SWITCH-LIGHT/ LAMP
5308012296 5308012296 TAPPING PLATE
5303916855 5303916855 TUBE
5308009617 5308009617 WASHER
5303206754 5303206754 WASHER
5308000186 5308000186 WASHER , .34 X .62 X .10, NYLON
5308003633 5308003633 WASHER-COMPR MTG
